TENTS

INSTANT PITCH TENTS

HYBRID FRAME

INSTANT UP™ 4P LIGHTED NORTHSTAR™ DARK ROOM™ MODEL # 1515009

HUB FRAME

INSTANT UP™ GOLD 4P MODEL # 1508029

Tent Range

INSTANT UP™ 6P LIGHTED NORTHSTAR™ DARK ROOM™ MODEL # 1515010

INSTANT UP™ GOLD 6P MODEL # 1508030

INSTANT UP™ GOLD 10P MODEL # 1508032

INSTANT UP™ 4P MODEL # 1410587

TRADITIONAL PITCH TENTS

GOLD

TRAVELLER™ 3P MODEL # 1393964

INSTANT UP™ 6P MODEL # 1424454

CHALET™ 9CV MODEL # 1217814

DOME

SUNDOME® 2P MODEL # 2000024579

ADVENTURE

RIDGELINE™ 2P MODEL # 1410679

SUNDOME® 4P MODEL # 2000024582

RIDGELINE™ 3P MODEL # 1410680

INSTANT UP™ 8P MODEL # 1411978

SUNDOME® 6P MODEL # 2000024583

BLOCKS 95% of daylight penetrating the tent

Our Coleman® DarkRoom™ technology is a revolutionary new sleep system for campers. Ideal for parents or anyone who is sensitive to daylight.

HELPING YOU GET A LONGER, MORE RESTFUL SLEEP!

NORTHSTAR DARKROOM ™ SERIES WITH INTERNAL STRIP LIGHTING

FEATURES:

Coleman®’s Northstar Instant 4P & 6P tents with front vestibule for added living & storage space Dark Room™ patented fabric treatment blocks 95% of sunlight & keeps inside 5 degrees cooler than untreated tents Instant Up™ Hub frame design sets up in under 2 minutes with integrated pre-attached frame Integrated strip lighting - Silicone flexible strip lighting with LED lights integrated into the inner tent. Front door can be pitched out as a 2 pole awning Hook & Loop strip on awning for attaching to Coleman® Deluxe Gazebos Coleman® circle ventilation for added air flow Ultra fine mesh throughout & integrated internal storage hammock & organisers Plus power cord management system & convenient welcome mat keep your tent clean & dry Heavy duty carry bag Available is 4, 6 & 10 person versions

4P LIGHTED NORTHSTAR WITH DARKROOM ™

SPECS:

MODEL # 1515009

FABRIC: 75D/185T POLYESTER RIP-STOP, 3000MM PU WATERPROOF FLY, HEAVY DUTY POLYOXFORD PVC FLOORING FRAME: STEEL (INCLUDES 2 AWNING POLES), INSTANT UP™ HUB WEIGHT: 16.8KG SIZE: 2.4X2.4M (1.5M VESTIBULE)

PACK QTY: 1 INNER SIZE: 114X25X25CM INNER WEIGHT: 13KG OUTER SIZE: 115X26X26CM OUTER WEIGHT: 14KG

3.3M X 2.7M

6P LIGHTED NORTHSTAR WITH DARKROOM ™

SPECS:

MODEL # 1515010

FABRIC: 75D/185T POLYESTER RIP-STOP, 3000MM PU WATERPROOF FLY, HEAVY DUTY POLYOXFORD PVC FLOORING FRAME: STEEL (INCLUDES 2 AWNING POLES), INSTANT UP™ HUB WEIGHT: 20.6KG SIZE: 3.3X2.7M (1.5M VESTIBULE)

PACK QTY: 1 INNER SIZE: 112X25X25CM INNER WEIGHT: 15KG OUTER SIZE: 114X28X28CM OUTER WEIGHT: 16KG

INSTANT UP ™ FRAME TECHNOLOGY

Set-up in as little as 60 SECONDS!

UNROLL

LIFT

LOCK

INSTANT UP ™ GOLD SERIES

FEATURES:

Instant Up™ Hub frame design sets up in under 2 minutes with integrated pre-attached frame Front door can be pitched out as 2 pole awning Additional detachable oversized 3 pole awning attaches to either left or right side of tent Hook & Loop strip on awning for attaching to Coleman® Deluxe Gazebos Coleman® circle ventilation for added air flow Ultra fine mesh throughout plus integrated internal storage hammock, organisers & power cord management system Convenient welcome mat keep your tent clean & dry Heavy duty carry bag

INSTANT UP™ GOLD 4P

SPECS:

MODEL # 1508029

FABRIC: 75D/185T POLYESTER RIPSTOP, 3000MM PU WATERPROOF FLY, HEAVY DUTY POLYOXFORD PVC FLOORING FRAME: STEEL (INCLUDES 5 AWNING POLES), INSTANT UP™ HUB WEIGHT: 12.7KG SIZE: 2.4X2.4M PACK QTY: 1 INNER SIZE: 112X24X24CM INNER WEIGHT: 12.72KG OUTER SIZE: 113X26X26CM OUTER WEIGHT: 15.9KG

3.3M X 2.7M

INSTANT UP™ GOLD 6P

SPECS:

MODEL # 1515030

FABRIC: 75D/185T POLYESTER RIPSTOP, 3000MM PU WATERPROOF FLY, HEAVY DUTY POLYOXFORD PVC FLOORING FRAME: STEEL (INCLUDES 5 AWNING POLES), INSTANT UP™ HUB WEIGHT: 14KG SIZE: 3.3X2.7M

PACK QTY: 1 INNER SIZE: 135X25X25CM INNER WEIGHT: 14KG OUTER SIZE: 136X26X26CM OUTER WEIGHT: 17.9KG

INSTANT UP™ GOLD 10P

MODEL # 1515032

4.3 X 3.05M M

FEATURES: SPECS:

• Instant Up™ design sets up in under 3 min with integrated frame pre-attached to tent • Full side awning provides plenty of shade for the whole family • Front door can be pitched out as additional awning • Stitched in room divider creates two spaces – divide sleeping/living or have dual sleeping areas • Two large side D doors allow independent access to each room • Front D door allows for additional access • Coleman® Circle Ventilation for added air flow • Ultra fine mesh throughout & integrated internal storage hammock, organisers & power cord management system • Dual mesh welcome mats keep your tent clean • Heavy duty carry bag

FABRIC: 75D/185T POLYESTER RIP-STOP, 3000MM PU WATERPROOF FLY, HEAVY DUTY POLYOXFORD PVC FLOORING FRAME: STEEL (INCLUDES 5 AWNING POLES), INSTANT UP™ HUB WEIGHT: 30KG SIZE: 4.3X3.05M

PACK QTY: 1 INNER SIZE: 119X29X29CM INNER WEIGHT: 23KG OUTER SIZE: 120X33X33CM OUTER WEIGHT: 23.5KG

GUARANTEED TO KEEP YOU DRY IN THE MOST UNRULY AUSSIE CONDITIONS

Our tents are subjected to rigorous high wind & water saturation conditions at our testing laboratory, so you don't have to test them out in the field. Each tent design is engineered & then tested to its failure point to ensure that you receive the industry leading quality that Coleman® is famous for.

INSTANT UP ™ SILVER SERIES

FEATURES:

Instant Up™! Set up in under 2 minutes with built in HUB frame WeatherTec™ system welded floors & inverted seams keep water out Fully seam sealed fly with large front awning Large windows with roll up rear flaps Internal cord management Carry bag included

INSTANT UP™ 4P

SPECS:

FABRIC: 150D/150D POLYESTER 1,500MM WATERPROOFED FULL FLY PE FLOORING FRAME: STEEL POLES, INSTANT UP™ HUB WEIGHT: 12.7KG SIZE: 2.4X2.4X1.9M

MODEL # 1410587

PACK QTY: 1 INNER SIZE: 112X24X24CM INNER WEIGHT: 12.72KG OUTER SIZE: 113X25X25CM OUTER WEIGHT: 13.9KG

3.3M X 2.7M

INSTANT UP™ 6P

SPECS:

FABRIC: 150D/150D POLYESTER 1,500MM WATERPROOFED FULL FLY PE FLOORING FRAME: STEEL POLES, INSTANT UP™ HUB WEIGHT: 14.2KG SIZE: 3.3X2.7X1.9M

MODEL # 1424454

PACK QTY: 1 INNER SIZE: 135X23X23CM INNER WEIGHT: 14.19KG OUTER SIZE: 136X24X24CM OUTER WEIGHT: 15.86KG

INSTANT UP™ 8P

MODEL # 1411978

8

FEATURES: SPECS:

• Removable section divider to create two room feel

FABRIC: 150D/150D POLYESTER 1,500MM WATERPROOFED FULL FLY PE FLOORING FRAME: STEEL POLES, INSTANT UP™ HUB WEIGHT: 19.4KG SIZE: 4.3X2.4X1.9M

PACK QTY: 1 INNER SIZE: 119X28X28CM INNER WEIGHT: 19.4KG OUTER SIZE: 119X28.5X28.5CM OUTER WEIGHT: 21.19

TRADITIONAL PITCH SERIES

FEATURES:

WeatherTec™ system welded floors & inverted seams keep water out Fully seam sealed Large windows with roll up rear flaps and multiple awnings Internal cord management Carry bag included

TRAVELLER ™ 3P

MODEL # 1393964

FEATURES: SPECS:

• A large single room tent with side windows & floored vestibule • Large D-doors front & rear for easy access • Floored front vestibule area to keep the tent dry & clean • WeatherTec™ System ensures optimum performance in all conditions • Circle Ventilation™ system & Cool-Air™ port for efficient airflow • Internal organiser/accessory pockets • Power cord management system • Colour coded poles to ensure easy & correct set up • Generous sized carry bag for easy pack-down • Repair kit included

FABRIC: 75D/185T POLYESTER / TAPED SEAMS, 3,000MM PROOFED FLY, PE FLOORING FRAME: 9.5MM/8.5MM COLEMAN® DURAWRAP™ POLES WEIGHT: 6KG SIZE: 2X3.6M

PACK QTY: 4 INNER WEIGHT: 6.65KG INNER SIZE: 58X21X21CM OUTER WEIGHT: 31KG OUTER SIZE: 60.5X47X46.5CM

CHALET ™ 9 CV

MODEL # 1217814

6M X 2.8M

FEATURES: SPECS:

• Three room tent with fully sectioned bedrooms either side of living area • Permanently attached LED night light next to gear organiser • Large D-doors at front & rear of the centre room with full mesh screens • Mesh roof panels & seam-sealed skylight over centre room for improved ventilation & daytime lighting • Large windows with external weatherproof flaps on the bedrooms • Mesh & privacy screened doorways from bedroom to central room • Geo design frame for added strength & easy set up pre-tied guy ropes & colour coded Durawrap™ poles with Ring & Pin system • Circle ventilation™ system • Internal organiser/accessory pockets • Power cord management system

FABRIC: 75D/185T POLYESTER/TAPED SEAMS, 3,000MM PROOFED FLY, HEAVY-DUTY PE FLOORING FRAME: 11MM COLEMAN® DURAWRAP™ POLE, 16MM STEEL AWNING POLES WEIGHT: 26KG SIZE: 6X2.8M PACK QTY: 1 INNER SIZE: 88X50X26CM INNER WEIGHT: 26.1KG OUTER SIZE: 90X52X28CM OUTER WEIGHT: 28.1KG

SUNDOME ® SERIES

FEATURES:

Ground vent & large windows move air up & out Dome design for quick setup, 10 minutes Snag-free, continuous pole sleeves for easy setup Rain fly awning for shade & rain protection Storage pockets keep gear organised WeatherTec™ System—patented welded floors & inverted seams keep water out Insta-Clip™ Pole attachments Carry bag included for easy transport

SUNDOME® 2P

SPECS:

FABRIC: POLYESTER 68D FRAME: 8.5MM FIBERGLASS WEIGHT: 3KG SIZE: 2.13X1.52M

MODEL # 2000024579

PACK QTY: 4 INNER WEIGHT: 3.4KG INNER SIZE: 61X14X14CM OUTER WEIGHT: 14.9KG OUTER SIZE: 62X31X32CM

SUNDOME® 4P

SPECS:

FABRIC: POLYESTER 68D FRAME: 8.5MM FIBERGLASS WEIGHT: 4KG SIZE: 2.74X2.13M

MODEL # 2000024582

PACK QTY: 4 INNER WEIGHT: 4.65KG INNER SIZE: 61X16.9X16.9CM OUTER WEIGHT: 19.5KG OUTER SIZE: 62.5X35X35CM

6

SUNDOME® 6P

SPECS:

FABRIC: POLYESTER 68D FRAME: 11MM FIBERGLASS WEIGHT: 7KG SIZE: 3X3M

MODEL # 2000024583

PACK QTY: 2 INNER WEIGHT: 7.6KG INNER SIZE: 67X19X19CM OUTER WEIGHT: 16.5KG OUTER SIZE: 69X21.8X42.7CM

RIDGELINE ™ 2P ADVENTURE

FEATURES: SPECS: MODEL # 1410679

• Compact & lightweight 3 season tent for hiking, backpacking & touring • Easy to set up 2 pole tunnel construction featuring lightweight aluminium poles & V-stakes • Full ultra fine mesh inner for use as screen tent in warmer climates • Lightweight 75D seam sealed polyester fly with four heavy duty Q/R buckle attachment points for easy setup & heavy duty 190T polyester bathtub floor

TENT FLOOR AREA: 240 X 120CM TENT WITH FLY: 320 X 140CM TENT HEAD HEIGHT: 90CM FRAME: 2 X ALUMINIUM 7MM FLY: 75D P/190T PU WR 3000MM FLOOR: 75D P/190T PU WR 3000MM WEIGHT: 1.75KG SIZE: 320X140X90CM

PACK QTY: 4 INNER SIZE: 40X16.5X15.5CM INNER WEIGHT: 1.7KG OUTER SIZE: 43X30X28CM OUTER WEIGHT: 8KG

RIDGELINE ™ 3P ADVENTURE

FEATURES: SPECS: MODEL # 1410680

• Compact & lightweight 3 season tent for hiking, backpacking & touring • Easy to set up 2 pole tunnel construction featuring lightweight aluminium poles & V-stakes • Full ultra fine mesh inner for use as screen tent in warmer climates • Lightweight 75D seam sealed polyester fly with four heavy duty Q/R buckle attachment points for easy setup & heavy duty 190T polyester bathtub floor

TENT FLOOR AREA: 240 X 175CM TENT WITH FLY: 320 X 180CM TENT HEAD HEIGHT: 100CM FRAME: 2 X ALUMINIUM 7MM FLY: 75D P/190T PU WR 3000MM FLOOR: 75D P/190T PU WR 3000MM WEIGHT: 2.4KG SIZE: 320X178X110CM

PACK QTY: 4 INNER SIZE: 42X19X18CM INNER WEIGHT: 2.5KG OUTER SIZE: 43X35X30CM OUTER WEIGHT: 10.5KG
