The IVS 360 team recently supported a customer with an Volvo C70 2004 model year. The cruise control was reported as inoperable. A clutch pedal sensor fault code was also recorded. They identified the cause and steps needed to fix the problem:

Make: Volvo

Models affected: C70 (2001 - 2004), S60 (2001 - 2004), S80 (2001 - 2004), V70 (2001 - 2004)

Symptoms:

1. Cruise control may not function. 2. Fault codes for the clutch pedal position sensor.

Fault codes:

• 9300 - Clutch pedal position sensor, faulty signal. Signal too high. Permanent fault Engine Control Module - ECM • 928C - Cruise control lever. Signal too low. Permanent fault

Engine Control Module - ECM

Possible causes:

1. Clutch pedal position sensor may be faulty and need replacing.

Repair steps:

1. Remove the drivers’ side dash undertray.

2. Inspect position sensor for clutch fluid contamination.

3. Connect your Opus IVS device.

4. Go to Drive.

5. Select dynamic data values, brake/clutch pedals.

6. Check the clutch pedal position sensor values.

When the clutch is completely released, the value is approx. 60-70%. The value decreases when the clutch pedal is depressed.

7. If the values are lower than 9.0% for longer than 0.16 seconds, or higher than 79.7% for longer than 0.16 seconds, replace the clutch pedal position sensor.

Parts required:

Clutch position sensor (9472979)
