ASTEC Drum Chipper

ASTEC Industries Peterson’s 4300 and 6300 series drum chippers are available in double or triple grouser tracked options. Powered by a Caterpillar engine, Peterson drum chippers boast high torque for high volume production. Chip accelerators enable faster load times with more chips in each truck.

The 4300B drum chipper can easily handle material from logs up to 26" (61 cm) in diameter, to brush and small feedstock.

The chipper utilizes a 36" diameter by 40" wide (91 by 102 cm) drum with wear resistant AR450 wear surfaces on the drum pockets and shell.

A sloped feed deck makes feeding the chipper easier. The optional material sizing grate and chip accelerator ensures tight chip packing and fully loaded chip vans. All models come standard with an end-load spout; the 4310B and 6310B are available with an optional top-load spout. The discharge system can either add load density or propel chips significantly farther from the machine for in-woods and clearing operations.

The grate system provides ultra-consistent chip sizing; twigs and small stems are easily fractured through an innovative system. Easy access knives on all drum chipper models have a patented safety latch system which prevents the drum from moving during knife changes. Anvils are made from AR400, for long life and accurate chip sizing.

The 4310B is also available as a Highwalker giving extra ground clearance for landclearing operations. More torque creates superior fuel efficiency. Longer knife life reduces downtime from replacing wear parts frequently and the Adaptive Feed speeds reduce engine load and increase fuel efficiency. Visit astecindustries.com.

Tigercat Track F-B

The Tigercat LX830E is a powerful and stable leveling feller-buncher with a compact tail swing and a high performance closed loop track drive system, well suited to steep slope thinning and final felling applications.

The updated Eseries cab includes a new parallel action air ride seat with integrated heating and cooling. The reclining seat is fully adjustable with seat angle and seat extension adjustment. The wider seat cushion and lumbar support provide operator comfort all day long.

HVAC controls feature a new infinitely variable fan speed control, adjusted on the control panel or the machine control system touchscreen, adding to operator comfort. Multiple convenient storage locations with nets

have been added to the cab to keep items secure.

A redesigned engine enclosure provides improved roof access for clearing debris. A boom slider also reduces debris build-up in hard-toreach areas.

A hot shutdown feature has been added. This allows the turbo to sufficiently cool before stopping the engine, improving turbo life. A larger, spring-assisted pump cover allows for easier service access to the hydraulic pump area. Hydraulic enhancements include quicker anti-stall response, consistent anti-cavitation flow and improved heat rejection. Visit tigercat.com.

The purpose-built Tigercat 180 swing yarder combines the speed and stability of conventional yarders with the mobility and simpler controls of excavator-based yarders. The result is a powerful and versatile yarding machine for extreme terrain logging applications. The 409 HP carrier was carefully designed with a component layout, hydraulic system, drivetrain, and boom system optimized for yarding. The result is high line pull, excellent stability, and efficient operation.

Grapple Attachments

Tigercat is steadily growing its line of grapple attachments in an effort to provide end-to-end Tigercat branded solutions that integrate seamlessly with Tigercat loggers, loaders and shovel loggers.

The new butt-n-top and shovel clam grapples are built with durable boxed style jaws fabricated from high strength steel. Replaceable tine tips are made from abrasion resistant steel.

High quality, heavy duty components are used throughout. Cushioned cylinders, and a softstart and stop slew hydraulic circuit prevent structural shock loads and promote extended grapple life while providing ample speed and torque for excellent performance.

Hydraulic hoses are routed on top of the boom and under the connecting pin to best protect the hoses from damage. The BT08 and SC08 grapples are simple to maintain with easy access to daily service points and critical components. A sealed electrical box protects electrical components from the elements.

With an 8 ft2 load capacity area, the BT08 butt-n-top grapple is designed to match up to the 865, 875E and 880E series loggers. The overall design provides exceptional control of tree-length timber. The jaw profile rolls the logs into the load area to maximize load size and minimize cycle times.

The new Tigercat SC08 shovel clam grapple is designed for the LS855E and LSX870D shovel loggers. Also with an 8 ft2 load capacity, the shovel clam grapple provides an alternative to dangle style log and bunching grapples. The SC08 can enhance shovel logger functionality and productivity by increasing control of the trees and the speed at which the operator can gather and manipulate the bunches. Visit tigercat.com.

Designed to achieve exceptional stability, the 180 can achieve high line pull without the use of guylines in most operating conditions. The undercarriage has a reinforced pedestal and carbody with an extended blade for added stability. Blade mounts are tied directly into the carbody for added strength. The machine can be quickly moved to the next setup by simply lifting the blade. In operating situations where additional stability is required, such as with extremely long yarding distances or low deflection conditions, a simple static guyline can be quickly set up. The machine still retains the ability to swing with this guyline attached.

The winches are driven with efficient dedicated closed loop hydraulic circuits for smooth operations and infinitely variable speed control. The closed loop circuits provide energy when lowering the load for increased efficiency. Intuitive joystick controls, along with many programmable features reduce, operator training time and increase production. Visit tigercat.com.

Komatsu Forwarder

Komatsu’s 845-1 forwarder offers an excellent combination of high crane capacity, maneuverability and rough terrain capability to help you maximize your productivity. With high productivity for thinning and light clear-cutting, the 12-metric-ton class forwarder offers several frame-length options. Designed for smooth and precise operation, the 8451 has a long reach with excellent lifting power and slewing torque.

Even when fully loaded, operators can maneuver with confidence in the most rugged forests. The chassis and suspensions on Komatsu forwarders are designed for performance under demanding conditions. Komatsu Comfort Bogie axles with a high portal offset and V-shaped frames provide some of the highest ground clearance in the industry.

Designed to maximize performance with high power and torque with a Tier IV Final fuel-efficient engine, the sophisticated control system on the 845-1 automatically adapts to changes in engine load. Computerized HST system considers machine load, terrain conditions, power and torque output to give you exceptional tractive force. Hydraulic retarder overspeed protection ensures the driveline won’t run too fast.

Operator comfort is key to productivity and the spacious and open cab on the 845-1 provides excellent visibility, ergonomic controls and a seat that delivers all-day comfort.

The state-of-the-art MaxiXT system monitors and controls everything from engine and crane to the transmission and service ladders. Multiple options are available to enhance productivity and comfort, including bunk wideners, rear- and front-view video cameras, computer touchscreen and electric fuel fill pump. For ground or stump leveling on tough terrain, an optional heavyduty stacking blade is available. Mounted with a high angle of departure for climbing obstacles, there’s no interference between blade, battery boxes or hood guard. A standard diesel heater system heats the engine coolant, hydraulic oil and the batteries to facilitate cold-weather starting on the 845-1. Maintenance is quickly and easily completed with a service-friendly design that features an electronically powered tilting hood. All filters are located together for easy access under the hood. Visit komatsu.com.

John Deere revealed the newly enhanced 350 Ptier and 380 P-tier excavators to the manufacturer’s mid-size excavator lineup. These revamped machines are the first excavator models to launch as part of John Deere’s new Performance Tiering strategy

Both excavators offer SmartGrade technology as a factory option and field upgrade kits. Customers can choose from 2D guidance, 3D guidance, 2D SmartGrade Ready Control, and SmartGrade 3D Control. These grade management options allow customers to choose a level of technology that’s right for them with the ability to upgrade as their business grows. Overdig protect limits the bucket’s cutting edge from going below the target design surface.

Visibility around the machines has been improved with the option of a right, rear and left camera system with LED surround lighting that provides enhanced 270° visibility and is integrated into the primary display in the cab.

The machines’ fuel economy is up 7% compared to previous models via electric on-demand cooling fans that reduce engine load, in-line after treatment for less restriction and system complexity, along with increased front piping diameter to cut down hydraulic restriction. Visit johndeere.com/excavators.

Doosan Infracore North America introduces three additional models of its next-generation 7 Series wheel loaders. These new 200 size class machines include many of the same features as the larger models and are now available at Doosan dealerships.

Similar to the -7 Series wheel loaders that were launched in spring 2021, this next generation offers all-new redesigned cabs with first-class comfort features, increased bucket capacities and new fuel-saving technologies.

The three new models—DL200-7, DL220-7 and DL250-7—are smaller than the models launched last year. They have standard bucket capacities between 2.6 and 3.3 cubic yards. All three new models are available with a high-lift option for additional dump height and reach.

Each model of the -7 Series can be equipped with an optional Transparent Bucket, a Doosan-exclusive technology that offers a supplemental view from a monitor inside the cab to improve operator visibility and productivity. The Transparent Bucket has two cameras with protective guarding, one mounted high and one mounted low on the front of the machine.

An improved Load Isolation System improves wheel loader stability while moving, which can reduce cycle times, increase productivity and boost fuel efficiency. The new Doosan Smart Load weighing system tells the operator the weight of material in the bucket. All menus and settings are integrated into the Doosan Smart Touch screen. Visit na.doosanequipment.com.

Tigercat Industries has developed a forestry dozer. The new TCi 920 will be making the rounds at several U.S. forestry industry tradeshows this spring.

The dozer will be branded under the new TCi badge, as Tigercat Industries continues to design machines for applications beyond forest harvesting systems. All products falling under the TCi brand are, and will continue to be designed, manufactured, and supported by Tigercat Industries.

Seeking to overcome shortcomings that harvesting professionals have experienced when applying standard-build, mass production dozers to forestry operations, the

new 920 is designed specifically for use in logging applications.

The 920 is powered by the Tigercat FPT N45 Tier 4f engine rated at 101 kw (135 hp). It is equipped with a 190 mm (7.5 in) pitch heavyduty undercarriage, a responsive and efficient closed loop track drive system, strong, impact-resistant belly pans, and durable structural components throughout. The 920 provides the power, durability and versatility for deck clearing, road building and cleanup activities on logging sites.

The carefully designed forestry cab offers the operator clear sightlines augmented by the sloped front hood and rear-mounted exhaust. The cab is quiet and comfortable with a heated and cooled air ride seat, ergonomic armrest mounted joysticks, and a large touchscreen machine control system interface.

Visit tigercat.com.
