leave gaps where sound travels into or out of the space. Nevertheless, doors play a role in sound reduction.

Traditionally, swing doors out-performed sliding doors for controlling sound. Until recently, sliding doors typically had lower STC (sound transmission class)/NIC (noise isolation class) ratings than swing doors due to the difficulty of sealing all sides of a sliding door in the closed position. Now, however, sliding door options are available that achieve NIC values on par with swing doors by sealing all four sides of the door leaf. Some sliding door assemblies provide NIC values to 39, which meets or exceeds the Chicago-based Facility Guidelines Institute’s STC 35 target for speech privacy in exam rooms. In addition to providing privacy for conversations, this level of sound attenuation helps reduce noise outside the private space for an overall healthier and more productive indoor environment.

In addition to sliding doors that help block sound, design professionals, as of 2018, can now use sliding doors where building codes require a fire rating. The first such product is a surface-mounted, top-hung, single-leaf wood door with a 45-min. UL 10B fire rating. As a result of this fire-rated configuration, even more spaces are open to realizing the benefits of sliding doors.

Conference rooms benefi t from the space-saving form and clean lines of sliding doors.

Stop Battling Volatile Prices and Corrosion

Pricing for steel mechanical piping systems is rising significantly. Lightweight, stably priced Aquatherm polypropylene-random (PP-R) piping is connected by quick, reliable heat fusion. Plus, PP-R doesn’t rust, scale, or corrode and it has a 60-year projected lifespan and many other benefits. Learn more at aquatherm.com

MOUNTAIN VIEW HOSPITAL The expanded and refurbished emergency department at Mountain View Hospital in Payson, UT, features sliding doors from AD Systems, Everett, WA.

“It was critical that we create transparency in the department so that everyone—doctors, nurses, staff, and patients—can look around and immediately see what’s heading their way,” said Nathan Murray, design principal of TSA Architects, Salt Lake City. The sliding doors “enabled us to maximize the space in an efficient way so we could achieve a fluid environment that can respond to the fluctuating levels of demand placed on it at any given time,” he said.

The doors offer space savings, durability, and acoustic mitigation. ADA-compliant operation and soft-close features ensure that patients of all ages and abilities can easily open and close the doors.

“We now have the means to provide a broad range of emergency-care services faster to even more people,” said Kevin Johnson, CEO of Mountain View Hospital. “This state-of-the-art expansion, combined with our award-winning emergency department processes, will help us deliver care in the most effective manner possible.”

For design professionals who value the contemporary aesthetics and space-saving nature of sliding doors, the growth in options available with today’s technology and designs means not trading acoustic performance, fire-ratings, hardware options, or reliability by deciding to design with sliding doors. CA

Tysen Gannon, LEED AP, is director of business development for AD Systems, Everett, WA. She has more than 15 years of experience in the architectural-products industry, including roles in sales, product management, research, and marketing, with a focus on glass and glazing, fenestration and, façade systems.

Want more information? The items listed below are linked at

commercialarchitecturemagazine.com/ 1812adsyst.

Circle 2 on the Reader Service Card.

AD Systems, specadsystems.com Facility Guidelines Institute, fgiguidelines.org TSA Architects, tsa-usa.com
