Soil, the farmer’s most important asset. Part 4

Soil:

The farmer’s most important asset

Part 4: The clay minerals

Martiens du Plessis, Soil Scientist, NWK Limited & Prof Cornie van Huyssteen, Lecturer: Soil Science, University of the Free State in South Africa.

Soil is the most fundamental resource for the farmer, without which food and natural fibre cannot be produced. This article forms part of a series to highlight this resource. In this article, we discuss the most important clay minerals occurring in the soil. Primary minerals weather chemically to form the basic elements for the formation of secondary minerals. Because oxygen (O; 46,6%), silicon (Si; 27,7%), and aluminium (Al; 8,1%) are the most prolific elements, in the earth’s crust, one may conclude that these three elements will also be the most prolific in the secondary minerals.

CLAY SHEETS The silicon cation is surrounded by four oxygen anions to form a four sided tetrahedron. The tetrahedral clay sheet forms when the tetrahedra arrange themselves to form a layer. The aluminium cation is surrounded by six hydroxide (OH) anions to form an eight-sided octahedron. These octahedra also arrange themselves into a sheet, which is then referred to as the octahedral layer. It is combinations of these tetrahedral and octahedral layers that form the basic building blocks of the clay minerals. Because these secondary minerals occur mainly in the clay fraction and, as a result of the layered nature thereof, the terms secondary, clay or phyllosilicates (layered) minerals are used interchangeably, but they all refer to the same thing.

negative charge of between 10 and 15 cmolc kg-1 of clay. [One mole is equal to 6,023 x 1023 (Avogadro’s number) particles. One centimole is therefore one hundredth, or 6,023 x 1021 of this. Therefore, kaolinite has 10 x 6,023 x 1021, or 6,023 x 1022 (60 230 000 000 000 000 000 000) negative charges per kg of clay.] This charge has to be balanced by cations and gives clay the ability to bind cations – the so-called cation exchange capacity (CEC). [Kaolinite’s charge is mainly pH dependent – more about this in a later issue.] Hydrogen bonding takes place between the Al-OH octahedral layer and the adjacent Si-O tetrahedral layer, of the two respective clay minerals. This bond is relatively weak, but is strong enough to prevent water moving in between the layers. As a result, kaolinite minerals do not expand and shrink during wetting and drying. It therefore has stable physical properties. Kaolinite clay crystals are relatively large and occur in the coarse clay fraction. The clays are therefore non-sticky and are “nonplastic”. The kaolinite minerals occur towards the end of the weathering cy-

KAOLINITE CLAY MINERAL Kaolinite is the most common clay mineral in poorly structured soils, which include the vast majority of the arable land in Southern Africa. Kaolinite is formed when one Al octahedral layer and one Si tetrahedral layer combine to form a 1:1 clay mineral (Figure 1a and Figure 2). Limited isomorphic substitution (replaced by the same shape) of Al 3+ which replaces Si 4+ in the tetrahedral layer, leads to the formation of a

cle, are rather resistant to weathering, and weather further to form aluminium oxides. As a result of the low CEC, it does not retain many cations and is therefore a poor provider of basic cations (potassium, calcium, magnesium and sodium). Halloysite is also a 1:1 clay mineral, but of lesser importance in soil.

THE 2:1 CLAY MINERALS The 2:1 clay minerals form when one Al octahedral layer occurs between two Si tetrahedral layers. The most important 2:1 clay minerals are the fine micas (Figure 1b), vermiculite (Figure 1c) and montmorillonite (Figure 1d).

The fine micas The fine micas and vermiculite have undergone isomorphic substitution in the octahedral (Mg 2+ replacing Al 3+ ) and tetrahedral (Al 3+ replacing Si 4+ ) layers. In the case of the fine micas, the negative charge is balanced to a great extent by potassium (K + ), which fits snugly between respective clay layers. As a result, the fine micas cannot expand and shrink during wetting and

Make use of Logistics? We are the answer.

Save more money & headaches than you ever thought possible. Join today and experience why this is the future!

Safe | Quick | Easy

From as low as R12 000 per year you have access to Africa’s fastest growing logistics network. Our platform not only connects verifi ed and preapproved transporters & cargo owner, but offers easy to use tools designed to streamline your logistics management like never before. Once-off listings also available. It will be done on your behalf and the costs is R350. s,

Sign Up Now:

www.logisticsworldnetwork.com

(R1 000 p.m. on an annual subscription) Once-off listing @ R350

Dorpstraat 156, Stellenbosch

jcgenade@logisticsworldnetwork.com

Figure 2. Scanning electron microscopic image of kaolinite crystals, which indicates the hexagonal (sixsided) piles of crystals and interlayer spaces. Photo: rdg.ac.uk/ cfam/imageofthemonth/2008/February2008.

drying. The fine micas are an important source of K + in the soil when it weathers. The nett CEC of fine mica is 40 cmolc kg-1 of clay.

Vermiculite Vermiculite forms when the fine mica minerals lose the K + cations in the inter-layer spaces due to weathering. Vermiculite clay, therefore, has a high CEC of 140 cmolc kg-1 of clay. Water and cations can move into the inter-layer spaces but, because the clay strongly binds the cations, the clay has a limited expansion and shrinkage ability during wetting and drying. The most important property of vermiculite is that it can fix K + in the interlayer spaces, making it inaccessible to plants. It is therefore a significant fixer of sink of potassium fertilizer in the soil, although this K + can be released in the long-term through weathering. Montmorillonite Montmorillonite (Figure 1d and Figure 3) is also a 2:1 clay mineral, but has isomorphic substitution of Mg 2+ which replaces Al 3+ solely in the Al octahedral layer. The charge is therefore lower than in the case of vermiculite and is also concentrated in the middle of the clay mineral. The cations are therefore not attached as strongly as in the case of vermiculite, and water, together with cations, can move easily in and out of the inter-layer spaces. This results in montmorillonite expanding and shrinking considerably (almost doubling in size) during wetting and drying. These clay minerals are small and have a high CEC of 100 cmolc kg-1 of clay. The charges of 2:1 clay minerals are mainly permanent and are not influenced by pH. Montmorillonite clay minerals are very small and are therefore extremely sticky and “plastic” and have a high affinity for water and cations. These clays are therefore good providers of plant nutrients but, as such, can retain water so strongly that it is inaccessible to plants. As the soil shrinks, it results in major cracks. Water infiltration will thus be rapid when the soil is dry, but very slow when wet. The sticky nature of the clay results in it being difficult to till when wet. When dry it is usually too hard to till. Soil comprising mainly montmorillonite is problematic to till and to irrigate, although it is very fertile. This soil is known colloquially as turf or black cotton clay. 40 cmolc kg-1 of clay. The properties of chlorite are very similar to those of the fine micas. They have a limited CEC and moderate hydration, expansion, and plasticity. The exception is that it is a good source of Mg 2+ during weathering.

SUMMARY Clay minerals may be seen as the engine room of the soils, as it is the clay that retains water and cation plant nutrients. Although the various clay species comprise the same Al octahedral and Si tetrahedral layers, they have widely divergent properties, as a result of the varying degrees of isomorphic substitution in these layers. Knowledge of the type of clay mineral in the soil can therefore enable the land user to better manage their soils.

Chlorite Chlorite (Figure 1e) is a special 2:1 clay mineral, where an Mg octahedral layer is found in the inter-layer spaces, which neutralises most of the negative charge. Chlorite is therefore in essence a 2:1:1 clay mineral. Isomorphic substitution, (Mg 2+ replaces Al 3+ ) in the Al octahedral layer, provides chlorite with a CEC of

REFERENCES The following references were used extensively during the compilation of this series of articles: 1. Van Huyssteen, CW. 2009. Soil ecology. Unpublished class notes for GKD214. University of the Free State, Bloemfontein. 2. Brady, NC. and Weil RR. 2002. The Nature and Properties of Soils. 13th ed. Prentice Hall, New Jersey.

ProAgri BNZ acknowledges Grain SA for the use of this series which originally appeared in Afrikaans in SA Graan/Grain.

Figure 3. Scanning electron microscope image of montmorillonite. The fineness and amorphous character of the mineral is clearly visible. Photo: minersoc.org/pages/gallery/claypix/smectite/a-rose. For further information, please contact: Martiens du Plessis at martiens@nwk.co.za or Cornie van Huyssteen at vanhuysteencw@ufs.ac.za.
