How Does Horizontal Directional Drilling Work?

At its heart, the HDD process is easy to understand. Most times the objective of the drilling is to go beneath all existing utilities. However, there may be cases where the drilling needs to be done at levels above or between existing utilities. The first order of business is to make sure the existing underground utilities and structures in the proposed path of the drilling activity are located and marked out. In most cases calling DigSafe at 811 will take care of this, but some utility owners may not be members of DigSafe and those owners need to be contacted directly to mark out what they own.

Horizontal Directional Drill Rig

A powerful hydraulic drill rig will be set up at the starting point and begins the bore by rotating a steel cutting head followed by 20 feet long steel rods (Typically 4” to 6” in diameter). This is called the pilot bore and it advances through the soil 20 feet at a time as each length of steel pipe is added at the drill rig end.

The object is to know where the cutting head is at all times –both horizontally and vertically. On short length drilling projects, the location of the steel drilling head can be tracked by an employee walking on the ground surface using a magnetic locator that will provide alignment and depth readings. On longer length projects or deeper or underwater projects the drilling head will be outfitted with a special transmitter that sends signals back to more sophisticated electronic monitoring equipment.

As the cutting head advances it can be remotelysteered by the drill rig operator based on the need to correct alignment or depth. Once the initial pilot bore arrives at the end point the advancing cutting head is removed and a larger cutter (spinning in the opposite direction) is attached to the pilot bore piping. This head is called the “back-reamer’ and it is also attached to the HDPE pipe that will remain in the ground.

At that point, the drill rig operator will pull back the pilot bore piping as the “back-reamer” enlarges the pilot drill hole while also pulling back the permanent HDPE ( or steel) pipe.

During this pull back process drilling fluids are added that create a slurry that cools the “backreamer”, lubricates the trailing HDPE (or steel) pipe, assists in removing the drilling spoils, and stabilizes the bore hole. As the “back-reamer spins, both pipes are pulled back (again 20 feet at a time) toward the starting point at the drill rig, completing the process.

As one might suspect, larger piping (over 10 inches in diameter) may require multiple passes with increasing sizes of cutting heads and “backreamers”. The larger the pipe size and the longer the bore, the more modifications to this process might be required also increasing the risks and costs of the work. n
