YAMAHA RMAX2 ROCK REVIEW

RAMX

ROCK CRAWLING

Advertisement

Putting the Wolverine RMAX2 1000 through its paces in Johnson Valley

It’s no secret that the UTV market is hot right now. More than that, buyers like you and I are more often than not looking for vehicles that can truly “do it all”. Such is the reason why the sport/ rec market and vehicles like the General, Teryx, and Wolverine lineup sell so well – all of these UTVs can do it all and do it all well. The latest sport/rec vehicle on the market is the Yamaha Wolverine RMAX 1000, which has been praised for many reasons, including the fact that it can really “do it all” in terms of hauling a heavy load or trailer around the farm or hauling the mail out on your local trails. So, to switch things up a bit, we had to put it to the test at one of the ultimate off-road rock climbing areas on the planet – Johnson Valley in California, also known as the birthplace of King of the Hammers. No, this isn’t a test of how much the RMAX can haul around the farm (although it can do that, too). This is a test of how well the RMAX rock crawls up some of the gnarliest trails out there. Bet you didn’t think we’d

do this in an RMAX…

ROCK CRAWLING REVIEW

Putting the Wolverine RMAX2 1000 through its paces in Johnson Valley

STORY: THE GHOST PHOTOS: STAFF OF UTV OFF-ROAD

For starters, the RMAX comes with a host of standard features that make it willing and able to tackle rock trails like this, including: 30” tires from the factory, full length steel skid plates, a healthy 13.8” of ground clearance, arched a-arms in the front and plated suspension parts in the rear, no rear sway bar for increased articulation and traction, and the all-new D-mode system that allows the driver to change the throttle and engine braking delivery of the RMAX on the fly (on all models but the base model). Right off the showroom floor, the RMAX is a very capable and you can begin to see why someone who buys one of these machines would feel comfortable taking this side-by-side on challenging rock climbs, rutted trails, etc. It’s ready for the adventure!

Our test day consisted of taking the RMAX2 1000 up the technical and challenging Turkey Claw trail. However, it wouldn’t be enough to do it once and say, “we did it”. No, we put this RMAX through the ringer and went UP Turkey Claw over 25 times in one day to see how it held up, how it clawed its way up the hill on multiple rock-laden lines, and how well the entire package performed in the variety of terrain that Turkey Claw presents, including loose sections, 2-3 foot boulders, and of course the tight and technical curves over and around those aforementioned boulders. At the end of the test session, there were a couple things about the RMAX that really stood out…

The first thing we noticed is how well this powertrain system is mated together, and it all starts with the Ultramatic transmission. It’s smooth, precise, consistent, and allows the driver to put the RMAX exactly where he/she needs it to be to tackle the rock ledges. Plus, the fully locking front and rear differentials eliminated any worries that we’d lose traction. There were times where we thought that the tires would spin on a 3-foot-tall rock ledge and there wouldn’t be enough pulling power to get the RMAX up and over the obstacle. Every single time we were proved wrong as the RMAX simply put the power to the ground and climbed its way up and over the ledge. We’ve done a lot of rock crawling in UTVs, and the RMAX was extremely impressive with how capable it was out there.

A lot of credit has to go to the tires in this case, and the all-new 30” GBC Dirt Commander 2.0 tires on this base model are stellar. Not only do these tires have great high-speed stability when you get to the open terrain, but their cornering ability and traction are just wonderful at any speed. The soft compound made those rock climbs disappear with ease, and we really enjoyed how versatile this tire proved to be. Plus, a 30” tall tire on a stock sport/ rec vehicle is unique and appreciated, especially in a rock climbing situation where the extra meat and ground clearance are both well utilized. The only negative with this tire is the soft compound will likely wear out a bit faster for those of you who are hard on tires, but that doesn’t take away from the fact that this tire has a ton of traction and proved

to be extremely tough with its 8-ply rating and no flats or tears after our brutal day of testing.

You can check out the pictures closer to verify, but the only accessories we added were steel skid plates in the front for the undercarriage and front a-arms, along with a full UHMWPE skid plates underneath. No winch and no rock sliders, just the basics. Be sure to check out the next issue of UTV Off-Road for more information on these accessory installs, and we can tell you now that the skid plates are a must if you’re going to be in the rocks or gnarly terrain. The plastic-based underbody skid plates make sliding over the rocks easy as they don’t get caught on any of the rock edges.

With all of the standard features and just a couple add-ons like this, the RMAX proved to be stellar rock climber on our day of testing. Also, the suspension is tuned to where the vehicle is plush and doesn’t jostle the occupants around on the climbs, but it also holds up well in the high speed sections we found on the backside of Turkey Claw. It still boggles our minds how we went up this trail over 25 times in one day and never had one issue, all while passing other rigs stuck on the trail several times. The overall package of the RMAX is so versatile that we are rethinking what we can do in a sport/rec side-by-side like this. We haven’t even mentioned the fact that the interior

is a comfortable complement to this machine’s extreme capability. At no point did our testers say they were tired or sore after multiple hours in the seats.

I’ll leave it at this – there were some Jeep guys with fully built rigs who saw us complete Turkey Claw twice within 12 or so minutes while they sipped on some cold ones stopped at the top. They weren’t pointing at the birds soaring high above, they were showing us their middle fingers as we completed the trail twice in half the time it took them to do it once, in a stock side-by-side, while everything was still purring along perfectly in the RMAX. What they were really saying is how impressed they were that a vehicle made to be an “all-arounder” can haul supplies or trailers around a farm just as easily as it can conquer a supremely challenging rock climb in the iconic hills of Johnson Valley. Over and over and over, without any issues. We didn’t winch once, or even feel like we were starting to get stuck. Yes, there are more scratches on the bottom and built-in rock sliders than when we started, but that’s what riding is all about, right?!

The Wolverine RMAX2 1000 (and RMAX4) are available at your local Yamaha dealer now with a retail price on the base model of $19,799. That includes the 10-year belt warranty and a whole host of standard features that make this side-by-side a champion of the rock trails.

TURBO S 4

The Most Technologically Advanced RZR Yet

STORY: CODY HOOPER PHOTOS: BRAD HOWE/ADAM CAMPBELL

The current, non-PRO Polaris RZR XP has been around for the better part of a decade now. How crazy is that? Polaris has continually improved upon the first XP platform over the years, and we have been lucky enough to slide behind the steering wheel of every iteration. The Turbo S models released a few short years ago dials the car up to 11 in many of the right categories, but it also highlights some weaker spots in the aging XP platform. So, just how well does this $31,000 super-UTV justify its massive price tag?

HIGHLIGHTS:

• Terrain-devouring suspension • Great ground clearance • Available with or without the electronics package • Massive aftermarket and local parts network • The best version of this chassis Polaris has made yet

ENGINE

The RZR Turbo S 4 uses Polaris’s own ProStar 925cc parallel twin engine, designed for and fitted with a factory turbocharger. It uses a four valve per cylinder, dual overhead cam design with EFI and a host of very intricate sensors to help it run smoothly. Polaris’s ProStar engine develops 168 horsepower at the crank at 14 pounds of boost, and most cars make between 120-130 wheel horsepower on a chassis dyno.

Unfortunately, the almighty Turbo S 4 isn’t the RZR with the highest horsepower rating from the factory stable (at the time we write this). Polaris offers the new-ish Pro XP, which is rated at 181 horsepower and uses a very similar version of the engine in the Turbo S in a different chassis. If you’re the type that doesn’t plan on ever using Polaris’s factory warranty, a simple aftermarket tune for under $1,000 will get your Turbo S far past the Pro XP’s power levels.

TRANSMISSION/ DRIVETRAIN

Polaris utilizes their PVT (CVT) transmission in the Turbo S cars. While there are plenty of rumors running around about a new beltless transmission coming from Polaris soon, today you can only get one with a belt. Luckily, this one puts the power down very well. The clutch engagement is smooth and linear, even with turbocharged power. Always carry a spare belt and the tools to change it, because this is also the second-heaviest RZR they make. Polaris has made clutching improvements to the 2021 model year Turbo S models that they say will result in longer belt life.

Like any CVT, the Turbo S 4’s engine mates to a pair of mechanical clutches linked by a large, ribbed drive belt. It is an offshoot of snowmobile and ATV technology that dates back decades. It makes for an easy driving experience with no physical shifting required besides choosing high or low gear when you set off. Low gear should be used for any steep climbs or lowspeed, high load driving, such as rocks, slow sand sections, mud, etc. Get in the habit of shifting to low gear when you should use it, as it will save you a couple of belts in the long run.

Polaris has had a lot of time to perfect the CVT transmission, but we cannot help but feel like there is still room for improvement. Sudden throttle changes at low speeds often result in some loud clunking from the driveline as the clutches engage and disengage. Once you are moving, the transmission is seamless and always delivers a hard shove when you mat the throttle. Top speeds of 80+ mph are easily achieved with enough runway. In the end, the CVT transmission is easy to use, but it feels like the last piece of the RZR that needs to step into the next generation.

SUSPENSION

Here is where the Turbo S 4 really gets to shine. Starting with the XP 4 Turbo platform, Polaris engineers redesigned the suspension system of the 64” wide cars to create this 72” wide, long-travel beast. After frame reinforcements, significant gusseting, and some enlarging of parts and hardware, the Turbo S 4 is 250 American pounds heftier than the non-S XP Turbo 4 seater. This means that stock for stock, you will lose a drag race to a 64” XP Turbo in your 72” Turbo S.

If that’s the kind of thing that matters to you, then you’re likely looking at the wrong machine – the Turbo S is not the quickest car Polaris will sell you, nor is it the outright fastest 4 seat UTV on the market. The Turbo S was built to take a beating from Mother Earth so its passengers can ride at ridiculous speeds across horrid terrain in total comfort, and it absolutely excels at its mission.

Up front, insanely long dual A-arms control 19 inches of front wheel travel. From the factory, the car’s front end is set up far too soft for our liking, so we added about a half inch of preload to get the car to sit up a bit under braking and when aimed downhill. In the rear, Polaris’s signature 3-link trailing arm design is employed and enlarged to allow an outstanding 21 inches of suspension travel. That’s neck and neck with Can-Am’s Maverick X3, although it gives up a couple inches on paper. In feel on the trail, they are very close.

Polaris and Fox have been working on intelligent shock technology for years, and the Turbo S employs their Live Valve smart suspension system with 3 selectable modes. This means that you can tune your suspension’s stiffness with the literal flick of a switch, right there on the dash next to the 2WD/4WD selector. Three preset “maps” for the shocks allow tuning without even unbuckling your seatbelt. Welcome to 2021.

Three selectable modes allow the driver to dictate how mushy he or she wants their ride quality. Putting around with the kids? Leave it in comfort. Hitting the trail with some friends? Stick it in Sport mode to firm up the ride and keep body roll in check. Want to hang the back end out at 60 mph in a full-lock drift before you hammer down a deep sandy whoop section? Throw it in firm for incredible bottoming resis-

tance! It is a genuinely nice feature that makes a noticeable difference, and one that you won’t find a gimmick as an owner of the vehicle.

Polaris’s Turbo S with Live Valve is void of any external shock adjusters for compression or rebound damping, as the computer-controlled solenoid system takes place of those features. The 2.5” body front and 3.0” body rear shocks do offer preload and crossover adjustability. The RZR has a dedicated electronic control unit for the suspension that takes into account speed, steering angle, throttle/brake position, G force/acceleration, and more to precisely control shock stiffness during your ride. While not yet shock-position sensitive, the system has enough data inputs to make a well-informed decision about how stiff it should be, leading to a great ride and quite an impressive and useful feature set.

TIRES/WHEELS/BRAKES

Pushing the wheels away from the bodywork of the car allowed Polaris engineers to fit massive 32-inch-tall ITP Coyote 8-ply desert tires to the Turbo S’s lanky limbs. Unique 8-spoke Polaris star pattern wheels grace the Turbo S, and while they look nice, they do lack beadlock functionality. At this price, that’s a hard pill to swallow. The ITP tires do a wonderful job of providing traction in intermediate terrain, but they don’t offer a ton of lateral grip when sliding. Some testers mentioned that the tire’s square profile hampers cornering grip at the limit, and we tend to agree. The tires are great for stock meats, but they don’t offer a ton of side bite. This is exaggerated by how much the long Turbo S 4 plows at very low speeds in looser terrain- turning around in the sand requires significant real estate or significant wheelspin, neither of which are ideal in certain situations on the trail.

Polaris upsized the Turbo S brakes, using three piston front and two piston rear calipers. Factory stainless braided brake lines keep the pedal travel firm and squish-free. The extra clamping force afforded by the upsized calipers and rotors is much appreciated with the massive tires and hefty chassis. The RZR’s brakes will lock up all four tires if you stomp them hard enough, and the rear-biased feel is great for trail braking on corner entry. Overall, the brakes get an A+.

INTERIOR & EXTERIOR

The Turbo S interior at the Live Valve trim level is packed with features that make it feel more upscale. A 7” Ride Command digital display takes up the center of the dash and brings a massive amount of functionality to the RZR.

Here’s a rundown of the top available features:

• Dynamix Visualizer/Control • Digital Instrumentation • Built-In GPS • Topographic Mapping • Bluetooth Phone/Audio • USB Smartphone connectivity • AM/FM & Weather Radio • In-Vehicle communication

ready (headsets sold separately) • Speedometer/Tachometer • Odometer/Tripmeter • Engine Parameters/

Temperatures • Diagnostic Code Reader • Music Controller • Backup Camera • Front Camera Ready

This particular Onyx Black Turbo S 4 comes factory with a 2-speaker MB Quart stereo (more speakers can be added later) and a factory backup camera. While useful, especially when belted in, the backup camera is very low-resolution and a couple steps behind a modern street car’s camera quality.

The Ride Command system is very easy to use and can even be operated with gloves on. Having access to all of this connectivity will not be important to some people, which is why Polaris will sell you a Turbo S 4 Velocity Edition for a whopping $5k savings! The “base model” Velocity package is equipped with Walker Evans Velocity Series shocks instead of the Fox Live Valve units, and it is also stripped of the Ride Command digital display, speakers, and everything that comes with the digital dash. It even loses the wonderful Polaris/Grant leatherwrapped steering wheel, the aluminum roof, factory lower door panels, and a few other creature comforts. You’ll take a downgrade in comfort and convenience, but the RZR’s structural and suspension improvements are all there, making the Velocity Edition Turbo S a great buy.

If you have sat in a RZR XP before, this cabin won’t shock you. While Polaris has added some extra storage compartments to the dash, the rest of the car’s cabin is the same as every RZR before it, save for some nice upscale touches like the leather-wrapped Grant steering wheel. The cabin is cramped for taller riders, and the seat bases are noticeably short. The RZR’s seatbacks are not very secure, allowing a lot of side-toside flex, especially with taller or heavier riders. The “Subzero” Hshaped harnesses do a better job of securing occupants than a standard 3-point but are still miles off the comfort of a true 4- or 5-point harness. The simple yet expensive fix is to add aftermarket seats and harnesses, but with a starting price north of $25,000, the factory hardware should be higher grade.

TRAVEL TRAILER

TRUCK CAMPER

NOW BOARDING, THE ULTIMATE SOCIAL DISTANCING MACHINE!

Model 2075

Model 2075

Model 650 Lithium Batteries - Lightweight Cutting Edge Power With More Usable Capacity! (Select Travel Trailers) OPTIONAL FEATURES INCLUDE:

Power Inverter – Run Conventional Appliances At All Outlets! (Select Travel Trailers) Roof Mounted Solar Panels – Clean, Quiet Power Anywhere!

Control your environment while creating memories.

Take control of your vacation with a Lance Travel Trailer or Truck Camper. All the comforts of home with the serenity, isolation and beauty the wilderness has to offer. An all-inclusive resort wherever you park!

Make it a Lance. We are social distancing pros with 55+ years of experience building RVs. Unmatched quality achieved through composite construction and lightweight design with off the grid features keeping you powered up and connected with family and friends.

Our dealer partners are open and ready to serve you in a safe environment! LIVE.LANCE.LIFE.

MSRP: $30,999 www.RZR.Polaris.com

IMPRESSIONS

Big suspension and big horsepower equate to massive smiles in the Turbo S 4. Living up to its Porsche-esque name, it is a true performer in its intended environment. Big rocks, trail debris, whoops as deep as your tires are tall- you name it, and the Turbo S gobbles it up with a smile. Having this much suspension travel really highlights how playful the RZR Turbo models are. While not tuned for surgical precision, they sure do work when you swing the hammer hard. Put your foot to the floor and aim for the choppy stuff, because that’s where the Turbo S wants to spend its time.

This is the most solid-feeling RZR 4 seat unit we have ever driven, the whole seemingly made better by the sum of its parts. The suspension feels incredibly compliant, and changes to the Dynamix system’s dash-mounted rocker switch respond with instantaneous shifts in damping for the car’s almost bottomless suspension. The 4 seat unit’s long wheelbase adds another layer of stability at speed over the 2 seat units, as well as more comfort in hard rear-wheel impacts. Simply put, it does a wonderful job at dancing through the roughest of terrain.

The Turbo S 4 is an absolute bomber on the fire roads, where its wide stance and high horsepower work together to create the perfect package for 2WD full-lock drifting. The RZR changes direction with surprising agility, and feels more stable than most, even when at the limit. This is a fantastic-driving car, the ultimate expression of this version of the Polaris RZR. If you look all the way back to 2014 when the RZR XP 4 platform was first released, you can see that the DNA is the same. Sit behind the wheel of both cars, however, and you will feel a million miles of R&D time worth of difference. The new RZR Turbo S 4 is the best 4 seat RZR Polaris has ever put out, and we cannot stop driving it.

Check out some exclusive video content of the Polaris RZR Turbo S 4
