Linear encoder for industrial applications

SICK sick.com

SICK launched the new DAX linear encoder product family for highprecision detection of piston positions in hydraulic cylinders and monitoring linear movements in machines, providing flexibility for countless industrial applications. The product family o ers three designs to suit these applications, all with industry-appropriate measuring ranges. An Online Configurator provides step-by-step assistance to users in selecting a suitable DAX. For applications with special requirements, the smart and flexible system architecture of the product family allows for tailored and e cient customization.

The detection of a linear position is contactless — and therefore wear and maintenance-free — based on magnetostriction. This absolute measurement principle ensures the highest level of machine availability with no reference runs required. In addition, DAX linear encoders o er comprehensive diagnostic functions. This opens the possibility of using the sensors for condition monitoring and integration into digital transformation environments.

The DAX linear encoder is suitable for measuring positions in many applications, including injection molding machines, presses, automotive machinery, printing and packaging machines, wind, hydro, and solar plants, wood processing, or medical technology.

With the DAX product family, SICK has expanded its portfolio of magnetostrictive linear encoders for industrial applications. Since the device uses an absolute measurement principle, no reference run is required. Three housing variants are available for the market launch of the DAX: a design for integration into industrial hydraulic cylinders, a flat type with block magnets for mounting in tight installation situations, and a version with a slide profile that guides the position magnet, thereby ensuring a very precise and repeatable position measurement. The available measuring range is between 50 and 2,500 mm and is individually configurable in 1-mm increments.

Drive calculator

FAULHABER faulhaber.com

The FAULHABER Drive Calculator is the perfect tool for developers to find a suitable drive system for a specific application in record time. It is easy to use and functional: the modern, clear user interface was designed with optimal usability in mind, and helpful tool tips provide valuable detailed information. For faster calculation, the program uses global presets with common average values. Of course, the default settings can be adjusted to individual needs, such as considering the ambient temperature, supply voltage, or available space.

The suitable solutions are then shown to the user in a clear list of results, which he or she can further narrow down as needed using powerful filters. The FDC currently enables the calculation of seven drive types and two operating modes. A detail page for each drive system shows the calculated thermal values and performance diagrams as well as other important information and data. What makes this unique is that the user can change the values on the fly and have them recalculated and displayed immediately. In addition to the calculation, optimal controls are also displayed to complete the drive system. In the end, the user can download the selected solutions as a PDF or request them directly online.
