Design Notes

three windows, when stacked sided-by-side, only require 6 inches of total thickness.

For each glass window system, two IP65-Rated Crown Right Angle Gear Drives are enclosed in a header beam above the window mechanism. A Crown Gear Drive is positioned on each side of the window system, with both Crown Gear Drives interconnected by an intermediate shaft, allowing one motor to drive the system. Included are vertical lead screws on both sides of the window system, which are connected to the output shafts of the Crown Gears to run the windows up and down.

The intermediate shaft connecting the pair of Crown Gear Drives synchronizes the assembly so that each side of the window panel lifts at an even rate, providing a smooth vertical lifting and lowering of the window panels. The framework has all the mechanical and electrical components concealed within the framework, making for a very clean, contemporary exterior design. DW
