Description & Features:
• Heavy-duty submersible transmitter for level measurement in sludge and slurry installations • 316L SS housing with anti-clogging sensor and reinforced diaphragm seal • Standard ranges from 2 thru 50 psi, optional ranges from up to 140 psi • ±0.25% accuracy • 33’ (10m) of vented cable standard, other lengths also available • NEMA 6P / IP68 for full immersion • 5 year warranty
Applications:
• Manufactured for level measurement in sludge and slurry installations including lifting stations
Order Codes
Output Signal
Accuracy Specifications
Standard 2-wire: 4-20 mA / Vs = 10-36 Vdc
Optional 3-wire: 0-5 V / Vs = 10-36 Vdc 3-wire: 0-10 V / Vs = 10-36 Vdc
Standard: ±0.25% FSO
Optional: ±0.5% FSO
Response Time Permissible Temperature Reverse Polarity Protection
<10 ms Operating: -40°F to 185°F (-40°C to 85°C) No damage. No function.
Electromagnetic Compatibility
EN50081-1/2
Housing Pressure Port Diaphragm Electrical Connector Lightning Protection Enclosure Rating
316L SS Flush mount 316L SS w/1Cr18Ni9Ti 1/2” NPTM submersible conduit Lifetime
NEMA 6P/IP68
Range psi (“H2O)
0/2 psi (0/55) 0/5 psi (0/138) 0/10 psi (0/277) 0/15 psi (0/415) 0/25 psi (0/692) 0/30 psi (0/830) 0/50 psi (0/1,384)
Overpressure 3 psi 7.5 psi 15 psi 22.5 psi 37.5 psi 45 psi 75 psi
Burst Pressure 6 psi 15 psi 30 psi 45 psi 75 psi 90 psi 150 psi
Other scales available on request.
Pin Configuration Electrical Connection Cable Colours
2-wire system
3-wire system Power V+ Signal Output Shield Power V+ Signal Output Ground Shield Red Green/Blue Yellow Red Green/Blue Black Yellow
Wiring Diagram Standard
Optional Code
LM1002 LM1005 LM1010 LM1015 LM1025 LM1030 LM1050
