2014EASTERNSHIPBUILDINGGROUP
LOA: 141' 2" (43.03m)
Beam: 25' 6" (7.77m)
Max Draft: 19' 6" (5.94m)
Speed: Cruising 10 Knots Max13Knots
VATPaid:
Build/Model Year: 2014 / 2014
Builder: EASTERNSHIPBUILDING GROUP
Type: Schooner
Price: (€10,919,671 EUR est.)
$11,950,000USD
Location: Portsmouth,RhodeIsland
UnitedStates
1 rue Barthez
Montpellier, Occitanie 34000 France
P: (33) 4 67 66 39 93
anissa.garni@bernard-gallay.com www.bernard-gallay.com
AdditionalSpecificationsForCOLUMBIA:
LOA: 141'2"(43.03m)
Beam: 25'6"(7.77m)
MaxDraft: 19'6"(5.94m)
HullMaterial: Steel
Superstructure: Steel
HullDesigner: JohnW.Gilbert&Associates
DeckMaterial: Teak
Tonnage: 145.00
Delivery/Model Year: 2014
YearBuilt: 2014
Builder: EASTERNSHIPBUILDING GROUP
Type: Schooner
Engines: 587HP,Single,Inboard,Diesel, Caterpillar,C-18, Staterooms: 4
RangeAtCruise
Speed: 4000
Speed: Cruising10Knots
Max13Knots
FuelCapacity: 6252Gal
WaterCapacity: 2050Gal
HoldingTank: 150Gal
Flag: UnitedStates
Location: Portsmouth,RhodeIsland UnitedStates
Price: (€10,919,671EURest.)
$11,950,000USD
Sleeps: 12
Heads: 7
CaptainCabin: Yes
Classifications:
MCA: ISM:
MAINCHARACTERISTICS
CONSTRUCTIONGUIDANCE
The vessel’s hull, superstructure and underwater gear are designed and constructed in accordance with the Lloyds Registry Rules for Building and Classing Steel Vessels.
VESSELOVERVIEWANDHISTORY
The original COLUMBIA was a 141’ classic Gloucester Fishing Schooner built at the historic A.D. Story shipyard of Essex, Massachusetts and launched April 17, 1923. Essex was the center for American Fishing Schooner construction. Designed by the innovative William Starling Burgess, the COLUMBIA was bred for speed. In the fall of 1923, the COLUMBIA challenged the BLUENOSE, Canada’s legendary schooner, in the International Fishermen’s Cup Races in Halifax, The BLUENOSE was skipperedbyCaptainAngusWaltersandtheCOLUMBIAwascommandedbyCaptainBenPine.Nearly winning the title, the COLUMBIA was narrowly defeated by the BLUENOOSE and was one of the few AmericanschoonerstoprovideachallengetoBLUENOSE.
Tragedy struck the promising young COLUMBIA on August 24, 1927 near Sable Island, the notorious
“GraveyardoftheAtlantic”,wheretheCOLUMBIAwaslostwithallhandsinagale.
Decades later, the owner of Eastern Shipbuilding Group, Inc., in Panama City, Florida, discovered the original lines plan of the COLUMBIA in the Essex Shipbuilding Museum in Massachusetts. He took the opportunity to fulfill a lifelong dream of bringing a significant piece of maritime history back to life. Drawn by her proud history and her beauty, the owner began the journey of bringing the COLUMBIA back to life, and returning her to the glory she deserves.
Working with John W. Gilbert and Associates of Boston, Massachusetts, the design was re-engineered with a steel hull instead of wood. An engine room and staterooms were added to the design. Covey Island Boatworks of Lunenburg, Nova Scotia, built the rigging and spars. Blocks were fabricated by A. Dauphinee & Sons and all the sails were constructed by Michelle Stevens Sailloft, LTD, both from the Second Peninsula, Lunenberg, Nova Scotia. Teak decking was completed by Teakdecking Systems of Florida.
In early 2006 the owner researched the original COLUMBIA’s history and made the commitment. He and his management staff, employees and subcontractors brought to life the design, engineering, purchasedthematerialsandconstructedtheexactreplicaoftheCOLUMBIA(ESGHull981).
The hull lines were redrawn from a copy of the original hand drawn lines plan using AutoCAD computer software by John W. Gilbert & Associates. The hull plate, its formed shapes and structure, were electronically lofted, nested and numerically cut (NC) using ShipConstructor computer software at Eastern’s Allanton Engineering and Steel Processing Facility.
The vessel’s services, steering and propulsion systems were designed and installed for maximum efficiency when under sail or diesel power. There is a transverse bow thruster for ease of docking and undocking. The twin electrical power generation plants, switchgear and wiring were designed and installed meeting current marine regulatory requirements. Also installed are modern interior and exterior lighting, underwater lighting system, air-conditioning and heating and machinery space electric ventilation with plenty of thermal and acoustic insulation.
The onboard electronics, communication and navigational equipment are state-of-the-art with two 36 nautical mile radars, wind sensor, navigational LED lighting, electronic charting, electronic compass and autopilot for open water high performance efficiency. The entertainment systems are interfaced with a VSAT broadband Satellite system with phone, entertainment and internet service.
Using today’s technology coupled with proven early 1900’s craftsmanship, Eastern’s Team of shipbuilders, sub-contractors and vendors collectively constructed and completed sailing trials of this new, modern, historic schooner on September 18, 2014 from Eastern’s Nelson Street Facility in PanamaCity,Florida.
Eastern’s COLUMBIA is truly a robust steel hull replica derived from the historic Gloucester Fishing Schooner, meeting today’s USA regulatory requirements, utilizing today’s technology, machinery, materials, electronics and safety equipment. It was designed with modern crew amenities and comfort in mind. It is a vessel designed with onboard features like no other for a worldwide port-to-port sailing adventure.
HULL
HullNon-WatertightBulkheads 1/4”
Bulkwark Plate 1/4”
ACCOMMODATIONDETAILS
InteriorbyEastern Shipbuilding Group
InteriorMahoganycustomcabinetry–woodhandcrafted, bunks, lockers, desks, leather settee and tables
(4)GuestCabins Sleeps 12 with ensuite facilities
(7)Fullheads
(1)Captain’sCabin Sleeps 3 with ensuite facilities
(1)CrewCabin–Forward (12)singleberths,(1)headandshower
TANKCAPACITIES@100%
TotalFuelOilin(4)tanks
6,252USGallons/23,666liters
Fixed Ballast Lead(47Tons)
PotableWater
GrayWater#1
GrayWater#2
Black Water
2,050 US Gallons / 7,760 liters
150 US Gallons / 567liters
200 US Gallons / 757 liters
150 US Gallons / 567 liters
(2)@225ft3 (insulated) MainDeckArea
Fish Holds
MAST,SAIL&RIGGINGDETAILS
MainMast
Foremast
Sails
TotalSailArea
Spars
Standard Rigging
Running Rigging
Blocks
MACHINERYSYSTEMDETAILS
Diesel Propulsion
PropulsionSystem
TailShaft
Propeller
TailShaftBearings
TailShaftGland
Bow Tunnel Thruster
Main Rudder
Rudder Bearings
SteeringSystem
SteeringRams
Steering Control
(1) 19” x 124’10” Covey Island Boatworks, Douglas Fir LaminatedLower.
SitkaSpruceLaminatedTopMast
(1) 19” x 115’7” Covey Island Boatworks, Douglas Fir Laminated Lower.
SitkaSpruceLaminatedTopMast
MichelleStevensSailloftLTD.OceanusSAILCloth
10,220 ft2
CoveyIslandBoatworks,SitkaSpruceLaminated
Covey Island Boatworks, Traditional Gaff-Rigging 6x19 and
6x36
Parceled and served, Lignum Vitea Deadeyes
CoveyIslandBoatworks,TraditionalNewEnglandRopes
Vintage “Sta-Set” Double Braided Lines
CoveyIslandBoatworks,A.Dauphinee&Sons
Caterpillar C-18, 587 HP @ 1800 RPM
(1)HundestedCPG32CP,3.07:1Reduction
(1)HundestedCP120mmTailShaft
(1) Hundested CP (4) Blade Full Feathering Propeller
1200mmDia.MaterialNi-Al-Bz
Cutlass Strut & Stern Tube Bearings
(1)SimplanDriplessSeal
(1)KeyPowerKP-16,70HP@1500RPMElectro-Hydraulic PTO Drive off the Main Engine
(1) Eastern Shipbuilding Group, Foil Type
ThordonSXLBearings
(1) Pine Hill Equipment Electro-Hydraulic Steering System w/2x 10HPHPU’s
(2)PineHillEquipmentHydraulicCylinders
(1)Electro/Hydraulicw/ManualBackup
Brokerage COLUMBIA
BERNARDGALLAYYacht
1 rue Barthez
Montpellier, Occitanie 34000 France
P: (33) 4 67 66 39 93
anissa.garni@bernard-gallay.com www.bernard-gallay.com
Propulsion Control
Bow Thruster Control
Generator Engines
Generator Rating
ElectricalInstallation
MainSwitchboard
Distribution Panels
Engine Cooling
FirePump
Fish Hold Refrigeration
Freshwater Makers
(1) Hundested Electronic
(1)KeyPowerElectronic
(2) TAW Power Systems – John Deere, 65 kW, 200 AMP @ 1800RPMGensets
(2) Kohler 65 kW each Continuous Rating 230 VAC, 3 Phase, 60Hz@1800RPMMarineGenerators
Eastern Shipbuilding Group, 230/120V AC and 24/12V DC
(1) TAW Power Systems – Parallel Operation Swithboard, 230V AC,
65kW60Hz,3Phase
Ward Electronic – 208/120V AC 60 Hz, 3 Phase Primary
Distribution Panels
HeatExchanged,Raw-waterCooled
(2)MPPump,Inc.5HP#36085
(2)EskimoIceMakersE1510d-230-WP
(2) Cathelco Seafresh H208 Water Makers, 37 USG/per hour, w/RMF-2Re-mineralizers
FreshwaterPump (2) Mach 5, #3380SWTH
HotWaterHeaters
(10) On-demand Electric Hot Water Heaters Hubbell, MTX0183R
5HP#36085 Transfer Fuel
BilgePumps
DECKEQUIPMENTDETAILS
SailWinches
Oberdorfer 1.5 HP T12CT
Racor Duplex Filter – Diesel Engines
20.5
(10) Hydraulic (4 Fwd, 4 Mid-ship, 2 Aft) Harken #74
SailWinch (1) Hydraulic (Mid-ship) Harken #68
SailWinch (1) Hydraulic (Aft) Harken #980
SailWinches (8) Manual – Harken
Manholes PacificCoastMarine
Watertight Doors PacificCoastMarine
Port lights PacificCoastMarine
DeckHatches PacificCoastMarine
DeckPrisms
NAVIGATIONANDCOMMUNICATIONDETAILS
Radar #1
Radar #2
AISSystem
MarineSkylights
B&G Broadband 36 nm, 4G Radar, 24” Radome
B&G Broadband 36 nm, 4G Radar, 24” Radome
SimradNAIS-400,Class-BAISw/GPSAntenna
Chart Plotter (4)B&GZEUS12”ColorDisplaysw/SailSoftware
GPS (3)B&GZG50GPS
NavigationDisplays
Graphical Function Displays
(3)B&G20/20HVDisplays
B&GHerculesBaseBack-GFDH3000/CPUHTDRA
Echo Sounder Simrad GFD H3000 Interface, Flanged Transducer
Speed Log
Simrad, GFD H3000 Interface, Flanged Speed Sensor
anissa.garni@bernard-gallay.com www.bernard-gallay.com
B&GH3000AWA360Displayw/SimNetInterface
Autopilot Simrad AP20, WR20 Remote Commander w/SimNet Wireless Interface
GPSCompass SimradHS70w/SimNetWirelessInterface
Course Computer SimradAC12,w/SimNetWirelessInterface
Rudder Feedback Simrad RF300
Wind Sensor
VHFRadios
VHFHandheld
Weather Station
SecurityCameraSystem
B&GVerticalMastheadPack-1050mm
(2)ICOMRadio/Hailer,25W12VDCw/NEWMARHailerandDeck Horn
(2)ICOMIC-M604A
(1) Simrad Weather Module
(2)OrlacoCompactColorHRCameraswithLEDLights
UnderwaterLighting Lumishore Color Change Lighting
NavigationLights
COLREGS/USCGapprovedLOPO3nmLED
Ship’sBell One
Ship’sClock One
Ship’sBarometer One
Ship’sWhistle
LIFESAVINGEQUIPMENT
EPIRB
SART
Life Rafts
LifeJackets
RingBuoys
Fire Stations
(1) Federal Single #41X 24VDC
(1)A5406MhzUnit
(2)S49GHzX-BandSearchandRescueTransponders
(4) USCG approved 15-man throw-overboard inflatable rafts
(30) USCG approved adult life jackets
(2) 30” Ring Buoys w/lights and lines
(2) Main Deck
FirstAidKit One
Flares
ALARMS&FIREFIGHITNGDETAILS
EngineAlarmSystem
Fire & Smoke Detection
GeneralAlarmSystem
(10) Rocket Parachute Flares
LocalMonitoring,byCaterpilar&TAWPowerSystems
(1) USCG approved, smoke and heat detection
(1)w/twoContactMakers
FireExtinguishers (2) Co2 – Machinery Space; (4) Dry-Chemical –AccommodationSpace
FireAxe One
DECK&ACCOMODATIONSDETAILS
Joiner Fabrication Eastern Shipbuilding Group
ExteriorDeckCovering
TeakDeckSystems–Teakwoodw/Hollystrips
Interior Deck Covering TeakDeckSystems–Teakwoodw/Hollystrips
Overhead Sheathing
Bulkhead Sheathing
Traditional V-Bead Wood – painted
Traditional V-Bead Wood – painted
Mahogany custom cabinetry – wood hand crafted, bunks, lockers, desks, leather settee and tables
ThermalInsulation 4” Rock Wool
Noise&SoundInsulation
ExhaustInsulation
GALLEY/LAUNDRYEQUIPMENT
Refrigerator
Soundown, Barrier acoustic insulation
2”RockWoolInsulatedBlankets
KitchenAid 28 ft3 –StainlessSteel#KSC24C8EYP02
Freezer Cospolich Refrigerator Co. – Built-in unit
Range
KitchenAid, electric four-burner #W10524726A
MicrowaveOven Range Hood, KitchenAid #W10249655A
BERNARDGALLAYYacht Brokerage
1 rue Barthez Montpellier, Occitanie 34000
anissa.garni@bernard-gallay.com www.bernard-gallay.com
IceMaker
Trash Compactor
Dishwasher
Washer/Dryer
KitchenAid,#KUIC15PLXS3
Electrolux,#E15TC75HPS
KitchenAid#KUDE70FXSS5
(2) LG 24” All-in-one, Combo units, #Wm3455HS
Galley/Mess Countertops StainlessSteel
MessAreaTabletop
GalleySink
MainSalonTabletop
Wet Bar
Main Salon Fireplace
TigerMaple&MahoganyWood
Single,StainlessSteel
Tiger Maple & Mahogany Wood – retractable
TigerMaple&MahoganyWoodw/sink
(1)MaxxIceRefrigerator#MCR3U
(1)MaxxIceIcemaker#MIM5C-0
(1)MaxxIce28-BottleWineCooler#MCWC28-0
(1)ElectricDimplex#DWF36PG
ELECTRONICS/COMMUNICATIONS/AUDIO-VISUAL
VSAT
Marine TV Antenna
MainSalonTelevision
Television/DVDPlayers
Radio/CDSystem
PAINTSYSTEM
AllPlate&Shapes
ExteriorCoatingbelowWL
KVHV3w/M5Dome,Mini-VSATPhone/HDTV/InternetSystem
Shakespeare SeaWatch Marine Antenna, 14” Diameter
(1)Samsung46”SmartHDTV
(6)RCA22”HDTV/DVDCombo-units
Crestron/BostonAcoustic&JBL
Wheelabrated with Carboline 8703, Pre-construction Primer
ALEXSEAL–Primer161
ALEXSEAL–FairingCompound202
ALEXSEAL–SuperBuild302
ALEXSEAL–Finish442
ALEXSEAL–Primer161
ALEXSEAL–FairingCompound202
Exterior Coating above WL
PotableWaterTankCoating
VoidTankCoating
Interior Superstructure
Machinery & Storage Spaces
Fuel, Lube Oil & Dirty Oil
CATHODICPROTECTION
ImpressedCurrentSystem
ALEXSEAL–SuperBuild302
ALEXSEAL–Finish442
International Paint – Interline 925
International Paint – Intershield 300V
International Paint – Intershield 300V
International Paint – Interthane 990
International Paint – Intershield 300V
Tank Coating - none
Cathelco(ICCP)MiniteckSystem
DISCLAIMER
All speeds, measurements, capacities, consumptions, etc. may be approximate or estimated. Specifications provided for informationonly. Data was obtained from sources believed to be reliable and is not guaranteed by owner or brokers. Buyer assumes the responsibility to ascertain the correctness of all data contained herein and otherwise provided and must instruct his agent and surveyors to confirm all details for accuracy prior to purchase. Subject to prior sale price and inventory change or withdrawal from market without notice.
