TRUSTED WORLDWIDE SINCE 1908 ECONOMY HIGHMULTIPURPOSEPRESSUREUHP-HVCAFS FAST ATTACK SKID UNITS
CORPORATE HEADQUARTERS 325 SPRING LAKE DRIVE ITASCA, IL 60143-2072 W.S. DARLEY & CO. @WSDA1.800.4.DARLEYWWW.DARLEY.COM•630.735.3500RLEY DARLEY SINCE 1908, DARLEY HAS BEEN DEVOTED TO SERVING THE WORLD’S FIRST RESPONDERS AND WARFIGHTERS. WE ARE DEDICATED TO EXCELLENCE AND OFFER A DIVERSE LINE OF QUALITY EQUIPMENT, PUMPS, AND CUSTOM UNITS THROUGH PROGRESSIVE DESIGN, MANUFACTURING AND WORLDWIDE DISTRIBUTION. THROUGHOUT THE YEARS WE HAVE MAINTAINED A ROCK-SOLID REPUTATION FOR BUILDING QUALITY PRODUCTS AND CREATING POSITIVE RELATIONSHIPS WITHIN THE INDUSTRIES THAT WE SERVE. TO PASSIONATELY SERVE THE WORLD'S FIRST RESPONDER AND TACTICAL COMMUNITIES BY PROVIDING HIGH QUALITY, SAFE AND INNOVATIVE PRODUCTS WITH UNMATCHED COMMITMENT AND SERVICE. MISSION STATEMENT WHETHER YOU NEED A BASIC ECONOMY SKID UNIT OR A CUSTOM UNIT LOADED WITH FEATURES, WE ARE HERE TO HELP. OUR TEAM IS TRAINED TO QUICKLY ASSESS YOUR NEEDS AND GET YOU A QUOTE FAST! WE’VE BEEN BUILDING SKIDS FOR YEARS AND UNDER STAND EACH DEPARTMENT HAS UNIQUE NEEDS. CONTACT US AT 1-800-323-0244 OR EMAIL SKIDS@DARLEY.COM. WE MAKE PURCHASING EASY CHECK FUNDING OPPORTUNITIES AVAILABLE THROUGH FEDERAL GRANT ASSISTANCE. FUNDING OPPORTUNITIES TO LEARN MORE, CONTACT SKIDS@DARLEY.COM
WWW.DARLEY.COM/PUMP-SOLUTIONS/SKID-UNITS 1 TANK UPGRADES • 150 Gallon tank - 48"W x 96"L with a 34" platform • 250 Gallon tank - 48"W x 96"L with a 34" platform • 300 Gallon tank - 48"W x 96"L with a 34" platform • 400 Gallon tank - 48"W x 96"L with a 34" platform • Foam cell, built-in foam tank (10 gallon) • AR317 - FRC tank level gauge - water • TMP WLA 260-A00 FRC tank level gauge - foam • Set of 5" x 16" risers upgrade • Set of 8" x 16" risers upgrade NOZZLES • 1" pistol grip shut off only (part # AM073)/NH thread • 1" aerating foam nozzle 15 GPM - (part # H00014)/NH thread • 1" dual flow nozzle - 10 and 30 GPM (part # BB097)/NH thread PUMP OPTIONS PICK ONE ONLY IF CHANGING THE BASE UNIT • AK314 - 6.5 HP - twin impeller - Honda - electric start • AK313 - 10 HP Davey - twin impeller - Yanmar diesel - electric start BOOSTER REEL UPGRADES • Roller & spool assembly/hose guide • Upgrade to a large steel booster reel, electric, 150' capacity • Upgrade to a large aluminum booster reel, electric, 200' capacity • Additional low profile booster reel with 100' of 1" booster hose • Additional large steel booster reel only • Additional large aluminum booster reel only • BG28150 - Additional booster hose 50' x 1" - red • BG281100 - Additional booster hose 100' x 1" - red • 10' x 1" whipline - net pricing • BL38501 - Additional lightweight booster hose 50' x 1" - red • Credit for booster reel and hose - (piping only) MISCELLANEOUS OPTIONS • Hose tray to fit 200' of 1.5" hose with mattydale swivel • Additional 1" NST discharge • Additional 1.5" NST discharge with cap • LED work light ECONOMY SKID UNIT FOAM EQUIPMENT • Foam, inductor/mixer, Darley Foam Flurry "Around the Pump" foam proportioner (suction side) IDEAL FOR BRUSH FIREFIGHTING NEEDS. DESIGNED TO FIT INTO STANDARD 8' PICKUP TRUCK BEDS. • Davey 13HP - Honda twin impeller pump: electric start • 200 gallon poly water tank • Pressure gauge • 1.5" welded stainless steel auxiliary suction with a 2.5" adapter • All welded stainless steel manifold painted red, including 1" tank fill • 1" pump to booster reel • 1.5" NST discharge • Chrome caps • Electric booster reel with 100' of 1" booster hose • Guzzler hand primer FEATURES WITHECONOMYOPTIONS
This skid unit is equipped with 1-1/2 AGE gear-driven Darley pump coupled to an 18 HP Vanguard or 21 HP Honda engine with control panel. Additional pump upgrades are available. 2 1.800.4.DARLEY | 630.735.3500 HIGH PRESSURE SHOWN WITH FOAM TANK UPGRADES • 150 gallon tank - 48"W x 96"L with a 34" platform • 250 gallon tank - 48"W x 96"L with a 34" platform • 300 gallon tank - 48"W x 96"L with a 34" platform • 400 gallon tank - 48"W x 96"L with a 34" platform • Foam cell, built-In foam tank (10 Gallon) • AR317-FRC tank level gauge - water • TMP WLA 260-A00 FRC tank level gauge - foam • Set of 5" x 16" risers upgrade • Set of 8" x 16" risers upgrade PUMP OPTIONS PICK ONE ONLY IF CHANGING THE BASE UNIT • 1.5 AGE 23 V - Briggs & Stratton • 1.5 AGE 37V EFI - Briggs & Stratton • 1.5 AGE 24 - Kubota • AP01707 - 12 volt fluidless primer with Digitrol™ interface HIGH PRESSURE SKID UNIT HIGH-PRESSURE, LOW VOLUME PUMP FEATURES 1. 1.5 AGE 18V or 21H 2. Exhaust primer 3. 200 gallon poly water tank 4. Designed to fit into standard 8' pickup truck beds 5. Illuminated pressure gauge 6. 2" welded stainless steel auxiliary suction with a 2.5" adapter 2" tank to pump 7. All welded stainless steel manifold painted blue, including 1" tank fill - 1" pump to booster reel - 1.5" NST discharge 8. Chrome caps 9. Electric booster reel with 100' of 1" booster hose 1 2 3 9 8 76
MISCELLANEOUS OPTIONS • Hose tray to fit 200' of 1.5" hose with mattydale swivel • Additional 1" NST discharge • Additional 1.5" NST discharge with cap • LED work light WWW.DARLEY.COM/PUMP-SOLUTIONS/SKID-UNITS 3 NOZZLES • 1" pistol grip shut off only (part # AM073)/NH thread • 1" aerating foam nozzle 15 GPM (part # H00014)/NH thread • 1" dual flow nozzle-10 and 30 GPM (part # BB097)/NH thread BOOSTER REEL UPGRADES • Roller & spool assembly/hose guide • Upgrade to a large steel booster reel, electric, 150' capacity • Upgrade to a large aluminum booster reel, electric, 200' capacity • Additional low profile booster reel with 100' of 1" booster hose • Additional large steel booster reel only • Additional large aluminum booster reel only • BG28150 - Additional booster hose 50' x 1" - red • BG281100 - Additional booster hose 100' x 1" - red • 10' x 1" whipline - net pricing • BL38501 - Additional lightweight booster hose 50' x 1" - red • BL38502 - Additional lightweight booster hose 100' x 1" - red • Credit for booster reel and hose - (piping only) FOAM EQUIPMENT • Foam, inductor/mixer, Darley Foam Flurry "Around the Pump" foam proportioner (suction side) • Foam, proportioning system, Darley Fast Foam (discharge side/available on FA 2 units only) 1.5 AGE 23V 1.5 AGE 37V 1.5 AGE 24K 5 4
4 1.800.4.DARLEY | 630.735.3500 TANK UPGRADES • 150 gallon tank - 48"W x 96"L with a 34" platform • 250 gallon tank - 48"W x 96"L with a 34" platform • 300 gallon tank - 48"W x 96"L with a 34" platform • 400 gallon tank - 48"W x 96"L with a 34" platform • Foam cell, built-in foam tank (10 gallon) • AR317 - FRC tank level gauge - water • TMP WLA 260-A00 FRC tank level gauge - foam • Set of 5" x 16" risers upgrade • Set of 8" x 16" risers upgrade PUMP OPTIONS PICK ONE ONLY IF CHANGING THE BASE UNIT • 2 BE 23 V Briggs & Stratton • 2.5 AGE 23 V Briggs & Stratton • 2.5 AGE 37V EFI - Briggs & Stratton • 2 BE 24 Kubota • 2.5 AGE 24 Kubota • AP01707 - 12 volt fluidless primer with Digitrol™ interface MULTIPURPOSE SKID UNIT This skid unit is equipped with 2BE direct drive Darley pump coupled to an 18 HP Vanguard or 21 HP Honda engine with control panel. Additional pump upgrades are available. HIGH VOLUME, MEDIUM PRESSURE PUMP FEATURES 1. Darley 2BE (multi-purpose/direct drive) 21 HP Honda gas engine: electric start 2. 200 gallon poly water tank 3. Illuminated pressure gauge, 2.5" welded stainless steel auxiliary suction with a 2.5" adapter 4. 2.5" tank to pump 5. All welded stainless steel manifold painted blue, including 1" tank fill 6. 1" pump to booster reel 7. 1.5" NST discharge 8. Chrome caps 9. Electric booster reel with 100' of 1" booster hose 1 3 4 5 6 7 8 9
ULTRAHIGH PRESSURE-HIGH VOLUME • 2BE 24 Kubota • 2BE 24 Vanguard • 2BE 23V & 24K • Simultaneous flows WWW.DARLEY.COM/PUMP-SOLUTIONS/SKID-UNITS 5 NOZZLES • 1" pistol grip shut off only (part # AM073)/NH thread • 1" aerating foam nozzle 15 GPM - (part # H00014)/NH thread • 1" dual flow nozzle - 10 and 30 GPM (part # BB097)/NH thread MISCELLANEOUS OPTIONS • Hose tray to fit 200' of 1.5" hose with mattydale swivel • Additional 1" NST discharge • Additional 1.5" NST discharge with Cap • Additional 2.5" NST discharge with Cap (2.5" valve/available on FA 2 option 2 units only) • LED work light BOOSTER REEL UPGRADES • Roller & spool assembly/hose guide • Upgrade to a large steel booster reel, electric, 150' capacity • Upgrade to a large aluminum booster reel, electric, 200' capacity • Additional low profile booster reel with 100' of 1" booster hose • Additional large steel booster reel only • Additional large aluminum booster reel only • BG28150 - additional booster hose 50' x 1" - red • BG281100 - additional booster hose 100' x 1" - red • 10' x 1" whipline - net pricing • BL38501 - additional lightweight booster hose 50' x 1" - red • BL38502 - additional lightweight booster hose 100' x 1" - red • Credit for booster reel and hose - (piping only) FOAM EQUIPMENT • Foam, inductor/mixer, Darley Foam Flurry "Around the Pump" foam proportioner (suction side) • Foam, proportioning system, Darley Fast Foam (discharge side/ available on FA 2 units only) 2 2.5 AGE 23V 2.5 AGE 37V 2BE 24K
WWW.DARLEY.COM/PUMP-SOLUTIONS/SKID-UNITS © DARLEY 2022: V1
