JASON FUNG ARCHITECT INC. 675 King St W, Unit 211 Toronto ON M5V www.jasonfungarchitect.com1M9jason@jasonfung.ca6479489176x3 September 24, 2021 Re: Letter of Recommendation for Grace Liang To whom it may concern With this letter, I wish to highly recommend Grace Liang for a co-op work placement and to be an active participant on your design team.
If you have any further questions, you are welcome to contact me by phone or email.
JASONRegards,FUNG ARCHITECT Jason___________________________INC.Fung,OAA,M.Arch.,MRAIC. 7
During the summer of 2021, I have had the pleasure of providing a part-time internship placement for Grace. At the studio, Grace was eager to learn and maintained a positive attitude during all of her tasks. On site, and when meeting with contractors and clients, Grace was attentive and a keen observer of the surrounding context.
Grace also has strong technical and artistic skill. I have no doubt that she will perform at a high-level during her co-op work placement. With further guidance and support at your firm, I am confident that Grace will be a productive contributor to your design team.
With warm regards,
1B DESIGN STUDIO 8
As an extention of the landscape, specifically the Joel Weeks Park, Persephone’s Garden is a library + garden and kitchen which supports local sustainable food production and businesses. Highlighting its central courtyard, Persephone’s Garden is simply an urban building with an outdoor space within. During warmer months, the library’s courtyard allows community gardening. While in the winter, plants can be transported indoors as the visibility of the sun peeks through the east. This method of gardening allows fresh produce to be brought straight to the community kitchen or to local markets which encourages environmentally friendly activities while supporting its own community altogether. As timber and glass are the two main materials used, it allows total visibility and visual connections throughout the entire building. It also provides a view of the Don Valley River and the Joel Weeks Park. The library also features a cafe, various relaxation spaces, and shelves for cookbooks and plant storage.
GARDENPERSEPHONE’S
01 PROJECT: LIBRARY + LOCATION: TORONTO, ONTARIO
SOFTWARE: RHINO 7, ENSCAPE, ADOBE PS, AI, IN INDIVIDUAL PROJECT WINTER 2021 INSTRUCTORS: JESSICA HANZELKOVA & CAMERON PARKIN 9
10 SITE PLAN
PLANTS INDOOR 1. ALOE VERA 2. THYME 3. OREGANO 4. CHIVES 5. GREEN ONION 6. SPINACH 7. ROSEMARY 8. BASIL 9. CEROPEGIA WOODII 10. 10.9.8.7.6.5.4.3.2.1.PLANTSFERNINCOURTYARDSTRAWBERRIESBROCCOLIPUMPKINTOMATOESSQUASHCARROTSGARLICPEPPERSBLUEBERRIESBEANS 11SOUTH SITE ELEVATION
12
13 GROUND PLAN THIRD FLOOR PLAN SECOND FLOOR PLAN
14
UNFOLDED DIAGRAM SHOWING VIEWS AROUND THE COURTYARD 15
ISOMETRIC MODEL16
COURTYARDKITCHEN17
18
SECTION
AA 19
Situated on the coast of Puerto Ayora, a vibrant and research-oriented town in the Galápagos Islands, Go Go Galápagos aims to uncover the mysteries of sea, earth, and sky - much like evolutionist Charles Darwin. Go Go Galápagos places emphasis on environmental building design, incorporating sustainable HVAC and water systems into its envelope and structure. The building uses island vernacular and modern construction techniques to best fit Puerto Ayora’s hot equatorial climate. Three researchers, a marine biologist, a botanist, and a meteorologist converge in the centre’s main building to sleep, eat, and connect, then dispere into their respective research huts to conduct experiments in their field of study.
1B ENVIRONMENTAL DESIGN LOCATION: PUERTO AYORA, GALÁPAGOS PROJECT: OASIS02GOGALÁPAGOSGO 20
SOFTWARE: RHINO 7, ENSCAPE, ADOBE PS, AI, IN WINTER 2021COLLABORATOR: AVINA GONEN INSTRUCTOR: ANNA BEZNOGOVA 21
SITE PLAN PUERTO AYORA CHARLES RESEARCHDARWINCENTRE 22
WALL SECTION BAMBOO CLADDING | 100MM GYPSUM BOARD |13MM DENSELY PACKED CELLULOSE INSULATION | 200MM AIR/VAPOUR BARRIER WOVEN BAMBOO GRID SHEET | 20MM BAMBOO PURLIN | 100MM RADIANT BAMBOOBARRIERROOFCLADDING | 100MM RAIN RECLAIMEDDOUBLEGUTTERGLAZINGWOOD PANELLING | 50 MM GYPSUM BOARD | 19MM DENSELY PACKED CELLULOSE INSULATION | 150MM AIR/VAPOUR BARRIER WOVEN BAMBOO GRID SHEET | 20MM RECLAIMED WOOD SIDING | 50MM STEEL TREATEDFLOORTIMBERTIESLINKJOISTWOOD POST TIMBER RECLAIMEDUNDISTURBEDPACKEDCONRETECONCRETELINKPIERSTEELTIESFOOTINGSANDSOILWOODCLADDING | 35MM GYPSUM BOARD | 13MM DENSELY PACKED CELLULOSE INSULATION | 200MM AIR/ VAPOUR POLYISOCYANURATEBARRIERINSULATION | 35MM RECLAIMED PLYWOOD | 19MM GYPSUM CONCRETE | 19MM FLATTENED BAMBOO FLOORING | 20MM 23
GROUND PLAN 1 2 3 54 OUTDOORENTRANCELEGEND RAINWATER COLLECTION & WATER TREATMENT ROOM MARINE RESEARCH ROOM KITCHEN & DINING INDOOR WATER & ENERGY STORAGE GEOLOGY RESEARCH ROOM ASTROLOGYBATHROOMBEDROOM RESEARCH ROOM987654321 24
SECOND FLOOR PLAN THIRD FLOOR PLAN 6 7 8 7 7 9 25
SOUTH-WESTSECTIONELEVATIONAA26
SYSTEMS DIAGRAM 27
ESKYARTHSEA 28
EXTERIOR 29
30
31
Red Snake looks to emulate the linear eastern asian night market typology. The linear canopy is a l-shaped covering located in Shanghai Alley, a historical street in Chinatown, Vancouver B.C. Red Snake emulates the skeleton of a snake. It is in reference to the famous chinese folklore story of the White Snake, a symbol of good harvest, health, and its ability to bring together families and communities. The canopy’s symbolic form engages the surrounding Chinatown community through its cultural reference to the community’s historical Chinese diaspora and its market Theprogram.structure is supported in tension by eight curved towers which evokes the maw of a snake. The canopy consists of a curved i-beam central spine with steel plate ribs reaching down from its centre. The whole carapace is covered in a steel mesh and polyester sheet providing shading and protection from the outdoor environment.
LOCATION: VANCOUVER, COLUMBIA
1B BUILDING CONSTRUCTION COMPETITION: 20TH CISC ARCHITECTURAL STEEL COMPETITION03 BUILDINGSAM 32
BRITISH
RED SNAKE
SOFTWARE: RHINO 7, ENSCAPE, ADOBE PS, AI, IN SAM BUILDINGKEE WINTER 2021COLLABORATOR: ALEX BAE INSTRUCTORS: CAMERON PARKIN & JUSTIN BREG 33
34
NORTH-EAST ELEVATION 35
GROUND PLAN ROOF PLAN 5.4.3.2.1.LEGENDMARKETPLACESEATINGAREAFOODCOURTWASHROOMSBIKERACKS 3 2 52 4 1 1 36
STEEL TYPE, CONNECTION, AND FINISHES DIAGRAM STEEL COMPONENT DIAGRAM 37
38
LOCATION: KITCHENER, ONTARIO 04 2A DESIGN STUDIOPROJECT: ADAPTIVE REUSE FRAGMENTED
Preserving various historical fragments of the existing Police Station in Kitchener, Ontario, Fragmented is a community centre that promotes the arts, sustainability, and creativity through its program and connections. This consists of solid volumes made out of the existing limestone or brick and transparent pavilions constructed out of glass and steel mullions. Fragmented consists of seven separate volumes which are stand alone or connected as it guides its users through it’s openings and pathways. Through the combination of outdoor and indoor spaces, positive and negative spaces, this composition represents equality within the overall site.
SOFTWARE: RHINO 7, ENSCAPE, ADOBE PS, AI, IN WINTER 2021INDIVIDUAL INSTRUCTORS:PROJECT RICK HALDENBY 39
1. INCUBATION THEATRE 2. DRESSING ROOMS 3. MAIN THEATRE 4. OUTDOOR THEATRE 5. SAFE ROOM 6. LOBBY 7. GIFT SHOP 8. WASHROOMS 9. 10.CAFE/BARGENERAL STORAGE 11. SOUND PRODUCTION 12. GREEN ROOMS 13. COMMUNITY GARDEN 14. DARK ROOM 15. BLACK ROOM 16. PHOTOGRAPHY ROOM 17. REHERSAL ROOMS 18. OFFICE SPACE 19. STORAGE 20. PRINTING 21. LOADING / PARKING 22. SHARED WORKING SPACE 23. WORKSHOP 24. STUDIO 25. OUTDOOR 26. DINING 27. COMMUNITY 28. APARTMENTS 29. MULTIMEDIA 30. LIGHTINGB B AA2828282813 4 6 2423 25 2627 321 GROUND LEGEND 40
1313 AAAAB BBB OUTDOOR GALLERY / LIGHTINGMULTIMEDIAAPARTMENTSCOMMUNITYLOUNGEKITCHENANDSOUND 24 29 30 28282828 18 20 22 28282828 GROUND FLOOR PLAN SECOND FLOOR PLAN THIRD FLOOR PLAN 41
42 MAIN ENTRANCE & LOBBY
43PERSPECTIVE SECTION BB MAIN THEATRE & OUTDOOR DININGCOMMUNITY GARDEN
FUNGUSFOLLOWSFORM
Form Follows Fungus is a proposed high-rise which aims to address a number of Toronto’s housing needs, as well as explore ideas of ecology in the context of skyscraper design. The project employs a system of fungi-shaped planting terraces to filter the tower’s greywater and use it to humidify the “core” where mycelium, the precursor to fungi, can be cultivated quickly and harvested to support the building’s mechanical systems. Mycelium is used in both dried and living form as an insulation method. The tower is located at the major downtown intersection of Bloor St. and Spadina Ave., and a walk away from the University of Toronto campus, making it an ideal location for students and adults entering the workforce. Form Follows Fungus’ program is divided into four components: retail and office spaces, student living, single and double-rooms, and resident amenities.
44
LOCATION: TORONTO, ONTARIO
PERSONAL WORKCOMPETITION: SKYHIVE05
SUMMER 2022COLLABORATORS: SOEUN PARK, AVINA GONEN & MEGAN SOUSA INSTRUCTORS: FIONA LIM TUNG SOFTWARE: RHINO 7, ENSCAPE, ADOBE PS, AI, IN 45
46 MORPHOLOGYEXTERIOR
AXONOMETRIC & VIEWPOINTS 47SITE ANALYSIS
SYSTEMS48
10MM GYPSUM BOARD 50MM BATT INSULATION 90MM LIVING MYCELIUM INSULATION STEEL 50MM25MMTYVEK15MMSTUDSPLYWOODAIRSPACEMYCELIUM CLADDING 15MM CEMENT BOARD 150MMLINTEL REINFORCED CONCRETE 75MM CONCRETE 20MM MYCELIUM BRICK 60MM SOIL MIX PLANTINGGRAYWATERDRAINAGESPRINKLER 300MM CONCRETE SLAB 140MM BATT 19MM19MMINSULATIONPLYWOODFLOORING GRAYWATER PIPING TERRACE CONNECTION 49
1. Sterilized soil mix and saw dust innoculated into mushroom 2. daysconditionscontrolledincubatedmediumInnoculatedunderfor14 3. dead)forandcompositeMyceliumharvesteddried(harvestedliving,bothfor4a.panel4b.usecontrolledpackedcompositeMyceliumthenintohumiditypanelstoaslivinginsulationMediumpouredintounits 5. Panels demouldedare 6. Chitin fuses to form formaterialbuilding-readytough(readyuse) 50 MYCELIUM GROWTH DIAGRAMCORE
20MM MYCELIUM CLADDING 10MM GYPSUM BOARD 50MM BATT INSULATION 35MM MYCELIUM INSULATION 50MM BATT INSULATION STEEL 20MMSTUDSGYPSUM BOARD 12MM PLYWOOD 40MM CONCRETE CLADDING 300MM CONCRETE SLAB 140MM BATT INSULATIONWOOD PLANTER SOIL FUNGIMYCELIUMMIX 300MM CONCRETE SLAB 140MM BATT 19MM19MMINSULATIONPLYWOODFLOORING 51CORE WALL DETAIL
