WIDEWALL VISIONS

52”-54” Fabric-Backed Vinyl Contract Wallcovering

PHYSICAL PROPERTIES

Weight: 15oz. PLY Roll Size: 52-54” x 30yds Backing: Sheeting

Meets or exceeds Federal Specification CCC-W-408D physical characteristics for Type I Wallcovering

FIRE SAFETY

• Class 0/1 – BS476 PART 6/7

• Class “A” – ASTM E-84

Flame Spread 15; Smoke Developed 30

ENVIRONMENTAL AND HEALTH

WideWall Visions is an environmental – green product as it has eliminated all heavy metals such as lead, mercury, cadmium and chromium.

BATCHING

Since slight variations in color may occur between different production batches, it is important than in one single area, rolls from the same production batch are used

OTHER CHARACTERISTICS

• Contains antimicrobial additives to resist the growth of mildew and bacteria. Passed ASTM G21. These additives will not prevent mold growth if residual wall moisture is in excess of 4% and/or is allowed to accumulate in or behind the walls.

• WideWall Visions is supplied with a 5-year warranty against manufacturing defects.

ORIGIN

Made in Thailand, Designed in USA

CORD FABRIC

MESHWORK

CROSSHATCH LINEN

ROLL

ROLL

HIGH FASHION ESSEX

TUXEDO

WVA5201 WVA5202 WVA5203 WVA5204 WVA5205 WVA5206 WVA5207 WVA5208 WVA5209 WVA5210 WVA5211 WVA5212 WVA5213 WVA5214 WVA5215 WVA5216 WVA5217 WVA5218 WVA5219 WVA5220 WVA5221 WVA5222 WVA5223 WVA5224 WVA5225 WVA5226 WVA5227 WVA5228 WVA5229 WVA5230 WVA5231 WVA5232 WVA5233 WVA5234 WVA5235 WVA5236 WVA5237 WVA5238 WVA5239 WVA5240 WVA5241 WVA5242 WVA5243 WVA5244 WVA5245 WVA5246 WVA5247 WVA5248 WVA5249 WVA5250 WVA5251 WVA5252 WVA5253 WVA5254

RUSTIC HERRINGBONE

RUSTIC HERRINGBONE

RUSTIC HERRINGBONE

RUSTIC HERRINGBONE

CORD FABRIC

CORD FABRIC

CORD FABRIC

CORD FABRIC

CORD FABRIC

CORD FABRIC MESHWORK MESHWORK MESHWORK MESHWORK SUKI SUKI

CROSSHATCH LINEN

CROSSHATCH LINEN ESSEX ESSEX ESSEX ESSEX ESSEX HIGH FASHION HIGH FASHION

HIGH FASHION LEGEND LEGEND LEGEND HEMP HEMP HEMP HEMP

SPEC KLE LINEN

SPEC KLE LINEN

SPEC KLE LINEN

SPEC KLE LINEN

SPEC KLE LINEN

MARC H

MARC H

PAIN TED CANVAS

PAIN TED CANVAS

PAIN TED CANVAS

LYRICAL

LYRICAL

BEN WEAVE

BEN WEAVE

TUXEDO

TUXEDO TUXEDO

Ho ri zo nt al Vert ical 1 00 2 00 3 00 4 00 5 00 6 00 7 00 8 00 9 00 10 00 11 00 12 00 13 00 14 00 15 00 16 00 17 00 18 00 19 00 20 00 21 00 22 00 23 00 24 00 25 00 26 00 27 00 28 00 29 00 30 00 31 00 32 00 33 00 34 00 35 00 36 00 37 00 38 00 39 00 40 00 41 00 42 00 43 00 44 00 45 00 46 00 47 00 48 00 49 00 50 00 51 00 52 00 53 00 54

STUC CO STUC CO STUC CO STUC CO

15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15

Reverse Random Reverse Random Reverse Random Reverse Random Reverse Random Reverse Random Reverse Random Reverse Random Reverse Random Reverse Random Reverse Random Reverse Random Reverse Random Reverse Random Reverse Random Reverse Random Reverse Random Reverse Random Reverse Random Reverse Random Reverse Random Reverse Random Reverse Random Reverse Random Reverse Random Reverse Random St raight Random St raight Random St raight Random Reverse Random Reverse Random Reverse Random Reverse Random Reverse Random Reverse Random Reverse Random Reverse Random Reverse Random Reverse Random Reverse Random Reverse Random Reverse Random Reverse Random Reverse Random Reverse Random Reverse Random Reverse Random Reverse Random Reverse Random Reverse Random Reverse Random Reverse Random Reverse Random Reverse Random

Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng Sheeti ng

52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds 52" 54" x 30yds

Back ingRoll Si ze Page Patt ern No Desi gn / Patt ern Name Weight (o z/yd)

Pattern Repeat (In) Patt ern Match

BEFORE YOU BEGIN

Examine the material carefully to ensure that the patter n, colour, and quality are satisfactory and as ordered. Check that the quantity and dimensions match the required specifications, prior to cutting. In the event that any discrepancies are found, STOP and contact Goodrich Global before proceeding. We recommend that the wall moisture content does not exceed 4% using a reputable moisture meter, and that active moisture infiltration, condensation, and/or accumulation - particularly in warm, humid climates - is not present. If walls show mould, mildew or visible moisture damage, or if moisture content exceeds recommendations, do not proceed with installation until the condition has been fully corrected under the direction of a qualified professional. Goodrich Global will not be responsible for any performance or quality issues if moisture problems are not addressed before or following installation.

HANGING GUIDELINES

Wa llcovering ro lls are numbered c onsecutively and should be cut and i nstalled in re vers e sequence, s tarting with the highest numbered roll. A ll strips should be hung in s equence as they are c ut from the roll, using full widths of material, whenever possible. Install th e wallcovering under permanent lighting conditions to evaluate colour and texture uniformity

When hanging non- re versible or matching patter ns, m easure the wall height, allowing fo r patter n match, add 4", and table trim using a straight edge to ensure alignment across seams. Large, dominant pattern repeats require more careful planning as far as starting point, ceiling line, chair rails, door/window headers, etc. Patter ns are meant to match at eye level and may run off slightly at the top and bottom of the wall. When hanging textured or random-match patter ns, reverse hang alter nate strips for a more uniform appearance; overlap and double cut, being careful not to score the wall. If the pattern effect is not acceptable after three strips are hung, re-hang strip #2 without reversing.

If any defect, colour variation, or unacceptable pattern effect is noticeable after three panels are cut and hung, STOP and contact Goodrich Global immediately Goodrich Global cannot accept any claims on labour or material after more than three lengths have been installed.

ADHESIVE APPLICATION

Apply a uniform coat of a premixed vinyl wallcovering adhesive to the back of the material using a s hort-napped paint roller or s tiff bristle brush (a pasting machine can be used at the installer's discretion). Goodrich WA202 adhesive is recommended for heavyweight vinyl wallcovering. Fold each sheet over and allow up to 10 minutes booking time for the adhesive to penetrate the backing of the lightweight vinyl material (up to 15 minutes for heavyweight vinyl), and to avoid paste drying at the edges.

I NSTALLATION

Hang the first strip to a plumb line, overlapping the c eiling and baseboard, within 12 minutes of paste a pplication. Use a stiff bristle brush to ensu re tha t the wallcovering m akes contact with the wall. A plastic s moother can also be used on non-metallic Vinyls, providing only light pressure is applied (d o not use sharp-edged tools). Smooth from the middle to the o utside edges, b eing ca re ful not to str etch the material, and work out all a ir bubbles. Tr im at the ceiling and baseboard with a sharp razor blade. For matched patte rn s, butt the s econd strip to th e edge of the first and smooth out firmly When double cutting non-matching patter ns, place a 2-3" wide strip b ehind the s eam to avoid scoring the w all. Flatten seams exerting light pressure with a seam roller Lowadhesive painter's tape can be used to keep the face of the seams clean. Before applying the next strip, trim the top and bottom as with the first panel, an d proceed in the same manner around the room.

Avoid cutting narrow widths of material for placement above doors and below windows. Vertical joints should not occur less than six inches from inside or outside cor ners. When t rimming at chair rails and c eilings, always use a broad knife rather than a straight edge. Take extra care in keeping the adhesive off the face of the wallcovering.

Remove excess adhesive immediately with a natural sponge, frequently rinsed in clear, warm water, and dry with a soft, lint free cloth. After installation, the walls and wallcovering should be monitored for potential moisture or vapour infiltration, which must be promptly eliminated.

MAINTENANCE

Most wallcovering is easily cleaned using clear, warm water and mild soap with a natural sponge. A soft cloth or towel should only be used to tamp dry (do not rub). Stubbor n stains can be removed with a laundry spot remover or rubbing alcohol. Do not use solvent-based cleaning agents, lacquer thinners, nail polish remover, pine oil, or cleaning agents containing bleach, which may cause discoloration over time.

Note: The a bove is intended only as a guideline . Wallcovering installations must conform to current hanging instructions included with each shipment. T he i nstaller has final re sponsibility for pr oper installation and evaluation of jobsite conditions.
