Tigercat 880E Logger

The 880 series logger is a multi-purpose forestry carrier that can be configured for loading, shovel logging, or processing applications. It introduces several features including an updated operator’s station and various grapple configurations to tailor the machine to your specific needs.

The 880E is powered by the Tigercat FPT N67 engine, producing 308 HP. The F7-163 undercarriage is designed and built to withstand rigorous, full-time forest duty with exceptional stability for heavy timber applications.

The spacious cabin has a new heated operator’s seat. Controls are integrated into both sides of the joystick pods, eliminating the need for any bolt-on control pods. The optimally positioned controls and large machine control system touchscreen interface improve ergonomics and machine monitoring. The quiet interior helps the operator enjoy the auxiliary audio input port, Bluetooth audio and hands-free calling.

Additional new features include a standard equipped rearVIEW camera system, emergency stop button, and a key fob to turn on exterior lights remotely when entering the cab in the dark.

The 880E can be configured as a loader equipped with various power clam, butt-n-top and log grapple options. Equipped with a live heel boom system, the 880E is a highly capable shovel logger with excellent stability, tractive effort and swing torque. The carrier can also be configured as a high-capacity processor capable of running large harvesting heads in demanding duty cycles.

Some of the many advantages of the 880E over excavator conversions include better service access, higher cooling capacity, a better operating environment with superior sightlines, more robust undercarriage components and extremely efficient hydraulic circuits. The result is higher production, uptime and fuel efficiency. Visit tigercat.com.

John Deere Harvester Heads

John Deere offers the new, small-size H423 harvester head and the largesize H425 and H425HD. These new attachments replace the previous H413, H415 and H415HD models. Like its predecessor, these heads have 4WD feed.

The H423 harvester head works on the 1070G, 1170G and 1270G base machines and is ideal for thinnings and other fellings, where the tree diameter at chest height (BHD) is 150-350 mm.

With improved hose routing from boom to harvester head, and from valve block to feed motors, this attachment offers improved durability, easy hose replacement and improved hose protection with modifications to the frame. It has an operating range of minimum diameter at chest height (BHD) 40 mm to a maximum 500 mm.

The H425 harvester head for the larger size class is available on the 1270G and 1470G base machines. This attachment is ideal for final fellings and other fellings where the tree diameter at chest height (BHD) is 250-500 mm. Also including improved hose routing from loader to harvester head and from valve block to feed motors, the hoses are routed through the frame and well protected within the structures, improving durability.

Additionally, the H425HD harvester head added to the H425 model offers an HD tilt frame, expander pins in the upper end of the tilt cylinder, feed motor arms, and lower delimbing knives. A wide selection of saw motors and saw bars are also available for the H425 and H425HD harvester heads. Visit johndeere.com.
