EXTERIORS

EDITORS’ CHOICE

LED round high bay for high ceilings

LED PL fi xture:

High-ceiling applications Three models to 240 W IP69K, IK10 rated

LED round high bay PL fi xture for abroad range of high-ceiling application has a polycarbonate prismatic lens said to distribute even illumination while minimizing glare.  e luminaire reportedly enhances visual acuity in applications including warehouse and storage settings in industrial and manufacturing facilities, sports facilities/gyms, and retail centers.

Using a die-cast aluminum heat sink that optimizes air fl ow for improved effi ciency and available in 115-, 175, and 240-W models, output ranges from 16,100 to 33,600 lumens.  e luminaire is IP69K-rated to resist the ingress of dust, high-temperature steam, or high-pressure water, IK10-rated to withstand external mechanical impacts, and operable in extreme temperatures from -10 F to 115 F.

Litetronics, Bedford Park, IL Circle 50 litetronics.com

Wall mounts with rotatable LEDs The Linear EXT LED line includes three wall-mounted models. With six distribution patterns, the LXT wall mounts use the company’s PLED optical modules that are fi eld replaceable and rotatable. The luminaires are available in three sizes from 20 to 60 LEDs with 4,000 K CCT.

U.S. Architectural Lighting, Palmdale, CA Circle 51 usaltg.com

Linear LED fi xtures L-Line LED linear fi xtures in 2-, 4-, and 8-ft. lengths have surface- or pendant-mount options. A sleek aluminum housing provides a modern appearance. A diffused polycarbonate lens creates symmetrical light distribution. Fixtures provide 1,050 lumens/ft. and are available in a range of color temperatures. Lengths can be joined with connectors.

Nora Lighting, Commerce, CA Circle 52 noralighting.com

Work-area airfl ow

Pivot 2.0 fan has a direct-drive motor and steel cage. With a 6-ft. dia., the fan provides cooling air to 120 ft. Installation 6-ft. dia., the fan provides cooling air to 120 ft. Installation includes ceiling, beam, and column mounting options. Variable-speed control and 73 airfl ow positions direct air where it’s needed. The fan is Intertek/ETL-certifi ed to UL 507 and CSA C22.2 No. 113.

Big Ass Fans, Lexington, KY Circle 53 bigassfans.com

Compact LED emergency light The Dual-Lite EV4D-02WAL compact LED emergency light is suitable for indoor and damp locations. The wide-area lens provides 50-ft. multiple spacing in long hallway applications such as conference centers, hotels, and oversized open spaces when mounted at 7 1/2 ft. to ensure a superior path of egress.

Hubbell Lighting Inc., Greenville, SC Circle 54 hubbelllighting.com

Cylinder luminaires Scout cylindrical luminaires have a simple, clean aesthetic with no visible seams or hardware. Available in three lengths (6 1/4, 10 1/2, and 18 in.), and two diameters (2 3/4 and 4 1/2 in.), standard colors include pale green, gray, navy blue, black, and white. Products can be wall mounted, suspended with a wider beam for general illumination, or with a narrow beam to provide focus, and ceiling surface mounted.

Eureka Lighting, Montreal Circle 55 eurekalighting.com

Night light Crescent LED night light illuminates dark rooms at a comfortable level. The luminaire can be controlled by a switch or activated automatically by sensor in low-light conditions, bringing an even, low-level light distribution to any room or hallway. Available in 2700 K, 3000 K, and 3500 K, and amber and blue colors, the device has a low-profi le faceplate.

Waldmann Lighting, Wheeling, IL Circle 56 waldmannlighting.com

GOOD BETTER BEST

EXACTLY.

Edge-lit troffer Vora 50L architectural recessed troffer uses edge-lit technology. Through laser-etched, acrylic light guides, illumination is provided in a uniform manner across the entire surface of the fi xture. With effi cacies to 120 lumens/W and outputs to 8,000 lumens, a center mixing chamber uses the excess light exiting the opposite end of the light guides and recycles that light uniformly within the center chamber.

Litecontrol, Greenville, SC Circle 57 litecontrol.com

Energy-code update tool The Wattstopper LMCS software Sequence of Operation design tool for confi guring its Digital Lighting Management (DLM) system, provides commissioning documentation including LEED projects. The tool, as part of a cloud-enabled lighting-controls platform, is said to add convenience and simplify code compliance by pre-populating documents such as room diagrams and bill of materials (BOM), and generating sequences of operation based on the specifi c energy code chosen. New templates are automatically updated from the Wattstopper online library of code templates as new code changes are introduced.

Legrand, West Hartford, CT Circle 58 legrand.us

Finding The Ideal Vegetative Roof Here are factors to consider when specifying planted-roof systems.

The functional design of a rooftop makes a difference not only in the sort of materials used to construct the space, but in the types of plants installed. For example, will a patio, garden, or other usable space be incorporated? V egetative roofs are not a new concept, but it is new to many architects and designers who are approaching their first planted-roofing project. These green roofs are progressively catching on with building owners, as they offer a variety of benefits. Here are several reasons to pursue a vegetative roof.

MANDATED/EXTERNAL REASONS Various cities, such as Toronto and San Francisco, require or heavily incentivize vegetative roofs to deal with larger problems affecting the area, such as excessive stormwater runoff or urban heat-island effects. • Stormwater runoff is a major issue in municipalities where aging sewer systems can be overwhelmed and chemicals/waste can end up in waterways. Some sewer districts tax stormwater runoff as a result, and cities sometimes require new buildings to have water-retaining roofs to mitigate the problem. Vegetative roofing not only slows the rate of runoff during storms but can remove as much as 95% of heavy metals in rainwater. • Urban heat islands, where cities become especially hot when sunlight is absorbed into hard, dark surfaces, are another long-standing problem. Planted roofs alleviate this by absorbing sunlight instead of reflecting is as happens with nonporous surfaces. Vegetative roofs typically emit a temperature of only 95 F on a 90 F day. A traditional roof might exceed 160 F. • Green roofs can also help combat CO 2 and smog levels, actively converting CO 2 to O 2 to improve air quality.

BUILDING-SPECIFIC REASONS In other cases, a building owner might choose a green roof because of the benefits such a system grants to the owner. • A vegetative roof can help save energy by absorbing sunlight that

Work with a landscape architect to determine which plants are best based on the desired use, the climate, and how much time and resources can be dedicated to upkeep.

would otherwise raise the temperature in the building and tax the HVAC system, which is part of why its inclusion in a design can contribute points toward LEED credentials. • If a building has solar panels on the roof, green roofing can help the panels perform more efficiently. • Vegetative rooftops also protect the roofing membrane from UV radiation, heat aging, extreme temperature fluctuation, and physical damage. • Planted roofs simply look good, making them attractive in situations where the rooftop is visible to occupants or is an occupied space featuring useful overburden, such as pavers, flanked by plant life.

ASK CORRECT QUESTIONS There are a number of factors to consider when determining the proper design and construction of a planted roof. The following questions offer information to aid in the selection of a vegetative-roofing solution for a variety of needs.

What is the intended use of a vegetative rooftop?

Is the rooftop going to be a generally unoccupied space, chiefly designed to absorb rain and solar rays, or will it have visitors? Will a patio, garden, or other usable space be incorporated?

The functional design of the rooftop makes a difference in the materials used to construct the space and in the types of plants installed.

Work with a landscape architect to determine which plants are best, based on the desired use, climate, and how much time and resources can be dedicated to upkeep. Then, select the correct type of planted-roofing system to meet the requirements of those plants and the needs of the mixed-use design.

What value is to be received from the planted roof?

If you simply want the rooftop to look attractive, that is one thing. But if you want to derive more utility from the roof design (for instance, carbon dioxide/ greenhouse-gas management or stormwater management), that can affect vegetation choice and construction decisions.

Using a green roof for stormwater management is partially influenced not only by the ability of plants to soak up water through their roots, but also by structural factors below the soil layer of a planted rooftop.

Is storage space needed that allows water to collect below the soil level, minimizing the amount flowing off the roof during heavy rains? The construction of the drainage layer and choice of moisture-retention mats will depend on the answer to this question.

Based on the performance expected from the roof, is a traditional vegetative-roof construction or a traybased system needed?

Traditional vegetative roofs have various layers installed as part of their design, and the composition of those layers depends on the performance one is seeking, the weight-carrying capability of the roof, and other factors. Traditional vegetative-roofing constructions typically include: • Growing medium with custom soil depth on top with plants embedded

Top. Traditional vegetative roofs have various layers installed as part of their design, and the composition of those layers depends on the performance sought, the weight-carrying capability of the roof, and other factors.

Above. Planted roofs help save energy by absorbing sunlight that would otherwise raise the temperature within buildings and tax the HVAC system, which is part of why their inclusion in a design can contribute points toward LEED credentials.

• A drainage layer with water-retention mats underneath to let plants absorb the needed amount of water • An insulation layer under the drainage layer to insulate the building against the elements • A root barrier designed to prevent penetration of roots into the waterproofing membrane • A waterproofing-membrane system to protect the building.

Tray systems can be used for smaller, multifunction spaces where water retention is less of a priority and vegetation is installed around patios, pavers, or designated garden areas. These reportedly easy-toinstall systems, such as the Sopranature modular tray system from Soprema Inc., Wadsworth, OH, are all-in-one systems that include a drainage layer, filter fabric, and pre-installed vegetation. They offer

How extensive/intensive a green- roof system is planned?

If a tray-based system is chosen, there are fewer decisions to make. A contractor simply installs what was purchased. If the roof is a traditional approach with a built-in-place system, the consideration process is more complex. What type of system will be created? • An extensive system is designed for projects requiring lightweight vegetative roofing. This typically includes sedum, herbs, or other low-maintenance plants that may not require an irrigation system and are installed more for utility than aesthetics. • A semi-intensive system allows more plant diversity, including small shrubs, grasses, and flowers. This design means more maintenance and irrigation is needed than an extensive system but provides better stormwater retention. • An intensive system requires the most maintenance and irrigation, but allows the creation of on-structure landscapes with deep soil profiles that can sustain large shrubs and small trees. These systems are often used to facilitate rooftop vegetable gardens or park-like spaces for multifamily residential buildings. This sort of system can retain the largest quantity of stormwater.

What is the real cost of the project?

Material choice is one factor infl uencing vegetative-roofi ng costs, based on the intensity of the project and which material options are chosen for each layer. Maintenance is another consideration, as certain plants require more care than others, especially when diverse, intensive plantscapes are designed.

Also consider what government incentives and tax abatements may be available. These can vary from city to city and state to state, and there could also be federal incentives for implementing green-roofing options. One can begin by reviewing some of the current offers listed at the following link to get an idea of how net costs of implementing a planted rooftop may be lower than anticipated. (http:// blog.soprema.us/vegetated-roofing-tax-incentives)

DON’T FEAR COMPLEXITY Vegetative roofi ng is, by nature, a complex topic, and there are many resources available to ensure the correct decision is made. Begin by considering the questions presented above, and then reach out to professionals who can help with the details. From roofi ng-material suppliers to landscape architects to contractors who have carried out planted-roofi ng projects, know that the expertise is available for a successfully completed project. CA

Want more information from Soprema Inc. (soprema.us)? Circle 6 on the Reader Service Card.

Sources listed below are linked at commercialarchitecturemagazine.com/1904soprema.

• Government incentives,

blog.soprema.us/vegetated-roofi ng-tax-incentives
