T A B L E O F C O N T E N T S Final Project in Architecture Bachelor (S1) HEALING SPACE DESIGN WITH HAPPINESS ARCHITECTURE APPROACH | 3 Personal description in living life in the discipline of architecture CURRICULUM VITAE | 1 Islamic International Boarding School Al Maahira Malang City AL MAAHIRA MOSQUE | 5 The Architecture respons for children after natural disaster HONEYCOMB HEALING CENTER | 7 Housing project for respons the problem of pandemic session (covid-19) INCLUSIVE | 9 To be Contemporer from the Pancasila Mosque in Kalimantan SULTAANUL BALAADUDDIN MOSQUE | 11 Medieval Style for targetting the people to buy some food and beverage ONE FIVE SHOPPING LANE | 13 The breaker central business between traditional and modern market PASAR MALL PADANG | 15 The transition culture for arriver from the village UKHUWAH RESIDENCE | 17 Together with family for long time and timeless SPROUT HOUSE | 19 The stage of product appearance in the face of store BERKAH ABADI STATIONERY STORE | 21 The compilation of interior design INTERIOR DESIGN PORTFOLIO | 23 The compilation of Detailed Engineering Drawing (DED) DETAILED ENGINEERING DRAWING PORTFOLIO | 25

MUAMMAL ILMI

A man born in Nganjuk who has many plans in the architecture. Always try to provide something useful for society. A person who has discipline and spirit in every challenge he faced, especially in social problems. He believe that architecture can make a lot of revolutions for human beings, happiness, poverty, commerce, religion, relationship, etc.

WORKING EXPERIENCES

TK Ar Rahman Nganjuk

SDIT Baitul ‘Izzah Nganjuk

MAN 3 Kediri

Bachelor Architecture UIN Malang Architecture Profession ITS

RELIGIOUS EDUCATION

Ponpes Al Fattah Pule Nganjuk

Madin Al Huda Nganjuk

Ponpes As Sa’adah Kediri

Madin As Sa’idiyah

Ma’had Sunan Ampel Al ‘Aly

Madin Anwarul Huda Malang

Top 6 - International Archstud Competition Archfest UK Petra Top 10 - National Archstud Design Competition UHO Top 20 - National Archstud Student Competition ARRIVAL AWARDS

2019 - PT. Wijaya Karya (Project Contract)

3D Artist - Tamansari Emerald Apartment Surabaya City

2020 - PT. Griya Facade (Project Contract)

Interior Designer - Interior Ballroom Filkom Brawijaya University Malang

2021 - Imajiner Architect (Internship Program and Assistant Architect)

Internship Program - Al Izzah Dome, Pasar Mall Padang, Ukhuwah Residence, etc.

Assistant Architect - Al Maahira Mosque Malang, Sultanul Baladuddin Kalimantan, etc.

2021 - Geriya (Volunteering Program)

Architect - Mushola Al Ikhlas, Mushola Sidoarjo, Mushola An Nur Nganjuk, MI Al Huda Nganjuk

Architect and Co-Construction - SLB Tamima Mumtaz Playground Batu Malang

2021 - Lincak Interior (Interior Designer)

Project Manager - Commercial and Housing Interior

2022 - PT. CatraSena Engineering (Project Contract)

Architect - Islamic Materny Hospital Nirmala Kediri

Interior Designer - Bhayangkara Hospital Kediri

2022 - Studio OffCampuss (Architecture Profession Program)

Mr. Yuli Kalson S. (Mentor) - Nina House

PT. Archimetric (Architecture Consultant) - One Five Shopping Lane Kenjeran, Samarinda Central Plaza,etc.

ORGANIZATIONS

2017 - Remaja Masjid - As Sa’adah Kediri

2018 - Founder - 3D CAD Forum Malang City

2018 - Member - Ikatan Mahasiswa Kota Angin (IMAKA)

2019 - Creative Dept. - Indonesian Future Leaders Malang

2019 - Remaja Masjid - Al Kautsar Mosque Sukun Malang

2022 - Ikatan Arsitek Indonesia (IAI)

2022 - Asaatidz Madin Al Huda Nganjuk

C U R R I C U L U M V I T A E

Bachelor Architect - Ar. Muammal Ilmi, S.Ars

SketchUp - 90% Autocad - 90% Revit - 50% Enscape - 85% Lumion - 80% Adobe Graphics - 70% Adobe Videos - 60% Rhinoceros - 50% SOFTWARE SKILLS FORMAL

NGANJUK,

| +62 81 230 865 046 | INSTA : @ILMIMUAMMAL

EDUCATION

DECEMBER 27TH 1998 | ILMIMUAMMAL@GMAIL.COM

1 | Architectural Design Portfolio - Muammal Ilmi

ARCHITECTURE COMPETITION EXPERIENCES

2020 ACSENT Universitas Udayana Bali

2020 ADW Universitas Kristen Duta Wacana

2019 | 2020 ARCHFEST Universitas Kristen Petra Surabaya

2019 ARRIVAL Universitas Islam Negeri Maulana Malik Ibrahim Malang

2018 IDC Interior Decoruma Competition

2019 INDECOR Himpunan Desainer Interior Indonesia (HDII) Jatim

2016 ID Mitra 10 Jawa Timur

2018 RENDERING CONTEST SketchUnesia

2018 SDC Millenials Berkarya

2021 PORTAL Himayana

2019 SDCC Universitas Indraprasta PGRI

2019 | 2020 TEXTURE Universitas Teknologi Yogyakarta

2018 TCH Mitra 10

2021 CORDOVA Universitas Diponegoro Semarang

2021 GBP Universitas Halu Oleo

2019 WEX Universitas Gadjah Mada Yogyakarta

2022 M. SIDOARJO Pemerintah Kota Sidoarjo

H i d u p y a n g t i d a k d i p e r t a r u h k a n t i d a k a k a n p e r n a h d i m e n a n g k a n Architectural Design Portfolio - Muammal Ilmi | 2

The psychological health of students in Malang is a concern that needs to be solved. The demands of learning to prepare young people in the future become a frightening specter so that a place is needed to provide a sense of pleasure, comfort, and freedom from the bonds of the demands of the times. The happy room as well as the healing room takes on the role of a psychic doctor for today's young people.

HEALING

SPACE DESIGN WITH HAPPINESS ARCHITECTURE APPROACH

3.5 years of completed undergraduate studies

3 | Architectural Design Portfolio - Muammal Ilmi

A N A L Y Z E T H E S P A C E S FINAL PROJECT (BACHELOR DEGREE)

https://www.youtube.com/watch?v=RGvpls3TYYw

Architectural Design Portfolio - Muammal Ilmi | 4

VIDEO ANIMASI

AL MAAHIRA MOSQUE

MALANG CITY EAST JAVA - AL MAAHIRA INTERNATIONAL ISLAMIC BOARDING SCHOOL

5 | Architectural Design Portfolio - Muammal Ilmi

Greatness accompanied by simplicity, displays a simple shape but looks magnificent with a roof that covers like an umbrella for students studying at Al Maahira boarding school. Design development starts from the shape based on the basic formation of Noah's Ark and is covered with Islamic patterns and massive calligraphy as a symbol of the great degree for a student in studying. On the roof, there is a curvilinear area that resembles a wide umbrella like a lousy wing that is ready to take students off to get closer to the creator of Allah SWT. A screen that stretches wide from the corner to the corner of the building, giving the impression of the majesty of God from the interior of the mosque.

https://www.youtube.com/watch?v=6Yzav7R-e-g&list=PL-YAynARxml1FeFbEziI9My48fVgOEIm_&index=7

B A H T E R A B E R P A Y U N G I L M U FIRST SECOND THIRD FORTH

VIDEO ANIMASI

Architectural Design Portfolio - Muammal Ilmi | 6

M O D U L A R I T Y A R C H I T E C T U R A L S Y S T E M 7 | Architectural Design Portfolio -

Ilmi

Muammal

HONEYCOMB HEALING CENTER

Disaster have mentality impact for people who feels the disaster circumstances. Especially for children and their trauma need to be overcome together with us, then the trauma healing center occurs to answer the problem of children trauma. Sangkareang park is located on of the city in Mataran Nusa Tenggara Barat. The location is placed next to the Nusa Tenggara Barat Provincial BAPPEDA Office making it easy to access the place and because it is one of the locations used to evacuate victims of the earthquake disaster (Lombok:2018). Hexagon module plan that has 6 sides as a connector between modules. Which has the strongest form stability. The connection could be constructed by horizontal, vertical, even split level.

HEXAGONAL MODULARITY SYSTEM

Architectural Design Portfolio - Muammal Ilmi | 8

Giving hug by sweety spaces

INCLUSIVE

Kampung Inggris Pare Kediri East Java

HEALTH DIMENSION

The COVID-19 pandemic is an epidemic that has become a massive fear for the entire community. Cultural changes occurred on a large scale for all sectors of the field, especially in a geographically high population density environment. The characteristics of residential objects needed from an English language course institution in the English village area are to provide a sense of security from the transmission of COVID-19. The basic philosophy of the health dimension according to Ibn Sina (a philosopher of medicine) consists of 3 main points, namely (1) panic is half the disease, (2) tranquility is half the medicine, (3) patience is the beginning of healing.

VEGETATION COVER VEGETATION COVER

T O G E T H E R L I V I N G

GRASSBLOCK PORSELEN TEMBAGA VINYL KAYU ALDERON SIRIH

TOILET DINING ROOM LIVINGROOM INCLUSIVE CLASS MUDROOM DROP IN AREA AKSES PUBLIC ACTIVITY REDZONE SAFETY ZONE PORTAL SANITIZING LIVING ZONE

SIRIH

BEDROOM

9 | Architectural Design Portfolio - Muammal Ilmi

TANGGA MUDROOM PARKING AREA LIVING ROOM DINING TABLE TOILET KITCHEN BEDROOM DESK SANITIZER PORTAL 10.00 5.00 3.08 3.08 3.85 1.00 3.00 1.00 3.08 3.01 3.91 10.00 5.00 3.15 6.85 10.00 5.00 DENAH LANTAI 1 DENAH LANTAI 2 DENAH LANTAI 3 A B 5.00 10.34 10.00 10.34 3 POTONGAN A POTONGAN B 3 TAMPAK DEPAN TAMPAK SAMPING MUDROOM LIVING R KITCHEN KITCHEN STUDYING STUDYING LT. 1 BEDROOM BEDROOM DROP IN LT. 2 LT. 3 LT. 1 LT. 2 LT. 3 Architectural Design Portfolio - Muammal Ilmi | 9

SULTAANUL BALAADUDDIN MOSQUE

ReFacade Pancasila Mosque Kalimantan

The Pancasila Mosque is a mosque founded by President Soeharto as a sign of the rise of Muslims in Indonesia. The concept of the garden of paradise that is carried out in this design is a symbol that Muslims in Indonesia continue to grow by presenting the essence of heaven in yaumul aakhir in the landscape of the mosque. The space element created is the result of the nuances of heaven which is the most beautiful place as a gift for people who are obedient to worship Allah SWT.

S P A C E S D I A G R A M

11 | Architectural Design Portfolio - Muammal Ilmi

Architectural Design Portfolio - Muammal Ilmi | 12

The selection of medieval style is based on providing a different atmosphere around the surroundings. In an effort to bring out the uniqueness of one area, this European-born style was taken with a modern contemporary touch in the form of brick elements with formable angles. Apart from the brick material used, there are several modern materials used in this design, namely engineering wood and cast in situ landscape pavement with a cubistic pattern and very eye-catching for visitors who come and enjoy the atmosphere in the interior landscape environment.

M E D I E V A L C O N T E M P O R E R Y

13 | Architectural Design Portfolio - Muammal Ilmi

ONE FIVE SHOPPING LANE

The need for food and beverage trading business activities occurs in each region. This has become a similar need in the scope of the grand kenjeran housing area located in Surabaya. In presenting the attraction of visitors to buy products that will be consumed, the strategy taken in this case provides its own visual nuance in the form of incorporating the experience of space that exists in the European environment, more precisely the nuances of the medieval style.

F O O D A N D B E V E R A G E

Architectural Design Portfolio - Muammal Ilmi | 14

Kenjeran Surabaya City East Java

15 | Architectural Design Portfolio - Muammal Ilmi

PASAR MALL PADANG

Project Location - Padang - West Sumatra

The project is intended to provide a forum for traders to make buying and selling transactions in a place in the form of a market. In this case, the people's traditional market is sought to blend in with the modern market mode in the form of a mall. So the design strategy that unifies each group is to unite the nuances of space as well as semi-traditional spaces in the form of natural materials. The hope of this building is to increase business value in the market which is needed to adapt to the times

The first floor is used as a traditional market. Then it is connected to an escalator that can be accessed by users to go up to the 2nd floor. On the 2nd floor to the 4th floor, the function of the mall space is accommodated for visitors. The unification of traditional and modern nuances is bridged by the cursive shape of the facade which is combed by vertical wooden planks with hanging vines.

the target market is aimed at the middle to upper class

T A B L E O F C O N T E N T S

ANIMASI VIDEO Architectural Design Portfolio - Muammal Ilmi | 16

https://youtu.be/soxAcghOkL0

UKHUWAH RESIDENCE

ISLAMIC TRADITIONAL CULTURES

In creating a residential environment for residents in suburban areas, it is more appropriate to present a residential atmosphere that is very friendly with surrounding neighbors. This effort is due to the fact that housing located on the outskirts of the city is predominantly inhabited by people who are overseas or trying to improve the fate of their home village environment. The data notes that East Java is a province that is very thick with Islamic culture in rural areas, it can be seen that there are lots of activities for praying together, eating together, praying, etc. Therefore, houses that are designed as much as possible can provide a cultural platform as an adaptor for immigrants from their hometown habits to an environment that is tougher for work competition in urban industries.

Batu Malang East Java

17 | Architectural Design Portfolio - Muammal Ilmi

https://youtu.be/FFGltQ3HjMg

BLOCK A BLOCK B Architectural Design Portfolio - Muammal Ilmi | 18

ANIMASI VIDEO

19 | Architectural Design Portfolio - Muammal Ilmi

SPROUT HOUSE

Water Kediri East Java - Housing Project

ALWAYS TOGETHER WITH US

A house that is built from a sense of togetherness among residents. Home is a means to live life together, happy, sad, laughing, or something else, all felt together. In this regard, the basis that is grown is that there is no time constraint that becomes an obstacle to mutual cooperation. The spaces created as much as possible become the legendary value of the descendants from the time the house was built, until later.
