InstMC Ex-SIG Briefi ng Note

Intrinsically Safe Junction Boxes

Harvey T. Dearden – HTS Engineering Group

The notion that a junction box containing more than one intrinsically safe circuit must be certifi ed may be gaining currency and may be being actively taught on some courses.

There is however no such requirement within the IEC 60079 standard.

The EEMUA publication 214 ‘A Toolbox Guide for potentially explosive atmospheres’, Edition 7, published in 2016 says (4.4.3.v) of ‘terminal boxes’: Where the terminal box contains more than one intrinsically safe circuit, the enclosure shall meet the requirements of IEC 60079-0. This effectively means that, under these circumstances, the enclosure should be certifi ed.

Part 0 (General Requirements) does not specify particular requirements in relation to enclosures with more than one intrinsically safe circuit.

‘Effectively means’ is a judgement of the author(s).

Part 25 (Intrinsically safe electrical systems) and Part 11 (Equipment protection by intrinsic safety “i”) do not stipulate any explicit requirement for certifi cation of intrinsically safe junction boxes containing more than one circuit.

Part 11 6.1 says that where a non-portable enclosure meets the ingress protection and separation requirements that ‘The enclosure does not need to be subjected to the tests for enclosures in IEC 60079-0’. (E.g. impact resistance).

Part 14 16.5.3 ‘Terminal boxes with more than one intrinsically safe circuit’ says: Except where an assessment of the combination proves that the intrinsic safety of a combination of intrinsically safe circuits is not impaired, in order to maintain the requirements for intrinsic safety, terminal boxes shall comply with the following minimum requirements: – In addition to the enclosure requirements of 16.5.1 the enclosure shall meet the requirements as given in IEC 60079-0 for non-metallic enclosures and non-metallic parts of enclosures, metallic enclosures and metallic parts of enclosures as appropriate.

This section of the standard says in a note ‘The use of an increased safety enclosure with suitably rated increased safety terminals will satisfy the requirements of 16.5.2 (single i.s. circuit) and 16.5.3.(multiple i.s. circuits as above).

It does not explicitly require certifi cation but points to Ex ‘e’ as one means of meeting the requirements.

Part 25 Annex B (Assessment of circuits with more than one source of power) says: ‘Where there is more than one source of power and the interconnections are made under controlled conditions so as to provide adequate segregation and mechanical stability in accordance with IEC 60079-11, then the interconnections are considered to fail to open and short circuit but not so as to reverse the connections or to change a series into a parallel connection or a parallel connection into a series one. Interconnections made within a rack or panel constructed in a location with adequate quality control and test facilities are an example of the degree of integrity required.’

So, since an exception per Part 14 16.5.3 may be made when ‘assessment of the combination proves that the intrinsic safety of a combination of intrinsically safe circuits is not impaired’ a terminal box providing ‘adequate segregation and mechanical stability in accordance with IEC 60079-11’ does not require consideration of series/ parallel/reverse connections and intrinsic safety would not be considered impaired by the combination.

There is no mandatory requirement for certifi cation of ‘simple apparatus‘ junction boxes that contain multiple intrinsically safe circuits that are of appropriate good practice design. Such a requirement could, particularly if applied retrospectively, have profound implications for existing installations, with potentially very extensive disruption and expense with little or no benefi t and the introduction of risk arising from disturbance to established installations.

Note also that Part 17 (Inspection) explicitly says in the introduction: Inspections are carried out in accordance with this standard, however for older installations the details for the equipment and installations requirements should be referenced to the standards applied at the date of the installation.

So regardless of any other consideration, a legacy i.s. junction box should not be failed just because it is not certifi ed.

This document is distributed by the Ex-SIG as an information service to the SIG membership. No guarantee is made by the institute or the author(s) concerning the accuracy, reliability or completeness of the information provided. This document should not be construed as providing advice. Readers should satisfy themselves of the applicability of the information provided. Readers make use of the information provided at their own risk.
