Honda Parts & Accessories 2024

2024 Honda Accessories

Customers love hitting the trail with their Hondas, whether it's a Talon™ or Pioneer side-by-side, or a utility ATV. Tough, reliable, and fun to drive or ride, these machines match the needs of a wide range of people. For people with demanding tasks, extreme terrain or weather conditions, or personal comfort preferences, only Honda accessories will fill the bill. And they're only available from Honda dealers.

Talon ®

ROOFS/WINDSHIELDS

A, B- Aluminum Roof * ‡‡

Durable, integrated top shields occupants from harsh weather and sun.

• Installs easily to existing roof attachment points

• Black powder coat finish

• Race-inspired design features Honda Racing logo

• Lightweight 0.080-inch-thick 5052 aluminum alloy construction

A 1000X-4 0SL90-HL7-A00 $845.95

B 1000X/R 0SL90-HL6-A00 $695.95

C- Full Poly Vented Windscreen*‡‡ (hard coat)

Premium hard coating offers superior strength, impact resistance and durability to protect your Talon’s windscreen against chips and scratches.

• 6-mm-thick optical-grade polycarbonate material

• Adjustable vents allow for easy control of cabin airflow

• Unique clamp system allows for quick installation and removal

0SR73-HL6-A00 $649.95

D- Glass Windshield *

Designed for maximum visibility and comfort. Keeps out dust, debris, bugs and inclement weather.

• AS1 laminated safety glass offers the highest clarity for windshields

• Black powder-coated frame

• Uses Honda’s unique clamp system

• Honda Accessory Windshield Wiper Washer Kit available

0SU85-HL6-A00 $838.95

E- Half Wind Deflector * ‡‡ (hard coat)

Helps keep out dust, dirt and debris without sacrificing airflow.

• Uses Honda’s unique clamp system that allows for quick installation and removal

• Constructed from 0.236-inch- (6 mm) thick hard-coated polycarbonate material

• Offers superior strength, impact resistance, durability and performance

0SR71-HL6-A00 $315.95

*

1000X/R shown with optional 40-inch LED Light Bar.

F- Windshield Wiper Washer Kit *

Includes a windshield wiper and a washer reservoir to provide the ability to clean your windshield.

• 2022 requires a Honda Accessory Glass Windshield, Busbar Kit, Fuse Box and Fuse Box Mount

• 2019-21 requires a Honda Accessory Glass Windshield and Switch Plate with Volt Meter

2022-23

2019-21

0SE10-HL6-A10

$567.95

0SE10-HL6-A01 $599.95 (Shown)

G- Aluminum Doors *

Strong, lightweight aluminum doors add style, comfort and functionality.

• Single-piece stamped aluminum for superior quality and fit

• Finished with a durable, black powder coat

• Race-inspired design features Honda Racing logo

• Replace existing doors and attach to factory mounting brackets

Front 1000X/R/X-4

Rear 1000X-4

0SA80-HL6-A00 $749.95

0SA80-HL7-A00 $945.95 (Not shown.)

H- Fabric Upper Doors

* ‡‡ (black)

Rigid upper door frames integrate easily with standard equipment half doors to enhance comfort.

• Thermoformed panels help keep out inclement weather, mud, dust and bugs

• Water-repellent fabric is mold/mildew-resistant and provides superb UV and abrasion resistance

• Double-zipped, polished vinyl windows roll down to increase airflow thru the cab

• Polished vinyl windows hold up to extreme cold and resist cracking

• Honda Accessory Lower Door Panels required for full door coverage

• Not compatible with Honda Accessory Side Mirrors

• Requires Honda Accessory Fabric Rear Panel and Lower Door Panels

Front 1000X/R 0SR90-HL6-A00 $929.95 (Set of Two)

Front & Rear 1000X-4 0SR90-HL7-A00 $1945.95 (Set of Four)

‡‡ NOTICE: Do not tow any Talon on an open trailer with any of the following Honda Genuine or Signature Accessories installed: Fabric Doors and Fabric Panels, Aluminum Roofs, Poly Windscreens/Wind Deflectors. These Honda Accessories are not designed for use at highway speeds. Open trailering a Talon at highway speed with these accessories installed may damage them or the vehicle.

Shown on 1000R

Shown on 1000X-4

PANELS/REAR PANELS/MIRRORS

A- Lower Door Panels *

Customize the look of your Talon with factory color-matched panels.

• Install to factory doors to create a unique look for your vehicle

• Provide added protection from the elements

• Shown on 1000X-4

• 1000X-4 requires Honda Accessory Lower Front Door Panels

Front 1000X/R/X-4

Rear 1000X-4

08R77-HL6-A00 $229.95

08P71-HL7-A20 $227.95

B- Rear Panel * (hard coat)

Attractive, lightweight panel offers superior strength, impact resistance, durability and comfort.

• Constructed from 4.5-mm-thick hard-coated polycarbonate material

• Black powder-coated support frame

• Reduces the inflow of dust and debris

• 1000X/R image shown

1000X-4

1000X/R

0SB73-HL7-A00 $532.95

0SB73-HL6-A00 $534.95

C- Fabric Rear Panel * ‡‡

Thermoformed panels are water-repellent and help keep out inclement weather and enhance comfort of occupants.

• Provides superb UV and abrasion resistance as well as mold/mildew resistance

• Features a polished vinyl window

• Polished vinyl window is resistant to cracking in extreme cold

• For use with factory roof

• 1000X/R image shown

1000X-4

0SR85-HL7-A00 $384.95

1000X/R 0SR85-HL6-A00 $310.95

D- Side Mirrors * **

Sporty driver and passenger side mirrors can adjust to multiple positions and angles.

• Die-cast aluminum mounting clamps

• Install in seconds

• Not compatible with Honda Accessory Fabric Upper Front Doors

0SV05-HL6-A00 $398.95

E- Rear View Mirror **

Features a sporty design and is adjustable for excellent rear visibility.

• Die-cast aluminum mounting clamp

• Installs in seconds

0SV06-HL6-A00 $215.95

* Weight of cab system components may increase risk of vehicle rollover.

** Not intended for on-road use.

† Shown on 1000X-4

‡‡ NOTICE: Do not tow any Talon on an open trailer with any of the following Honda Genuine or Signature Accessories installed: Fabric Doors and Fabric Panels, Aluminum Roofs, Poly Windscreens/Wind Deflectors. These Honda Accessories are not designed for use at highway speeds. Open trailering a Talon at highway speed with these accessories installed may damage them or the vehicle.

F- Intrusion Bar

Strong, durable steel tube construction helps provide protection from various offroad hazards.

• Black powder-coated finish matches the look of the vehicle

• Does not work with Honda Accessory Windscreens and Audio System

0SA81-HL6-A00 $289.95

G- A-Arm Guards† (Front)

Provides additional protection to the underside and the front A-Arms from trail hazards such as rocks and logs.

• Set of two, 0.25-inch-thick A-Arm Guards

• Rugged High Molecular Weight Polyethylene (HMWPE) construction helps your Talon slide over obstacles 2022-23

1000X/X-4

0SK10-HL6-A01 $184.95

1000R 0SK20-HL6-A10 $245.95 2019-21

1000X/X-4

0SK10-HL6-A00 $184.95

1000R 0SK20-HL6-A00 $245.95

H- Trailing Arm Guards†

Provides additional protection to the underside and the rear arms from trail hazards such as rocks and logs.

• Set of two, 0.25-inch-thick Arm Guards

• Rugged High Molecular Weight Polyethylene (HMWPE) construction helps your Talon slide over obstacles

1000X/X-4

0SK11-HL6-A00 $231.95

1000R 0SK21-HL6-A01 $210.95

I- Trailing Arm Mud Guards

Designed to help protect the rear under carriage of your vehicle from mud and debris.

• Made of durable rubber material

• Includes all necessary hardware

• Easy to install

0SK12-HL6-A00 $151.95

J- Fender Flares

Front and rear fender flares are designed exclusively for your Talon resulting in an integrated look with superior fit and finish.

• Constructed of high-density Polyethylene (HDPE) for long-lasting durability

• Includes heavy-duty all rubber front mud flap

• Helps protect vehicle and occupants from mud, rocks and trail debris

0SF70-HL6-A01 $448.95

A- Frame Skid Plates

These skid plates help your Talon slide over obstacles and protect the underside from trail hazards such as rocks and logs.

• 0.25-inch-thick High Molecular Weight Polyethylene (HMWPE) construction

• Black powder-coated steel junction links between the plates for a seamless fit

• Integrates with Honda Accessory Side Skid Plates (recommended)

1000X-4

0SK30-HL7-A00 $431.95

1000X/R 0SK30-HL6-A00 $466.95

B- Nerf Bars

Heavy-duty, large-diameter steel tubes are finished with durable black powder coat and help protect your vehicle from rocks and debris.

• Uses factory mounting points for seamless integration

• Shown on 1000X-4

• Not compatible with Side Skid Plates

1000X-4

08P70-HL7-A20 $657.95

1000X/R 08P70-HL6-A40 $466.95

C- Side Skid Plates

Helps your Talon slide over obstacles and provides additional protection to the lower sides of your vehicle from trail hazards such as rocks and logs.

• Set of two, 0.25-inch-thick Side Skid Plates

• Rugged High Molecular Weight Polyethylene (HMWPE) construction

• Shown on 1000X-4

• Requires Honda Accessory Frame Skid Plates

1000X-4

0SK40-HL7-A00 $359.95

1000X/R 0SK40-HL6-A00 $230.95

*

C- Cargo Bag *

Made with UV-treated, water-resistant UltraMax ® fabric and reinforced Fibertech accent panels for protecting and storing your gear.

• Removable center divider for storage separation and lid support

• Top lid has reverse coil zipper that opens up to the main compartment

• 4 interior zipper pockets and 2 elastic mesh pockets for added storage

• 4 quick-release web straps and 2 side carry handles included

0SL56-HL6-A00 $189.95

D-

Cargo Box *

23.7-gallon (90-liter) Cargo Box is lockable and weather-sealed for secure, clean and dry storage.

• 4 tie-down points on the lid provide additional carrying area

• Honda Pro-Connect™ attachment system for quick installation and removal

• Two Honda Accessory Mount Plates required for installation (Sold separately.)

0SL51-HL6-A01 $482.95

E- Half Cargo Box *

9.2-gallon (35-liter) Half Cargo Box is lockable and weather-sealed for secure, clean and dry storage.

• Two can be installed at the same time for separate storage options

• 4 tie-down points on the lid provide additional carrying area

• Honda Pro-Connect™ attachment system for quick installation and removal

• Honda Accessory Mount Plate required for installation (Sold separately.)

0SL52-HL6-A01 $453.95

F- Mount Plate

• Required for installation of Cargo Box and Half Cargo Box

0SL41-HL6-A01 $142.95

CARGO/INTERIOR

*

A- Roof Storage Bags *

Made from UV-treated, water-resistant TriMax ® fabric. The bag’s semi-ridged construction helps hold its shape and features a reverse coil zipper.

• Bags securely attach to vehicle using 4 hook and loop straps

• Includes both left and right bags (Set of two.)

• Each bag measures 16.5" L x 6" W x 1.5" D

0SL57-HL6-A00 $94.95

B- Corner Storage Bags *

Made from UV-treated, water-resistant UltraMax ® fabric with Fibertech accent panels and reverse coil zippers to help keep out dust and dirt.

• Bags securely attach to vehicle using hook-and-loop straps

• Includes both left and right bags (Set of two.)

• Each bag measures 15" L x 11.5" W x 3" D

0SL58-HL6-A00 $95.95

C- Center Storage Bag *

Designed for maximum accessibility and made with high-quality TriMax ® Ballistic Nylon and Fibertech accent panels.

• Attaches to vehicle using 4 quick-release web straps

• Reverse coil zipper opens up to the main compartment

• Carry handle and exterior mesh pouch

• Measures 14.5" L x 7" W x 3" D

1000X/R 0SL55-HL6-A00 $54.95

D- Lower Front Door Storage Bags *

Made from UV-treated, water-resistant TriMax ® fabric with Fibertech accent panels and reverse coil zippers to help keep out dust and dirt.

• Removable front knee pad for maximum storage

• Includes bags for both left & right doors (Set of two.)

• Each bag measures 21" L x 7" W x 2" D

• Requires Honda Accessory Lower Front Door Panels

0SL59-HL6-A00 $95.95

E- Rubber Floor Mats

An integrated design and durable, nonslip rubber construction help protect the inner floor of your Talon.

• Contoured fit with trim clips help keep mats in place

• Branded with the Talon logo

Front & Rear 1000X-4 0SP63-HL7-A00 $242.95 Front 1000X/R 0SP63-HL6-A00 $118.95

F- Winch

• The WARN® VRX 35-S winch features 3,500-lb. pulling capacity, a heavy-duty contactor, robust new clutch design, a load holding brake and a smooth and reliable all-metal three-stage planetary gear train.

• Durable all-metal construction, black powder-coated finish for corrosion resistance and IP68-rated waterproof sealing to keep the elements out.

• Includes 50' of 3/16" synthetic rope.

• Requires Honda Accessory Winch Mount Kit and Honda Accessory Front Bumper or Aluminum Front Bumper

0SL71-HL6-A20 $576.95

G- Winch Mount Kit

Includes winch mount, mounting hardware and wiring for easy installation.

• Requires Honda Accessory Winch and Honda Accessory Front Bumper or Aluminum Front Bumper

0SL70-HL6-A00 $299.95

H, I- Aluminum Bumpers

High-strength, lightweight aluminum construction adds racing-inspired style and protection.

• Branded with Honda Racing logo

• Uses factory mount points for easy installation

• Shown on 1000X-4

2022

H Front 0SP80-HL6-A01 $556.95 2019-21

Front 0SP80-HL6-A00 $556.95

I Rear 0SP83-HL6-A00 $360.95

J, K- Steel Bumpers

Strong, heavy-duty steel construction adds vehicle protection and matches vehicle body lines for an integrated look.

• Uses factory mount points for easy installation

• Durable black powder coat adds a stylish finish

• Shown on 1000X-4

2022

J Front 0SP70-HL6-A01 $649.95 2019-21

Front 0SP70-HL6-A00 $395.95

K Rear 0SP73-HL6-A00 $377.95

NAVIGATION/ELECTRICAL

A- Garmin Tread® Powersport Navigator

Tread is built to withstand extreme terrains, temperatures and weather. It features a 5.5" glove friendly touchscreen with built-in Altimeter, Barometer, Compass and Pitch and Roll gauges. Stay connected to your friends with the Group Ride Radio for up to 20 riders.

• Includes topographic maps of North and Central America, public land boundaries, U.S. Forest Service roads and trails with Motor Vehicle Use Maps

• Includes downloadable high-resolution Birdseye Satellite Imagery via Wi-FiW® directly to Navigator at no extra cost.

• Use the Tread app to sync your waypoints, tracks, routes and collections across devices, plus get easy GPX Import/Export and access to live weather

• Requires Honda Accessory GPS Wire Harness (04301-HL6-3050)

Garmin Tread Powersport Navigator

GPS Wire Harness

B- Particle Separator

0SS50-HL4-A00

04301-HL6-3050

$749.95

$8.95

The Particle Separator by S&B ® helps eject dusty air before reaching the air filter.

• Helps keep the air filter cleaner longer

• Kit includes two different options for mounting low or high on the ROPS

• Standard LED rocker switch that allows you to turn the fan off when parked included

• Requires fusebox, fusebox mount kit and busbar

• 1000X-4 also requires Honda Accessory Power Harness

• Not compatible with both Rear Panels

2019-22 0SB01-HL6-A01 $456.95

C- 40-inch LED Light Bar

Brighten up any path with 36 LEDs and a total output of 10,400 lumens in a combination spot and flood pattern.

• Rugged aluminum powder-coated housing, IP67 rated— dust- and water-resistant

• Includes switch, harness and mounting hardware

• 2022 requires Honda Accessory Fuse Box, Fuse Box Mount Kit

• 2019-21 requires Honda Accessory Switch Plate with Voltmeter and Accessory Sub-Harness (Sub-Harness included with Winch Mount Kit)

2022 0SV31-HL6-A10 $614.95

2019-21 0SV31-HL6-A00 $614.95 (Shown.)

D- Auxiliary LED Lights

Increase visibility with Auxiliary Lights featuring 6 LEDs and a total output of 2100 lumens in a spot pattern.

• Rugged aluminum powder-coated housing, IP67 rated—dustand water-resistant

• Includes switch and harness. (Mounting clamps sold separately.

• 2022 requires Honda Accessory Fuse Box, Fuse Box Mount Kit, Busbar and Lightbar/Aux Light Clamps.

• 2019-21 requires Honda Accessory Switch Plate with Voltmeter and Accessory Sub-Harness (Sub-Harness included with Winch Mount Kit)

2022 0SV41-HL6-A10 $246.95

2019-21 0SV41-HL6-A00 $267.95 (Shown.)

Auxiliary Lights shown with optional 38mm clamps (0SV31-HL3-201A) for use when mounting on Honda Accessory Front Aluminum Bumper or Front Bumper.

Shown with optional Aluminum Roof.

E- Light Bar/Aux Lights Clamp

OSV31-HL3-201A fits bumper tubes (38-mm).

• Required when mounting Honda Accessory Light Bar/Auxiliary Lights to bumper (upper and lower tubes) and cab frame

38-mm

0SV31-HL3-201A $29.95

F- Switch Plate with Voltmeter

Integrates into your Talon’s dash and streamlines all Honda Accessory electrical needs into a single source.

• Accommodates up to 5 Honda Accessories

• LCD volt meter displays battery voltage and includes customizable High/Low voltage reminder

• IP68 rated for dust/water resistance

• Switches not included

• 1000X-4 requires Honda Accessory Power Harness

• Requires Honda Accessory Sub-Harness (Sub-Harness included with Winch Mount Kit)

2019-21 0SA30-HL6-A00 $399.95

G- Switch Plate

Designed specifically for your Talon dash with slots for up to 5 electrical switches for Honda Accessory expansion:

• Includes a Dual USB Connection to charge up to 2 phones with 2.1A each

• Dual USB Connection is removable and can be replaced with another switch

• Accommodates up to 4 other Honda Accessories

• Switches not included

• Requires: Honda Accessory Fuse Box, Fuse Box Mount Kit and Busbar.

2022 0SA30-HL6-A10 $149.95

H- Power Harness

• Required on 1000X-4 when installing Honda Accessory Switch Plate with Voltmeter. Sub-Harness required when installing Switch Plate with Voltmeter (Sub-Harness included with Winch Mount Kit)

2019-21 1000X-4 0SA31-HL7-A00 $40.95

I- Accessory Sub-Harness

• Required for Honda Accessory Switch Plate with Voltmeter, only one Sub-Harness required per Talon. (Accessory Sub-Harness included with Winch Mount Kit)

2019-21 0SZ08-HL6-A00 $82.95

J- Dome Light

Provides the convenience of a weatherproof light to your interior.

• Consists of 6 warm white LEDs rated 300 Lumens with easy to use on/off button

• Fits 1.75" and 2" tube sizes

• Plugs easily into Honda Accessory Fuse Box

• Requires: Honda Accessory Fuse Box, Fuse Box Mount and Busbar

2022 0SV51-HL6-A00 $79.95

ELECTRICAL/HEATER/AUDIO

A- Horn Kit

Easy-to-install horn assembly.

• Requires Horn Kit Wire Harness

08P75-HL5-A00

$34.95

B- Horn Kit Wire Harness

• Required to install Horn Kit

08Z70-HL6-A00

C- Heater

$116.95

Features a 3-speed fan with temperature control that allows maximum heat output in cold climates and cool ambient air in warmer climates.

• Multi-Zone Mode control allows user to direct air flow to areas needed most including windshield, body and floor

• Includes all mounting hardware, templates and heater controls

• Requires Honda Accessory Fuse Box, Fuse Box Mount and Busbar

2022-23 0SE08-HL6-A00

D- Audio System

$1,039.95

Audio System by SSV Works ® offers plug-and-play installation and comes with molded kick panels to optimize sound quality without compromising legroom or ergonomics.

• Two 6.5" powersports speakers ruggedized for the outdoors

• 25-mm titanium tweeters for ultrabright highs

• On-dash media controller features Bluetooth,® aux input, AM, FM and a large hyperwhite LED backlit display and buttons

• 50-watt x 4-channel amplifier

0SS22-HL6-A00

$647.95

E- Rear Speakers

Two, SSV Works custom molded, cage mount pods include two 6.5", 195 watt, 2-way coaxial Powersports Speakers with 25mm titanium tweeters for ultra bright highs.

• Weatherproofed and ruggedized for the outdoors

• Requires Honda Accessory Rear Speaker Mount Kit for installation

0SS22-HL4-A40 $349.95

Rear Speakers Mount Kit

Features easy to install clamp system that allows for full 360° speaker pod adjustability while on the cage.

• Complete with plug and play 2P harness and 4P extension harness

• Includes stainless steel mounting hardware.

• Required for Honda Accessory Rear Speaker Pods

0SS23-HL6-A00 $99.95 (Not shown.)

F- Subwoofer

Features a custom molded SSV Works subwoofer enclosure that holds an SSV 10" subwoofer and a built-in internal amplifier.

• Amplifier is pre-tuned with a maximum power rating of 500 watts

• Includes all necessary wires and brackets

• Requires Honda Accessory Audio System and Busbar for installation

0SS22-HL6-A50 $767.95

G- Busbar

Features 3 positions for Power and 3 positions for Ground distribution.

• Rated at 300A

• Hardware is corrosion resistant and easy to install

• Provides relocation for WARN winch contactor

2023

0SS27-HL6-A10

$102.95 (fits non-S models only)

2022-23 0SS27-HL6-A00 $102.95

Busbar Cable

• Required for Busbar when VRX Winch is installed.

2022-23 0SL72-HL6-A00 $29.95 (Not shown.)

H- Fuse Box

Supports up to eight accessories and includes:

• 4 switch outputs

• 1 wiper/washer output

• 3 constant power auxiliary outputs

• Rated at 80 amps

• Talon models require Fuse Box Mount Kit and Busbar Kit.

2022-23 0SS25-HL4-AOO $210.95

Fuse Box Mount

Features powder-coated mild steel mounting plate and includes stainless steel mounting hardware.

• Easy to install with no vehicle modifications necessary

• Requires Honda Accessory Fuse Box for installation

2023 0SS26-HL6-A10 $155.95 (Fits non-S models only)

2022-23 0SS26-HL6-A00 $155.95 (Not shown.)

I- Accessory Wiring Connector

For use on electrical accessories that do not use the same connections as the Accessory Fuse Box. Provides a replacement connector that is designed to work with the Accessory Fuse Box.

• Includes two connectors

2022 0SZ05-HL6-A00 $29.95

J- Flag Kit

Flag is mounted on a 3/8-inch-diameter fiberglass pole and installs easily to the integrated vehicle flag mount.

• Flag reaches 9 feet high when installed

0SR95-HL6-A00 $65.95

K- Storage Cover

Durable, 100% waterproof cover with vented design minimizes condensation while elastic hem ensures a snug and secure fit.

• UltraMax® durable polyester material offers maximum UV protection

• Heat taped seams

• Driver’s side zipper for easy access to vehicle

• Multiuse carry bag for compact storage

• 1000X-4 measures 164" L x 66" W x 70" H

• 1000X/R measures 131" L x 54" W x 69" H

• Cover is not designed for trailering

1000X-4 0SP35-HL7-A00 $155.95

1000X/R 0SP35-HL6-A00 $129.95 (Shown.)

PIONEER ®

E. Steel Front Bumper and Warn VRX45 Winch 2023

A. SSV Works 10" Powered Subwoofer

B. Garmin TREAD Powersport Navigator

C. Front Fender Flares

D. Multi Zone Heater

B A

ROOFS/TOPS/WINDSHIELD

A- Hard Roof * (black)

Compatible with all Pioneer ® 1000-6 Honda Accessory Windscreens.

• Manufactured from ultrarugged polyethylene—extremely durable

• Superior weather protection

• Styled to integrate with vehicle design

• Clamps pre-installed from the factory

• Quick-release attachment, installs in minutes without tools

Black 0SR85-HL8-A00 $828.95

B- Fabric Roof/Rear Panel **‡‡ (black)

For superior performance in harsh conditions.

• Black one-piece design is constructed of durable Sur Last ® material for excellent water repellency and is UV-, mold/mildewand abrasion-resistant

• Fiber rods create a tight, custom fit to the roof while promoting water runoff

• Rear panel rolls up increasing airflow through the cab

• Polished vinyl window resists cracking even at temperatures as low as -30˚ F

Black 0SR85-HL8-210B $428.95

C- Bimini Top ‡‡ (black)

Durable top shields occupants from the sun and helps protect from harsh exposure.

• Sur Last ® material is water-repellent and provides superb UV and abrasion resistance as well as mold/mildew resistance

• Quick and easy to install

• Not compatible with Windshield, Windscreens, Fabric Doors

Black 0SR85-HL8-322A $238.95

D- Glass Windshield *

Top-quality ASI laminated safety glass offers protection from wind, dust and trail debris while providing a more comfortable driving experience.

• Uses Honda Tool-Less Clamp system

• Quick installation and quick removal

• Shown with optional Honda Accessory Wiper Kit

0SU85-HL4-A00 $1,043.95

E- Glass Windshield Wiper Kit and Washer*

Includes a windshield wiper and a washer reservoir to provide the ability to clean your windshield.

• Kit contains all necessary installation parts

• Requires: Honda Accessory Glass Windshield, Fuse Box, Fuse Box and Audio Mount Bracket and Fuse Box Wiring Kit. Not compatible with Under Seat Storage Box or Powered Subwoofer.

0SE10-HL4-A00 $516.95

†

Shown on Pioneer 1000-5

Shown on Pioneer 1000-5

F- Vented Full Poly Windscreen * ‡‡ (hard coat) †

Adjustable driver and passenger vents allow occupants to adjust the amount of outside airflow to their individual comfort levels. Premium hard coating helps protect windscreen against scratches, promotes longer life.

• Optical-grade polycarbonate construction enhances visual clarity

• Noncracking, nonyellowing material for excellent impact resistance

• Modular design for a variety of vehicle configurations

• Uses Honda Tool-Less Clamp system for quick installation and removal

0SR72-HL4-A20

$665.95

G- Vented Full Poly Windscreen* ‡‡ (optical) †

Adjustable driver and passenger vents allow occupants to adjust the amount of outside airflow to their individual comfort levels.

• Optical-grade polycarbonate construction enhances visual clarity

• Noncracking, nonyellowing material for excellent impact resistance

• Modular design for a variety of vehicle configurations

• Uses Honda Tool-Less Clamp system for quick installation and removal

0SR72-HL4-A10 $533.95

H- 2-Piece Poly Windscreen* ‡‡ (hard coat) **

Premium hard coating helps protect windscreen against scratches on upper portion of windscreen, promoting longer life.

• Two-piece pivoting windscreen opens up approximately 7-inches for increased airflow

• Features overlap profile for improved sealing

• Optical-grade polycarbonate construction enhances visual clarity

• Noncracking, non-yellowing material for excellent impact resistance

• Modular design for a variety of vehicle configurations

• Uses Honda Tool-Less Clamp system for quick installation and removal

0SR71-HL4-A20 $761.95

I- 2-Piece Poly Windscreen * ‡‡ (optical) **

Two-piece pivoting windscreen opens up approximately 7-inches for increased airflow

• Features overlap profile for improved sealing

• Optical-grade polycarbonate construction enhances visual clarity

• Noncracking, nonyellowing material for excellent impact resistance

• Modular design for a variety of vehicle configurations

• Uses Honda Tool-Less Clamp system for quick installation and removal

0SR71-HL4-A10 $602.95

‡‡ NOTICE: Do not tow any Pioneer on an open trailer with any of the following Honda Genuine or Signature Accessories installed: Hard, Fabric or Bimini Roofs, Poly Windscreens/Wind Deflectors, Fabric Doors and Fabric Panels.These Honda Accessories are not designed for use at highway speeds. Open trailering a Pioneer at highway speed with these accessories installed may damage them or the vehicle.

WINDSCREENS/DOORS/PANELS

A- Half Wind Deflector ‡‡ (optical)

Adds protection from dust, dirt and debris without sacrificing airflow.

• Optical-grade polycarbonate construction enhances visual clarity

• Noncracking, nonyellowing material for excellent impact resistance

• Custom, screen-printed graphics complement vehicle styling

0SR73-HL4-A00 $227.95

B- Fabric Front and Rear Doors † ‡‡ (black)

Precision-manufactured aluminum door frames are lightweight and integrate easily with standard half doors.

• Black fabric is constructed of durable Sur Last ® material for excellent water repellency and is UV-, mold/mildew- and abrasion-resistant

• Double-zipped, polished vinyl windows roll down increasing airflow thru the cab

• Polished vinyl windows are resistant to cracking in extreme cold

Front Black 0SR90-HL4-212A $626.95

Rear Black 0SR90-HL8-210B $698.95

C- Fabric Rear Panel (black)

‡‡

Well-made, attractive panel help keep out inclement weather and enhance comfort of occupants.

• Durable Sur Last ® material is water-repellent and provides superb UV and abrasion resistance as well as mold/mildew resistance

• Zippered vinyl window rolls up to increase airflow thru cab

• Polished vinyl window is resistant to cracking in extreme cold

• Must be used with Windscreens or Windshields and Hard or Fabric Roofs

Black 0SR95-HL8-211B $205.95

D- Hard Rear

Panel † ‡‡ (black)

Modular design integrates seamlessly with other Honda Accessory cab components.

• Manufactured from ultrarugged polyethylene—extremely durable

• Tempered glass, vented sliding window for increased airflow

• Includes rear rubber closeout and compression gaskets for improved sealing.

• Requires Honda Accessory 6P Hard Roof (0SR85-HL8-A00)

Black 0SU95-HL8-A00 $699.95

* Weight of cab system components may increase risk of vehicle rollover.

** Only windscreens with the optional premium hard coating meet the abrasion resistance requirements specified in ANSI/OPEI B71.9-2012 standards.

† Includes right and left doors.

‡‡ NOTICE: Do not tow any Pioneer on an open trailer with any of the following Honda Genuine or Signature Accessories installed: Hard, Fabric or Bimini Roofs, Poly Windscreens/Wind Deflectors, Fabric Doors and Fabric Panels.These Honda Accessories are not designed for use at highway speeds. Open trailering a Pioneer at highway speed with these accessories installed may damage them or the vehicle.

E, F- Winch

The WARN ® VRX 45 features 4,500 lb. pulling capacity, a heavy duty contactor and robust new clutch design.

• Smooth and reliable all-metal three-stage planetary gear train

• Load holding brake

• Limited lifetime warranty by WARN

• Requires Honda Accessory Winch Mount Kit

E Winch

F Winch Mount Kit

G, H, I- Plow Blade

08L71-HL3-A43 $524.95

08L72-HL4-AK1 $391.95

Designed for your Honda with unique Pioneer logo stamping and graphics. Made from thick, 15-gauge steel with heavy-duty formed reinforcements and center cross tube for added structural rigidity for extra support.

• Blade is 72" wide and 17" high and is powder coated for durability and corrosion resistance

• Features progressive radius design for more effective snow rolling

• Thick reversible wear bar and adjustable plow skids to control plowing height of the blade

• Requires Honda Accessory Plow Push Tube and Plow Mount Kit

• Requires lifting device such as Honda Accessory Winch/Winch Mount Kit

G Plow Blade 72" 0SL76-HL4-A00 $598.95

H Plow Push Tube 0SL70-HL4-A00 $593.95

I Plow Mount Kit 0SL73-HL4-A00 $292.95

J- Hitch Ball

1 7/8" hitch ball. Includes nut and lock washer.

08L90-HL1-100C $14.95

K- Receiver Hitch Plug

Heavy-duty, weather-resistant plastic insert helps keep dirt and water out.

08L76-HL4-A00 $14.95

L- Drawbar

Allows installation of 1 7/8" or 2" hitch ball.

08L90-HL1-100A $44.95

A- Steel Front Bumper

Strong, steel construction for added vehicle protection.

• Accepts Honda Accessory Lighting with Honda Accessory 45-mm clamp

• Durable-gloss black powder coat adds a stylish finish

• Attaches to factory mount points

08P71-HL8-A10 $595.95

B- Rear Bumper

Strong, steel construction for added vehicle protection.

• Durable-gloss black powder coat adds a stylish finish

• Attaches to factory mount points

08P70-HL4-AN0 $253.95

C- HMWPE A-Arm Guards (rear)

Rugged High-Molecular-Weight Polyethylene (HMWPE) construction has a low coefficient of friction—which helps your SxS slide over rocks and obstacles.

• A-Arm Guards are .25" thick and help provide additional protection to the underside of your SxS from impacts and trail hazard

• Quick and easy to install

0SP75-HL4-100 $199.95

D, E- Aluminum A-Arm Guards

Set of two, lightweight 3.2 mm (.126") thick 5052-O brushed aluminum alloy.

• Added protection from trail hazards such as rocks and branches

• Quick and easy to install FRONT

E 08P70-HL4-AK0 $240.95 REAR

F 08P73-HL4-F00 $265.95

F, G- HMWPE Skid Plates

0.25 inch thick HMW Skid Plate provides additional protection to the underside of your SxS from trail hazards such as rocks and logs

• Rugged High Molecular Weight (HMWPE) Polyethylene construction has low coefficient of friction which helps your Pioneer slide over obstacles

• Requires 0SK30-HL4-A00 HMWPE Skid Plate

F 0SK30-HL4-A00 $246.95

G 0SK30-HL8-A00 $189.95

H- Fender Flares

Front Fender Flares are designed specifically for your Pioneer, resulting in an integrated, stylish look and a superior fit and finish.

• Constructed of High-Density Polyethylene (HDPE) for long-lasting durability

• Protects your vehicle and passengers from mud, rocks and trail debris

08F70-HL4-AK0 $196.95

I- Cab Frame Cargo Bag**

Made of durable polyester, the Cab Fame Cargo Bag attaches to cab frame with hook-and-loop straps and locking buckles to keep bag secure and items at hand.

• Seven convenient, zipper pull compartments for easy access

• Not compatible with Hard and Fabric Mid/Rear Panels

0SL57-HL3-101 $69.95

J- Underseat Storage Bag**

Water resistant and highly durable, this Honda branded all purpose storage bag is made of PVC tarpaulin and is designed to fit under the front seat.

• Inside features two zippered mesh pockets, one elastic mesh pocket and two Velcro tie-down straps.

• Includes Handy Tool Bag with slots for 20 assorted tools, a zippered mesh pocket and two Velcro roll-up straps. (Tools not included)

• Bags securely attach to vehicle using two hook and loop straps

• Measurements equal 20"L x 14"W x 5"H, 23 Liter volume

0SL77-HL8-A00 $152.95

K- Storage Bag**

Made from UV-treated, water-resistant UltraMax™ fabric which protects against fading and discoloration.

• Generously sized storage bag comes with reverse coil zippers to help keep out dust and dirt

• Bags securely attach to vehicle using four hook and loop straps

• Features a front, see through pocket which is glove friendly for accessing your phone or tablet.

• Measurements equal 13L x 5W x 9H inches, 9.6 Liter volume

0SH55-HL8-A00 $64.95

L- Dash Pocket Net

**

Integrated Dash Pocket Net helps to prevent items from coming loose in rough terain.

• Provides quick and easy access to important items (cell phone, wallet, sunglasses, etc.)

0SL60-HL4-A00 $27.95

M- Bed Mat

Tight, contoured fit helps keep mat from slipping and sliding.

• Manufactured from rugged, nonslip, specially vulcanized rubber compound

• Custom designed featuring Pioneer logo.

0SP42-HL4-202 $194.95

** Refer to installation instructions for cargo weight capacities.

A- Seat Covers (camo)

Fits over front and rear seats/seatbacks and headrests. Requires two sets for front and rear installation.

• Quick and easy to install, no special tools required

• Exclusive Honda Phantom Camo® design matches unit camo color

0SP32-HL4-A30C $189.95

B- Rubber Floor Mat

Tight, contoured fit helps keep mat in place.

• Manufactured from rugged, nonslip, specially vulcanized rubber compound

• Custom designed with Pioneer logo

0SP63-HL4-102 $149.95

C- Rearview Mirror *

Rigid mount panoramic mirror provides excellent rear visibility.

• Easily attaches to frame with included hardware

0SV05-HL4-300 $99.95

D- Side Mirrors *

Adjustable mirrors work with hard doors or as a stand-alone mirror kit.

• Mirrors attach with Honda Quick-Release clamps when used without Honda Accessory Hard Doors

• Do not apply with Fabric Front Doors and Glass Windshield

0SV05-HL4-202 $159.95

E- Dome Light

Provides the convenience of a weatherproof light to your interior.

• Consists of six warm white LEDs rated 300 Lumens with easy to use on/off button

• Fits 1.75" and 2" tube sizes

• Plugs easily into new Fuse Box.

0SV51-HL6-A00 $79.95

F- 20-inch LED Light Bar

Features 4-watt LED lights producing 5,200 lumens in a dual row combined spot and flood pattern, IP-67 rated for dust and water protection.

• Rugged aluminum powder-coated housing

• Lights draw 4.4 amps of current at 12 volts

• Includes switch and mounting hardware for Honda Hard Roofs

• Requires: Honda Accessory Fuse Box, Fuse Box Wiring Kit, and Fuse Box and Audio Mount Bracket

• Additional clamps required to mount to Pioneer 1000-6 standard bumper, Honda Accessory Front Bumper/Brush Guard and cab frame.

0SV31-HL4-A00 $381.95

G- LED Auxiliary Lights

Pair of 4", 3-watt Cree LEDs producing a combined 2,400 lumens in a flood pattern., IP68 rated—waterproof and submersible.

• Rugged aluminum powder-coated housing,

• Includes mounting hardware to Honda Accessory windshield and switch

• Additional Honda Accessory (45-mm) clamps required for mounting to Pioneer 1000 standard bumper, Honda Accessory Bumper or cab frame

• Requires Honda Accessory Switch Plate/Volt Meter/Wire Harness

0SV41-HL3-A10 $320.95

H- Light Bar/Auxiliary Lights 45-mm Clamp

Fits lower tubes of Pioneer 1000 standard bumper, Honda Accessory Front Bumper/Brush Guard and cab frame.

0SV31-HL4-201A $29.95

I- LED Headlights

Stylish, high-intensity, direct illumination LED headlights are IP-67 rated and provide excellent performance for varied riding conditions

• High/Low Beam Specifications: Raw Output — 1,400/800 Lumens Effective Output — 897/506 Lumens Amp Draw — 1.6A/1.0A @ 12.8VDC

• 4,500K lamp conforms to SAE J1623 headlight specifications.

• Requires Honda Accessory LED Headlight Wire Harness

LED Headlights

08V70-HL4-AK0 $399.95

LED Headlight Wire Harness 33130-HL4-A10 $19.75

J- Garmin Tread® Powersport Navigator

Tread is built to withstand extreme terrains, temperatures and weather. It features a 5.5" glove friendly touchscreen with built-in Altimeter, Barometer, Compass and Pitch and Roll gauges. Stay connected to your friends with the Group Ride Radio for up to 20 riders.

• Includes topographic maps of North and Central America, public land boundaries, U.S. Forest Service roads and trails with Motor Vehicle Use Maps

• Includes downloadable high-resolution Birdseye Satellite Imagery via Wi-FiW® directly to Navigator at no extra cost.

• Use the Tread app to sync your waypoints, tracks, routes and collections across devices, plus get easy GPX Import/Export and access to live weather

• Requires Honda Accessory GPS Wire Harness (0SS51-HL4-A00)

J Garmin Tread Powersport Nav.

GPS Wire Harness

0SS50-HL4-A00 $749.95

0SS51-HL4-A00 $22.95

ELECTRICAL

A- Heater

Features 3-speed fan with temperature control that allows maximum heat output in cold climates and cool ambient air in warmer climates.

• Multi-zone mode control allows user to direct air flow to areas needed most including windshield, body and floor

• Includes all mounting hardware, templates and heater controls.

• Requires Honda Accessory Fuse Box, Fuse Box & Audio Mount Bracket and Fuse Box Wiring Kit.

0SE08-HL4-A00 $999.95

B- Audio System

SSV Works Audio System is powered by a 50 watt x 4 channel amplifier.

• Includes two 6.5" 195 watt 2-way coaxial Powersports Speakers, weatherproofed & ruggedized for the outdoors with 25mm Titanium Tweeters for ultra-bright highs

• Molded front speaker kick panels optimize sound quality without compromising legroom

• On-dash media controller features Bluetooth, Aux -input, AM, FM with a large, bright LED backlit display and a Direct-Fit dash kit.

• Plug & Play installation

• Requires: Honda Accessory Fuse Box and Audio Mount Bracket

0SS22-HL4-A00 $744.95

C- Rear Speaker Pods

Two, SSV Works custom molded, Cage Mount Pods include two 6.5" 195 watt, 2-way coaxial Powersports Speakers with 25mm Titanium Tweeters for ultra bright highs

• Weatherproofed and ruggedized for the outdoors

• Requires Honda Accessory Rear Speaker Mount Kit for installation

0SS22-HL4-A40 $349.95

Rear Speaker Mount Kit

Easy to install clamp system allows for full 360 ̊speaker pod adjustability while on the cage.

• Includes Plug and Play extension harness, stainless steel mounting hardware and step-by-step installation instructions

• Required for Honda Accessory Rear Speaker Pods

0SS23-HL4-A00 $99.95 (Not shown.)

D- Powered Subwoofer

Features a custom molded SSV Works subwoofer enclosure that holds an SSV 10" subwoofer and a built-in internal amplifier.

• Amplifier is pre-tuned with a maximum power rating of 500 watts

• Includes all necessary wires and brackets

• Requires: Honda Accessory Audio System, Fuse Box, Fuse Box Audio Mount Bracket, and Fuse Box Wiring Kit

0SS22-HL8-A50 $679.95

* Not available in Oregon.

E- Fuse Box

New design supports up to eight accessories.

• 4 switch outputs with one wiper/washer output

• 3 constant power auxiliary outputs

• Rated at 80 amps

• Requires: Honda Accessory Fuse Box and Audio Mount Bracket, and Fuse Box Wiring Kit

0SS25-HL4-A00 $210.95

F- Fuse Box and Audio Mount Bracket

This Mount Bracket can be used for only the Accessory Fuse Box, or for both the Fuse Box and the Accessory Audio System amplifier.

• Includes all necessary hardware

• Required for installation of Honda Accessory Fuse Box

0SS27-HL4-A00 $54.95

G- Fuse Box Wiring Kit

For use with Honda Accessory Fuse Box, allowing for the installation of electrical accessories.

• Provides wiring and connectors

0SS26-HL4-A00 $82.95

H- Accessory Wiring Connector

For use on electrical accessories that do not use the same connections as the Accessory Fuse Box. Provides a replacement connector that is designed to work with the Accessory Fuse Box.

• Includes two connectors

2022 0SZO5-HL6-A00 $29.95

I- Horn Kit

• Requires Honda Accessory Horn Kit Wire Harness

I Horn Kit 08P75-HL5-A00 $34.95 Horn Kit Wire Harness 08Z77-HL4-A00 $59.95

J- Back-Up Alarm *

Automatically activates a loud beep whenever Pioneer is put into reverse.

• Requires Honda Accessory Back-Up Alarm Mount

J Back-Up Alarm 08V70-HL5-A00 $39.95 Back-Up Alarm Mount 08Z76-HL4-A00 $29.95

Flag with Mount

• Marker flag to satisfy ORV regs

0SR95-HL4-F10 $57.95 (Not shown.)

K- Storage Cover

Made from weather-resistant synthetic material with taped seams to help keep your Pioneer 1000 protected and dry.

• Side zippers allow cab access without removing the cover

• Fits with or without most Honda Accessories

• Includes handy storage pouch

• New Pioneer logo

0SP34-HL8-100 $180.95

PIONEER ®

A. Pioneer 1000/1000-5 LED Headlight

B. Pioneer 1000/1000-5 Bed Extender

C. Pioneer 1000/1000-5 A-Arm Guards and Skid Plates

B

ROOFS/TOPS

A, B, C, D- Hard Roof *‡‡

Compatible with all Pioneer ® 1000 Honda Accessory Windscreens.

• Manufactured from ultrarugged polyethylene—extremely durable

• Superior weather protection

• Styled to integrate with vehicle design

• New gray interior option helps brighten up the inside of the cab.

• Clamps pre-installed from the factory

• Quick-release attachment, installs in minutes without tools

A 5P Black 0SR85-HL4-A50

$826.95

B 5P Gray/Black 0SR85-HL4-G50 $947.95

C 3P Black 0SR85-HL4-A30 $557.95

D 3P Gray/Black 0SR85-HL4-G30 $639.95

E, F- Fabric Roof/Rear Panel

**‡‡

For superior performance in harsh conditions.

• Black one-piece design is constructed of durable Sur Last ® material for excellent water repellency and is UV-, mold/mildewand abrasion-resistant

• Camo one-piece design is made of durable 600-denier and is UV-fade-resistant and also DWR (durable-water-repellent) for maximum water repellency

• Exclusive Honda Phantom Camo ® design matches unit camo color

• Fiber rods create a tight, custom fit to the roof while promoting water runoff

• Rear panel rolls up increasing airflow through the cab

• Polished vinyl window resists cracking even at temperatures as low as -30˚ F

E 5P Black 0SR85-HL4-222A $359.95

F 3P Black 0SR85-HL4-211A $259.95

G, H- Bimini Top ‡‡

Durable top shields occupants from the sun and helps protect from harsh exposure.

• Sur Last ® material is water-repellent and provides superb UV and abrasion resistance as well as mold/mildew resistance

• Quick and easy to install

• Not compatible with Windshield, Windscreens, Fabric or Hard Doors

G 5P Black 0SR85-HL4-322A $197.95

H 3P Black 0SR85-HL4-322B $129.95

I- Glass Windshield *

Top-quality ASI laminated safety glass offers protection from wind, dust and trail debris while providing a more comfortable driving experience.

• Uses Honda Tool-Less Clamp system

• Quick installation and quick removal

• Shown with optional Honda Accessory Wiper Kit

0SU85-HL4-A00 $1,043.95

J- Glass Windshield Wiper and Washer

*

Includes a windshield wiper and a washer reservoir to provide the ability to clean your windshield..

• Kit contains all necessary installation parts

• Requires: Honda Accessory Glass Windshield, Fuse Box, Fuse Box and Audio Mount Bracket and Fuse Box Wiring Kit. Not compatible with Under Seat Storage Box or Powered Subwoofer.

2022-23 0SE10-HL4-A00 $516.95

K- Glass Windshield Wiper Kit *

Add a measure of convenience with wipers that integrate seamlessly only with Honda Accessory Glass Windshield.

• Requires installation of accessory Switch Plate/Volt Meter/ Wire Harness

2016-21

L- Vented Full Poly Windscreen * ‡‡ (hard coat) †

New adjustable driver and passenger vents allow occupants to adjust the amount of outside airflow to their individual comfort levels. Premium hard coating helps protect windscreen against scratches, promotes longer life.

• Optical-grade polycarbonate construction enhances visual clarity

• Noncracking, nonyellowing material for excellent impact resistance

• Modular design for a variety of vehicle configurations

• Uses Honda Tool-Less Clamp system for quick installation and removal

0SR72-HL4-A20 $665.95

‡‡ NOTICE: Do not tow any Pioneer on an open trailer with any of the following Honda Genuine or Signature Accessories installed: Hard, Fabric or Bimini Roofs, Poly Windscreens/Wind Deflectors, Fabric Doors and Fabric Panels.These Honda Accessories are not designed for use at highway speeds. Open trailering a Pioneer at highway speed with these accessories installed may damage them or the vehicle.

WINDSCREENS

A- Vented Full Poly

Windscreen* ‡‡ (optical) †

New adjustable driver and passenger vents allow occupants to adjust the amount of outside airflow to their individual comfort levels.

• Optical-grade polycarbonate construction enhances visual clarity

• Noncracking, nonyellowing material for excellent impact resistance

• Modular design for a variety of vehicle configurations

• Uses Honda Tool-Less Clamp system for quick installation and removal

0SR72-HL4-A10

$533.95

B- 2-Piece Poly

Windscreen* ‡‡ (hard coat) **

Premium hard coating helps protect windscreen against scratches on upper portion of windscreen, promoting longer life.

• Two-piece pivoting windscreen opens up approximately 7-inches for increased airflow

• Features overlap profile for improved sealing

• Optical-grade polycarbonate construction enhances visual clarity

• Noncracking, non-yellowing material for excellent impact resistance

• Modular design for a variety of vehicle configurations

• Uses Honda Tool-Less Clamp system for quick installation and removal

0SR71-HL4-A20

$761.95

C- 2-Piece Poly Windscreen * ‡‡ (optical) **

Two-piece pivoting windscreen opens up approximately 7-inches for increased airflow

• Features overlap profile for improved sealing

• Optical-grade polycarbonate construction enhances visual clarity

• Noncracking, nonyellowing material for excellent impact resistance

• Modular design for a variety of vehicle configurations

• Uses Honda Tool-Less Clamp system for quick installation and removal

0SR71-HL4-A10 $602.95

D-

Half Wind Deflector ‡‡ (optical)

Adds protection from dust, dirt and debris without sacrificing airflow.

• Optical-grade polycarbonate construction enhances visual clarity

• Noncracking, nonyellowing material for excellent impact resistance

• Custom, screen-printed graphics complement vehicle styling

0SR73-HL4-A00 $227.95

* Weight of cab system components may increase risk of vehicle rollover.

** Only windscreens with the optional premium hard coating meet the abrasion resistance requirements specified in ANSI/OPEI B71.9-2012 standards.

† Includes right and left doors.

‡‡ NOTICE: Do not tow any Pioneer on an open trailer with any of the following Honda Genuine or Signature Accessories installed: Hard, Fabric or Bimini Roofs, Poly Windscreens/Wind Deflectors, Fabric Doors and Fabric Panels.These Honda Accessories are not designed for use at highway speeds. Open trailering a Pioneer at highway speed with these accessories installed may damage them or the vehicle.

E- Hard Front Doors*†

Heavy-duty doors are manufactured from ultrarugged and durable polyethylene.

• New gray interior color brightens the inside of the cab for better interior visibility

• Interior door panel features new “soft touch” material for a premium feel

• Automotive-style roll-up crank window maximizes airflow and cab comfort

• Door handles include key lock for security and convenience

• Includes rubber seal kit for improved cab sealing.

• Custom inner panel includes convenient cargo net storage panel

• Accepts Honda Accessory Mirrors

• Compatible with Hard Roof

Gray/Black

0SU95-HL4-GD0 $3,667.95

F- Side Mirrors **

Adjustable mirrors work with hard doors or as a stand-alone mirror kit.

• Mirrors attach with Honda Quick-Release clamps when used without Honda Accessory Hard Doors

• Not compatible with Fabric Front Doors

0SV05-HL4-202 $159.95

FABRIC DOORS

A, B- Fabric Front Doors

† ‡‡ (black & camo)

Precision-manufactured aluminum door frames are lightweight and integrate easily with standard half doors.

• Black fabric is constructed of durable Sur Last ® material for excellent water repellency and is UV-, mold/mildew- and abrasion-resistant

• Camo fabric is constructed of durable 600-denier fabric for superior UV resistance along with DWR (durable water repellency) for maximum water repellency

• Exclusive Honda Phantom Camo® design matches unit camo color

• 2021 camo doors feature updated Honda Phantom Camo pattern

• Double-zipped, polished vinyl windows roll down increasing airflow thru the cab

• Polished vinyl windows are resistant to cracking in extreme cold

2016-23

A Black 0SR90-HL4-212A $626.95 2021-23 (Not shown.)

Camo 0SR90-HL4-232C $699.95

2018-2020

B Camo 0SR90-HL4-222A $590.95

C,

D- Fabric

Rear Doors * ‡‡ (black & camo)

Top section flips up allowing easy entry/exit for passengers. Precision-manufactured aluminum frames are lightweight and integrate with standard half doors.

• Black fabric is constructed of durable Sur Last ® material for excellent waterrepellency and is UV-, mold/mildew- and abrasion-resistant

• Camo fabric is constructed of durable 600-denier fabric for superior UV resistance along with DWR (durable water repellency) for maximum water repellency

• Exclusive Honda Phantom Camo ® design matches unit camo color

• Double-zipped, polished vinyl windows roll down increasing airflow thru the cab

• Resistant to cracking in extreme cold

• Not compatible with Hard Mid/Rear Panels or Fabric Mid Panels

C 5P Black 0SR90-HL4-212B $610.95 2021-22 (Not shown.)

D 5P Camo 0SR90-HL4-252C $649.95

* Includes right and left doors. **Not intended for on-road use.

† Weight of cab system components may increase risk of vehicle rollover.

‡‡ NOTICE: Do not tow any Pioneer on an open trailer with any of the following Honda Genuine or Signature Accessories installed: Hard, Fabric or Bimini Roofs, Poly Windscreens/Wind Deflectors, Fabric Doors and Fabric Panels. These Honda Accessoriess are not designed for use at highway speeds. Open trailering a Pioneer at highway speed with these accessories installed may damage them or the vehicle.

E, F, G, H- Hard Mid/Rear Panel † ‡‡

Modular design integrates seamlessly with other Honda Accessory cab components.

• Manufactured from ultrarugged polyethylene—extremely durable

• Tempered glass, vented sliding window for increased airflow

• New gray interior option helps brighten up the inside of the cab.

• Includes rear rubber closeout and compression gaskets for improved sealing.

• Requires Honda Accessory Hard Roof 5P or 3P

• Not compatible with Fabric Rear Doors

E 5P Black 0SU95-HL4-A50 $682.95

F 5P Gray/Black 0SU95-HL4-G50 $736.95

G 3P Black 0SU95-HL4-A30 $725.95

H 3P Gray/Black 0SU95-HL4-G30 $783.95

I- Fabric Mid Panel ‡‡

Well-made, attractive panels help keep out inclement weather and enhance comfort of occupants.

• Durable Sur Last ® material is water-repellent and provides superb UV and abrasion resistance as well as mold/mildew resistance

• Zippered vinyl window rolls up to increase airflow thru cab

• Polished vinyl window is resistant to cracking in extreme cold

• Not compatible with Fabric Rear Doors

5P 0SR95-HL4-211A $148.95

J, K- Fabric Rear Panel ‡‡

Well-made, attractive panels help keep out inclement weather and enhance comfort of occupants.

• Durable Sur Last ® material is water-repellent and provides superb UV and abrasion resistance as well as mold/mildew resistance

• Zippered vinyl window rolls up to increase airflow thru cab

• Polished vinyl window is resistant to cracking in extreme cold

• Must be used with Windscreens or Windshields and Hard or Fabric Roofs

J 2016-23 5P 0SR95-HL4-211B $139.95

K 2022-23 3P 0SR95-HL4-206B $148.95

WINCH/PLOW/TOWING

A, B- Winch

The WARN ® VRX 45 features 4,500 lb. pulling capacity, a heavy duty contactor and robust new clutch design.

• Smooth and reliable all-metal three-stage planetary gear train

• Load holding brake

• Limited lifetime warranty by WARN

• Requires Honda Accessory Winch Mount Kit

A Winch

08L71-HL3-A43 $524.95 Winch Mount Kit (2017-2023) 08L72-HL4-AK1 $391.95

B Winch Mount Kit (2016) 08L72-HL4-A04 $299.95

C, D, E- Plow Blade

Designed for your Honda with unique Pioneer logo stamping and graphics. Made from thick, 15-gauge steel with heavy-duty formed reinforcements and center cross tube for added structural rigidity for extra support.

• Blade is 72" wide and 17" high and is powder coated for durability and corrosion resistance

• Features progressive radius design for more effective snow rolling

• Thick reversible wear bar and adjustable plow skids to control plowing height of the blade

• Requires Honda Accessory Plow Push Tube and Plow Mount Kit

• Requires lifting device such as Honda Accessory Winch/Winch Mount Kit

C Plow Blade 72" 0SL76-HL4-A00 $598.95

D Plow Push Tube 0SL70-HL4-A00 $593.95

E Plow Mount Kit

F- Hitch Ball

0SL73-HL4-A00 $292.95

1 7/8" hitch ball. Includes nut and lock washer.

08L90-HL1-100C $14.95

G- Receiver Hitch Plug

Heavy-duty, weather-resistant plastic insert helps keep dirt and water out.

08L76-HL4-A00 $14.95

H- Drawbar

Allows installation of 1 7/8" or 2" hitch ball. 2017-2023 08L90-HL1-100A $44.95

I- Front Bumper/Brush Guard

Strong, steel construction for added vehicle protection.

• Accepts Honda Accessory Lighting with Honda Accessory 45-mm clamp

• Durable-gloss black powder coat adds a stylish finish

• Attaches to factory mount points

• Standard on LE models

2022-23

08P71-HL4-AK0 $434.95

2016-21 08P70-HL4-A00 $434.95

J, K- Rear Bumper

Strong, steel construction for added vehicle protection.

• Durable-gloss black powder coat adds a stylish finish

• Attaches to factory mount points

2022-23

J 5P 08P72-HL4-AK0 $258.95

K 3P 08P70-HL4-AN0 $253.95

L- Fender Flares

Front Fender Flares are designed specifically for your Pioneer, resulting in an integrated, stylish look and a superior fit and finish.

• Constructed of High-Density Polyethylene (HDPE) for long-lasting durability

• Protects your vehicle and passengers from mud, rocks and trail debris

2022-23 08F70-HL4-AK0 $196.95

2016-21 08P70-HL4-F00 $175.95

M, N- A-Arm Guards

Rugged High-Molecular-Weight Polyethylene (HMWPE) construction has a low coefficient of friction—which helps your SxS slide over rocks and obstacles.

• A-Arm Guards are .25" thick and help provide additional protection to the underside of your SxS from impacts and trail hazard

• Quick and easy to install

FRONT (2016-21)

M 0SP74-HL4-200 $199.95

REAR (2016-22)

N 0SP75-HL4-100 $199.95

A, B- Aluminum A-Arm Guards *

Set of two, lightweight 3.2 mm (.126") thick 5052-O brushed aluminum alloy.

• Added protection from trail hazards such as rocks and branches

• Quick and easy to install FRONT

A 2022-23 08P70-HL4-AK0 $240.95 2016-21 08P72-HL4-F00 $263.95 REAR

B 2016-23 08P73-HL4-F00 $265.95

C- Aluminum Skid Plates

2-piece skid plate is made of lightweight 4 mm (.157 ") thick 5052-H32 brushed aluminum alloy.

• Added protection from trail hazards, such as rocks and branches

• Quick and easy to install

2022-23

08P71-HL4-F00* $524.95

08P73-HL4-AK0* $524.95 2016-21

D- Cab Frame Cargo Bag**

Made of durable polyester, the cab frame cargo bag attaches to cab frame with hook-and-loop straps and locking buckles to keep bag secure and items at hand.

• Seven convenient, zippered compartments

• Zipper pulls for easy access

• Not compatible with Hard and Fabric Mid/ Rear Panels

0SL57-HL3-101 $69.95

E- Underdash Storage Pocket

Integrated storage pocket nets help prevent items from coming loose in rough terrain.

• Manufactured from ultrarugged HMWPE (high-molecular-weight polyethylene)

• Designed to provide maximum storage with out obstructing operator/passenger leg room

• Quick and easy access to important items (cell phones, wallet, sunglasses, etc)

08L71-HL4-F00 $124.95

F- Dash Pocket Net

Dash pocket net helps secure items while keeping them within easy reach.

2022-23 0SL60-HL4-A00 $27.95

G, H- Under Seat Storage Box ***

Conveniently fits under driver side front seat with large opening for ease of access.

• Made from injection molded plastic with 18.5 liters of storage volume

• Easy to install

• 08L71-HL4-AK0 not compatible with Powered Subwoofer or Windshield Wiper Washer Kit. 08L70-HL4-FOO not compatible with Heater

G 2022-23 08L71-HL4-AK0 $129.95

H 2017-21 08L70-HL4-F00 $129.95

I- Bed Mat

Tight, contoured fit helps keep mat from slipping and sliding.

• Manufactured from rugged, nonslip, specially vulcanized rubber compound

• Custom designed featuring Pioneer logo.

• Rear Seats cannot be used when Bed Mat is installed

2022-23

I 5P 0SP42-HL4-502 $160.95 3P 0SP42-HL4-202 $194.95

2016-21

J- Bed Liner

Sturdy liner helps protect the Pioneer’s bed and rear seat area from scratches, dents and dings.

• Manufactured from ultrarugged polyethylene—extremely durable

• Molded side slots enable use of partitions

• Allows for easy unloading of dirt or other materials

• Quick installation and removal

• Rear seats cannot be used when Bed Liner is installed

J 0SP43-HL4-203† $378.95 0SP43-HL4-203CA $378.95

K- Carpet Bed Mat

Custom fit to each model, carpet provides a soft bed surface and includes model-specific embroidered Pioneer logo.

• Easy to use fastening system holds carpet in place while allowing use of bed tie downs

• Breathable construction allows for faster drying

• Rear seats cannot be used when installed 2016-21

5P 0SP44-HL4-A50 $99.95

K 3P 0SP44-HL4-A30 $99.95

CARGO/INTERIOR

A- Bed Extender

Strong, durable-gloss black steel bed extender for added bed space.

• Flips forward into the bed allowing tailgate to close when not in use

08L71-HL4-A02 $398.95

B- Front Seat Covers (camo)

Fit over standard front seat/seatback and headrests.

• Quick and easy to install, no special tools required

• Exclusive Honda Phantom Camo® design matches unit camo color

2021-23 0SP32-HL4-A30C $189.95

C- Rear Seat Covers (camo)

Fit over standard rear seat/seatback and headrests.

• Quick and easy to install, no special tools required

• Exclusive Honda Phantom Camo ® design matches unit camo color

2021-23 0SP32-HL3-A40C $139.95

D- Rubber Floor Mat

Tight, contoured fit helps keep mat in place.

• Manufactured from rugged, nonslip, specially vulcanized rubber compound

• Custom designed with Pioneer logo

2022-23 0SP63-HL4-102 $149.95

2016-21 0SP63-HL4-101 $105.95

E- Rearview Mirror *

Rigid mount panoramic mirror provides excellent rear visibility.

• Easily attaches to frame with included hardware

2022-23 0SV05-HL4-300 $99.95

2016-21 0SV05-HL4-201 $102.95

F- Drink Holder

Easy to install, secures to mount points on unit standard doors.

• Accommodates most sized cups, cans and bottles

• Fits left or right rear doors

2016-21 08U70-HL3-A40 $15.95

*Not intended for on-road use.

G- Garmin Tread® Powersport Navigator

Tread is built to withstand extreme terrains, temperatures and weather. It features a 5.5" glove friendly touchscreen with built-in Altimeter, Barometer, Compass and Pitch and Roll gauges. Stay connected to your friends with the Group Ride Radio for up to 20 riders.

• Includes topographic maps of North and Central America, public land boundaries, U.S. Forest Service roads and trails with Motor Vehicle Use Maps

• Includes downloadable high-resolution Birdseye Satellite Imagery via Wi-FiW® directly to Navigator at no extra cost.

• Use the Tread app to sync your waypoints, tracks, routes and collections across devices, plus get easy GPX Import/Export and access to live weather

• Requires Honda Accessory GPS Wire Harness (0SS51-HL4-A00)

G Garmin Tread Powersport Nav.

GPS Wire Harness

H- 20-inch LED Light Bar

0SS50-HL4-A00

$749.95

0SS51-HL4-A00 $22.95

Features 4-watt LED lights producing 5,200 lumens in a dual row combined spot and flood pattern, IP-67 rated for dust and water protection.

• Rugged aluminum powder-coated housing

• Lights draw 4.4 amps of current at 12 volts

• Includes switch and mounting hardware for Honda Hard Roofs

• 2022-23 models require: Fuse Box, Fuse Box Wiring Kit, and Fuse Box and Audio Mount Bracket

• 2016-21 models require: Switch Plate and Volt Meter Wire Harness, and Fuse Box Relocation Bracket (if Winch Mount installed)

• Additional clamps required to mount to Pioneer 1000 standard bumper, Honda Accessory Front Bumper/Brush Guard and cab frame.

0SV31-HL4-A00 $381.95

I- LED Auxiliary Lights

Pair of 4", 3-watt Cree LEDs producing a combined 2,400 lumens in a flood pattern., IP68 rated—waterproof and submersible.

• Rugged aluminum powder-coated housing,

• Includes mounting hardware to Honda Accessory windshield and switch

• Additional Honda Accessory (45-mm) clamps required for mounting to Pioneer 1000 standard bumper, Honda Accessory Bumper or cab frame

• Requires Honda Accessory Switch Plate/Volt Meter/Wire Harness

0SV41-HL3-A10 $320.95

J- LED Headlights

Stylish, high-intensity, direct illumination LED headlights are IP-67 rated and provide excellent performance for varied riding conditions

• High/Low Beam Specifications: Raw Output — 1,400/800 Lumens

Effective Output — 897/506 Lumens Amp Draw — 1.6A/1.0A @ 12.8VDC

• 4,500K lamp conforms to SAE J1623 headlight specifications.

• Requires Honda Accessory LED Headlight Wire Harness

J LED Headlights 08V70-HL4-AK0 $399.95

2022-23 LED Headlight Wire Harness 08V70-HL4-AQ0 $25.95

2016-21 LED Headlight Wire Harness 33130-HL4-A10 $19.75

ELECTRICAL

A- Light Bar/Auxiliary Lights 45-mm Clamp

Fits lower tubes of Pioneer 1000 standard bumper, Honda Accessory Front Bumper/Brush Guard and cab frame.

0SV31-HL4-201A $29.95

B- Heater (2022-23)

Features 3-speed fan with temperature control that allows maximum heat output in cold climates and cool ambient air in warmer climates.

• Multi-zone mode control allows user to direct air flow to areas needed most including windshield, body and floor

• Includes all mounting hardware, templates and heater controls.

• Requires Honda Accessory Fuse Box, Fuse Box & Audio Mount Bracket and Fuse Box Wiring Kit.

2022-23 0SE08-HL4-A00 $999.95

C- Heater (2016-21)

Custom fit heater helps keep occupants more comfortable in cold weather.

• High-efficiency 153-CFM blower delivers maximum warmth

• 6 adjustable vents with 2-speed fan switch

• Includes all mounting hardware and switch

• Underseat Storage Box is not compatible with Heater installation

• Requires Honda Accessory Switch Plate/Volt Meter/Wire Harness

2016-21 0SE01-HL4-102 $779.95

D- Switch Plate/Volt Meter Wire Harness (2016-21)

Designed specifically for your Pioneer the all-in-one system consolidates your Honda Accessory electrical needs into a single source.

• Switch Plate mounts conveniently on dash, accommodates four Honda accessories

• Precision Volt Meter monitors power usage, includes customizable hi/low settings

• Included fuse box mounts conveniently under the hood, switches not included

• Fuse Box Relocation Bracket necessary when used with Winch Mount

E- Horn Kit

• Requires Honda Accessory Horn Kit Wire Harness E

F- Back-Up Alarm *

Automatically activates a loud beep whenever Pioneer is put into reverse.

• Requires Honda Accessory Back-Up Alarm Mount

F Back-Up Alarm 08V70-HL5-A00 $39.95 Back-Up Alarm Mount 08Z76-HL4-A00 $29.95

G- Audio System

SSV Works Audio System is powered by a 50 watt x 4 channel amplifier.

• Includes two 6.5" 195 watt 2-way coaxial Powersports Speakers, weatherproofed & ruggedized for the outdoors with 25mm Titanium Tweeters for ultra-bright highs

• Molded front speaker kick panels optimize sound quality without compromising legroom

• On-dash media controller features Bluetooth, Aux -input, AM, FM with a large, bright LED backlit display and a Direct-Fit dash kit.

• Plug & Play installation

• Requires: Honda Accessory Fuse Box and Audio Mount Bracket

0SS22-HL4-A00 $744.95

H- Rear Speaker Pods

Two, SSV Works custom molded, Cage Mount Pods include two 6.5" 195 watt, 2-way coaxial Powersports Speakers with 25mm Titanium Tweeters for ultra bright highs

• Weatherproofed and ruggedized for the outdoors

• Requires Honda Accessory Rear Speaker Mount Kit for installation

0SS22-HL4-A40 $349.95

I- Rear Speaker Mount Kit

Easy to install clamp system allows for full 360 ̊speaker pod adjustability while on the cage.

• Includes Plug and Play extension harness, stainless steel mounting hardware and step-by-step installation instructions

• Required for Honda Accessory Rear Speaker Pods

0SS23-HL4-A00 $99.95

J- Powered Subwoofer (2022-23)

Features a custom molded SSV Works subwoofer enclosure that holds an SSV 10" subwoofer and a built-in internal amplifier.

• Amplifier is pre-tuned with a maximum power rating of 500 watts

• Includes all necessary wires and brackets

• Not compatible with Under Seat Storage Box (08L71-HL4-AK0)

• Requires: Honda Accessory Audio System, Fuse Box, Fuse Box Audio Mount Bracket, and Fuse Box Wiring Kit

0SS22-HL4-A50 $679.95

ELECTRICAL/SUSPENSION

A- Fuse Box

New design supports up to eight accessories.

• 4 switch outputs with one wiper/washer output

• 3 constant power auxiliary outputs

• Rated at 80 amps

• Requires: Honda Accessory Fuse Box and Audio Mount Bracket, and Fuse Box Wiring Kit

2022-23 0SS25-HL4-A00 $210.95

B- Fuse Box and Audio Mount Bracket

This Mount Bracket can be used for only the Accessory Fuse Box, or for both the Fuse Box and the Accessory Audio System amplifier.

• Includes all necessary hardware

• Required for installation of Honda Accessory Fuse Box

2022-23 0SS27-HL4-A00 $54.95

C- Fuse Box Wiring Kit

For use with Honda Accessory Fuse Box, allowing for the installation of electrical accessories.

• Provides wiring and connectors

2022-23 0SS26-HL4-A00 $82.95

D- Accessory Wiring Connector

For use on electrical accessories that do not use the same connectors as the Accessory Fuse Box. Provides a replacement connector that is designed to work with the Accessory Fuse Box.

• Includes two connectors

2022-23 0SZ05-HL6-A00 $29.95

E- Load Leveling Suspension System *

A mechanical hydraulic system that seamlessly adjusts automatically while you drive. Maintains rear ride height with changing loads.

• Maximizes ride comfort

• Helps keep vehicle handling consistent

E 2017-2021 08Z70-HL4-M50 $699.95 2016 08Z70-HL4-A51 $699.95 (Not shown.)

F, G- Fox® Shocks **

Valved exclusively for Honda 1000/1000-5. Helps smooth your ride and improve handling. Comes with three-position compression damping adjustment—Soft, Medium and Firm. Easily tune the machine for the terrain or your driving style—from comfort-focused to firm—with a simple turn of the dial. Standard on Trail Models.

• Must be installed as a front and rear set on non-California units

F 5P Front (PR)

G 5P Rear (PR)

3P Front (PR)

3P Rear (PR)

08Z70-HL4-F00† $849.95

08Z71-HL4-F00†† $879.95

08Z70-HL4-F50† $849.95 (Not shown.)

08Z71-HL4-F50†† $879.95 (Not shown.)

H- Flag with Mount

• Does not apply to Pioneer 3P with Hard or Fabric Rear Panel

0SR95-HL4-F10 $57.95

I- Storage Cover

Weather-resistant synthetic material and taped seams help keep your Pioneer 1000 protected and dry.

• Side zippers allow cab access without removing the cover

• Fits with or without Honda Accessories

• Includes handy storage pouch

I 2022-23 5P 0SP34-HL4-101 $179.95

2022-23 3P 0SP35-HL4-101 $148.95 (Not shown.)

2016-21 5P 0SP34-HL4-100 $179.95 (Not shown.) 2016-21 3P 0SP35-HL4-100 $148.95 (Not shown.)

5P Front

5P Rear G F F

PIONEER ®

Hard Front Doors B. Garmin TREAD Powersport Navigator C. Bed Light/Outlet Kit D. Aluminum Front A-Arm Guards E. Drink Holder

ROOFS

A- Hard Roof * ‡‡ (extended)

Compatible with Honda Pioneer 700 Accessory windscreens. Hard Roof covers front and rear seating areas of 4P Pioneer.

• Manufactured from ultrarugged polyethylene—extremely durable

• Superior weather protection

• Styled to integrate with vehicle design

• Uses Honda Tool-Less Clamp system

• Includes mount points for Honda Accessory Light Bar

• Quick installation and removal

2014-2024

0SR85-HL3-100 $632.95

B- Hard Roof * ‡‡ (short)

Designed to fit over cab area of 2P Pioneer. Hard Roof is compatible with all Honda Accessory windscreens.

• Manufactured from ultrarugged polyethylene—extremely durable

• Superior weather protection

• Styled to integrate with vehicle design

• Includes mount points for Honda Accessory Light Bar

• Quick-release attachment, installs in minutes without tools

2014-2024

0SR85-HL3-101 $429.95

C- Hard Roof * ‡‡ (short)

Designed to fit over front forward cab area of 4P Pioneer. Hard Roof is compatible with all Honda Accessory windscreens. (Shown with Fabric Roof/Rear Panel rear section.)

• Manufactured from ultrarugged polyethylene—extremely durable

• Superior weather protection

• Styled to integrate with vehicle design

• Includes mount points for Honda Accessory Light Bar

• Quick-release attachment, installs in minutes without tools

2014-2024

0SR85-HL3-101B $430.95

D- Fabric Roof/Rear Panel ‡‡ (rear section)

Designed to work with Hard Roof (short) OSR85-HL3-101B. One-piece design delivers superior performance in harsh conditions.

• Constructed of durable Sur Last ® material for maximum water repellence and excellent UV resistance as well as abrasion and mold and mildew resistance

• Fiber rods create a tight, custom fit to the roof while promoting water runoff

• Rear panel rolls up to increase airflow through cab

• Polished vinyl window resists cracking in extreme cold

• Rear fabric doors not included

• Requires Honda Accessory Hard Roof (short) 4P, 0SR85-HL3-101B 2014-2024

0SR85-HL3-223B $229.95

‡‡ NOTICE: Do not tow any Pioneer on an open trailer with any of the following Honda Genuine or Signature Accessories installed: Hard, Fabric or Bimini Roofs, Poly Windscreens/Wind Deflectors, Fabric Doors and Fabric Panels.These Honda Accessories are not designed for use at highway speeds. Open trailering a Pioneer at highway speed with these accessories installed may damage them or the vehicle.

* Weight of cab system components may increase risk of vehicle rollover.

** Available for Deluxe models only.

E, F- Fabric Roof/Rear Panel

‡‡ (black)

For superior performance in harsh conditions.

• One-piece roof is constructed of durable Sur Last ® material for maximum water repellence and excellent UV resistance as well as abrasion resistance

• Mold/mildew-resistant

• Fiber rods create a tight, custom fit to the roof while promoting water runoff

• Rear panel rolls up to increase airflow through cab

• Polished vinyl window resists cracking even at temperatures as low as -30°F

• Requires Honda Accessory Full Poly Windscreen, 08R73-HL3-A00 or OSR73-HL3-200 or 2-Piece Poly Windscreen, 08R72-HL3-A00 or OSR72-HL3-100

E 2014-2024

G, H- Fabric Roof/Rear Panel

** ‡‡ (camo)

For superior performance in harsh conditions.

• One-piece design is made of durable 600-denier fabric for superior performance

• UV fade-resistant

• DWR (durable-water-repellent) for maximum water repellency

• Fiber rods create a tight, custom fit to the roof while promoting water runoff

• Exclusive Honda Phantom Camo® design matches unit camo color

• Requires Honda Accessory Full Poly Windscreen or 2-Piece Poly Windscreen (either hard coat or optical)

G 2022-2024 4P

I- Bimini Top ‡‡

Durable top shuns the sun and helps protect occupants from harsh exposure.

• Sur Last ® material is water-repellent and provides superb UV and abrasion resistance as well as mold/mildew resistance

• Designed to fit over front forward cab area

• Quick and easy to install

• Not compatible with Honda Fabric Doors, Hard Doors and Windscreen/Windshield accessories

J- Bimini Top ‡‡

Durable top shuns the sun and helps protect occupants from harsh exposure.

• Sur Last ® material is water-repellent and provides superb UV and abrasion resistance as well as mold/mildew resistance

• Designed to fit over entire cab area

• Quick and easy to install

• Not compatible with Honda Fabric Doors, Hard Doors and Windscreen/Windshield accessories 2014-2024 Black 0SR85-HL3-323A $182.95

WINDSHIELD/WINDSCREENS

A- Glass Windshield *

Top-quality ASI laminated safety glass offers protection from wind, dust and trail debris while providing a more comfortable driving experience.

• Uses Honda Tool-Less Clamp system

• Quick installation and removal

• Shown with Honda Accessory Wiper Kit

• Does not fit with fabric tops

2014-2024 0SU95-HL3-A00 $999.95

B- Glass Windshield Wiper Kit and Washer*

Includes a windshield wiper and a washer reservoir to provide the ability to clean your windshield.

• Kit contains all necessary installation parts

• Requires: Honda Accessory Glass Windshield, Fuse Box, Fuse Box and Audio Mount Bracket and Fuse Box Wiring Kit. Not compatible with Under Seat Storage Box or Powered Subwoofer.

0SE10-HL3-A00 $516.95

Glass Windshield Wiper Kit *

Add a measure of convenience with wipers that integrate seamlessly only with Honda Accessory Glass Windshield.

• Requires installation of accessory Switch Plate/Volt Meter/ Wire Harness

2016-2021 0SE10-HL3-500 $311.95 (Not shown.)

C- Full Poly Windscreen * ‡‡ (hard coat) **

Premium hard coating helps protect windscreen against scratches, promotes longer life.

• Optical-grade polycarbonate construction enhances visual clarity

• Noncracking, nonyellowing material for excellent impact resistance

• Modular design for a variety of vehicle configurations

• Uses Honda Tool-Less Clamp system

• Quick installation and removal

• Not compatible with Bimini Tops

2014-2024 08R73-HL3-A00 $567.95

D- Full Poly Windscreen * ‡‡ (optical) **

Optical-grade polycarbonate.

• Noncracking, nonyellowing material for excellent impact resistance

• Modular design for a variety of vehicle configurations

• Custom, screen-printed graphics complement vehicle styling

• Uses Honda Tool-Less Clamp system

• Quick installation and removal

• Not compatible with Bimini Tops

2014-2024 0SR73-HL3-200 $448.95

WINDSCREENS/WIND

E- 2-Piece Poly Windscreen * ‡‡ (hard coat) **

Premium hard coating helps protect windscreen against scratches, promotes longer life on upper portion of windscreen.

• Two-piece pivoting windscreen allows for increased airflow.

• Optical-grade polycarbonate construction enhances visual clarity

• Noncracking, nonyellowing material for excellent impact resistance

• Quick installation and removal

• Not compatible with Bimini Tops

2014-2024

0SR72-HL3-A00 $693.95

F- 2-Piece Poly Windscreen* ‡‡ (optical) **

Two-piece pivoting windscreen allows for increased airflow while optical-grade polycarbonate enhances visual clarity.

• Noncracking, nonyellowing material for excellent impact resistance

• Modular design for a variety of vehicle configurations

• Custom, screen-printed graphics complement vehicle styling

• Uses Honda Tool-Less Clamp system

• Quick installation and removal

• Not compatible with Bimini Tops and Hard Front Doors OSU95-HL3-104A or 0SU90-HL3-A00

2014-2024 0SR72-HL3-100 $517.95

G- Half Wind Deflector * ‡‡

Adds protection from dust, dirt and debris without sacrificing airflow.

• Optical-grade polycarbonate construction enhances visual clarity

• Noncracking, nonyellowing material for excellent impact resistance

• Modular design for a variety of vehicle configurations

• Custom, screen-printed graphics complement vehicle styling

• Uses Honda Tool-Less Clamp system

• Quick installation and removal

2014-2024 08R71-HL3-A00 $217.95

‡‡ NOTICE: Do not tow any Pioneer on an open trailer with any of the following Honda Genuine or Signature Accessories installed: Hard, Fabric or Bimini Roofs, Poly Windscreens/Wind Deflectors, Fabric Doors and Fabric Panels.These Honda Accessories are not designed for use at highway speeds. Open trailering a Pioneer at highway speed with these accessories installed may damage them or the vehicle.

DOORS

A- Hard Front Doors *

Heavy-duty doors with automotive-style locking push-button handles and latches add security and convenience. Manufactured from ultrarugged polyethylene.

• Tempered glass, sliding windows help increase airflow

• Styled to integrate with vehicle design

• Works in a variety of vehicle configurations

• Accepts Honda Accessory Side Mirrors

• Includes right and left doors

• Quick installation and removal

• Use with Glass Windshield or 2-Piece Hard Coat Poly Windscreen

• Side Mirror Brackets must be used when mounting Side Mirrors to Hard Front Doors 0SU95-HL3-104A

A 2023-2024 0SU90-HL3-A00 $3,366.95 2017-2022 0SU95-HL3-104A $3,154.95

B, C- Fabric Front Doors

‡‡ (black & camo)

Precision-manufactured aluminum door frames are lightweight and attractive and integrate easily with standard half doors.

• Durable Sur Last ® material is waterrepellent and provides superb UV and abrasion resistance as well as mold/mildew resistance

• Double-zippered vinyl windows roll down to increase airflow through cab

• Polished vinyl windows are resistant to cracking in extreme cold

• Includes right and left doors

• Quick installation and removal BLACK

B 2023-2024 0SU92-HL3-A00 $599.95 2017-2022 0SR91-HL3-211A $572.95 CAMO

C 2023-2024

‡‡ NOTICE: Do not tow any Pioneer on an open trailer with any of the following Honda Genuine or Signature Accessories installed: Hard, Fabric or Bimini Roofs, Poly Windscreens/Wind Deflectors, Fabric Doors and Fabric Panels. These Honda Accessories are not designed for use at highway speeds. Open trailering a Pioneer at highway speed with these accessories installed may damage them or the vehicle.

* Weight of cab system components may increase risk of vehicle rollover.

D, E- Fabric Rear Doors

‡‡ (black & camo)

Precision-manufactured aluminum door frames are lightweight and attractive and integrate easily with standard half doors.

• One-piece design is made of durable 600-denier fabric for superior performance

• UV fade-resistant

• DWR (durable-water-repellent) for maximum water repellency

• Fiber rods create a tight custom fit to the roof while promoting water runoff

• Exclusive Honda Phantom Camo ® design matches unit camo color

D 2014-2022 4P Black 0SR91-HL3-211B $524.95

E 2021-2022 4P Camo 0SR92-HL3-241C $554.95 2014-2016 4P Camo 0SR90-HL3-211C $399.95

F- Side Mirrors **

Adjustable mirrors work with hard doors or as a stand-alone mirror kit.

• Mirrors attach with Honda Quick-Release clamps when used without Honda Accessory Hard Doors

• Not compatible with Fabric Front Doors

• Mirror Brackets must be used with Side Mirrors when mounted on Hard Doors 0SU95-HL3-104A

2014-2024

0SV05-HL5-100 $163.95

G- Side Mirror Brackets **

• Side Mirror Mounting Brackets required when installing Side Mirrors on Hard Front Doors. OSU95-HL3-104A

2017-2022

0SV10-HL3-200 $47.95

H- Hard Mid/Rear

Panel

*

Integrates with Honda A ccessory Hard Roof on Pioneer 4P.

• Manufactured from ultrarugged polyethylene—extremely durable

• Modular design integrates seamlessly with other Honda Accessory cab components

• Tempered glass, vented sliding window increases airflow

2017-24 Combines with Short Hard Roof 0SU95-HL3-102C $659.95

2017-24 Combines with Extended Hard Roof 0SU95-HL3-104C $707.95

2014-16 Combines with Short Hard Roof 0SU95-HL3-102B $599.95

2014-16 Combines with Extended Hard Roof 0SU95-HL3-104B $599.95

I- Hard Rear Panel

*

Integrates with Honda Accessory Hard Roof on Pioneer 2P.

• Manufactured from ultrarugged polyethylene—extremely durable

• Modular design integrates seamlessly with other Honda Accessory cab components

• Tempered glass, vented sliding window increase airflow

I 2017-2024

0SU95-HL3-102A $692..95 2014-2016 0SU95-HL3-102 $686.95

DOORS/REAR

** Not intended for on-road use.

REAR PANELS/WINCH/PLOW

A- Fabric Mid/Rear Panel ‡‡

Well-made, attractive panels help keep out inclement weather and enhance comfort of occupants.

• Durable Sur Last ® material is water-repellent and provides superb UV and abrasion resistance as well as mold/mildew resistance

• Zippered vinyl window rolls down to increase airflow through cab

• Polished vinyl window is resistant to cracking in extreme cold

2014-2024

0SR95-HL3-211A $126.95

B- Fabric Rear Panel‡‡

Occupants enjoy superior protection from wind and weather.

• Durable Sur Last ® material is water-repellent and provides superb UV and abrasion resistance as well as mold/mildew resistance

• Rear panel rolls up to increase airflow through cab

• Polished vinyl window resists cracking in extreme cold

2014-2024

C- Winch

0SR95-HL3-211B $119.95

The VRX 45 features 4,500 lb. pulling capacity, a heavy duty contactor, robust new clutch design, a load holding brake and a smooth and reliable all-metal three-stage planetary gear train.

• Durable all-metal construction,

• Black powder-coated finish for corrosion resistance

• IP68-rated waterproof sealing to keep the elements out

• Includes 50' of 1/4" steel rope

• Requires Honda Accessory Winch Mount Kit

C 2014-2024 Winch 08L71-HL3-A43 $524.95 2023-2024 Winch Mount Kit 0SL72-HL3-A00

D, E, F- Plow

Designed for your Honda with unique Pioneer logo stamping and graphics, engineered to perform season after season.

• Made from thick, 15-gauge steel with heavy-duty formed reinforcements and center cross tube for added structural rigidity for extra support

• Features progressive radius design for more effective snow rolling

• Thick reversible wear bar and adjustable gravel skids to control plowing level and height of the blade

• Requires Honda Accessory Plow Push Tube, Honda Accessory Plow Mount and lifting device such as Honda Accessory Winch/ Winch Mount Kit

D 2023-2024

G- Drawbar

Allows installation of 1 7/8" or 2" hitch ball.

2014-2024

08L90-HL1-100A $44.95

H- Hitch Ball

1 7/8" hitch ball. Includes nut and lock washer.

2014-2024

08L90-HL1-100C $14.95

Receiver Hitch Plug

Heavy-duty, weather-resistant plastic insert helps keep dirt and water out of hitch receptacle. (Not shown.)

2014-2024

08L76-HL4-A00 $14.95

I, J- Steel Bumpers

Strong, steel construction adds heavy-duty protection for vehicle front and rear.

• Durable-gloss black powder coat paint

• Factory mount points

• Quick and easy to install FRONT

I 2014-2024 0SP11-HL3-A00 $499.95 REAR

J 2014-2024 08P75-HL3-A00 $264.95

‡‡ NOTICE: Do not tow any Pioneer on an open trailer with any of the following Honda Genuine or Signature Accessories installed: Hard, Fabric or Bimini Roofs, Poly Windscreens/Wind Deflectors, Fabric Doors and Fabric Panels. These Honda Accessories are not designed for use at highway speeds. Open trailering a Pioneer at highway speed with these accessories installed may damage them or the vehicle.

A- Fender Flares

Front Fender Flares are designed specifically for your Pioneer resulting in an integrated, stylish look and a superior fit and finish.

• Constructed of High-Density Polyethylene (HDPE) for long-lasting durability

• Protects your vehicle and passengers from mud, rocks and trail debris

2014-2024

08P70-HL3-600 $151.95

B- Skid Plates

2-piece skid plate is .25" thick and helps protect the underside of your SxS from impacts and trail hazards.

• High-Molecular-Weight Polyethylene (HMWPE) construction has a low coefficient of friction, which helps your SxS slide over rocks and obstacles

• Uses the OEM attachment hardware

2014-2024

08P71-HL3-601 $279.95

C, D- Aluminum A-Arm Guards

Set of two lightweight, brushed-aluminum plates provide added protection for front and rear drive shafts.

• Added protection from trail hazards, such as rocks and logs

• Quick and easy to install FRONT

C 2017-2024 08P72-HL3-600 $153.95 FRONT 2014-2016 08P73-HL3-A00 $149.95 REAR

D 2014-2024 08P74-HL3-A00 $149.95

E- Cab Frame Cargo Bag*

Attaches to cab frame with hook-and-loop straps and locking buckles to keep bag secure, items at hand.

• Seven convenient, zippered compartments

• Zipper pulls for easy access

• Made of durable polyester

• Not compatible with Hard and Fabric Mid/ Rear Panels

2014-2024 0SL57-HL3-101 $69.95

* Refer to installation instructions for cargo weight capacities.

F- Rear Cab Net

Practical accessory looks good, allowing maximum airflow through the cab.

• No special tools required

• Off-road performance styling

• Quick and easy to install

• Not compatible with Fabric Rear Panels or Fabric Roof/RearPanels

2014-2024

0SR95-HL3-200B $99.95

G- Bed Mat

Tight, contoured fit helps keep mat from slipping and sliding.

• Manufactured from rugged, nonslip, specially vulcanized rubber compound

• Pioneer logo shows pride of ownership

• Rear seats in 4P cannot be used when Bed Mat is installed 2023-2024

4P 0SP42-HL3-202 $169.95 2014-2022

4P 0SP42-HL3-201 $168.95 2014-2022

G 2P 0SP42-HL3-101 $131.95

H- Carpet Bed Mat

Custom fit to each model, carpet provides a soft bed surface and includes model-specific embroidered Pioneer logo.

• Easy to use fastening system holds carpet in place while allowing use of bed tie downs

• Breathable construction allows for faster drying

• Rear seats in 4P cannot be used when carpet bed mat is installed 2014-2022

4P 0SP44-HL3-A40 $99.95

2P 0SP44-HL3-A20 $99.95

I- Bed Extender

Strong, durable-gloss black steel bed extender for added bed space.

• Flips forward in the bed allowing tailgate to close when not in use

• Gloss-black, powder-coat paint adds a stylish, durable finish

• Quick and easy to install

2014-2024

08L74-HL3-A41 $249.95

CARGO/INTERIOR

A- Poly Bed Liner

Sturdy liner helps protect the Pioneer’s bed and rear seat area from scratches, dents and dings.

• Manufactured from ultrarugged polyethylene—extremely durable

• Molded side slots enable use of partitions

• Allows for easy unloading of dirt and other materials

• Quick installation and removal

• Rear seats cannot be used when Bed Liner is installed. Does not fit Pioneer 700-4 Deluxe or Forest.

A 2017-2024 0SP43-HL3-102 $328.95 2014-2016 0SP43-HL3-101 $229.95

B- Rearview Mirror *

Panoramic mirror provides excellent rear visibility.

• Secure and rigid mount

• Uses Honda Tool-Less Clamp system

• Quick installation and removal

2014-2024

0SV05-HL5-201 $92.95

C- Rear Drink Holder

Easy to install, secures to mount points on unit standard doors.

• Accommodates most sized cups, cans and bottles

• Fits left or right rear doors 2014-2024

08U70-HL3-A40 $15.95

D- Underdash Storage Tray

Integrated storage pocket nets help prevent items from coming loose in rough terrain.

• Manufactured from ultrarugged HMWPE (high-molecular-weight polyethylene)

• Designed to provide maximum storage without obstructing operator/passenger legroom

• Quick and easy access to important items (cell phones, wallet, sunglasses, etc) 2014-2022 08L73-HL3-A41 $299.95

E- Rubber Floor Mat

Tight, contoured fit helps keep mat in place.

• Manufactured from rugged, nonslip, specially vulcanized rubber compound

• Pioneer logo shows pride of ownership 2023-2024 0SP63-HL3-102 $99.95 2014-2022 0SP63-HL3-101 $82.95 E

* Not intended for on-road

F- Front Seat/ Headrest Covers (camo)

Fit over standard front seat/seatback and headrests.

• Quick and easy to install, no special tools required

• Polyester fabric with a UV-resistant urethane coating

2021-2024

0SP32-HL3-A20C $220.95

G- Rear Seat/ Headrest Covers (camo)

Fit over standard rear seat/seatback and headrests.

• Quick and easy to install, no special tools required

• Polyester fabric with a UV-resistant urethane coating

2021-2024

H- Heater

0SP32-HL3-A40C $139.95

Features 3-speed fan with temperature control that allows maximum heat output in cold climates and cool ambient air in warmer climates.

• Multi-Zone Mode control allows user to direct air flow to areas needed most including windshield, body and floor

• Includes all mounting hardware, templates and heater controls

• Requires installation of Honda Accessory Busbar Kit, Fuse Box and Fuse Box Wiring Kit

2023-2024

0SE02-HL3-A00 $899.95

ELECTRICAL

A- Heater

Custom-fit heater helps keep occupants comfortable in cold weather.

• High-efficiency 153-CFM blower delivers maximum warmth

• Four adjustable vents, two dash/two floor

• Includes 2-speed fan switch

• Includes all mounting brackets and hardware

• Requires Honda Accessory Switch Plate/Volt Meter/Wire Harness

2014-2022

0SE01-HL3-104 $549.95

B- Garmin Tread® Powersport Navigator

Tread is built to withstand extreme terrains, temperatures and weather. It features a 5.5" glove friendly touchscreen with built-in Altimeter, Barometer, Compass and Pitch and Roll gauges. Stay connected to your friends with the Group Ride Radio for up to 20 riders.

• Includes topographic maps of North and Central America, public land boundaries, U.S. Forest Service roads and trails with Motor Vehicle Use Maps

• Includes downloadable high-resolution Birdseye Satellite Imagery via Wi-FiW® directly to Navigator at no extra cost.

• Use the Tread app to sync your waypoints, tracks, routes and collections across devices, plus get easy GPX Import/Export and access to live weather

• Requires Honda Accessory GPS Wire Harness (0SS51-HL4-A00)

0SS50-HL4-A00 $749.95

C- 20-inch LED Light Bar

Features 4-watt LED lights producing 5,200 lumens in a dual row combined spot and flood pattern, IP-67 rated for dust and water protection.

• Rugged aluminum powder-coated housing

• Lights draw 4.4 amps of current at 12 volts

• Includes switch and mounting hardware for Honda Hard Roofs.

• 2023-24 models require: Honda Accessory Busbar Kit (0SS27-HL3-A00), Fuse Box (0SS25-HL4-A00) and Fuse Box Wiring Kit (0SS26-HL3-A00)

• 2014-22 models require: Honda Accessory Switch Plate /Volt Meter/ Wiring Harness (0SA30-HL3-100)

0SV31-HL4-A00 $381.95

D- LED Auxiliary Lights

Kit includes 2 lights and switch, features a 40°#8451; flood beam that produces 2650 lumens per light.

• Heavy duty metal casing

• Each LED is rated at 10 watts for a total output of 20 watts per light

• Requires Honda Accessory Mounting Clamps (sold separately). Clamp size based on desired mounting location.

0SV41-HL3-A10 $320.95

E- LED Headlights

Stylish, high-intensity, direct illumination LED headlights are IP-67 rated and provide excellent performance for varied riding conditions

• High/Low Beam Specifications: Raw Output — 1,400/800 Lumens Effective Output — 897/506 Lumens Amp Draw — 1.6A/1.0A @ 12.8VDC

• 4,500K lamp conforms to SAE J1623 headlight specifications.

• Requires Honda Accessory LED Headlight Wire Harness

2017-2024

08V70-HL4-AK0 $399.95

LED Headlight Wire Harness

• Required for installation of LED Headlight

2023-2024

08Z70-HL3-B40 $99.95 (Not shown.) 2017-2022

0SV15-HL3-A00 $99.95 (Not shown.)

F/G- Work Light

Handy 10-watt Cree LED light produces 1,000 lumens in a flood pattern and provides exceptional performance with minimal battery draw.

• Adjustable pedestal mount

• Protected in a rugged aluminum black powder-coated housing and polycarbonate lens

• IP68 rated—waterproof, submersible

• Requires Honda Accessory Sub Harness and Work Light Mount Kit

F 2017-2022 Work Light 08U71-HL5-A00 $149.95

G 2017-2022 Work Light Mount 08Z71-HL3-600 $142.95

H- Bed Light/Outlet Kit

Provides lighting in the bed area for increased visibility of your gear when its dark out.

I- Dome Light

Provides the convenience of a weatherproof light to your interior.

• Consists of 6 warm white LEDs rated 300 Lumens with easy to use on/off button

• Fits 1.75" and 2" tube sizes

• Plugs easily into Honda Accessory Fuse Box

• Requires: Honda Accessory Fuse Box, Fuse Box Mount and Busbar 2023-2024

0SV51-HL6-A00 $79.95

ELECTRICAL

A- Busbar Kit

Features 3 positions for Power and 3 positions for Ground distribution.

• Rated at 300A

• Hardware is corrosion resistant and easy to install

• Provides relocation for WARN winch contactor

2023-2024

0SS27-HL3-A00 $122.95

Busbar Cable

• Required for Busbar when VRX Winch is installed.

2023-2024

0SL25-HL3-A00 $29.95 (Not shown.)

B- Fuse Box

New design supports up to eight accessories.

• 4 switch outputs with one wiper/washer output

• 3 constant power auxiliary outputs

• Rated at 80 amps.

2023-2024

0SS25-HL4-A00 $210.95

C- Fuse Box Wiring Kit

Includes all the necessary wiring for the Honda Accessory Fuse Box.

• Plug & Play installation

• Optional pigtails sold separately

• Requires: Honda Accessory Fuse Box and Busbar Kit.

2023-2024

0SS26-HL3-A00 $92.95

D- Accessory Wiring Connector

For use on electrical accessories that do not use the same connectors as the Accessory Fuse Box. Provides a replacement connector that is designed to work with the Accessory Fuse Box.

• Includes two connectors

2023-2024

0SZ05-HL6-A00 $29.95

E- Switch Plate/Volt Meter/ Wiring Harness

• All-in-one system consolidates your Honda Accessory electrical needs into a single source

• Switch plate mounts conveniently on dash, accommodates 4 Honda Accessories

• Precision Volt Meter monitors power usage, includes customizable hi/low settings

• Plug-and-play wire harness designed specifically for your Pioneer for quick, easy installation

• Included fuse box mounts conveniently under the hood

• Does not include switches

2014-2022

0SA30-HL3-100 $299.95

F- Back-Up Alarm *

Automatically activates a loud beep whenever Pioneer is put into reverse.

• Requires Honda Accessory Sub-Harness (08Z02-HL3-A00)

2017-2024

2014-2016

0SV70-HL5-A00 $39.95

08V70-HL3-A01 $89.95

Back-Up Alarm Mount Kit

• Required for installation of Back-Up Alarm

2017-2024

08Z73-HL3-600 $14.95 (Not shown.)

G- Horn Kit

Easy-to-install horn assembly.

• 2017-2022 Horn Kit requires Accessory Sub Harness 08Z01-HL3-600,

• 2015-2016 Horn Kit requires Accessory Sub Harness 08Z02-HL3-A00,

2023-2024

2015-2022

0SV09-HL3-A00 $99.95

0SP72-HL3-A00 $93.95

Accessory Sub Harness

• Required for installation of Honda Accessory Horn Kit (2015-2016) and/or Honda Accessory Back-Up Alarm

08Z02-HL3-A00 $10.95 (Not shown.)

Accessory Sub Harness

• Required for installation of Honda Accessory Horn Kit (2017-2022) and/or Honda Accessory Work Light

08Z01-HL3-600 10.95 (Not shown.)

H- Storage Cover

Weather-resistant synthetic material and taped seams help keep Pioneer protected and dry.

• Side zippers allow cab access without removing the covers

• Honda and Pioneer logos show pride of ownership

• Includes handy storage pouch

• Accommodates all accessories except for Flag and Front Bumper

H 2023-2024 4P 0SP34-HL3-A00 $179.95 2014-2022 4P 0SP34-HL3-100 $169.95 2023-2024 2P 0SP35-HL3-A00 $170.95 2014-2022 2P 0SP35-HL3-100 $134.95

PIONEER ®

A. Bed Rails

B. Front Underhood Tray

C. LED Auxillary Lights

D. Aluminum Rear A-Arm Guards

E. Mutli-Tool Holder

B A

ROOFS/TOPS/WINDSCREENS

A- Hard Roof *‡‡

Compatible with Honda Pioneer 520 Accessory Windscreens, includes mount points for Honda Accessory Light Bar.

• Outstanding weather protection

• Utilizes Honda Tool-Less clamp system for quick installation, quick removal

• Manufactured from ultrarugged, extremely durable HMWPE (high-molecular-weight polyethylene)

08R70-HL5-A01 $413.95

B- Fabric Roof/Rear Panel ‡‡

One-piece design is made of durable fabric for superior performance. Fabric is fade resistant and water repellant.

• Double zippered window rolls-up, increasing airflow through the cab.

• Polished vinyl window is resistant to cracking in extreme cold.

• Quick installation and removal

• Features exclusive Honda Phantom Camo pattern

• Requires Honda Accessory Full Poly Tip-Out Windscreen (hard coat or optical)

B Black 0SR85-HL5-A01B $296.95

Camo 0SR85-HL5-A02C $346.95

C- Bimini Top ‡‡

Made of durable fabric for superior performance in harsh conditions.

• Features exclusive Honda Phantom Camo pattern.

• Not compatible with Honda Fabric Doors and Windscreen/ Windshield accessories

Camo 0SR85-HL5-321C $155.95

D- Full Poly Tip-Out Windscreen *‡‡ (hard coat) **

Constructed of optical-grade polycarbonate with premium hard coating for optimal scratch resistance.

• Noncracking, nonyellowing material for excellent impact resistance

• Fully adjustable windscreen tips out allowing for increased airflow

• Utilizes Honda Tool-Less Clamp system for quick installation, quick removal

• Modular design works with either Honda Accessory Hard Roof's or Fabric Roof's configurations

08R74-HL5-A01 $647.95

‡‡ NOTICE: Do not tow any Pioneer on an open trailer with any of the following Honda Genuine or Signature Accessories installed: Hard, Fabric or Bimini Roofs, Poly Windscreens/Wind Deflectors, Fabric Doors and Fabric Panels.These Honda Accessories are not designed for use at highway speeds. Open trailering a Pioneer at highway speed with these accessories installed may damage them or the vehicle.

Shown on Pioneer 500.

**

E- Full Poly Tip-Out Windscreen * ‡‡ (optical)

Constructed of optical-grade polycarbonate.

• Noncracking, nonyellowing material for excellent impact resistance

• Windscreen tips out allowing airflow to driver and passenger. Fully adjustable

• Modular design works with either Honda Accessory Hard Roof or Fabric Roofs

• Utilizes Honda Tool-Less Clamp system for quick installation, quick removal

• Custom screen-printed graphics complement vehicle styling

0SR73-HL5-100 $502.95

F- Half Wind Deflector *‡‡

Constructed of optical-grade polycarbonate.

• Noncracking, nonyellowing material, excellent impact resistance

• Utilizes Honda Tool-Less Clamp system for quick installation, quick removal

• Custom screen-printed graphics complement vehicle styling

0SR73-HL5-101B $161.95

G- Fabric Doors † ‡‡

Features full fabric door design with formed A-pillar cover for improved fit and finish.

• Made of durable fabric for superior performance in harsh conditions

• Fabric is fade resistant and water repellant.

• Driver side door had outside zippered access to bed release lever.

• Requires Honda Accessory Hard Roof and Fabric Rear Panel or Fabric Roof/Rear Panel

G Black 0SR90-HL5-A01B $641.95 Camo 0SR90-HL5-A01C $691.95

REAR PANEL/WINCH/PLOW

A- Fabric Rear Panel ‡‡

Made of durable fabric for superior performance in harsh conditions.

• Fabric is fade resistant and water repellant

• Window rolls-up, increasing airflow through the cab

• Polished vinyl window is resistant to cracking in extreme cold

• Quick installation and removal

0SR95-HL5-A01 $146.95

B- Winch

The VRX 25 features 2,500 lb. pulling capacity, a heavy duty contactor, robust new clutch design, a load holding brake and a smooth and reliable all-metal three-stage planetary gear train.

• Durable all-metal construction

• Black powder-coated finish for corrosion resistance

• IP68-rated waterproof sealing to keep the elements out

• Limited lifetime warranty

• Requires Honda Accessory Winch Mount Kit (08L70-HL5-E60) and Honda Accessory Sub-Harness (08Z08-HL5-A00)

08L71-HL5-E61 $431.95

Winch Mount Kit

• Required for Honda Accessory Winch

08L70-HL5-E60 $433.95 (Not shown.)

C- Plow Blade (60")

Designed for your Honda Pioneer with unique Pioneer logo stamping and graphics. Made from thick, 15-gauge steel with heavy-duty formed reinforcements and center cross tube for added structural rigidity for extra support.

• Blade is 60" wide and 17" high

• Powder coated for durability and corrosion resistance

• Features progressive radius design for more effective snow rolling

• Thick reversible wear bar and adjustable plow skids to control plowing height of the blade

• Requires Honda Accessory Plow Push Tube, Plow Mount, Winch and Winch Mount Kit.

0SL76-HL5-A00 $351.95

D- Plow Push Tube

Designed for your Honda with special Pioneer graphics.

• Durable construction, engineered to perform season after season

• Features heavy-duty 3" trip springs

• Easy to reach angulation handle allows blade to be set at five different positions (±25°/±12.5°/0°)

• 4-position adjustable attack angle block.

• Features a Quick Connect system for easy installation and removal of plow in seconds.

• Requires Honda Accessory Plow Blade and Honda Accessory Plow Mount

0SL70-HL5-A00 $435.95

‡‡ NOTICE: Do not tow any Pioneer on an open trailer with any of the following Honda Genuine or Signature Accessories installed: Hard, Fabric or Bimini Roofs, Poly Windscreens/Wind Deflectors, Fabric Doors and Fabric Panels.These Honda Accessories are not designed for use at highway speeds. Open trailering a Pioneer at highway speed with these accessories installed may damage them or the vehicle.

E- Plow Mount

Custom-designed for your Honda Pioneer.

• Features a Quick Connect system for easy installation and removal of plow in seconds

• Requires Honda Accessory Plow Push Tube and Plow Blade

0SL73-HL5-A00 $177.95

F- Drawbar

Allows installation of 1 7/8" or 2" hitch ball.

08L76-HL5-A00 $44.95

G- Hitch Ball

1 7/8" hitch ball. Includes nut and lock washer.

08L90-HL1-100C $14.95

H- Front Bumper

Strong, steel construction for added vehicle protection.

• Durable gloss, black powder-coat adds a stylish finish

• Factory mount points. Quick and easy to install

08P73-HL5-A00 $357.95

I- Rear Bumper

Strong, steel construction for added vehicle protection.

• Durable gloss, black powder-coat finish

• Factory mount points

08P70-HL5-E60 $224.95

A- Rear Cab Net

Allows maximum airflow through the cab.

• Off-road performance look

• Quick and easy installation

• No special tools required

• Not compatible with Fabric Rear Panels or Fabric Roof Rear Panels

0SR95-HL5-200B $75.95

B, C- Aluminum A-Arm Guards (front and rear)

Lightweight 5052-H32 brushed aluminum.

• Added protection from trail hazards, such as rocks and logs

• Quick and easy to install

B Front 08P70-HL5-A00 $245.95

C Rear 08P71-HL5-A00 $159.95

D- Aluminum Skid Plates

Three-piece set of brushed-aluminum plates provide added vehicle protection. 5052 aluminum is 4 mm thick.

08P70-HL5-A40 $499.95

*

E- Nerf Bars

Heavy duty, large diameter steel tubes help protect your vehicle from rocks and debris.

• Features durable gloss, black powder-coat finish

0SP74-HL5-A00 $311.95

F- Bed Rack*

Provides additional storage area for your gear.

• Incorporates our exclusive Honda Pro-Connect ® attachment sytem for quick and easy attachment and removal

• Features durable gloss, black powder-coat finish

• Not compatible with Honda Bed Rails, Chainsaw Mount or Half Cargo Box.

0SE57-HL5-A00 $309.95

G- Bed Rails

Pioneer Bed Rails attach to bed with our exclusive Honda Pro-Connect ® attachment system.

• Feature durable gloss, black powder-coat finish

• Sold in sets of two

• Not compatible with Honda Chainsaw Mount or Bed Rack

0SB18-HL5-A00 $222.95

H- Half Cargo Box*

9.2-gallon (35-liter) Half Cargo Box is lockable and weather-sealed for secure, clean and dry storage.

• Two Half Cargo Boxes can be installed at the same time for separate storage options.

• Four tie-down points on the lid provide additional carrying area

• Honda Pro-Connect™ attachment system for quick installation and removal.

• Honda Accessory Mount Plate required for installation.

0SL52-HL6-A01 $453.95

I- Mount Plate

• Honda Accessory Mount Plate required to install the Half Cargo Box

0SL41-HL5-A00 $118.95

A- Chainsaw Mount*

Provides convenient way to carry your chainsaw while leaving you space in the bed to carry the rest of your gear.

• Attaches to the bed with our exclusive Honda Pro-Connect ® attachment system.

• Not compatible with Honda Accessory Bed Rails or Bed Rack

0SC13-HL5-A00 $242.95

B- Multi-Tool Holder*

Our Multi-Tool Holder provides a convenient way to carry your tools on the trail or to the work site.

• Features the Honda Pro-Connect ® attachment system for quick and easy attachment and removal

• The strap is a natural rubber [DURO 60+/-5 SHORE A] and the plastic base is PA66-25FG [Nylon with 25% fiber glass]

0SM19-HL5-A00 $108.95

C- Cargo Box*

Durable 9.3 Gallon (35 Liter) Cargo Box is lockable and weather sealed for secure, clean and dry storage.

• Four tie-down points on the lid provide additional carrying area

• Honda Pro-Connect attachment system for quick installation and removal

• Conveniently mounts to Honda Bed Rack

• Requires Honda Accessory Bed Rack for installation

0SL53-HR6-A01 $437.95

D- Utility Basket*

9.3 Gallon (35 Liter) Utility Basket increases cargo space and allows easy access to equipment and tools.

• Impact-resistant polypropylene is strong and durable

• Honda Pro-Connect attachment system for quick installation and removal

• Conveniently mounts to Honda Bed Rack

• Requires Honda Accessory Bed Rack for installation

0SL63-HR3-A01 $249.95

*Refer to installation instructions for cargo weight capacities.

**Fits most 5-gallon buckets.

E- Front Underhood Tray*

Large volume (22.5 Liters) storage tray is sealed to minimize water and dust intrusion.

• Easy install/removal with plastic push pins

08L78-HL5-A00 $199.95

F- Underseat Storage Box*

Convenient underseat box provides additional storage (5.2 Liters).

08L77-HL5-A00 $200.95

G- Cab Frame Cargo Bag*

Constructed of durable UV-treated polyester.

• Includes 7 convenient zippered compartments and zipper pulls for easy operation

• Secures to roll bar with hook & loop straps and locking buckles

• Honda logo shows pride of ownership

0SL57-HL5-101 $83.95

H- Rearview Mirror †

Panoramic mirror provides excellent rear visibility.

• Secure and rigid mount

• Utilizes Honda Tool-Less Clamp system for quick installation, quick removal

• Quick installation and removal

0SV05-HL5-201 $92.95

I- Side Mirror †

• Increased driver visibility

• Utilizes Honda Tool-Less Clamp system for quick installation, quick removal

• Adjustable positioning, includes right and left mirrors

• Not compatible with Honda Accessory Fabric Door

0SV05-HL5-100 $163.95

J- 20-inch LED Light Bar

Features 4-watt LED lights, producing 5,200 lumens in a dual row combined spot and flood patter.

• Rugged aluminum powder-coated housiing is IP-67 rated for dust and water protection

• Lights draw 4.4 amps of current @ 12 volts

• Includes switch and mounting hardware to Honda Hard Roofs

• Requires Honda Accessory Auxiliary Lights / Light Bar Wire Harness (0SV31-HL5-201E) and Accessory Sub Harness (08Z08-HL5-A00)

0SV31-HL4-A00 $381.95

ELECTRICAL

A- LED Auxiliary Lights

Pair of 4" lights features 3-watt Cree LEDs, providing exceptional performance with minimal battery draw.

• Produce a combined 2,400 lumens in a flood pattern

• Protected in a rugged aluminum, black-powder-coated housing and polycarbonate lens

• Requires installation of Honda Accessory Aux Lights/Light Bar Wire Harness and Accessory Sub Harness

0SV31-HL3-201 $319.95

B- Aux Lights/Light Bar Wire Harness

• Required for installation of Honda Accessory Aux Lights and/or Light Bar. One Sub Harness can accommodate both lights

0SV31-HL5-201E $99.95

Accessory Sub Harness

• Sub Harness can accommodate up to three Honda Accessories

• Required for installation of Honda Accessory Back-Up Alarm, Work Light, Horn Kit, Light Bar, or Auxiliary Lights

08Z08-HL5-A00 $8.95 (Not shown.)

C- Light Bar/Aux Lights Clamp

Required when mounting Honda Accessory Light Bar/Auxiliary Light to bumper (upper and lower tubes) and/or cab frame

OSV31-HL3-201A Fits lower bumper tubes (38 mm)

OSV31-HL3-302A Fits cab frame (41 mm)

OSV31-HL3-301B Fits upper bumper tubes (44 mm)

38 mm 0SV31-HL3-201A $29.95

41 mm 0SV31-HL3-302A $29.95

44 mm 0SV31-HL3-301B $29.95

D- Work Light

Handy 10-watt Cree LED light produces 1,000 lumens in a flood pattern and provides exceptional performance with minimal battery draw.

• Adjustable pedestal mount

• Protected in a rugged aluminum black powder-coated housing and polycarbonate lens

• IP68 rated—waterproof, submersible

• Requires Honda Accessory Sub Harness and Work Light Wire Harness

D Work Light

08U71-HL5-A00 $149.95 Work Light Wire Harness 08Z70-HL5-A00 $64.95

E- Back-Up Alarm*

Automatically activates a loud beep whenever Pioneer is put into reverse.

• Requires Honda Accessory Sub Harness, Back-Up Alarm Wire Harness and Back-Up Alarm Mount

E Back-Up Alarm

08V70-HL5-A00 $39.95 Back-Up Alarm Wire Harness 08V70-HL5-E60 $43.95

Back-Up Alarm Mount

• Required for installation of Back-Up Alarm

08Z70-HL5-E60 $61.95 (Not shown.)

F- Horn Kit

Easy-to-install horn assembly.

• Requires Honda Accessory Sub Harness and Horn Kit Wire Harness

F Work Horn Kit

Work Horn Kit Wire Harness

G- Full Storage Cover

08P75-HL5-A00 $34.95

08Z71-HL5-A00 $59.95

Constructed of weather-resistant synthetic material with waterproof taped seams.

• Features Honda and Pioneer logos

• Includes storage pouch

• Side zippers allow cab access without removing the cover

0SP35-HL5-A00 $129.95

G

G

PIONEER ®

A. Cargo Tray

Fabric Doors C. Bimini Top D. Rear Rack Bag (Large)

Rear Bumper

ROOFS/TOPS/WINDSCREENS

A- Hard Roof *‡‡

Compatible with Honda Pioneer 500 Accessory Windscreens, includes mount points for Honda Accessory Light Bar.

• Outstanding weather protection

• Utilizes Honda Tool-Less clamp system for quick installation, quick removal

• Manufactured from ultrarugged, extremely durable HMWPE (high-molecular-weight polyethylene)

08R70-HL5-A01 $413.95

B- Fabric Roof/Rear Panel ‡‡

Made of durable Sur Last ® fabric for superior performance in harsh conditions. Solution-dyed process for UV Fade Resistance. Urethanecoated and DWR (durable-water-repellent) for max water repellency. Mold/mildew- and abrasion-resistant.

• Fiber rods create a tight custom fit to the roof while promoting water runoff

• Rear window zips open and rolls up increasing airflow through the cab

• Polished vinyl window is rated at -30°F cold crack

• Exclusive Honda Phantom Camo ® design made of durable 600-denier fabric for superior performance matches unit camo color

• Requires Honda Accessory Full Poly Tip-Out Windscreen (hard coat or optical)

B Black 0SR85-HL5-200 $249.95

Camo 0SR85-HL5-400C $274.95

C- Bimini Top ‡‡

Made of durable Sur Last ® fabric for superior performance in harsh conditions. Solution-dyed process for UV Fade Resistance. Urethanecoated and DWR (durable-water-repellent) for max water repellency. Mold/mildew- and abrasion-resistant.

• Provides protection from the sun, easy and fast installation

• Fiber rods create a tight custom fit to the roof while promoting water runoff

• Exclusive Honda Phantom Camo ® design made of durable 600-denier fabric for superior performance matches unit camo color

• Not compatible with Honda Fabric Doors and Windscreen/ Windshield accessories

C Black 0SR85-HL5-322B $99.95 Camo 0SR85-HL5-422C $129.95

D- Full Poly Tip-Out Windscreen *‡‡ (hard coat) **

Constructed of optical-grade polycarbonate with premium hard coating for optimal scratch resistance.

• Noncracking, nonyellowing material for excellent impact resistance

• Fully adjustable windscreen tips out allowing for increased airflow

• Utilizes Honda Tool-Less Clamp system for quick installation, quick removal

• Modular design works with either Honda Accessory Hard Roof's or Fabric Roof's configurations

08R74-HL5-A01 $647.95

E- Full Poly Tip-Out Windscreen * ‡‡ (optical) **

Constructed of optical-grade polycarbonate.

• Noncracking, nonyellowing material for excellent impact resistance

• Windscreen tips out allowing airflow to driver and passenger. Fully adjustable

• Modular design works with either Honda Accessory Hard Roof or Fabric Roofs

• Utilizes Honda Tool-Less Clamp system for quick installation, quick removal

• Custom screen-printed graphics complement vehicle styling

0SR73-HL5-100

$502.95

F- Half Wind Deflector *‡‡

Constructed of optical-grade polycarbonate.

• Noncracking, nonyellowing material, excellent impact resistance

• Utilizes Honda Tool-Less Clamp system for quick installation, quick removal

• Custom screen-printed graphics complement vehicle styling

0SR73-HL5-101B $161.95

G- Fabric Doors † ‡‡

Aluminum CNC-formed door frames are lightweight and provide a consistent fit. Integrates with standard half doors.

• Made of durable Sur Last ® fabric for superior performance in harsh conditions

• Solution-dyed process for UV Fade Resistance

• Urethane-coated and DWR (durable-water-repellent) for max water repellency

• Mold/mildew- and abrasion-resistant

• Exclusive Honda Phantom Camo ® design made of durable 600-denier fabric for superior performance matches unit camo color

• Doubled-zippered vinyl windows roll down increasing airflow thru the cab. Vinyl is rated at -30°F cold crack

G Black 0SR90-HL5-210 $449.95 Camo 0SR90-HL5-410C $479.95

*Weight of cab system components may increase risk of vehicle rollover.

**Only windscreens with the optional premium hard coating meet the abrasion resistance requirements specified in ANSI/OPEI B71.9-2012 standards.

†Includes right and left doors.

‡‡ NOTICE: Do not tow any Pioneer on an open trailer with any of the following Honda Genuine or Signature Accessories installed: Hard, Fabric or Bimini Roofs, Poly Windscreens/Wind Deflectors, Fabric Doors and Fabric Panels.These Honda Accessories are not designed for use at highway speeds. Open trailering a Pioneer at highway speed with these accessories installed may damage them or the vehicle.

REAR PANEL/WINCH/PLOW

A- Fabric Rear Panel ‡‡

Made of durable Sur Last ® fabric for superior performance in harsh conditions.

• Solution-dyed process for UV fade resistance

• Urethane-coated and DWR (durable-water-repellent) for max water repellency

• Mold/mildew- and abrasion-resistant

• Window zips open and rolls up increasing airflow through the cab

• Polished vinyl window is rated at -30°F cold crack

0SR95-HL5-100 $148.95

B- Winch

The VRX 25 features 2,500 lb. pulling capacity, a heavy duty contactor, robust new clutch design, a load holding brake and a smooth and reliable all-metal three-stage planetary gear train.

• Durable all-metal construction

• Black powder-coated finish for corrosion resistance

• IP68-rated waterproof sealing to keep the elements out

• Limited lifetime warranty

• Requires Honda Accessory Winch Mount Kit (08L70-HL5-E60) and Honda Accessory Sub-Harness (08Z08-HL5-A00)

08L71-HL5-E61 $398.95

C- Winch Mount Kit

• Required for Honda Accessory Winch

08L70-HL5-E60 $393.95

D- Plow Blade (54")

Made from thick, 12-gauge steel with heavy-duty ribbing and a center cross member for added rigidity.

• Boxed design adds extra support

• PTFE-coated blade for durability and corrosion resistance. 17 3/4" blade height

• Shock and impact resistance

• Adjustable gravel skids to control plowing level

• Requires Honda Accessory Plow Push Tube Set and Plow Mount Kit

• Requires lifting device such as Honda Accessory Winch/Winch Mount Kit

08L76-HR3-A21 $377.95

‡‡ NOTICE: Do not tow any Pioneer on an open trailer with any of the following Honda Genuine or Signature Accessories installed: Hard, Fabric or Bimini Roofs, Poly Windscreens/Wind Deflectors, Fabric Doors and Fabric Panels.These Honda Accessories are not designed for use at highway speeds. Open trailering a Pioneer at highway speed with these accessories installed may damage them or the vehicle.

E- Plow Push Tube Set

Durable construction, engineered to perform season after season.

• Large base provides effective plowing surface

• Superior corrosion resistance. Quick connection

• Requires Honda Accessory Plow Blade and Plow Mount Kit

08L70-HL5-A01 $290.95

F- Plow Mount

Custom-designed for your Honda Pioneer.

• Quick connect system for easy installation and removal of plow components

• Requires Honda Accessory Plow Push Tube Set and Plow Blade

08L73-HL5-A00 $264.95

G- Drawbar

Allows installation of 1 7/8" or 2" hitch ball.

08L76-HL5-A00 $44.95

H- Hitch Ball

1 7/8" hitch ball. Includes nut and lock washer.

08L90-HL1-100C $14.95

I- Front Bumper

Strong, steel construction for added vehicle protection.

• Durable gloss, black powder coat adds a stylish finish

• Factory mount points. Quick and easy to install

08P73-HL5-A00 $299.95

J- Rear Bumper

Strong, steel construction for added vehicle protection.

• Durable gloss, black powder coat adds a stylish finish

• Factory mount points. Quick and easy to install

08P74-HL5-A00 $204.95

A- Rear Cab Net

Allows maximum airflow through the cab.

• Off-road performance look

• Quick and easy installation

• No special tools required

• Not compatible with Fabric Rear Panels or Fabric Roof Rear Panels

0SR95-HL5-200B $75.95

B, C- Aluminum A-Arm Guards (front and rear)

Lightweight 5052-H32 brushed aluminum.

• Added protection from trail hazards, such as rocks and logs

• Quick and easy to install

B Front 08P70-HL5-A00 $245.95

C Rear 08P71-HL5-A00 $159.95

D- Aluminum Skid Plates

Three-piece set of brushed-aluminum plates provide added vehicle protection. 5052 aluminum is 4 mm thick.

2016-2020 08P70-HL5-A40 $499.95

E- Cargo Tray *

Manufactured from ultrarugged, extremely durable HMWPE (high-molecular-weight polyethylene).

• Converts cargo rack into a convenient storage platform perfect for small yard work, landscaping or other tasks

• Lightweight design includes molded side slots to allow the use of customer-supplied partitions

• Rounded perimeter allows for bungee cord tie-downs or cargo nets

• Easy to clean–resistant to debris build-up

• Utilizes Honda Tool-Less Clamp system

• Quick installation, quick removal

2016-2021

08L70-HL5-A40 $439.95

F- Rear Rack Bag* (large)

Made of heavy-duty 600-denier material for superior performance. Water-, UV- and mold-resistant.

• Features a split lid for easy access to your contents and 2 adjustable center dividers to keep contents organized

• Solid construction holds shape when empty

• Securely mounts using 6 hook and loop mounting straps

• Measures 45" L x 14.5" W x 13.5" H with a 144.36-liter capacity

• Not compatible with Honda Accessory Cargo Tray

0SL56-HL5-100A $159.95

G-

Cab Frame Cargo Bag

*

Constructed of durable UV-treated polyester.

• Includes 7 convenient zippered compartments and zipper pulls for easy operation

• Secures to roll bar with hook & loop straps and locking buckles

• Honda logo shows pride of ownership

0SL57-HL5-101 $83.95

H- Front Underhood Tray*

Large volume (22.5 Liters) storage tray is sealed to minimize water and dust intrusion.

• Easy install/removal with plastic push pins

08L78-HL5-A00 $199.95

STORAGE/INTERIOR

A- Underseat Storage Box*

Convenient underseat box provides additional storage (5.2 Liters).

08L77-HL5-A00 $200.47

B- Rubber Floor Mat

Manufactured from rugged, nonslip, vulcanized rubber compound.

• Pioneer-branded with tight, contoured fit

0SP63-HL5-101 $89.95

*Refer to installation instructions for cargo weight capacities. **Fits most 5-gallon buckets.

C- Rearview Mirror †

Panoramic mirror with excellent visibility.

• Utilizes Honda Tool-Less Clamp system for quick installation, quick removal

• Secure and rigid mount

0SV05-HL5-201 $92.95

D- Side Mirror †

• Increased driver visibility

• Utilizes Honda Tool-Less Clamp system for quick installation, quick removal

• Adjustable positioning, includes right and left mirrors

• Not compatible with Honda Accessory Fabric Door

0SV05-HL5-100 $163.95

E- 20-inch LED Light Bar

Features 4-watt LED lights, producing 5,200 lumens in a dual row combined spot and flood patter.

• Rugged aluminum powder-coated housiing is IP-67 rated for dust and water protection

• Lights draw 4.4 amps of current @ 12 volts

• Includes switch and mounting hardware to Honda Hard Roofs

• Requires Honda Accessory Auxiliary Lights / Light Bar Wire Harness (0SV31-HL5-201E) and Accessory Sub Harness (08Z08-HL5-A00)

0SV31-HL4-A00 $381.95

F- LED Auxiliary Lights

Pair of 4" lights features 3-watt Cree LEDs, providing exceptional performance with minimal battery draw.

• Produce a combined 2,400 lumens in a flood pattern

• Protected in a rugged aluminum, black-powder-coated housing and polycarbonate lens

• Requires installation of Honda Accessory Aux Lights/Light Bar Wire Harness and Accessory Sub Harness

0SV31-HL3-201 $319.95

G- Aux Lights/Light Bar Wire Harness

• Required for installation of Honda Accessory Aux Lights and/or Light Bar. One Sub Harness can accommodate both lights

0SV31-HL5-201E $99.95

Accessory Sub Harness

• Sub Harness can accommodate up to three Honda Accessories

• Required for installation of Honda Accessory Back-Up Alarm, Work Light, Horn Kit, Light Bar, or Auxiliary Lights

08Z08-HL5-A00 $8.95 (Not shown.)

A- Light Bar/Aux Lights Clamp

Required when mounting Honda Accessory Light Bar/Auxiliary Light to bumper (upper and lower tubes) and/or cab frame

OSV31-HL3-201A Fits lower bumper tubes (38 mm)

OSV31-HL3-302A Fits cab frame (41 mm)

OSV31-HL3-301B Fits upper bumper tubes (44 mm)

38 mm 0SV31-HL3-201A $29.95

41 mm 0SV31-HL3-302A $29.95

44 mm 0SV31-HL3-301B $29.95

B- Work Light

Handy 10-watt Cree LED light produces 1,000 lumens in a flood pattern and provides exceptional performance with minimal battery draw.

• Adjustable pedestal mount

• Protected in a rugged aluminum black powder-coated housing and polycarbonate lens

• IP68 rated—waterproof, submersible

• Requires Honda Accessory Sub Harness and Work Light Mount Kit

B Work Light

08U71-HL5-A00 $149.95 Work Light Wire Harness 08Z70-HL5-A00 $64.95

C- Back-Up Alarm*

Automatically activates a loud beep whenever Pioneer is put into reverse.

• Requires Honda Accessory Sub Harness and Back-Up Alarm Wire Harness

Back-Up Alarm

08V70-HL5-A00 $39.95

Back-Up Alarm Wire Harness 08V71-HL5-A00 $39.95

D-

Horn Kit

Easy-to-install horn assembly.

• Requires Honda Accessory Sub Harness and Horn Kit Wire Harness

Horn Kit

Horn Kit Wire Harness

08P75-HL5-A00 $34.95

08Z71-HL5-A00 $59.95

*Not available in Oregon.

E- Full Storage Cover**

Constructed of weather-resistant synthetic material with waterproof taped seams.

• Features Honda and Pioneer logos

• Includes storage pouch

• Side zippers allow cab access without removing the cover

0SP35-HL5-A00 $129.95

E

E

ATV Utility

COMFORT/PROTECTION

TRX680 (2003-2022)

A- Windscreen

Premium polycarbonate material offers excellent impact resistance as well as nonyellowing, noncracking and UV-resistant properties. Featuring an integrated Honda Tool-Less Clamp mount system for easy installation and removal.

0SR02-TRX-100 $272.95

B- Front Brush Guard

Made of sturdy, 16-gauge steel tubing with a durable, gloss-black, powder-coated finish for added protection to the front-end components. Four-point frame mounting for superior strength. Aggressive wraparound styling enhances the look of your Honda ATV.

08P53-HN8-100 $254.95

C- A-Arm Guards

Added protection for front- and rearsuspension components from trail hazards such as rocks and logs. These tough, lightweight, 0.125"-thick 5052 aluminum alloy

A-Arm Guards feature recessed mounting bolts to help reduce exposure to damage.

Front 08P69-HP0-100A $129.95

Rear 08P69-HN8-100B* $124.95

D- Rear Frame Skid Plate

Added protection against trail hazards such as rocks and logs. Made of durable, lightweight, 0.16"-thick 5052 aluminum alloy.

Rear Skid Plate

08P51-HN8-100B $124.95

Outdoor Storage Cover

Water-resistant and fade-resistant, this Honda-branded, heavy-duty, coated-polyester cover keeps your Utility ATV out of the weather and sun. Features double-stitched seams for added durability and a shock cord to ensure a snug fit. Will not fit when accessory Windscreen is installed. (Not shown.)

XXL 08P34-HN8-200 $69.95

Shown on TRX420.

TRX520 (2020-2024)

A- Winch

2,500 lb of pulling force. Features an all-metal, 3-stage planetary gear train; full sealing to keep the elements out; a patented disc brake for excellent control; a short-throw clutch; and an efficient electrical system for less battery drain. Limited lifetime warranty.

• Requires Winch Mount Kit (08L70-HR6-MF0) and Accessory Sub Harness (08Z01-HR3-A20)

2022-24

08L71-HL5-E61 $398.95

B- Winch Mount Kit

Custom-designed for your Honda. Includes mini-rocker switch, mounting hardware and wiring for easy installation. Winch not included in Mount Kit. Kit requires Winch (08L71-HR5-E61 or 08L71-HL5-A02) and Accessory Sub Harness (08Z01-HR3-A20) required.

2022-24

08L70-HR6-MF0 $329.95

2020-21 08L74-HR3-A20 $256.95

Accessory Sub Harness

Allows installation of Honda Accessory Heated Grips, Winch, and/or 12V Socket. Required to install Winch, Plow and Heated Grips. (Not shown.)

08Z01-HR3-A20 $10.95

C- Plow Blade (54")

Made from thick, 12-gauge steel with heavy-duty ribbing and a center cross member for added rigidity. Boxed design adds extra support. PTFE-coated blade for durability and corrosion resistance 17 3/4" blade height. Shock and impact resistance. Adjustable gravel skids to control plowing level.

• Requires Winch, Winch Mount, Plow Push Tubes, Plow Mount & Wire Harness needed for installation.

08L76-HR3-A21 $377.95

Plow Push Tube Set

Durable construction engineered to perform season after season. Large-base design for increased stability and durability. Superior corrosion resistance. Thick, sturdy wear bar has steep angle of attack for maximum surface scraping. Quick connection. Required to install Plow Blade.

08L77-HR3-A21 $291.95 (Not shown.)

D- Plow Mount Kit

Custom-designed for your Honda. Mounting plate remains attached to the ATV and becomes a structural component adding rigidity to the ATV frame during plowing operations. Placement is forward of the foot pegs to avoid any reduction of ground clearance or operating interference. Designed for high ground clearance and quick installation or removal. Quick connect system for easy installation and removal of plow components. Required to mount Plow Blade.

08L75-HR3-A20 $275.95

E- Windscreen

Premium polycarbonate material offers excellent impact resistance as well as nonyellowing, noncracking and UV-resistant properties. Featuring an integrated Honda Tool-Less Clamp mount system for easy installation and removal.

0SR01-HR5-100 $237.95

F- Heated Grips

Clamps onto your Honda with plug-n-play connectors for easy installation. The Dual Zone controller has five heat settings that allow you to set thumb and grip heat levels separately. Controller has nighttime dimmer, auto shut off after two hours, reverse polarity, high-voltage protection and low-voltage cutoff. Maximum 45 watts (3.1 amps on highest setting).

• Requires Honda Accessory Sub Harness for installation (08Z00-HR3-A20 or 08Z01HR3-A20–depending on application).

0ST71-HR3-A00 $159.95

Recoil Starter Kit

Allows the option to start the vehicle manually. Includes all necessary wiring and hardware. (Not shown)

Applies to: FM1.FM2, FE2, and FM6 models

08U70-HR3-A40 $109.95

Applies to: FA5, FA6 and FA7 models 08U70-HR6-A60 $109.95

TRX520

(2020-2024) Continued

A, B- A-Arm Guards

Added protection for front- and rear-suspension components from trail hazards such as rocks and logs. These tough, lightweight, 0.125"-thick 5052 aluminum alloy A-Arm Guards feature recessed mounting bolts to help reduce exposure to damage.

A Front 08P70-HR6-B00 $169.95

B Rear 08P70-HR6-A60 $147.95

C- Frame Skid Plate

Added protection against rocks and debris. Made of durable, lightweight, 0.16"-thick 5052 aluminum alloy.

08P74-HR6-A60 $249.95

D- Rear Frame Skid Plate

Added protection against trail hazards such as rocks and logs. Made of durable, lightweight, 0.16"-thick 5052 aluminum alloy.

Applies to: FM6, FA5, FA6 and FA7 models

08P72-HR6-A60 $165.95

E- Rear Swingarm Guard

0.25"-thick 5052-aluminum-alloy armor plate, featuring a gusseted design that adds protection for the rear differential.

Applies to: FM1, FM2 and FE2 models

08P71-HR3-620 $124.95

F- Aluminum Wheel (front and rear)

Comes with lug nuts and center cap. Price per wheel, tires not included.

Applies to: FA5, FA6, FA7 and FM6 models

Front Wheel 08W70-HR5-A20 $129.95

Rear Wheel 08W71-HR5-A20 $129.95

G- Rear Bumper

Strong, steel construction for added vehicle protection. Durable gloss black powder coat adds a stylish finish. Quick, easy to install.

Applies to: FM6, FA5, FA6 and FA7 models

08P73-HR6-A60

$251.95

Outdoor Storage Cover

Water-resistant and fade-resistant, this Honda-branded, heavy-duty, coated-polyester cover keeps your Utility ATV out of the weather and sun. Features double-stitched seams for added durability and a shock cord to ensure a snug fit. Will not fit when accessory Windscreen is installed.

08P34-HN8-200 $69.95 (Not shown.)

H- Front Cargo Box*

Durable 9.3 Gallon (35 Liter) Cargo Box is lockable and weather sealed for secure, clean and dry storage.

• 4 tie-down points on the lid provide additional carrying area

• Honda Pro-Connect™ attachment system for quick installation and removal

• Conveniently mounts to factory rack

• Lockable latches

• Weather resistant

• Not compatible with Front Utility Basket or Front Rack Bag

0SL53-HR6-A01 $437.95

I- Rear Cargo Box*

Durable 17.2 Gallon (65 Liter) Cargo Box is lockable and weather sealed for secure, clean and dry storage.

• 4 tie-down points on the lid provide additional carrying area

• Honda Pro-Connect™ attachment system for quick installation and removal

• Conveniently mounts to factory rack

• Not compatible with Rear Utility Basket or Rear Rack Bag

0SL54-HR6-A01 $599.95

J- Front Utility Basket*

9.3 Gallon (35 Liter) basket increases cargo space and allows easy access to equipment and tools.

• Impact-resistant polypropylene is strong and durable

• Honda Pro-Connect™ attachment system for quick installation and removal

• Conveniently mounts to factory rack

• Not compatible with Front Cargo Box or Front Rack Bag

0SL63-HR3-A01 $249.95

* Refer to installation instructions for cargo capacities. All additional or replacement mounting hardware for the above accessories will be included unless otherwise noted.

TRX520 (2020-2024) Continued

A- Rear Utility Basket*

10.6 Gallon (40 Liter) basket increases cargo space and allows easy access to equipment and tools.

• Impact-resistant polypropylene is strong and durable

• Features two built-in 5-gallon buckets for added convenience and productivity

• Honda Pro-Connect™ attachment system for quick installation and removal

• Conveniently mounts to factory rack

• Not compatible with Rear Cargo Box or Rear Rack Bag

0SL64-HR3-A01 $268.95

B- Front Carrier Extender

Made from steel and featuring black powdercoat for durability, it creates an elevated rack perimeter of 4.3" on the front and sides.

• Quick installation and removal to the factory rack with the Honda Pro-Connect™ attachment system

• Offers additional tie down points for added flexibility when securing cargo

• Fits with Honda Accessory Front Cargo Box and Front Utility Basket

• Not compatible with Front Rack Bag

0SL73-HR4-A01 $240.95

C- Rear Carrier Extender

Made from steel and featuring black powdercoat for durability, the extender creates an elevated rack perimeter of 5.8" on the rear and 4.5"on the sides.

• Quick installation and removal to the factory rack with the Honda Pro-Connect™ attachment system

• Offers additional tie down points for added flexibility when securing cargo

• Fits with Rear Utility Basket

• Not compatible with Rear Cargo Box or Rear Rack Bag

0SL74-HR4-A01 $232.95

D- Cup Holder

Accessory Cup Holder replaces fender door for factory fit and finish, while still allowing smaller items to be stored inside.

• Made from impact resistant black polypropylene for strength and durability

• Holds drink containers up to 2.5" diameter

0SC38-HR5-A00 $66.95

* Refer to installation instructions for cargo capacities.

TRX500

(2014-2019)

(Does not apply to 2014 FA, FPA)

A- Winch Mount Kit

Custom-designed for your Honda. Includes mini-rocker switch, mounting hardware and wiring for easy installation. Winch not included in Mount Kit. Required to mount Winch. Winch (08L73-HR3-A21) and Accessory Sub Harness (08Z01-HR3-A20) required.

08L74-HR3-A20 $256.95

Accessory Sub Harness

Allows installation of Honda Accessory Heated Grips, Winch, and/or 12V Socket. Required to install Winch, Plow and Heated Grips.

08Z01-HR3-A20 $10.95 (Not shown.)

B- Plow Blade (54")

Made from thick, 12-gauge steel with heavy-duty ribbing and a center cross member for added rigidity. Boxed design adds extra support. PTFE-coated blade for durability and corrosion resistance 17 3/4" blade height. Shock and impact resistance. Adjustable gravel skids to control plowing level.

• Requires Winch, Winch Mount, Plow Push Tubes, Plow Mount & Wire Harness needed for installation.

08L76-HR3-A21 $377.95

Plow Push Tube Set

Durable construction engineered to perform season after season. Large-base design for increased stability and durability. Superior corrosion resistance. Thick, sturdy wear bar has steep angle of attack for maximum surface scraping. Quick connection. Required to install Plow Blade.

08L77-HR3-A21 $291.95 (Not shown.)

C- Plow Mount Kit

Custom-designed for your Honda. Mounting plate remains attached to the ATV and becomes a structural component adding rigidity to the ATV frame during plowing operations. Placement is forward of the foot pegs to avoid any reduction of ground clearance or operating interference. Designed for high ground clearance and quick installation or removal. Quick connect system for easy installation and removal of plow components. Required to mount Plow Blade.

08L75-HR3-A20 $275.95

D-Heated Grips

Clamps onto your Honda with plug-n-play connectors for easy installation. The Dual Zone controller has five heat settings that allow you to set thumb and grip heat levels separately. Controller has nighttime dimmer, auto shut off after two hours, reverse polarity, high-voltage protection and low-voltage cutoff. Maximum 45 watts (3.1 amps on highest setting).

• Requires Honda Accessory Sub Harness for installation (08Z00-HR3-A20 or 08Z01HR3-A20–depending on application).

0ST71-HR3-A00 $159.95

E-Windscreen

Premium polycarbonate material offers excellent impact resistance as well as nonyellowing, noncracking and UV-resistant properties. Featuring an integrated Honda Tool-Less Clamp mount system for easy installation and removal.

Applies to: FE1, FE2, FM1 and FM2 (2015-2016) and all 2014 models

2014-2019 0SR01-TRX-100 $253.95

Applies to: FA5, FA6, FA7, FM5, FM6, FM7 models

2015-2019 0SR01-HR5-100 $237.95

F-Cup Holder

Accessory Cup Holder replaces fender door for factory fit and finish, while still allowing smaller items to be stored inside.

• Made from impact-resistant black polypropylene for strength and durability

• Holds drink containers up to 2.5" diameter

0SC38-HR5-A00 $66.95

Recoil Starter Kit

Allows the option to start the vehicle manually. Includes all necessary wiring and hardware. (Not shown.) Applies to: FE1, FE2, FM1, FM2, FM5, FM6, FM7 (2015-2017) and all 2014 models.

2014-2019 08U70-HR3-A40 $109.95

Applies to: FA5, FA6 and FA7 models 2015-2019 08U70-HR3-A60 $115.95

TRX500 (2014-2019) Continued

A, B- A-Arm Guards

Added protection for front- and rear-suspension components from trail hazards such as rocks and logs. These tough, lightweight, 0.125"-thick 5052 aluminum alloy A-Arm Guards feature recessed mounting bolts to help reduce exposure to damage.

A 2014-2019 Front 08P71-HR6-A60 $105.95

Fits FA5, FA6, FA7, FM5, FM6 and FM7 models (2015-16)

B 2015-2019 Rear 08P70-HR6-A60 $147.95

C- Frame Skid Plate

Added protection against rocks and debris. Made of durable, lightweight, 0.16"-thick 5052 aluminum alloy.

2014 08P74-HR3-A20 $249.95

C 2015-2019 08P74-HR6-A60 $249.95

D- Rear Frame Skid Plate

Added protection against trail hazards such as rocks and logs. Made of durable, lightweight, 0.16"-thick 5052 aluminum alloy.

Applies to: FA5, FA6, FA7, FM5, FM6 and FM7 models (2015-16) 2015-2019 08P72-HR6-A60 $165.95

E- Rear Swingarm Guard

0.25"-thick 5052-aluminum-alloy armor plate, featuring a gusseted design that adds protection for the rear differential.

Applies to: FE1, FE2, FM1 and FM2 models 2015-2019 08P71-HR3-620 $124.95

F- Aluminum Wheel (front and rear)

Comes with lug nuts and center cap. Price per wheel, tires not included.

Applies to: FA5, FA6, FM5 and FM6 models (2015-16) 2015-2019 Front Wheel 08W70-HR5-A20 $129.95 2015-2019 Rear Wheel 08W71-HR5-A20 $129.95

G- Rear Bumper

Strong, steel construction for added vehicle protection. Durable gloss black powder coat adds a stylish finish. Quick, easy to install.

Applies to: FA5, FA6, FM5, FM6, and FA7 and FM7 models (2015-16) 2015-2019 08P73-HR6-A60 $251.95

Outdoor Storage Cover

Water-resistant and fade-resistant, this Honda-branded, heavy-duty, coated-polyester cover keeps your Utility ATV out of the weather and sun. Features double-stitched seams for added durability and a shock cord to ensure a snug fit. Will not fit when accessory Windscreen is installed.

08P34-HN8-200 $69.95 (Not shown.)

TRX500 (2012-2013)

(Applies to 2014 FA, FPA)

A- Winch Kit

2,500 lb of pulling force. Rugged and reliable, features a handlebar-mounted, mini-rocker switch that is fully sealed and a patented disc brake that provides the ultimate in winch control. Includes all required mounting-kit hardware. Limited lifetime warranty. Does not apply to TRX500 FA/FPA Rubicon.

08L94-HR0-100 $549.95

B- Windscreen

Premium polycarbonate material offers excellent impact resistance as well as nonyellowing, noncracking and UV-resistant properties. Featuring an integrated Honda Tool-Less Clamp mount system for easy installation and removal.

0SR01-TRX-100 $253.95

C- A-Arm Guards (front)

Added protection for front-suspension components from trail hazards like rocks and logs. These tough, lightweight, 0.125"- thick 5052 aluminum alloy A-Arm Guards feature recessed mounting bolts to help reduce exposure to damage. Does not apply to TRX500 FA/FPA Rubicon.

08P69-HR0-100A $134.95

D- Frame Skid Plate

Added protection against rocks and debris. Made of durable, lightweight, 0.16"-thick 5052 aluminum alloy. Does not apply to TRX500 FA/ FPA Rubicon.

08P51-HR0-100A $254.95

E- Rear Swingarm Guard

0.25"-thick 5052-aluminum-alloy armor plate, featuring a gusseted design that adds protection for the rear differential. Does not apply to TRX500 FA/FPA Rubicon.

08P51-HR0-100B $134.95

TRX500 (2006-2011)

A- Winch Kit

2,500 lb of pulling force. Rugged and reliable, features a handlebar-mounted, mini-rocker switch that is fully sealed and a patented disc brake that provides the ultimate in winch control. Includes all required mounting-kit hardware. Limited lifetime warranty. Also fits 2013-14 TRX500 FA/FPA Rubicon.

08L94-HP0-100 $529.95

B- Windscreen

Premium polycarbonate material offers excellent impact resistance as well as nonyellowing, noncracking and UV-resistant properties. Featuring an integrated Honda Tool-Less Clamp mount system for easy installation and removal.

0SR01-TRX-100 $253.95

C- A-Arm Guards (front)

Added protection for front-suspension components from trail hazards such as rocks and logs. These tough, lightweight, 0.125"-thick, 5052 aluminum alloy A-arm guards feature recessed mounting bolts to help reduce exposure to damage. Also fits 2013-14 TRX500 FA/FPA Rubicon.

08P69-HP0-100A $129.95

D- Frame Skid Plate

Added protection against trail hazards such as rocks and logs. Made of durable, lightweight, 0.16"-thick 5052 aluminum alloy. Also fits 2013-14 TRX500 FA/FPA Rubicon.

08P51-HP0-100A $229.95

E- Rear Swingarm Guard

0.25"-thick 5052-aluminum-alloy armor plate, featuring a gusseted design that adds protection for the rear differential against trail hazards such as rocks and logs. Also fits 2013-14 TRX500 FA/FPA Rubicon.

08P51-HP0-100B $99.95

TRX420 (2020-2024)

A- Winch

2,500 lb of pulling force. Features an all-metal, 3-stage planetary gear train; full sealing to keep the elements out; a patented disc brake for excellent control; a short-throw clutch; and an efficient electrical system for less battery drain. Limited lifetime warranty.

• Requires Winch Mount Kit and Accessory Sub Harness (08Z00-HR3-A20)

2022 08L71-HL5-E61 $431.95 2020-21 08L71-HL5-A02 $379.95

C- Plow Blade (54")

Made from thick, 12-gauge steel with heavy-duty ribbing and a center cross member for added rigidity. Boxed design adds extra support. PTFE-coated blade for durability and corrosion resistance 17 3/4" blade height. Shock and impact resistance. Adjustable gravel skids to control plowing level.

• Requires Winch, Winch Mount, Plow Push Tubes, Plow Mount & Wire Harness needed for installation.

08L76-HR3-A21 $377.95

B- Winch Mount Kit

Custom-designed for your Honda. Includes mini-rocker switch, mounting hardware and wiring for easy installation. Winch not included in Mount Kit. Kit requires: Winch (08L71-HR5-E61 or 08L71-HL5-A02) and Accessory Sub Harness (08Z01-HR3-A20).

2022 08L70-HR6-MF0 $329.95

2020-21 08L74-HR3-A20 $256.95

Accessory Sub Harness

Accessory Sub Harness allows installation of Honda Accessory Heated Grips and /or Winch. 08Z00-HR3-A20 $5.95 (Not shown.)

Accessory Sub Harness

Allows installation of Honda Accessory Heated Grips, Winch and /or 12V Socket

08Z01-HR3-A20 $10.95 (Not shown.)

Plow Push Tube Set

Durable construction engineered to perform season after season. Large-base design for increased stability and durability. Superior corrosion resistance. Thick, sturdy wear bar has steep angle of attack for maximum surface scraping. Quick connection. Required to install Plow Blade.

08L77-HR3-A21 $291.95 (Not shown.)

D- Plow Mount Kit

Custom-designed for your Honda. Mounting plate remains attached to the ATV and becomes a structural component adding rigidity to the ATV frame during plowing operations. Placement is forward of the foot pegs to avoid any reduction of ground clearance or operating interference. Designed for high ground clearance and quick installation or removal. Quick connect system for easy installation and removal of plow components. Required to mount Plow Blade.

08L75-HR3-A20 $275.95

E- Windscreen

Premium polycarbonate material offers excellent impact resistance as well as nonyellowing, noncracking and UV-resistant properties. Featuring an integrated Honda Tool-Less Clamp mount system for easy installation and removal.

0SR02-TRX-100 $272.95

12V Front Accessory Socket

Provides power to additional electrical equipment. Socket integrates into the front of your ATV. Accessory.

• Sub-Harness required for installation (08Z00-HR3-A20 or 08Z01-HR3-A20— see listing to determine application).

08U70-HR3-A20 $29.95 (Not shown.)

Heated Grips

Clamps onto your Honda with plug-n-play connectors for easy installation. The Dual Zone controller has five heat settings that allow you to set thumb and grip heat levels separately. Controller has nighttime dimmer, auto shut off after two hours, reverse polarity, high-voltage protection and low-voltage cutoff. Maximum 45 watts (3.1 amps on highest setting).

• Requires Honda Accessory Sub Harness for installation (08Z00-HR3-A20 or 08Z01-HR3-A20–depending on application).

0ST71-HR3-A00 $159.95 (Not shown.)

Recoil Starter Kit*

Allows the option to start the vehicle manually. Includes all necessary wiring and hardware. Applies to: TM1, TE1, FM1, FM2, FE1 and FA2 models. (Not shown.)

08U70-HR3-A40 $109.95*

08U70-HR3-A60 $115.95*

PROTECTION/CARGO

TRX420 (2020-2024) Continued

A, B- A-Arm Guards

Added protection for front- and rear-suspension components from trail hazards such as rocks and logs. These tough, lightweight, 0.125"-thick 5052 aluminum alloy A-Arm Guards feature recessed mounting bolts to help reduce exposure to damage.

Applies to: FA5 and FA6 models

Front 08P70-HR6-B00 $169.95

Applies to: TM1, TE1, FM1, FM2, FE1 and FA2 models

A Front 08P70-HR3-WB0 $187.95

Applies to: FA5 and FA6 models

B Rear 08P70-HR6-A60 $147.95

C- Frame Skid Plates

Added protection against rocks and debris. Made of durable, lightweight, 0.16"-thick 5052 aluminum alloy.

08P74-HR6-A60 $249.95

D- Rear Frame Skid Plate

Added protection against trail hazards such as rocks and logs. Made of durable, lightweight, 0.16"-thick 5052 aluminum alloy.

Applies to: FA5 and FA6 models

08P72-HR6-A60 $165.95.

E- Rear Swingarm Guard

0.25"-thick 5052-aluminum-alloy armor plate, featuring a gusseted design that adds protection for the rear differential.

Applies to: TM1, TE1, FM1, FM2, FE1 and FA2 models

08P71-HR3-620 $124.95

F- Bumper (front and rear)

Strong, steel construction for added vehicle protection. Durable gloss black powder coat adds a stylish finish. Quick, easy to install.

Front 08P70-HR3-WA0 $299.95 (Not shown.)

Rear 08P73-HR6-A60 $251.95 Applies to FA5 & FA6 models

Outdoor Storage Cover

Water-resistant and fade-resistant, this Honda-branded, heavy-duty, coated-polyester cover keeps your Utility ATV out of the weather and sun. Features double-stitched seams for added durability and a shock cord to ensure a snug fit. Will not fit when accessory Windscreen is installed.

08P34-HP5-200 $63.95 (Not shown.)

G- Front Cargo Box*

Durable 9.3 Gallon (35 Liter) Cargo Box with lockable latches and weather sealed for secure, clean and dry storage.

• 4 tie-down points on the lid provide additional carrying area

• Honda Pro-Connect™ attachment system for quick installation and removal

• Conveniently mounts to factory rack

• Not compatible with Front Utility Basket or Front Rack Bag

0SL53-HR6-A01 $437.95

*

H- Rear Cargo Box*

Durable 17.2 Gallon (65 Liter) Cargo Box is lockable and weather sealed for secure, clean and dry storage.

• 4 tie-down points on the lid provide additional carrying area

• Honda Pro-Connect™ attachment system for quick installation and removal

• Conveniently mounts to factory rack

• Not compatible with Rear Utility Basket or Rear Rack Bag

0SL54-HR6-A01

$599.95

I- Front Utility Basket*

9.3 Gallon (35 Liter) basket increases cargo space and allows easy access to equipment and tools.

• Impact-resistant polypropylene is strong and durable

• Honda Pro-Connect™ attachment system for quick installation and removal

• Conveniently mounts to factory rack

• Not compatible with Front Cargo Box or Front Rack Bag

0SL63-HR3-A01

$249.95

Rear Utility Basket*

10.6 Gallon (40 Liter) basket increases cargo space and allows easy access to equipment and tools.

• Impact-resistant polypropylene is strong and durable

• Features two built-in 5-gallon buckets for added convenience and productivity

• Honda Pro-Connect™ attachment system for quick installation and removal

• Conveniently mounts to factory rack

• Not compatible with Rear Cargo Box or Rear Rack Bag

0SL64-HR3-A01

$268.95 (Not Shown.)

J- Front Carrier Extender

Made from steel and featuring black powdercoat for durability, it creates an elevated rack perimeter of 4.3" on the front and sides.

• Quick installation and removal to the factory rack with the Honda Pro-Connect™ attachment system

• Offers additional tie down points for added flexibility when securing cargo

• Fits with Honda Accessory Front Cargo Box and Front Utility Basket

• Not compatible with Front Rack Bag

0SL73-HR4-A01

$240.95

Rear Carrier Extender

Made from steel and featuring black powdercoat for durability, the extender creates an elevated rack perimeter of 5.8" on the rear and 4.5"on the sides.

• Quick installation and removal to the factory rack with the Honda Pro-Connect™ attachment system

• Offers additional tie down points for added flexibility when securing cargo

• Fits with Rear Utility Basket

• Not compatible with Rear Cargo Box or Rear Rack Bag

0SL74-HR4-A01 $232.95 (See image C, page 96.)

TRX420 (2014-2019)

(Does not apply to 2014 FA, FPA)

A- Windscreen

Premium polycarbonate material offers excellent impact resistance as well as nonyellowing, noncracking and UV-resistant properties. Featuring an integrated Honda Tool-Less Clamp mount system for easy installation and removal.

0SR02-TRX-100 $272.95

C- Plow Blade (54")

Made from thick, 12-gauge steel with heavy-duty ribbing and a center cross member for added rigidity. Boxed design adds extra support. PTFE-coated blade for durability and corrosion resistance 17 3/4" blade height. Shock and impact resistance. Adjustable gravel skids to control plowing level.

• Requires Winch, Winch Mount, Plow Push Tubes, Plow Mount & Wire Harness needed for installation.

08L76-HR3-A21 $377.95

E- Heated Grips

B- Winch Mount Kit

Custom-designed for your Honda. Includes mini-rocker switch, mounting hardware and wiring for easy installation. Winch and Accessory Sub Harness (08Z00-HR3-A20 or 08Z01-HR3-A20—see listing to determine application) required. Winch not included in Mounting Kit.

08L74-HR3-A20 $256.95

Accessory Sub Harness

Plow Push Tube Set

Durable construction, engineered to perform season after season. Large base design for increased stability and durability. Superior corrosion resistance. Thick, sturdy wear bar has steep angle of attack for maximum surface scraping. Quick connection. Required to mount Plow Blade, in addition to the Plow Mount Kit.

08L77-HR3-A21 $291.95 (Not shown.)

D- Plow Mount Kit

Accessory Sub Harness allows installation of Honda Accessory Heated Grips and /or Winch.

08Z00-HR3-A20 $5.95 (Not shown.)

Allows installation of Honda Accessory Heated Grips, Winch and /or 12V Socket

08Z01-HR3-A20 $10.95 (Not shown.)

Custom-designed for your Honda. Mounting plate remains attached to the ATV and becomes a structural component adding rigidity to the ATV frame during plowing operations. Placement is forward of the foot pegs to avoid any reduction of ground clearance or operating interference. Designed for high ground clearance and quick installation or removal. Quick connect system for easy installation and removal of plow components. Required to mount Plow Blade, in addition to Plow Push Tubes.

08L75-HR3-A20 $275.95

Clamps onto your Honda with plug-n-play connectors for easy installation. The Dual Zone controller has five heat settings that allow you to set thumb and grip heat levels separately. Controller has nighttime dimmer, auto shut off after two hours, reverse polarity, high-voltage protection and low-voltage cutoff Maximum 45 watts (3.1 amps on highest setting).

• Requires Honda Accessory Sub Harness for installation (08Z00-HR3-A20 or 08Z01HR3-A20–depending on application).

0ST71-HR3-A00 $159.95

12V Front Accessory Socket

Provides power to additional electrical equipment. Socket integrates into the front of your ATV. Accessory Sub-Harness required for installation (08Z00-HR3-A20 or 08Z01-HR3A20—see listing to determine application).

08U70-HR3-A20 $29.95 (Not shown.)

F, G- A-Arm Guards

Added protection for front- and rear- suspension components from trail hazards such as rocks and logs. These tough, lightweight, 0.125"-thick 5052 aluminum alloy A-Arm Guards feature recessed mounting bolts to help reduce exposure to damage.

2014 Front 08P71-HR3-A20 $129.95 (Not shown.)

2015-2019 Front 08P70-HR3-620 $119.95

2015-2019 Rear 08P70-HR6-A60 $147.95 Applies to FA5 & FA6

H- Frame Skid Plate

Added protection against rocks and debris. Made of durable, lightweight, 0.16"-thick 5052 aluminum alloy.

2014 08P74-HR3-A20 $249.95

H 2015-2019 08P74-HR6-A60 $249.95

I- Rear Frame Skid Plate

Added protection against trail hazards such as rocks and logs. Made of durable, lightweight, 0.16"-thick 5052 aluminum alloy. 2015-2019 08P72-HR6-A60 $165.95 Applies to FA5 & FA6

J- Rear Swingarm Guard

0.25"-thick 5052-aluminum-alloy, featuring a gusseted design that adds protection for the rear differential. Does not apply to FA5 and FA6.

2015-2019 08P71-HR3-620 $124.95

K, L- Bumper (front and rear)

Strong, steel construction for added vehicle protection. Durable gloss black powder coat adds a stylish finish. Quick, easy to install.

2015-2019 Rear 08P73-HR6-A60 $251.95 Applies to FA5 & FA6

Applies to FA1, FA2, FE1, FM1, FM2, TE1 and TM1 models 2015-2019 Rear 08P70-HR3-W50 $139.95 (Not shown.)

Recoil Starter Kit

Allows the option to start the vehicle manually. Includes all necessary wiring and hardware. (Not shown.)

Applies to: 2015-17 FE1, FM1, FM2, TE1 and TM1 models, 2014 FA1, FA2, FE1, FM1, FM2, TE1 & TM1 models

08U70-HR3-A40 $109.95

Applies to: 2015-17 FA1, FA2, FA5 and FA6 models, 2014 FA & FPA models

08U70-HR3-A60 $115.95

Outdoor Storage Cover

Water-resistant and fade-resistant, this Honda-branded, heavy-duty, coated-polyester cover keeps your Utility ATV out of the weather and sun. Features double-stitched seams for added durability and a shock cord to ensure a snug fit. Will not fit when accessory Windscreen is installed.

08P34-HP5-200 $63.95 (Not shown.)

TRX420 (2007-2013)

(Applies to 2014 FA, FPA)

A- Windscreen

Premium polycarbonate material offers excellent impact resistance as well as nonyellowing, noncracking and UV-resistant properties. Features easy installation and removal.

0SR02-TRX-100 $272.95

B- Winch Kit

2,500 lb of pulling force. Rugged and reliable, features a handlebar-mounted mini-rocker switch that is fully sealed. Includes all required mounting-kit hardware. Limited lifetime warranty.

08L94-HP5-100 $529.95

C, D- Frame Skid Plates

Added protection for the ATV undercarriage and frame sides. Made of durable, lightweight, 0.16"-thick 5052 aluminum alloy.

Frame Skid Plate

08P51-HP5-100A $229.95

Rear Skid Plate

08P51-HP7-100B $124.95

E- A-Arm Guards

Added protection for front- and rearsuspension components from trail hazards such as rocks and logs. Constructed of lightweight, 0.125"-thick 5052 aluminum alloy.

Front 08P69-HP5-100A $129.95

Rear 08P69-HP7-100B $124.95

F- Rear Swingarm Guard

0.25"-thick 5052 aluminum alloy armor plate adds protection to swingarm against damage from rocks and debris.

2007-2013 08P51-HP5-100B $124.95

Miscellaneous

A- Trailer Hitch Kit*

Bolts directly to presets in rear frame and provides up to 850 lb of towing capacity.

RINCON ® (TRX650/680)

2003-2016 08L90-HN8-100 $47.95

Trailer Hitch Kit ** with Oil Temp Light

Features corrosion-resistant finish. Includes Oil Temp Light for added peace of mind while towing. Bolts directly to presets in rear frame. Tow weight 500 lb. Tongue weight 30 lb.

RECON ® (TRX250)

2009-2020 50820-HM8-B80 $322.88 (Not shown.)

B- 12V Front Accessory Socket

Add versatility to your ATV with this 12V power socket.

FOURTRAX RANCHER (TRX420)

B 2007-2013 Front 08U55-HP5-100 $39.95

FOREMAN (TRX500FE/FM/TM) 2005-2013 Rear 08U55-HP0-100 $43.95

Recoil Starter Kit

Allows the option to start the vehicle manually. Includes all necessary wiring and hardware. (Not shown.)

FOURTRAX FOREMAN RUBICON

2021 08U70-HR6-A60 $109.95

FOURTRAX RECON (TRX250TE/TM)

2021 08U70-HS0-AD0 $102.95

FOURTRAX RANCHER (TRX420)

2007-2013 08U78-HP7-100 $168.95

C- Soft Rear Rack Bag†

Made of 600-denier Yarn Dyed Polyester fabric with a DWR (Durable Water Repellent) finish that is UV resistant and durable in harsh conditions. Large main compartment with heavy duty zipper and Neoprene zipper gasket to protect against dirt, debris and water. Rear Bag has a 90,7 Liter capacity with quick-attach reinforced hook and loop straps for an easy and secure installation.

0SL56-HR3-100B $179.95

Outdoor Storage Cover

Water-resistant and fade-resistant, this Honda-branded, heavy-duty, coated-polyester cover keeps your Utility ATV out of the weather and sun. Features double-stitched seams for added durability and a shock cord to ensure a snug fit. Will not fit when accessory Windscreen is installed. (Not shown.)

XL 08P34-HP5-200 $63.95

XXL 08P34-HN8-200 $69.95

ACCESSORY INSTALLATION INSTRUCTIONS

APPLICATION GUIDE

TALON

ROOF/WINDSHIELDS/WIPER

Aluminum Roof

Aluminum Roof

Full Poly Vented Windscreen (hard coat)

Glass Windshield

Glass Windshield Wiper and Washer (2022-23)

Glass Windshield Wiper and Washer (2019-21)

Half Wind Deflector (hard coat)

DOORS

Aluminum Doors (front)

Aluminum Doors (rear)

Fabric Upper Doors (front and rear)

Fabric Upper Doors (front)

Lower Door Panels (front)

Lower Door Panels (rear)

REAR PANELS/MIRRORS

Rear Panel (hard coat)

Rear Panel (hard coat)

Fabric Rear Panel

Fabric Rear Panel

Rear View Mirror

Side Mirrors

PROTECTION

Intrusion Bar

A-Arm Guards (front, 2022-23)

A-Arm Guards (front, 2019-21)

A-Arm Guards (front, 2022-23)

A-Arm Guards (front, 2019-21)

Trailing Arm Guards

Trailing Arm Guards

Trailing Arm Mud Guards

Fender Flares

Frame Skid Plates

Frame Skid Plates

Nerf Bars

Nerf Bars

Side Skid Plates

Side Skid Plates

CARGO/INTERIOR

Cargo Bag

Cargo Box

0SL90-HL7-A00

0SL90-HL6-A00

0SR73-HL6-A00

0SU85-HL6-A00

0SE10-HL6-A10

0SE10-HL6-A01

0SR71-HL6-A00

0SA80-HL6-A00

0SA80-HL7-A00

0SR90-HL7-A00

0SR90-HL6-A00

08R77-HL6-A00

08P71-HL7-A20

0SB73-HL7-A00

0SB73-HL6-A00

0SR85-HL7-A00

0SR85-HL6-A00

0SV06-HL6-A00

0SV05-HL6-A00

0SA81-HL6-A00

0SK10-HL6-A01

0SK10-HL6-A00

0SK20-HL6-A10

0SK20-HL6-A00

0SK11-HL6-A00

0SK21-HL6-A01

0SK12-HL6-A00

0SF70-HL6-A01

0SK40-HL7-A00

0SK40-HL6-A00

08P70-HL7-A20

08P70-HL6-A40

0SK40-HL7-A00

0SK40-HL6-A00

0SL56-HL6-A00

0SL51-HL6-A01

TALON (Continued)

CARGO/INTERIOR (CONTINUED)

Half Cargo Box

Mount Plate

Roof Storage Bags

Corner Storage Bags

Center Storage Bag

Lower Front Door Storage Bags

Rubber Floor Mats (front and rear)

Rubber Floor Mats (front)

WINCH/BUMPERS

Winch (2021-23)

Winch Mount Kit

Aluminum Front Bumper (2022-23)

Aluminum Front Bumper (2019-21)

Aluminum Rear Bumper (2019-22)

Steel Front Bumper (2022-23)

Steel Front Bumper (2019-21)

Steel Rear Bumper

ELECTRICAL

Garmin Tread Powersport Navigator (2022-23)

GPS Wire Harness (2022-23)

Particle Separator

40” LED Light Bar (2022-23)

40” LED Light Bar (2019-21)

Auxiliary LED Lights (2022-23)

Auxiliary LED Lights (2019-21)

Light Bar/Aux Light Clamp (38-mm)

Switch Plate with Volt Meter (2019-21)

Switch Plate (2022-23)

Power Harness (2021-22)

Accessory Sub-Harness (2019-21)

Dome Light (2022-23)

Horn Kit

Horn Kit Wire Harness

Heater (2022-23)

AUDIO

Audio System

Rear Speakers

Rear Speakers Mount Kit

Subwoofer

Busbar

Busbar (2032, non-S models only)

0SL52-HL6-A01

0SL41-HL6-A01

0SL57-HL6-A00

0SL58-HL6-A00

0SL55-HL6-A00

0SL59-HL6-A00

0SP63-HL7-A00

0SP63-HL6-A00

0SL71-HL6-A20

0SL70-HL6-A00

0SP80-HL6-A01

0SP80-HL6-A00

0SP83-HL6-A00

0SP70-HL6-A01

0SP70-HL6-A00

0SP73-HL6-A00

0SS50-HL4-A00

04301-HL6-3050

0SB01-HL6-A01

0SV31-HL6-A10

0SV31-HL6-A00

0SV41-HL6-A10

0SV41-HL6-A00

0SV31-HL3-201A

0SA30-HL6-A00

0SA30-HL6-A10

0SA31-HL7-A00

0SZ08-HL6-A00

0SV51-HL6-A00

08P75-HL5-A00

08Z70-HL6-A00

0SE08-HL6-A00

0SS22-HL6-A00

0SS22-HL4-A40

0SS23-HL6-A00

0SS22-HL6-A50

0SS27-HL6-A00

0SS27-HL6-A10

APPLICATION GUIDE

TALON (Continued)

AUDIO (CONTINUED)

Busbar Cable

Fuse Box (2022-23)

Fuse Box Mount (2022-23)

Fuse Box Mount (2023, non-S models only))

Accessory Wiring Connector (2022-23)

MISCELLANEOUS

Flag Kit

Full Storage Cover

Full Storage Cover

0SL72-HL6-A00

0SS25-HL4-A00

0SS26-HL6-A00

0SS26-HL6-A10

0SZ05-HL6-A00

0SR95-HL6-A00

0SP35-HL7-A00

0SP35-HL6-A00

PIONEER 1000/1000-5/1000-6

TOPS/REAR PANELS

Hard Roof (Black)

Hard Roof (Black)

Hard Roof (Gray/Black)

Hard Roof (Black)

Hard Roof (Gray/Black)

Fabric Roof/Rear Panel (Black)

Fabric Roof/Rear Panel (Black)

Fabric Roof/Rear Panel (Black)

Bimini Top (Black)

Bimini Top (Black)

Bimini Top (Black)

Hard Mid/Rear Panel (Black)

Hard Mid/Rear Panel (Gray/Black)

Hard Mid/Rear Panel (Black)

Hard Mid/Rear Panel (Gray/Black)

Hard Rear Panel

Fabric Mid-Panel

Fabric Rear Panel (Black)

Fabric Rear Panel

Fabric Rear Panel (2022-23)

WINDSHIELD/WINDSCREENS

Glass Windshield

Full Poly Windscreen (Vented, Hard Coat)

Full Poly Windscreen (Vented, Optical Grade)

2-Piece Poly Windscreen (Hard Coat)

ACCESSORY INSTALLATION INSTRUCTIONS are

powersports.honda.com/accessories/listing

0SR85-HL8-A00

0SR85-HL4-A50

0SR85-HL4-G50

0SR85-HL4-A30

0SR85-HL4-G30

0SR85-HL8-210B

0SR85-HL4-222A

0SR85-HL4-211A

0SR85-HL8-322A

0SR85-HL4-322A

0SR85-HL4-322B

0SU95-HL4-A50

0SU95-HL4-G50

0SU95-HL4-A30

0SU95-HL4-G30

0SU95-HL8-A00

0SR95-HL4-211A

0SR95-HL8-211B

0SR95-HL4-211B

0SR95-HL4-206B

0SU85-HL4-A00

0SR72-HL4-A20

0SR72-HL4-A10

0SR71-HL4-A20

APPLICATION

PIONEER 1000/1000-5/1000-6 (Continued)

WINDSHIELD/WINDSCREENS (CONTINUED)

2-Piece Poly Windscreen (Optical Grade)

Half Wind Deflflector

Glass Windshield Wiper and Washer (2016-21)

Glass Windshield Wiper Kit (2016-21)

DOORS

Hard Front Doors (Gray/Black)

Fabric Front Doors (Black)

Fabric Front Doors (Camo, 2021-23)

Fabric Front Doors (Camo)

Fabric Rear Doors (Black)

Fabric Rear Doors (Black)

Fabric Rear Doors (Camo, 2021-23)

WINCH/PLOW/TOWING

Winch

Winch Mount Kit

Winch Mount Kit (2016)

Plow Blade (72")

Plow Push Tubes

Plow Mount Kit

Plow Pulley Kit

Draw Bar (2017-2023)

Hitch Ball

Receiver Hitch Plug

PROTECTION

A-Arm Guards (HMWPE, Front, 2016-21)

A-Arm Guards (HMWPE, Rear, 2016-21))

0SR71-HL4-A10

0SR73-HL4-A00

0SE10-HL4-A00

0SE10-HL3-500

0SU95-HL4-GD0

0SR90-HL4-212A

0SR90-HL4-232C

0SR90-HL4-222A

0SR90-HL8-210B

0SR90-HL4-212B

0SR90-HL4-252C

08L71-HL3-A43

08L72-HL4-AK1

08L72-HL4-A04

0SL76-HL4-A00

0SL70-HL4-A00

0SL73-HL4-A00

08L77-HL4-A01

08L90-HL1-100A

08L90-HL1-100C

08L76-HL4-A00

0SP74-HL4-200

0SP75-HL4-100

Aluminum A-Arm Guards (Front, 2022-23) 08P70-HL4-AK0

Aluminum A-Arm Guards (Front, 2016-21) 08P72-HL4-F00

Aluminum A-Arm Guards (Rear) 08P73-HL4-F00

Aluminum Skid Plates (2021-23) 08P73-HL4-AK0

Aluminum Skid Plates (2016-21) 08P71-HL4-F00

HMWPE Skid Plate

0SK30-HL8-A00

HMWPE Skid Plate (2022-23) 0SK30-HL4-A00

Front Bumper/Brush Guard (2022-23) 08P71-HL4-AK0

Front Bumper/Brush Guard (2016-21) 08P70-HL4-A00

Steel Front Bumper/Brush Guard 08P71-HL8-A10

Rear Bumper (2017-23) 08P72-HL4-AK0

Rear Bumper (2017-23) 08P70-HL4-AN0

APPLICATION GUIDE

PIONEER 1000/1000-5/1000-6 (Continued)

PROTECTION (CONTINUED)

Rear Bumper (2017-21)

Rear Bumper (2017-21)

Front Fender Flares (2022-23)

Front Fender Flares (2016-21)

Seat Covers (Camo, 2021-23)

Rear Seat Covers (Camo, 2021-23)

Rubber Floor Mat (2022-23)

Rubber Floor Mat (2016-21)

Storage Cover

Storage Cover

Storage Cover

CARGO

Carpet Bed Mat

Carpet Bed Mat

Bed Mat (2022-23)

Bed Mat (2016-21)

Bed Mat (2022-23)

Bed Mat (2016-21)

Bed Extender

Bed Liner (Non CA)

Bed Liner (CA)

Cab Frame Cargo Bag

Underseat Storage Bag

Storage Bag

08P70-HL4-A50

08P73-HL4-A00

08F70-HL4-AK0

08P70-HL4-F00

0SP32-HL4-A30C

0SP32-HL3-A40C

0SP63-HL4-102

0SP63-HL4-101

0SP34-HL8-100

0SP34-HL4-100

0SP35-HL4-100

0SP44-HL4-A50

0SP44-HL4-A30

0SP42-HL4-502

0SP42-HL4-501

0SP42-HL4-202

0SP42-HL4-201

08L71-HL4-A02

0SP43-HL4-203

0SP43-HL4-203CA

0SL57-HL3-101

0SL77-HL8-A00

0SH55-HL8-A00

Under Seat Storage (18.5 Liter, 2022-23) 08L71-HL4-AK0

Under Seat Storage (20 Liter, 2017-21)

Underdash Storage Pocket (2016-23)

Dash Pocket Net (2022-23)

Load Leveling Suspension System (2017-23)

Load Leveling Suspension System (2016)

Fox Shocks 5P (Front, Pair)

Fox Shocks 5P (Rear, Pair)

Fox Shocks 3P (Front, Pair)

Fox Shocks 3P (Rear, Pair)

ELECTRICAL

Garmin Tread Powersport Navigation

GPS Wire Harness

Heater (2022-23)

Heater (2016-21)

08L70-HL4-F00

08L71-HL4-F00

0SL60-HL4-A00

08Z70-HL4-M50

08Z70-HL4-A51

08Z70-HL4-F00

08Z71-HL4-F00

08Z70-HL4-F50

08Z71-HL4-F50

0SS50-HL4-A00

0SS51-HL4-A00

0SE08-HL4-A00

0SE01-HL4-102

PIONEER 1000/1000-5/1000-6 (Continued)

ELECTRICAL (CONTINUED)

Dome Light (2022-23)

20-inch LED Light Bar

LED Auxiliary Lights (2022-23)

LED Auxiliary Lights

LED Headlights (2016-23)

LED Headlights (2016-21)

LED Headlights Wire Harnes s (2022-23)

0SV51-HL6-A00

0SV31-HL4-A00

0SV41-HL3-A10

0SV31-HL3-201

08V70-HL4-AK0

08V71-HL4-A0O

08V70-HL4-AQ0

LED Headlights Wire Harnes s (2016-21) 33130-HL4-A10

Switch Plate/Volt Meter/Wire Harness (2016-21)

45-mm Light Bar/Auxiliary Lights Clamp

Audio System

Rear Speaker Pods

Rear Speaker Mount Kit

Powered Subwoofer

Powered Subwoofer

Fuse Box (2022-23)

Fuse Box and Audio Mount Bracket (2022-23)

Fuse Box Relocation Bracket (2016-21)

Fuse Box Wiring Kit (2022-23)

Horn Kit

Horn Kit Wire Harness

Back-Up Alarm

Back-Up Alarm Mount

MIRRORS (Not intended for on-road use)

Rearview Mirror (2022-23)

Rearview Mirror (2016-21)

Side Mirrors

MISCELLANEOUS

Drink Holder (2016-21)

Flag with Mount

0SA30-HL4-100

0 s V31-HL4-201A

0SS22-HL4-A00

0SS22-HL4-A40

0SS23-HL4-A00

0SS22-HL8-A50

0SS22-HL4-A50

0SS25-HL4-A00

0SS27-HL4-A00

0SA30-HL4-100B

0SS26-HL4-A00

08P75-HL5-A00

08Z77-HL4-A00

08V70-HL5-A00

08Z76-HL4-A00

0SV05-HL4-300

0SV05-HL4-201

0SV05-HL4-202

08U70-HL3-A40

0SR95-HL4-F10

APPLICATION GUIDE

PIONEER 700/700-4

TOPS/REAR PANELS

Hard Roof (extended)

Hard Roof (short)

Hard Roof (short)

Hard Roof

Fabric Roof/Rear Panel (Black)

0SR85-HL3-100

0SR85-HL3-101

0SR85-HL3-101B

08R70-HL5-A01

0SR85-HL3-223A

Fabric Roof/Rear Panel (Camo, 2022-24) 0SR85-HL3-240C

Fabric Roof/Rear Panel (Camo, 2014-22) 0SR85-HL3-221C

Fabric Roof/Rear Panel (Black) 0SR85-HL3-211A

Fabric Roof/Rear Panel (Camo, 2021-24) 0SR85-HL3-220C

Fabric Roof/Rear Panel (Rear Section) 0SR85-HL3-223B

Fabric Roof/Rear Panel (Black) 0SR85-HL5-A01B

Fabric Roof/Rear Panel (Camo) 0SR85-HL5-A01C

Fabric Roof/Rear Panel (Black) 0SR85-HL5-200

Fabric Roof/Rear Panel (Camo) 0SR85-HL5-400C

Bimini Top (Black)

0SR85-HL3-323A

Bimini Top (Black) 0SR85-HL3-322B

Bimini Top (Black) SR85-HL5-321C

Bimini Top (Black) 0SR85-HL5-322B

Bimini Top (Camo) 0SR85-HL5-422C

Hard Rear Panel (2017-24) 0SU95-HL3-102A

Hard Rear Panel (2014-16) 0SU95-HL3-102

Hard Mid/Rear Panel (Extd Roof, 2017-21) 0SU95-HL3-104C

Hard Mid/Rear Panel (Extd Roof, 2014-16) 0SU95-HL3-104B

Hard Mid/Rear Panel (Shrt Roof, 2017-24) 0SU95-HL3-102C

Hard Mid/Rear Panel (Shrt Roof, 2014-16) 0SU95-HL3-102B

Fabric Mid-Panel 0SR95-HL3-211A

Fabric Rear Panel 0SR95-HL3-211B

Fabric Rear Panel OSR95-HL5-A01

Fabric Rear Panel 0SR95-HL5-100

WINDSHIELD/WINDSCREENS

Glass Windshield (2022-24) 0SU95-HL3-A00

Glass Windshield (2014-22) 0SU95-HL3-105

Full Poly Windscreen (Hard Coat) 08R73-HL3-A00

Full Poly Windscreen (Optical Grade) 0SR73-HL3-200

2-Piece Poly Windscreen (Hard Coat) 08R72-HL3-A00

2-Piece Poly Windscreen (Optical Grade) 0SR72-HL3-100

Full Tip-Out Windscreen (Hard Coat) 08R74-HL5-A01

Full Tip-Out Poly Windscreen (Optical Grade) 0SR73-HL5-100

PIONEER 700/700-4

500 (Continued)

WINDSHIELD/WINDSCREENS (CONTINUED)

Half Wind Deflflflflffllector (Optical Grade)

0SR71-HL3-A00

Half Wind Deflflflflffllector (Optical Grade) 0SR73-HL5-101B

Glass Windshield Wiper/Washer Kit (2023-24) 0SE10-HL3-A00

Glass Windshield Wiper (2014-22) 0SE10-HL3-500

DOORS

Hard Front Doors (2023-24) 0SU90-HL3-A00

Hard Front Doors (2017-22) 0SU95-HL3-104A

Fabric Front Doors (Black, 2023-24)

0SU92-HL3-A00

Fabric Front Doors (Black, 2017-22) 0SR91-HL3-211A

Fabric Rear Doors (Black) 0SR91-HL3-211B

Fabric Front Doors (Camo, 2023-24) 0SU92-HL3-G00

Fabric Front Doors (Camo, 2017-22) 0SR92-HL3-221C

Fabric Front Doors (Camo) 0SR92-HL3-221A

Fabric Rear Doors (Camo, 2021-24) 0SR91-HL3-221C

Fabric Rear Doors (Camo, 2014-16) 0SR91-HL3-211C

Fabric Rear Doors (Camo), 2021-22 OSR92-HL3-241C

Fabric Rear Doors (Camo) 0SR91-HL3-211C

Fabric Front Doors (Black) 0SR90-HL5-A01B

Fabric Front Doors (Camo) 0SR90-HL5-A01C

Fabric Front Doors (Black) 0SR90-HL5-210

Fabric Front Doors (Camo) 0SR90-HL5-410C

WINCH/PLOW/TOWING

Winch

08L71-HL3-A43

Winch 08L71-HL5-E61

Winch 08L71-HL5-A02

Winch Mount Kit (2023-24) 0SL72-HL3-A00

Winch Mount Kit (2017-22) 08L70-HL3-601

Winch Mount Kit (2014-16) 08L70-HL3-A41

Winch Mount Kit 08L70-HL5-E60

Plow Blade, 72" (2023-24) 0SL76--HL4-A00

Plow Blade , 72" (2014-22) 08L75-HL3-A01

Plow Blade, 60" 0SL76-HL5-A00

Plow Blade, 54" 08L76-HR3-A21

Plow Push Tubes 0SL70-HL4-A00

Plow Push Tubes 0SL70-HL5-A00

Plow Push Tubes 08L70-HL5-A01

Plow Mount (2022-24) 0SL73-HL3-A00

Plow Mount Kit (2014-21) 08L70-HL3-A00

APPLICATION GUIDE

PIONEER 700/700-4

WINCH TOWING

Plow Mount

0SL73-HL5-A00

Draw Bar (2014-24) 08L90-HL1-100A

Draw Bar

Hitch Ball

08L76-HL5-A00

08L90-HL1-100C

Receiver Hitch Plug 08L76-HL4-A00

PROTECTION

Aluminum A-Arm Guards (Front) 08P72-HL3-600

Aluminum A-Arm Guards (Front) 08P73-HL3-A00

Aluminum A-Arm Guards (Rear) 08P74-HL3-A00

Aluminum A-Arm Guards (Front) 08P70-HL5-A00

Aluminum A-Arm Guards (Rear) 08P71-HL5-A00

HMWPE Skid Plates

Aluminum Skid Plates

Nerf Bars

Steel Front Bumper

Front Bumper

Steel Rear Bumper

Rear Bumper

Rear Bumper

Front Fender Flares

08P71-HL3-601

08P70-HL5-A40

0SP74-HL5-A00

08P76-HL3-A00

08P73-HL5-A00

08P75-HL3-A00

08P70-HL5-E60

08P74-HL5-A00

08P70-HL3-600

Front Seat Covers (Camo, 2022-24) 0SP32-HL3-A20C

Rear Seat Covers (Camo, 2021-24) 0SP32-HL3-A40C

Rubber flFloor Mat (2023-24) 0SP63-HL3-102

Rubber flFloor Mat (2017-22) 0SP63-HL3-101

Rubber flFloor Mat 0SP63-HL5-101

Storage Cover (2023-24) 0SP34-HL3-A00

Storage Cover (2014-22) 0SP34-HL3-100

Storage Cover (2023-24) 0SP35-HL3-A00

Storage Cover (2014-22) 0SP35-HL3-100

Full Storage Cover w/Accessories 0SP35-HL5-A00

Full Storage Cover

0SP35-HL5-A00

Full Storage Cover 0SP35-HL5-201

CARGO

Poly Bed Liner (2017-24) 0SP43-HL3-102

Poly Bed Liner (2014-16) 0SP43-HL3-101

Carpet Bed Mat

Carpet Bed Mat

†Does not apply to LE Models.

500 (Continued)

0SP44-HL3-A40

0SP44-HL3-A20

PIONEER 700/700-4

CARGO (CONTINUED)

Rubber Bed Mat (2023-24)

Rubber Bed Mat (2014-22)

Rubber Bed Mat (2014-22)

Bed Extender

Bed Rack

Bed Rails

Rear Cab Net

Rear Cab Net

Rear Rack Bag (large)

Cab Frame Cargo Bag

Cab Frame Cargo Bag

Under Seat Storage Box

Front Underhood Tray

Underdash Storage Tray

Cargo Tray

Half Cargo Box

Mount Plate

Chainsaw Mount

Multi-Tool Holder

ELECTRICAL

0SP42-HL3-202

0SP42-HL3-201

0SP42-HL3-101

08L74-HL3-A41

0SE57-HL5-A00

0SB18-HL5-A00

0SR95-HL3-200B

0SR95-HL5-200B

0SL56-HL5-100A

0SL57-HL3-101

0SL57-HL5-101

08L77-HL5-A00

08L78-HL5-A00

08L73-HL3-A41

08L70-HL5-A40

0SL52-HL6-A01

0SL41-HL5-A00

0SC13-HL5-A00

0SM19-HL5-A00

Garmin Tread Powersport Navigation 0SS50-HL4-A00

Heater (2023-24)

0SE02-HL3-A00

Heater (2014) 0SE01-HL3-104 * *

Fuse Box (2023-24) 0SS25-HL4-AOO

Fuse Box Wiring Kit (2023 -24) 0SS26-HL3-A00

Busbar Kit (2023-24) 0SS27-HL3-A00

Busbar Cable (2023-24) 0SL25-HL4-A00

20-inch LED Light Bar (2016-24) 0SV31-HL4-A00

LED Auxiliiary Lights (2023-24) 0SV41-HL3-A10

LED Auxiliary Lights (2017-22) 0SV31-HL3-201

LED Auxiliary Light/Light Bar Wire Harness 0SV31-HL5-201E

LED Headlights (2023-24) 08V71-HL4-A00

LED Headlights (2017-22) 08V70-HL4-AK0 † †

LED Headlights Wire Harnes S (2023-24) 08Z70-HL3-B40 * *

LED Headlights Wire Harnes S (2017-22) 0SV15-HL3-A00 * *

Bedlight/Outlet Kit (4P, 2023-24) 0SU74-HL3-A00

Bedlight/Outlet Kit (2P, 2023-24) 0SU72-HL3-AOO

APPLICATION GUIDE

PIONEER 700/700-4

ELECTRICAL

(CONTINUED)

LED Work Light

08U71-HL5-A00

LED Work Light Wire Mount (2017-22) 08Z71-HL3-600

LED Work Light Wire Harness 08Z70-HL5-A00

Dome Light (2023-24) 0SV51-HL6-A00

Sw. Plate/V. Meter/W. Harness (2014-22) 0SA30-HL3-100

38-mm Light Bar/Auxiliary Lights Clamp 0SV31-HL3-201A

41-mm Light Bar/Auxiliary Lights Clamp 0SV31-HL3-302A

44-mm Light Bar/Auxiliary Lights Clamp 0SV31-HL3-301B

Accessory Sub Harness (2014-16) 08Z02-HL3-A00

Accessory Sub Harness (2017-22) 08Z01-HL3-600

Accessory Sub Harness

Horn Kit (2023-24)

08Z08-HL5-A00

0SV09-HL3-A00

Horn Kit (2017-22) 08P72-HL3-A00

Horn Kit 08P75-HL5-A00

Horn Kit Wire Harness

08Z71-HL5-A00

Back-Up Alarm (2017-24) 0SV70-HL5-A00

Back-Up Alarm (2014-16) 08V70-HL3-A01

Back-Up Alarm Mount Kit 08Z73-HL3-600

Back-Up Alarm Mount Kit

08Z70-HL5-E60

Back-Up Alarm Wire Harness 08V70-HL5-E60

Back-Up Alarm Wire Harness 08V71-HL5-A00

MIRRORS (Not intended for on-road use)

Rearview Mirror

0SV05-HL5-201

Side Mirror (door mount) (2017-24) 0SV05-HL5-100

Side Mirror Brackets** (2017-22) 0SV10-HL3-200

MISCELLANEOUS

Drink Holder (2014-24) 08U70-HL3-A40

Flag with Mount

BIG RED ™

0SR95-HL3-F10

TRX520/420 2020-24

WORK

Winch (2022)

Winch Mount Kit (2022)

Part Number

08L71-HL5-E61

08L70-HR6-MF0

Winch Mount Kit (2020-21) 08L74-HR3-A20

Plow Blade (54")

Plow Mount Kit

Plow Push Tube Set

PROTECTION

Windscreen

Windscreen

Front Bumper

Rear Bumper

08L76-HR3-A21

08L75-HR3-A20

08L77-HR3-A21

0SR01-HR5-100

0SR02-TRX-100

08P70-HR3-WA0

08P73-HR6-A60

Front A-Arm Guards 08P70-HR6-B00

Front A-Arm Guards 08P70-HR3-WB0

Rear A-Arm Guards 08P70-HR6-A60

Frame Skid Plates

Rear Frame Skid Plate

08P74-HR6-A60

08P72-HR6-A60

Rear Swingarm Guard 08P71-HR3-620

CARGO

Front Carrier Extender

Rear Carrier Extender

Front Cargo Box

Rear Cargo Box

Front Utility Basket

Rear Utlity Basket

Soft Rack Bag (Front)

Soft Rack Bag (Rear)

Side Pocket Net

Cup Holder

OTHER

Front Aluminum Wheel

Rear Aluminum Wheel

Heated Grips

Recoil Starter Kit

Recoil Starter Kit

Recoil Starter Kit

0SL73-HR4-A01

0SL74-HR4-A01

0SL53-HR6-A01

0SL54-HR6-A01

0SL63-HR3-A01

0SL64-HR3-A01

0SL56-HR3-100A

0SL56-HR3-100B

08L72-HR4-A20

0SC38-HR5-A00

08W70-HR5-A20

08W71-HR5-A20

0ST71-HR3-A00

08U70-HR3-A40

08U70-HR3-A60

08U70-HR6-A60

APPLICATION GUIDE

TRX520/420 2020-24 (Cont.)

OTHER (CONTINUED)

12v Front Accessory Socket

Accessory Sub-Harness

Accessory Sub-Harness

Outdoor Storage Cover

Outdoor Storage Cover

08U70-HR3-A20

08Z01-HR3-A20

08Z00-HR3-A20

08P34-HN8-200

08P34-HP5-200

TRX500 2014-2019

Description

WORK

Winch

Winch Mount Kit

Plow Blade (54")

Plow Mount Kit

Plow Push Tube Set

PROTECTION

Windscreen

Windscreen

Rear Bumper

A-Arm Guards (Front)

A-Arm Guards (Rear)

Frame Skid Plate

Rear Frame Skid Plate

Rear Swingarm Guard

Outdoor Storage Cover

CARGO

Soft Rack Bag (Rear)

08L71-HL5-A02

08L74-HR3-A20

08L76-HR3-A21

08L75-HR3-A20

08L77-HR3-A21

0SR01-TRX-100

0SR01-HR5-100

08P73-HR6-A60

08P71-HR6-A60

08P70-HR6-A60

08P74-HR6-A60

08P72-HR6-A60

08P71-HR3-620

08P34-HN8-200

0SL56-HR3-100B

Side Pocket Net 08L72-HR4-A20

OTHER

Heated Grips

Recoil Starter Kit

Recoil Starter Kit

Accessory Sub Harness

Aluminum Wheel (Front)

Aluminum Wheel (Rear)

0ST71-HR3-A00

08U70-HR3-A40

08U70-HR6-A60

08Z01-HR3-A20

08W70-HR5-A20

08W71-HR5-A20

TRX420 2014-19

WORK

Winch Mount Kit

Plow Blade (54")

Plow Mount Kit

Plow Push Tube

PROTECTION

Windscreen

Front Bumper

Rear Bumper

Rear Bumper

A-Arm Guards (Front)

A-Arm Guards (Rear)

Frame Skid Plate

Rear Frame Skid Plate

Rear Swingarm Guard

Outdoor Storage Cover

CARGO

Soft Rack Bag (Rear)

Side Pocket Net

Heated Grips

Recoil Starter Kit

Recoil Starter Kit

12v Front Accessory Socket

Accessory Sub Harness

Accessory Sub Harness

08L74-HR3-A20

08L76-HR3-A21

08L75-HR3-A20

08L77-HR3-A21

0SR02-TRX-100

08P72-HR3-620

08P73-HR6-A60

08P70-HR3-W50

08P70-HR3-620

08P70-HR6-A60

08P74-HR6-A60

08P72-HR6-A60

08P71-HR3-620

08P34-HP5-200

0SL56-HR3-100B

08L72-HR4-A20

0ST71-HR3-A00

08U70-HR3-A40

08U70-HR3-A60

08U70-HR3-A20

08Z01-HR3-A20

08Z00-HR3-A20

APPLICATION GUIDE

ATV UTILITY

Winch

Winch Mount Kit

Winch Kit

Winch Kit

Winch Kit

Plow Blade (54")

Plow Push Tube Set

Plow Mount Kit

PROTECTION

Windscreen

Windscreen

Replacement Arm and Clamp for ATV Windscreen (Left & Right)

Brush Guard

Brush Guard

Rear Frame Skid Plate

A-Arm Guards (Front)

A-Arm Guards (Rear)

Skid Plate

A-Arm Guards (Front)

Frame Skid Plate

A-Arm Guards (Front)

Rear Swingarm Guard

Frame Skid Plate

Rear Swingarm Guard

A-Arm Guards (Front)

Frame Skid Plate

Rear Frame Skid Plate

Rear Swingarm Guard

A-Arm Guards (Front)

A-Arm Guards (Rear)

08L71-HL5-A02

08L74-HR3-A20

08L94-HR0-100

08L94-HP0-100

08L94-HP5-100

08L76-HR3-A21

08L77-HR3-A21

08L75-HR3-A20

0SR02-TRX-100

0SR01-TRX-100

0SR01-TRX-100RL

08P53-HN8-100

08P53-HP5-100

08P51-HN8-100B

08P69-HP0-100A

08P69-HN8-100B

08P74-HR3-A20

08P71-HR6-A60

08P51-HR0-100A

08P69-HR0-100A

08P51-HR0-100B

08P51-HP0-100A

08P51-HP0-100B

08P69-HP0-100A

08P51-HP5-100A

08P51-HP7-100B

08P51-HP5-100B

08P69-HP5-100A

08P69-HP7-100B

Rack Bag (Rear)

ATV UTILITY (Continued)

OTHER

Trailer Hitch Kit

Heated Grips

12-Volt Power Outlet

Accessory Sub-Harness

Heated Grips and/or Winch

Accessory Sub-Harness

Heated Grips, Winch and/or 12V Socket

12-Volt Front Accessory Socket

Recoil Starter

Recoil Starter

Recoil Starter Kit

Outdoor Cover XXL

Outdoor Cover XL

08L90-HN8-100

0ST71-HR3-A00

08U70-HR3-A20

08Z00-HR3-A20

08Z01-HR3-A20

08U55-HP5-100

08U70-HR3-A40

08U70-HR3-A60

08U78-HP7-100

08P34-HN8-200

08P34-HP5-200

1. Excludes TRX420FA and TRX420FPA. Includes all other 2014 TRX420 models. 2. Includes 2014 TRX420FA and TRX420FPA. Excludes all other 2014 TRX models.

and Chemicals

European model shown.

European models shown.

Only Pro Honda Offers Oils And Chemicals That Are Designed To

The Same Exacting Standards As Your Honda Motorcycle.

Nobody offers a more comprehensive line of motorcycle-specific oils and chemicals than Pro Honda. And nobody else crafts these products to the industry’s most demanding standards—Honda’s!

Pro Honda Oils and Chemicals are developed through the most severe test of performance and durability: professional racing. From the high banks of Daytona to the brutal Baja desert, Team Honda’s racing motorcycles and ATVs put our products to the test at every event. Unlike some oils and chemicals that are based on automotive products, Pro Honda Oils and Chemicals are motorcycle-specific products designed to meet the unique demands of motorcycle and ATV riders and racers.

Take, for example, Pro Honda’s latest JASO-approved HP4S fully synthetic

four-stroke engine oil. JASO stands for the Japanese Automobile Standards Organization. With strong input from Honda R&D, JASO established standards classifying the specific performance for motorcycle engine oils.

These standards were established to meet the higher demands of motorcycle engines. Compared to cars, motorcycle engines produce more power per displacement, run at higher RPM, and have smaller capacity oil volumes and cooling systems. Plus, motorcycles use their oil to lubricate their transmissions and clutches. Auto oils lack the ability to withstand the shear forces created by the transmission’s gear teeth, which quite literally tear the oil molecules apart. Also, their antifriction additives can cause a motorcycle’s clutch to slip. Pro Honda’s latest HP4S, though, is formulated

especially for use in motorcycles and ATVs to offer the ultimate in performance on or off the track.

Everything Pro Honda offers—two-stroke oil, suspension fiuids, coolant, brake fiuids, air-filter oils, chain lubes, cleaners and other vital fiuids—is formulated to be the very best. They’re what factory Honda race teams depend on to win! And nobody wins more National Motorcycle Championships than Honda.

Honda builds its Powersports products to the toughest engineering standards in the world. Pro Honda formulates its oils and chemicals to those same demanding standards to keep your Honda running at its maximum performance. They’re the very best motorcycle-specific products you can buy. And they are available exclusively at your Honda Dealer.

Visit Pro Honda online

A useful and highly informative website has been created just for Pro Honda Oils, Chemicals and Merchandise.This user friendly portal provides detailed information on all Pro Honda offerings in a convenient location, and is easily accessible by dealers and consumers. www.prohondaoils.com – the ultimate oil and chemical resource.

OILS

Pro Honda HP4RU

Pro Honda HP4RU Whether racing or for daily use, HP4RU improves clutch performance, delivers maximum horsepower and protects your engine better than any competitive brand! Meet Pro Honda HP4RU, a full synthetic, high performance, 4-stroke racing oil designed to provide a superior riding experience both on the track and over the road.

Pro Honda HP4S

Pro Honda HP4S is Honda’s first fully synthetic four-stroke motorcycle oil and was quite literally years in the making. HP4S offers lower friction than conventional oils, better oxidation resistance for better high-heat performance, higher film strength and quicker flow to vital engine parts at low temperatures, especially during startup. And best of all, HP4S provides maximum power due to less frictional drag. HP4S is approved for use in all 2006 or newer motorcycles, ATVs, Scooters and PWC. It is, quite simply, our very finest four-stroke oil. HP4S is compatible with synthetic blends such as HP4, as well as regular petroleum oils like GN4. There is no need to flush the crankcases before switching to HP4S.

Pro Honda HP4

Thanks to the establishment of JASO standards, HP4’s extraordinary additive package offers increased antifoaming qualities, a higher viscosity index for stability over a broader range of temperatures and even greater shear stability than most other oils. Naturally, HP4 blends the heat stability and shear resistance of synthetic oil with mineral oil’s natural lubricity, yielding premium-quality four-stroke engine oil. Best of all, HP4 is approved for use in all Honda Powersports products.

Pro Honda HP4M

A synthetic/mineral-oil blend that combines the very best qualities of both types, HP4M also features a comprehensive additive package and friction-reducing molybdenum compound for maximum fuel economy and peak horsepower. HP4M—the Pro Honda oil good enough to win a multitude of AMA National Championships as well as the grueling Baja 500 and 1000.

FOUR-STROKE OILS

08C35-HP4--1030RU

10W30 (Quart)

08C35-A251X01

Pro Honda HP2

Pro Honda HP2 is simply the finest two-stroke oil money can buy. Premium synthetic base stocks with high film strength give maximum wear protection while allowing a crisp 32:1 mixture ratio. The extremely clean-burning formula minimizes carbon deposits, extends spark plug life and reduces maintenance on Honda Power Port and ATAC systems. Special additives minimize friction for cooler running, maximum horsepower and quicker throttle response.

Pro Honda GN4

Honda set the standard for motorcycle oil when it introduced GN4 back in 1975. We selected the highest-quality base stocks and created an additive package specifically designed for the unique requirements of motorcycle and ATV engines. Constant testing and development give today’s GN4 even better shear resistance, viscosity stability and cleanliness to meet the requirements and stresses of a new era of engine technology.

Pro Honda GN2

Pro Honda GN2 is the only oil that has been tested and approved by Honda R&D for use in all older liquid-cooled and air-cooled two-stroke Honda Motorcycles, ATVs and Scooters. Its unique, clean-burning formula reduces exhaust smoke, carbon buildup and varnish deposits and helps prevent spark-plug fouling, ring sticking and exhaust plugging. GN2’s superior lubrication extends service life for piston rings and bearings and helps prevent against rust and corrosion.

Pro Honda HP Trans Oil

HP Trans Oil's cutting-edge, high-performance racing transmission oil is specifically formulated for all Honda CR and FourTrax® 250R models. HP Trans Oil is also the hot tip for use in all Honda CRF four-stroke transmissions. Transmission gears can whip conventional oil into a froth, and intense pressure at their teeth can lead to metal-to-metal contact. HP Trans Oil offers ultrahigh film strength and shear stability to minimize transmission wear, while its high thermal stability prevents foaming and premature oil breakdown. Special antifriction additives allow smoother shifting while minimizing drag and power loss. Antishear additives increase clutch life, reducing clutch slippage.

Pro

CLEANERS AND POLISHES/VITAL FLUIDS

CLEANERS & POLISHES

Spray Cleaner & Polish

• The #1-selling, original industry standard

• Exclusive Honda formula—superior performance at an economical price

• Complete detailer in a can

• Cleans road grime, grease and bugs without water

• Polishes paint, chrome, glass and clear plastic

• Protects vinyl, plastic and rubber

• Blocks UV rays to reduce fading and cracking

• Repels water and makes it bead up like on a wax finish

• Antistatic properties reduce dust buildup

Hondabrite™

• Cleans an entire motorcycle or ATV in just minutes

• Removes dirt, oil, road grime and insects

• Cleans paint, chrome, alloy and rubber

• Contains powerful corrosion inhibitors

• Easy to spray on and hose off

• Surface safe when used as directed

Detailer & Protectant

• Helps to restore original factory shine

• High gloss coating that helps to protect surfaces such as plastic, vinyl, rubber and carbon fiber

• Durable, long lasting coating that repels the elements (dirt, mud and other trail/road debris)

• Restores dull looking plastic.

• Leaves a high gloss shine

VITAL FLUIDS

HP Coolant

• Exclusive formula developed by Honda R&D

• Specifically designed for use in aluminum engines

• Uses high-tech organic corrosion inhibitors instead of more commonly used silicate corrosion inhibitors

• Unlike silicates, HP Coolant’s organic corrosion inhibitors won’t gel and cause radiator plugging

• These inhibitors are also more stable for a longer shelf life and don’t act as abrasives to mechanical water-pump seals, which may cause leaky seals

KYB Fork & Shock Oil

• Genuine KYB fork and shock oil specifically designed for the CRF450R equipped with KYB suspension (Not shown.)

HP Fork Oil SS-47

• Original equipment on several 2007 and newer motorcycles

HP Fork Oil A15-00

• Specially designed by SHOWA for 2019 and newer Honda CRF250R/RX, and CRF450R/RX/WE front forks.

• Increased service life of suspension components.

• Excellent damping performance at varying ride and temperature conditions.

SS-7 5W Suspension Fluid

• Genuine Showa fluid designed for use with cartridge-type and standard forks as well as rebuildable rear shocks including Pro-Link® systems

• Replaces ATF recommendations in owner’s manuals

• Gold in color

SS-8 10W Suspension Fluid

† Not pictured.

• Genuine Showa fluid designed for use with cartridge type or standard forks

• Recommended for firmer handling or heavier loads

• Bright red in color

VITAL FLUIDS

Shaft Drive Oil

• Single-application hypoid gear oil SAE 80W90

• Approved for use in Honda Gold Wings and other shaft-drive motorcycles and ATVs

• Exceeds API service classifications GL-4 and GL-5

DOT 4 Brake Fluid

• High-temperature formula for heavy-duty or racing applications

• Designed for use in all hydraulic brake and clutch systems requiring DOT 3 or DOT 4

Fuel Stabilizer by Sta-Bil®

• Genuine Sta-Bil formula eliminates the need to drain fuel for engines stored longer than 60 days

• Helps prevent rust, corrosion and fuel deposits

• Available in convenient 1-oz. packets, 8-oz. bottles and 32-oz. bottles

Pro Honda Foam Air Filter Maintenance Products by No Toil

• Eliminates the need for toxic chemicals when servicing air filters

• Pro Honda biodegradable filter oil is super tacky, trapping more dirt yet flowing more air than conventional air filter oils, resulting in superior performance

• Pro Honda air filter cleaning system is available as a three-piece kit containing filter oil, filter cleaner and filter rim grease

Caution:

Cannot be used to clean filters already treated with conventional petroleum products.

* From kit.

Pro

SERVICE AND MAINTENANCE

Contact/Brake Cleaner

(Ultralow VOC, California & Utah Compliant)

• Removes grease and oil quickly

• Cleans brake drums, liners, cylinders and springs

• Safe for most plastics

• Meets SCAQMD Rule 1171 requirements for unlimited use

• Ultralow VOC nonchlorinated formula

Contact/Brake Cleaner

(Low VOC, Nonchlorinated)

• Removes grease and oil even more quickly

• Cleans brake drums, liners, cylinders and springs

• Safe for most plastics

• Dries fast with no residue

• Low VOC formula

• Contains no chlorinated solvents or CFCs

• NOT available in California and Utah

Chain Lube with White Graphite

• Advanced technology for the ultimate in lubrication and protection

• Contains White Graphite for superior, long-lasting, weather-resistant lubrication

• Compatible with both O-ring and nonO-ring chains

• Works at both high- and low-temperature extremes

• No-fling formulation

Chain Lube with Moly

• Contains Moly and PTEF for superior lubrication

• Resists wear and weather for long-lasting lubrication.

• Compatible with both O-ring and non-O-ring chains

• Works at both high- and low-temperature extremes

• Contains no chlorinated solvents or CFCs

• No-fling formula

Chain Cleaner

• Prepares chain for reoiling

• Emulsifies and removes dirt, grime and built-up grease

• Spray on—rinse off

• Safe on all types of drive chains

White Lithium Grease

• Heavy-duty, general-purpose lubricant.

• Penetrates between parts to provide deep, long-lasting lubrication

• Displaces moisture and protects against rust and corrosion

• Works at both high- and low-temperature extremes

• White color shows coverage to help ensure complete application

• Low VOC formula meets current CARB and OTC standards

• Contains no chlorinated solvents or CFCs

Hondalube/Rust Penetrant

• Displaces moisture and protects against rust and corrosion

• Frees rusted parts

• Lubricates all metal surfaces

• Low VOC formula meets current CARB and OTC standards

• Contains no chlorinated solvents or CFCs

Silicone Spray

• Lubricates plastics, rubber and vinyl

• Eliminates sticking and squeaking

• Safe for painted surfaces

• Colorless formula will not stain surfaces

• Provides lubrication from -80° F to 600° F

Glass Cleaner

• Quick-foaming formula cleans glass, mirrors, headlights and chrome surfaces without streaking

• Available in 12-oz. aerosol cans

Note:

Not pictured, available in Honda Automotive packaging only.

Carburetor Cleaner

(Nonchlorinated, 50-State Legal)

• Cleans throttle and choke linkages

• Decarbonizes intake- and emission-system components

• Computer oxygen sensor safe

• Ultralow VOC nonchlorinated formula

• Legal in all 50 states

Hondalock 1

• Low-strength, blue-colored threadlock for frequently removed and/or low-torque fasteners

• Protects against corrosion and wear

• Resists vibration, moisture and most chemicals

Hondalock 2

• Medium-strength, orange-colored threadlock for medium-torque fasteners

Hondalock 2HT

• High-temperature, red-colored threadlock for medium-torque fasteners in hightemperature applications such as cylinder head exhaust studs

Hondalock 3

• High-strength, green-colored threadlock for semipermanent and/or high-torque fasteners

• Helps retain gears, bearings and pulleys to their shafts

Weatherstrip Cement

• Permanent, waterproof cement that remains elastic after drying

• Adheres to rubber, plastic and metal

• Glues in loose O-rings during assembly

• Excellent for vinyl and leather repairs

Handgrip Cement

• Required when installing PVC-type handgrips

• Ideal for use on rubber handgrips, footpeg covers, kickstart and shift-pedal rubbers

Dielectric Grease

• Nonconductive waterproofing compound

• Insulates electrical connections and adheres to most surfaces, sealing out moisture, dirt and corrosion

ASSEMBLY AND REPAIR

Hondabond 4

• Semidrying liquid gasket

• Seals irregular surfaces with a tough, elastic film

• Solvent-based for easy removal; also resists gasoline

Hondabond HT

• High-temperature, silicone liquid gasket

• Unique formula is nonacidic and won’t corrode aluminum like other silicon gasket products will

• For use in applications not requiring solid gaskets

Moly Paste M77

• Contents are solid and will not separate at room temperature

• Recommended for gears, bearings and other high-pressure, high-temperature applications

Anti-Seize Compound

• Protects against rust and corrosion caused by chemicals

• Provides excellent protection over an extended period for threaded fittings.

• Waterproof

• Prevents metal parts from galling and seizing

• Protects against temperatures up to 2,600° F

Other Greases Available (but not pictured)

• CV Joint Outer Grease

• Unirex N3 Grease

• Marine Grease

REPAIR/MISCELLANEOUS

TIRE SEALANT

Pro Honda Flat Tire Sealant†

• One time application

• Repairs punctures up to 3/4"

• Prevents bead and porosity leaks

• Protects against future flats

• Maintains tire inflation year-round

MISCELLANEOUS

Pro Honda Tie-Down Set

• White-zinc-plated cam buckle with Honda logo

• Offered in Red, Black and Blue colors

• Includes two 5.5'-long x 1"-wide webbed straps

• 1200-lb. tensile strength

• Vinyl-coated S-hooks

• Includes two soft straps

Pro Honda Optimate 1 DUO Automatic Battery Maintainer

• Optimizes battery power and life.

• Saves low voltage batteries.

• Automatically adapts to the connected battery type (lead or lithium).

• 24/7 safe long term maintenance.

Pro Honda Optimate Lithium 2.5 Amp 8-Stage Charger

• The world's most advanced automatic charger for lithium (LiFePO4) batteries

• Optimal cell balancing for battery performance and life

• Microprocessor adjusts to the ideal charge curve

• Low volt save mode

• Activates resettable BMS circuitry (if equipped)

Pro Honda Fast Funnel

• Disposable handy funnel that is sold as a three pack

• Folds flat for easy storage

• Convenient, inexpensive and compact— stores easily

• Eliminates contamination, no need to clean funnels between uses

• Sold in dealer multiples of 36 three packs

Pro Honda Cam Chain Tensioner Holder

• Fits CRF250R/X, CRF450R/X, TRX450R/ER and XR650R off-road machines

• Also fits ST1300, VTR1000, VF750C, 599, CBR600RR and CBR1000RR street machines

• Negates the need for slo ppy, homemade tools

• Features a tiny, one-way Sprag clutch

Pro Honda Cam Sprocket Holder

• Durable tool steel construction

• Stabilizes camshaft for easy sprocket bolt removal

• Fits CRF450R/X and TRX450R/ER

Pro Honda No-Spill Gas Cans

• CARB-approved in convenient 1.25-, 2.5- and 5.0-gallon sizes

• Feature a thumb-button-controlled, auto-stop fuel spout

• Fuel flow automatically stops when fuel reaches the edge of the spout

• High flow rate with stainless steel filter screen

• Meets state fuel can requirements in CA, CT, DC, DE, MD, ME, NJ, NY and PA

Official Licensed Products

Sometimes a name means everything. When customers see the Honda brand on a product, they know that it meets extremely high standards. We now offer a broader selection of Honda Official Licensed products than ever, ranging from track wear to casual apparel and rideable models for kids. That means more opportunities to connect with customers in ways that are fun for them and that make your shop a unique destination.

Photo courtesy of Troy Lee Designs

RACE PROVEN, STREET SMART

Works (815) 784-4000 2021 Johnson Court Kingston, IL 60145

A PERFECT PLAN FOR EVERY Honda

Honda customers purchase Honda products for quality. HondaCare Protection Plans are quality Extended Service Contracts and are backed by American Honda Motor Co., Inc., for the customer’s peace of mind. They provide all the stability and security of a Honda product to buyers of Honda SxSs and ATVs. HondaCare will add to the long-term enjoyment of owning a new or Certified Pre-Owned Honda.

GET PROTECTION UNDER OUR WING

HondaCare PROTECTION PLAN

Features and Benefits include:

Genuine Protection

HondaCare Protection is an exclusive product of American Honda and is offered through authorized Honda dealerships* in the United States. HondaCare is administered and backed by the resources of American Honda and include the same quality and support you expect with Honda products.

No Usage Limitation

Hondas are built to be enjoyed, and Honda customers are encouraged to do just that. Similar to Distributor’s Limited Warranty, there is no mileage or hour limitation for the term of the Plan.

Extent of Coverage

A HondaCare Protection Plan covers you for mechanical failures as a result of defects in materials or factory workmanship, with no additional out-of-pocket costs. Coverage is similar to the Honda Limited Warranty coverage you get with a new Honda; however, tires, batteries, audio equipment and accessories are not covered. Every HondaCare Protection Plan is good across the country, and replacements are always made with Honda Genuine Parts.

No Overlapping Coverage

HondaCare offers various term lengths. For new Honda products, coverage begins when the Distributor’s Limited Warranty expires.*

Nationwide Coverage

No matter how far away HondaCare is there. Coverage accepted at any authorized Honda Motorcycle/ATV dealer within the United States. Covered repairs can be performed by Honda trained technicians with only Honda Genuine parts.

No Deductible

Unlike some plans, with HondaCare there is no deductible to pay for any repair required because of defects in material or factory workmanship for the term of the Plan chosen.

No Transfer Fees

Should the day come when you decide to sell your Honda, the remaining coverage can be transferred to the subsequent owner of the same vehicle at no charge.

Pre-Owned Vehicles

HondaCare is available for Certified Pre-Owned Honda vehicles. The coverage starts when the Plan is purchased. Check with your Honda

Simple to Obtain

HondaCare Protection is available at authorized Honda Powersport Dealerships nationwide. See your local Dealer for a more detailed description of features, benefits and pricing for your vehicle.

Deadline

HondaCare Protection can prolong genuine Honda Limited Warranty coverage, but it’s only available while your new-vehicle warranty is still in effect. Check your paperwork carefully, because when your warranty expires, so does this offer.

For more information visit: powersports.honda.com/hondacare-protection-plan

* HondaCare Protection Plans are administered by American Honda Service Contract Corporation (AHSCC) in the state of Florida; license #60083. Different terms apply in Florida, see your Dealer for details.

H onda Accessories Warranty

Because we’re so confident in the quality of each of our Honda Genuine Accessories and Honda Signature Accessories, we’re pleased to offer one of the best warranties in the industry. Warranty begins on the day accessories are purchased by the customer. Gold Wing, Gold Wing Tour, Gold Wing F6B, ST1300 and Valkyrie: 3 years. **NT700V, NC700X, DN-01, Dual-Sport, Cruisers, Standards, Sportbikes, Scooters, SxS, ATV and PWC: 1 year.

American Honda will repair or replace, at its option, any Honda Genuine or Honda Signature Accessory that is defective in material or workmanship under normal use.

To qualify for this warranty, the Honda Genuine or Honda Signature Accessory:

• must have been purchased from an authorized Honda Dealer authorized to sell Honda Genuine or Honda Signature Accessories: And

• must have been used in an application for which it was designed or otherwise approved in writing by American Honda

Online Shopping

Online sales have never been more critical to your dealership’s bottom line. All the more reason why you should sign up to take advantage of the Honda Accessory eCommerce Program. As a participating dealer, you have the opportunity to fulfill orders placed from the Honda Powersports online store, turning your accessory inventory faster and acquiring new customers along the way.

Today’s digital customers expect brands to offer an online shopping experience where purchases can be made and orders fulfilled. To meet that need, we’re providing our Honda Accessory eCommerce platform. Fed through our massively popular powersports.honda.com website, thousands of customers are exposed to our accessories every day, potentially driving sales to your dealership and strengthening your profitability in the fast-moving digital marketplace.

Check it out at: http://shop.powersports.honda.com/

and make it part of your monthly payment. *

powersports.honda.com

ENVIRONMENTAL COMMITMENT AT Honda, WE BELIEVE IN PERFORMANCE AND LEADERSHIP. THAT’S WHY WE’RE TAKING A LEADERSHIP POSITION WHEN IT COMES TO THE ENVIRONMENT, IN OUR PRODUCTS AND IN ALL OTHER ASPECTS OF OUR BUSINESS AS WELL. FOR MORE INFORMATION VISIT http://powersports.honda.com/about/environment.

ATV LEGAL DISCLAIMER: Honda recommends Utility ATVs for riders 16 years of age and older, the TRX700XX, 400EX/X, TRX250X for riders 16 years of age and older, and the TRX90X for riders 10 years of age and older. Parents need to consider their youngsters’ age, size, ability and maturity before allowing them to ride. ATV vehicles can be hazardous to operate. For your safety, be responsible. Read the owner’s manual. Always wear a helmet, eye protection and protective clothing. Be careful on difficult terrain. All ATV riders should take a training course (free for new buyers, ask your dealer or call ASI at 800-887-2887) Never ride after consuming drugs or alcohol, on paved surfaces, on public roads, with passengers, or at excessive speeds. No stunt riding.

SXS LEGAL DISCLAIMER: Honda recommends multi-purpose utility and sports vehicles (side-by-sides) for drivers 16 years and older. Multi-purpose utility vehicles can be hazardous to operate. For your safety, drive responsibly. Always wear a helmet, eye protection and appropriate clothing. Always wear your seat belt, and keep the side nets and doors closed. Avoid excessive speeds and be careful on difficult terrain. We recommend that you complete the recreational

off-highway vehicle (ROV) E-course. The free course is available at www.rohva. org. Read the owner’s manual before operating the vehicle. Never drive after consuming drugs or alcohol, or on public roads. Driver and passengers must be tall enough for seat belt to fit properly and to brace themselves with both feet firmly on the floor. Passengers must be able to grasp the hand hold/grab bar with the seat belt on and both feet on the floor.

Prices listed are MSRP. Not including dealer installation and labor fees. Prices, specifications and availability are subject to change without notice. Installation of accessories decreases vehicle weight capacity. Please refer to Honda’s Website (powersports.honda.com) for the most up-to-date information on all Honda Accessories. Honda Genuine Accessories,™ Honda Signature Accessories,™ Honda Pro Connect,™ Pro Honda,® Hondabrite,® Talon,™ Honda Phantom Camo,® Pioneer,® HRC,® Big Red,™ TRX,® Foremen,® FourTrax,® Rancher,® Rincon ® Recon,® Rubicon ® are trademarks of Honda Motor Co., Ltd. WARN ® and the WARN logo are registered trademarks of WARN Industries, Inc., Garmin Tread® is a registered trademarks of Garmin, Ltd., Sur Last ® is a registered trademark of Glen Raven, Inc. S&B ® is a registered trademark of S&B Filters, Inc., Ultramax ® and Trimax ® are registered trademarks of Nelson-Rigg USA, Inc. ©2023 American Honda Motor Co., Inc. Published (06/2023)
