24/25 SPECIFICATION GUIDE
MESSAGE TO OUR VALUED CUSTOMERS:
As we embark on our 40th year in business, this major milestone is both a humbling experience and an exciting time to partner with us. Over the past year, we have not only concentrated on continuing to innovate with our new product offering but have also been working on our supply chain initiatives with our NEW Mexico wood manufacturing operation and our recent acquisition of Omega National Products. These initiatives further align our business with our commitment to wood cabinet accessories. We recognize that our Specification Guide has evolved into an indispensable tool for designers, fabricators, cabinet shops, and dealers alike.
So, what’s new in 2024?
- New Rev-A-Shelf® products have been added and are now in stock.
- Suggested List Pricing has been reintroduced for all items.
- Introduction of Tresco Lighting® 2024 products.
Our dedicated team of factory and independent reps is available to help you connect with our numerous distributor partners and resellers across the country. You can visit Rev-A-Shelf.com to find out who stocks our products in your area and how we can help you get set up.
Thank you for your ongoing support.
Introduction ................................. 2 Contents ....................................... 3 American Made 4 How-to’s ........................................ 5 Celebrating .................................. 6 New Products 8 Matte Black 13 Edge ............................................ 14 Omega National ....................... 16 Waste Solutions 20 Blind Corner Solutions ............. 60 Sink Solutions............................. 79 Base Solutions ......................... 107 Tall Pantry Solutions................ 156 Drawer Solutions 176 Wall Solutions .......................... 212 Vanity Solutions ....................... 229 Closet Solutions 257 Lazy Susan 304 Hardware .................................. 335 LED Lighting............................. 343 Index 408 Warranty/PROP 65/Terms ..... 417 Homes for Our Troops ............ 419 What's Inside Specification Guide 24/25 featuring ®
Proudly “Made in America” and manufactured and assembled in our two Kentucky facilities
Employing a local workforce of more than 400
Louisville-based and family owned for three generations
PRODUCT CHART
We’ve simplified our product chart and added a couple of columns to help make your buying decisions easier.
"MCO" = Minimum Cabinet Opening. Our recommended minimum cabinet opening dimensions are based upon installation into 1-1/2” face frame cabinets. This is important because occasionally the width of the product is wider than the part of the product that pulls out of the cabinet.
When both face frame and frameless dimensions are needed, we have listed them as FFMCO and FLMCO. The FF is for face frame and the FL for frameless (aka full access).
WHAT DOES THIS MEAN?
You will notice that our charts contain columns that
CAB's for that specific product. Below you will find a bank of what those letters mean.
"CAB" = Typical Cabinet. We get it, professionals just want to know what size cabinet the product is designed for. So we've tried to identify the typical cabinet for each of our products.
When both face frame and frameless typical cabinet recommendations are provided we have listed them as FF for face frame and FL for frameless (aka full access). Note: unless otherwise noted, typical cabinet recommendations are based upon 1-1/2” face frame cabinet construction.
5
Drawer Pullout w/ Euro Slides PRODUCT DESCRIPTION DIMS BC FINISH SLP 4WDB-12 Pullout Drawer 11" (280 mm) W x 18-1/2" (470 mm) D x 5-5⁄8" (143 mm) H B15 Maple $79.15 4WDB-15 Pullout Drawer 14" (356 mm) W x 22-1/2" (572 mm) D x 5-5⁄8" (143 mm) H B18 Maple $91.80 Drawer Pullout w/ BLUM Soft-Close 4WDB4-18SC-1 Standard Drawer 14” (356 mm) W x 21-5/8” (549 mm) D x 4-7/8” (124 mm) H B18 Maple $287.85 4WDB7-18SC-1 Tall Drawer with dividers 14” (356 mm) W x 21-5/8” (549 mm) D x 8” (203 mm) H B18 Maple $363.10 4WDB4-24SC-1 Standard Drawer 20” (508 mm) W x 21-5/8” (549 mm) D x 4-7/8” (124 mm) H B24 Maple $326.70 4WDB7-24SC-1 Tall Drawer with dividers 20” (508 mm) W x 21-5/8” (549 mm) D x 8” (203 mm) H B24 Maple $418.05 MCO CAB FINISH SLP D x 5-5⁄8" (143 mm) H 12” (305 mm) B15 Maple $79.15 D x 5-5⁄8" (143 mm) H 15” (381 mm) B18 Maple $91.80 D x 4-7/8” (124 mm) H 15” (381 mm) B18 Maple $287.85 D x 8” (203 mm) H 15” (381 mm) B18 Maple $363.10 D x 4-7/8” (124 mm) H 21” (533 mm) B24 Maple $326.70 D x 8” (203 mm) H 21” (533 mm) B24 Maple $418.05 MCO CAB FINISH SLP mm) D x 5-5⁄8" (143 mm) H 12” (305 mm) B15 Maple $79.15 mm) D x 5-5⁄8" (143 mm) H 15” (381 mm) B18 Maple $91.80 mm) D x 4-7/8” (124 mm) H 15” (381 mm) B18 Maple $287.85 mm) D x 8” (203 mm) H 15” (381 mm) B18 Maple $363.10 mm) D x 4-7/8” (124 mm) H 21” (533 mm) B24 Maple $326.70 mm) D x 8” (203 mm) H 21” (533 mm) B24 Maple $418.05
COLOR NUMBER CODE
MCO's and
FF FL FH B T W SB VB BC Face Frame Full Access (frameless) Full Height Door/ Drawer Tall Cabinet Wall Cabinet Sink Base Vanity Base Blind Corner a cabinet that has a fixed frame to the front of the cabinet a cabinet that allows full accessibility by eliminating the face frame of the cabinet a cabinet without a drawer opening, using the whole height of the cabinet a cabinet that has a drawer atop the cabinet opening Tall/ Utility cabinets a cabinet designed to be mounted above counter tops a cabinet designed to be used with a sink a shorter depth cabinet designed to be used in a vanity or bathroom a cabinet that is in the corner of your kitchen
house
White 11 Black 18 Orion Gray 13 Silver 17 Almond 15 Blue 22 Gray 14 Champagne 12 Green 19 Red 16 Orange 20 Yellow 21 Brown 10
Celebrating years!
For over four decades, our commitment to delivering original products, meticulously designed and crafted at our facility in Louisville, Kentucky has been unwavering. Our tradition of innovation continues as we once again introduce a new range of solutions designed to enhance storage and organization in various spaces, from kitchens, bathrooms, closets, pantries and beyond.
Where it began
In 1961 with funding from their family and friends, Harry and Larry Jones started a one machine plastic manufacturing operation. Along with their wives Nancy and Skeet, and six children in tow, the family business began. Initially, Jones Plastic manufactured whiskey caps for liquor bottles. Excellence in quality and customer service led to growth, and soon they would produce everything from “Star Wars” toys for Kenner in the 1970s to appliance parts for General Electric. Another early plastic manufacturing job was for the “Revolve-A-Shelf,” a plastic lazy susan for a California company named Ajax Hardware.
In 1978, Jones Plastic expanded its holdings with the acquisition of that division of Ajax Hardware. The establishment of Rev-A-Shelf®, a division of Jones Plastic & Engineering Company, soon followed. As the Rev-A-Shelf® product family grew, so did Jones Plastic. In the early 90s, Jones Plastic pioneered the use of gas assist, high-speed molding, and component kitting. It was their expertise in molding and their reputation for helping their customers distribute products to the market that paved the way to success. It reduced handling labor and shipping costs, which prompted expansions in Kentucky, Tennessee, and locations in Monterrey and Juarez, Mexico.
Meanwhile, our product line, which originated as a manufacturer of metal and polymer lazy susan components, has since grown into the market-leading innovator of residential cabinet storage and organization products of both quality and functionality. “We had high
6
- Harry & Larry Jones
hopes for this company when we started it. With the help of so many hardworking employees and great leadership, Rev-A-Shelf® has grown into an international company with an unequivocal reputation for very high-quality storage solutions,” said Harry Jones.
For over 30 years, Tresco Lighting® has been committed to creating innovative and affordable products, reinforced by unequal quality and service. In 2011, Rev-A-Shelf® acquired Tresco® and the mission has remained the same. We continue to broaden product offerings, expand distribution, and develop growth. In 2023, we opened our new plant in Juarez, Mexico. Dedicated entirely to producing our wood products, the opening of the plant is another example of our commitment to providing cost-effective and quality products, made in North America. It expands capacity and reinforces our investment in the future.
Today
As of 2024, we have acquired Omega National Products! We believe this move will allow us to innovate in ways not possible before, and set us apart even further from the competition. We currently employ approximately 435 people in our 315,000 square foot facility in Louisville, KY. Our mission of “changing the way you think about cabinet organization” wouldn’t be possible without our amazing staff. From product development, to production, and to sales and marketing: we have the best team in the world!
7 rev-a-shelf.com | 800-626-1126 | info@rev-a-shelf.com
- Rev-A-Shelf® Headquarters - Louisville, Ky
- Rev-A-Shelf® Mexico Headquarters - Juarez, Mexico
Lightfair 2017
Series Modular Base Cabinet Pullout
Series OXO Drawer Insert
Tip-Out Knife
P180
P128/160 NEW! NEW! NEW! NEW! 8
444
4OXO
4DMKB Series Door Mount
Storage 4PIL Series Maple Pilaster System P124
P122
4UH Series Universal Holder Pullout 4WCWM Series Waste Management System
4WCT Series “Right Fit” Cutlery Drawer Insert
P22
P199 NEW! NEW! NEW! NEW! 9
4WUT Series “Right Fit” Utensil Drawer Insert P123
P198
4WDIV Series
5WU Series Upright Storage Pullout
Shallow Drawer Divider Insert
P32 NEW! NEW! NEW! NEW! 10
4WLS87 Series Girasolo Maple Blind Corner Organizer RV Series Bi-Directional Lid P181 P214 P67
11
Pullout
P126
P183 NEW! NEW DESIGN! NEW! NEW!
4SDI-T Series Deep Drawer Insert 4WDB Series Base Drawer
4ADI Series Adjustable Deep Divider Insert 4WDR Series Drying Rack Drawer P179
P178
NEW DESIGN!
544 Series Undersink Caddy Pullout
P106
12
MATTEBLACK PANT RACKPULLOUT MATTE BLACK PULLOUT HAMPER New MATTE BLACK Finish! See Closet Section p257 13
ELEGANCE SARTORIAL
EDGE WARDROBE LINE
KIT 4 TROUSER HOLDER FOR “EDGE” FRAME
ADJUSTABLE LOW CASE FOR “EDGE” FRAME
2023 WINNER
collection makes modularity its distinctive component. Designed to contain and organize, drawers, trouser racks, skirt racks, shoe racks and laundry racks-are all removable, extractable and cushioned - they marry technology and elegance. The rubber profiles of the frames and the rods - and the special trays material - dampen noise and protect both garments and accessories. The semi-glossy, vibrant warm grey metal, which characterizes all the elements of the collection, is an additional touch of charm, capturing light in soft gleams and enhancing the soft and warm style of the sleeping area, drawing evocative geometries that cuddle clothes and accessories in an endless aesthetic liason.
15
EDGE WARDROBE LINE COMING SUMMER 2024
Welcome to the Family!
asdf 16
Omega National PRODUCTS Omega National PRODUCTS
“We are extremely excited for Omega National Products to join our organization. As we continue to make these strategic investments, this only strengthens our capabilities in developing wood organization products and accessories that our customers demand,” said Steve Jones, GM/VP of Consumer Sales. “We truly believe our mutual customer base will benefit greatly from our expanded capabilities and supply chain options.”
17
LED LIGHTING
NEOLOOP
Bold lighting for bright applications; achieve consistent, seamless illumination from start to finish with Neoloop flexible silicone LED lighting. Shatterproof and watertight, Luniform technology provides a continuous beam of light. This makes Neoloop perfect for adding light to dark millwork, creating unique wall designs, outlining commercial logos, accent lighting and more. Rated for indoor, outdoor*, damp and wet* locations.
*When used with factory-installed inputs
IMPROVED DESIGN
EUROLINX 2.0
At 4W and over 200 lumens per foot, Eurolinx 2.0 is a top pick for sleek, high-end illumination. Using a specialized diffuser and reflector technology to achieve Luniform output, the flat profile blends in with any residential/commercial application. Newly redesigned components ensure tight and reliable connections, and included surface mounting u-clips make installation a breeze.
18
®
PG 360
PG 372
ROUND CONTROLLERS
PG 401
Single Door Sensor
Door open, light on; door closed, light off
Sensor Range: 1/16” - 2” (2 mm - 50 mm)
Two Door Sensor
Either door open, light on; both doors closed, light off
Sensor Range: 1/16” - 2” (2 mm - 50 mm)
Touch Dimmer
Touch on/off and 0-100% dimming control
Hold finger down for dimming
Touch dimmer once to turn on/off
Power failure memory (retains last setting)
Motion Sensor
Turns on when human motion is detected
Sensor Range: 0” – 118” (0 mm – 3000 mm)
Viewing degree: 120º
Time on: 30 seconds if no motion is detected
19
rev-a-shelf.com | 800-626-1126 | info@rev-a-shelf.com
to Life
all
Needs! ®
DESIGN
Bringing Light
for
your Design
IMPROVED
