CATALOGO INGLES 2024

RIVISA ® , specialist in perimeter protection systems

RIVISA® is the first Spanish manufacturer and installer of Perimeter Protection Systems and one of the main European manufacturers. We design, manufacture and install fences and gates for all types of facilities that require physical perimeter protection.

RIVISA® is the continuation of a family business tradition that began in 1854 when Francisco Rivière Bonneton introduced single-twisted wire mesh to Spain from England.

During the last 40 years we have worked following this tradition and with the idea of developing innovative and quality products to meet the needs of our customers.

Wide range of products

RIVISA® currently offers a wide range of products including residential and rural fencing, residential and industrial fences, security gates and fencing, swing gates, self-supporting sliding and sliding gates, operators and barriers, movable fences, sports fencing and wire and mesh.

Residential and rural fences

Residential and industrial fences

Gates and fencing

Swing and sliding gates

Automated gates and barriers

Temporary site fencing

These are both for sale to distributors through our own sales offices, which both supply and install the material.

With its headquarters in Lliçà de Vall (Barcelona) and production centre in Santa Margarida de Montbui (Barcelona), it has offices in different parts of Spain (Valencia, Zaragoza, Madrid, Pamplona, Tarragona and Pontevedra) and its own Export Department for international attention and commercial management in more than 40 countries.

RIVISA® integrates the entire process in order to offer its customers a global service that meets all expectations.

Perimeter Protection Systems are defined as a physical barrier that allows:

- The demarcation of the boundaries of a property

- Deterrence of intrusion attempts

- Delaying of intrusion attempts

- Control of the access points

Our goal is to provide our customers with the best Perimeter Protection Systems to protect homes, industries and infrastructures, as well as public and private environments.

Safety, security and privacy

We want to be a trusted provider for our customers by offering the best possible solution. We are committed to perimeter protection, security and privacy — key and necessary aspects of today’s society.

Our products cover all perimeter protection needs: from a small garden in a residential house to perimeter protection of airports, ports, critical infrastructures, highways, railway lines, schools, sports facilities, industries, photovoltaic plants, power plants, etc.

Our professional team is able to advise regarding the most suitable approach for each situation, recommending the best product for each installation.

We use the best available technologies to ensure sustainable development, reducing our consumption of energy, water and gas during the manufacture of our products and avoiding polluting waste.

We manage our waste and monitor all our production processes with care, transparency and reliability

“We are perimeter specialists in the following sectors”

SECURITY SECTOR

· Prisons

· Airports

· Ports

· Critical infrastructure

INFRASTRUCTURE SECTOR

· Suburban, medium-distance and high-speed trains

· Motorways and dual carriageways

· Wildlife and infrastructure protection

SPORTS SECTOR

· Football stadiums

· Sports centres

· High-performance centres

· Racing circuits

RESIDENTIAL SECTOR

· Housing and residential developments

· Private residences

· Park

EDUCATION SECTOR

· Colleges and universities

· Student residences

TOURIST SECTOR

· Hotels

· Campsites

INDUSTRIAL SECTOR

· Factories and Industries

· Logistics centres

· Industrial estates

ENERGY SECTOR

· Regasification plants

· Power plants

· Photovoltaic parks

· Solar thermal plants

Means of manufacturing and production

Since its creation, the company has focused on innovation and the application of new technologies in production processes, without renouncing the use of top quality raw materials and working with the most suitable tools and equipment for each stage of the product.

The RIVISA® production centre has facilities measuring over 50,000 m2, where it has modern machinery and production lines for the manufacture of electro-welded mesh, robotised gratings, single-twist gratings, machinery for cold profiling of tubes and its own modern painting facility where the exclusive RIVISA® Protecline ® RIVISA® Protecline ® Plus and RIVISA® Protecline ® Triple anti-corrosion coating systems are applied.

RIVISA® has a locksmith workshop where we manufacture our special products and adapt them according to the needs of our customers

Technology and ecology

RIVISA® has succeeded in increasing the durability of the materials, extending their useful life and improving the final finish of the plasticised coating — a guarantee of durability.

The RIVISA® Protecline © system eliminates zinc salts, oils and greases in an environmentally friendly way: without residues or toxic residues.

RIVISA® is permanently focused on offering superior quality, a consequence of what the market demands from us.

DURABILITY

Rivisa ® performs a permanent anti-corrosion coating that guarantees all its materials an exceptional lifetime.

ENVIRONMENTAL PROTECTION

Rivisa ® has succeeded in eliminating all toxic residues from the anti-corrosion treatment process of its materials.

ECOLOGY

Rivisa ® has managed to eliminate all residues generated during the cleaning process of the materials by shot-blasting the parts.

Coating systems

RIVISA® uses galvanised materials and has developed exclusive anti-corrosion coating systems that are pioneers in the development and application of the most modern technologies to prevent corrosion. These and other research projects are the result of continuous investment in R&D and the work carried out by the engineers and technicians who form part of the RIVISA® team.

LAYER OF POLYESTER LAMINATION

COATING

Quality Control Guarantee

RIVISA ’ S business philosophy is firmly based on Total Quality and care for the environment. It maintains and continuously improves its Quality Management System in accordance with the ISO 9001:2000 standard.

The certification of the RIVISA ® Quality Management System by Bureau Veritas illustrates the desire to maintain the levels of commitment and satisfaction acquired from our customers.

The quality of the product is constantly evaluated. Corrosion resistance tests, in accordance with EN-10245-1, provide indications of longevity in aggressive environments:

-Salinity test: 1,000 hours.

-Kesternichtest (SO2 test): acid rain.

-QUV tests simulate resistance to deterioration due to sunlight, humidity and temperature.

All RIVISA ® products comply with European standards.

RIVISA ® is able to issue a “Guarantee Certificate” for the quality and mechanical stability of its perimeter protection systems. The guarantee covers all fencing components and is applicable under the following conditions:

· All elements of the fencing shall be original products of the brand. RIVISA ® .

· The installation of the fencing will be carried out entirely by a RIVISA ® . installation team or its network of fitters.

LAYER OF POLYESTER LAMINATION

1ST LAYER OF POLYESTER LAMINATION GALVANISED COATING

This coating provides a high degree of protection against corrosion.

Excellent laminate adhesion through innovative pre-preparation of the surface via shot blasting.

Long material service life.

Outstanding finish quality.

This coating provides a very high degree of protection against corrosion through its double layer of protection.

Excellent laminate adhesion through innovative pre-preparation of the surface via shot blasting.

Long material service life even in the most aggressive environments.

Extraordinary finish quality.

*The Interpon Redox Plus + Interpon Redox PZ system is used in very aggressive environments. The three-layer system consists of a zinc-rich primer (Redox Plus AL251F/AL258F), a barrier effect primer (Redox PZALZ90F) and a highly durable polyester plasticised finish.

This coating provides the highest degree of protection against corrosion through its triple layer of protection.

Excellent laminate adhesion through innovative pre-preparation of the surface via shot blasting.

Maximum material service life, even in very aggressive environments.

Extraordinary finish quality.

Colour Range

COLOUR IS AN IMPORTANT FEATURE IN THE CREATION OF A FENCE.

At RIVISA® we make sure that each of our customers can find the colour they like best for their fence, which is why our gates can be painted in various colours from the RAL colour chart

CHOICE OF COLORS IN GLOSSY FINISH FROM THE STANDARD RAL COLOR

There is no extra charge.

CHOICE OF COLORS IN GLOSSY FINISH FROM THE SPECIAL RAL COLOR

Special RAL chart colours are available for plastic coating of products.

The colours in this catalogue are approximate — for precise choices please consult a RAL colour chart.

Standard products

“The comfort of use is only guaranteed by a well thought-out and properly designed fence”

We are specialists in perimeter protection systems and want to offer you the most comprehensive service: from design to installation.

Only a well thought-out and correctly designed fence guarantees comfort of use. Therefore, it is important to plan all the elements of the fence in a functional way: the gate, the gate, the changes in level, the copings, the steps, the accessories, etc.

At RIVISA ® we are able to design, manufacture, install and manufacture all our standard products, and at the same time we are able to adapt to special projects according to the needs of our customers.

We offer our customers a customised design service for special perimeter protection systems.

Based on our customers’ ideas, we carry out a project study and evaluate its viability, and the project department ultimately proposes a viable, cost-effective solution so that together we can find the ideal enclosure.

Application places

Clôtures residenciales et agricoles Residential and rural fences

OUTSTANDING

• Mesh for multiple applications

• Highly impact-resistant mesh

• Long useful life

• Versatile multiple-application system

Application places

POSTS AND ACCESSORIES

• Lux 50 or Lux 80-type post, 1.5mm average thickness, depending on heights, provided with longitudinal rack for fixing accessories and the necessary BRACKETS to bear the tension of the wires and meshes. Lowcarbon sheet, in accordance with the EN-10327 standard. Pull strength of 300 to 400 N/mm2

• Accessories fastened to the rack by means of a fixing screw

• Polypropylene cap will not degrade in harsh weather

• Reinforced galvanised wires fixed to the posts in order to avoid possible lengthwise sliding

CHAIN LINK MESH

• Single wire twist rhomboidal shape mesh (chainlink), manufactured with wire of a minimum strength of 400 N/mm2

• 25m length rolls for fences 1m00, 1.5m and 2m00 high

Assembly

STRAIGHT SECTION

The end posts are installed at the beginning and the end of the fence, the mid posts every 3m and the tension posts every 30m of straight section. In hard or highly compacted soil the foundation may be optionally substituted by an anchoring system that is mechanically driven into the soil, the post being less than or greater than the useful height of the fence.

STEPPED SECTION

On the steps, install the longest post (normal length + step height) on the lower part of the fence and clamp the mesh to the upper and lower sections of the mesh. Install twice the number of brackets for the tension wires and struts on the post.

SLOPED SECTION

On the level changes of the fence (in other words, when the gradient of the slope changes), install a straight tension post. The posts on the slanted sections of the fence must be vertically levelled, so that they are oblique to the direction of the tension wires (parallel to the ground) and to the mesh.

Gates and bayonet extension

ANGLE TENSION POST

For changes of direction of the fence, position a corner tension post without a bayonet

SINGLE-TWIST

MESH

• Single-twist galvanised wire mesh, resistance: 400 N/mm2.

• Length of the rolls: 25 metres for fences 1m00, 1m0050 and 2m0000 high.

Swing and/or sliding gates can be inserted at any point in the enclosure. The Lux E.S.T. fenced enclosure harmonises with the Light or Strong gate models.

SECTION

WITH EXTENSION ARM FOR BARBED WIRE

Optional installation of barbed wire for security fences.

Supplement with a slanted arm for installing the necessary brackets and staples for the barbed wire.

Additional double inclined extension bracket with barbed wire (only for Lux-80 tube)

Assembly manual

Accessories

Anticorrosion coating

POSTS AND ACCESSORIES

• Galvanised and plastic-coated using the Rivisa Protecline anticorrosion coating system.

• Minimum thickness: 100 microns

• Option of applying the Rivisa Protecline Plus plastic coating, which prolongs the useful life of the materials by 30% MESH

• Single wire twist rhomboidal shape mesh (chainlink), manufactured with wire of a minimum strength of 400N/mm2, standard galvanised quality (60gr ZN/m2) or triple reinforced galvanised (240gr Zn/m2), with mesh widths of 40 or 50mm

• Single-twist galvanised and plastic-coated mesh with a minimum thickness layer of 0.5mm, with mesh width of 40 or 50mm

1 Mark the line of the pen with a rope. Cement the posts, with the rack facing outwards, starting with the ends, the tension posts and finally the intermediate posts.

5 Stretch and tension the mesh, stapling it to the nearest tensioning post.

2 Lay the net on the outside of the floor.

6 Pass the 3 rows of yarn between the meshes from one tensioning post to the next and tighten them, starting with the bottom row.

3 Connect the necessary rolls of mesh to complete the entire section.

7 Tension the wires between each pair of tension poles, starting with the bottom row.

4 Staple the mesh to the end post by inserting the ends of the clamp with the clamp into the holes in the zip tie and closing to tighten. Repeat the process.

8 Staple the wire strands to the intermediate posts and the fabric strands to the tensioning posts.

Technical features

POST AND ACCESORIES

• Lux 50 or Lux 80 type-post depending on heights, provided with longitudinal rack for fixing accessories and the necessary clamps to bear the tension of meshes. Low-carbon sheet, in accordance with the EN-10346 standard. Pull strength of 300 to 400 N/mm 2

• Accessories coupled to the rack by anchoring screw

• Polypropylene top which is resistant to atmospheric agents

• Galvanised, reinforced wire staple, anchored vertically to the rack to prevent it from slipping lengthways

• Orthogonal and plastic-coated electro-welded mesh, manufactured with wires with a strength of 940 N/mm 2

• At the upper part, the wires are closer together in order to make the mesh stiffer

Doors and bayonet extension

Place an angle tension post wherever the fence changes direction, and position a corner tension post without a bayonet.

Swing and/or sliding gates can be inserted at any point in the enclosure. The Lux Electro-Welded Mesh fenced enclosure harmonises with the Light or Strong gate models.

STRAIGHT SECTION

The end posts are installed at the beginning and the end of the fence, the mid posts every 3m and the tension posts every 30m of straight section. In hard or highly compacted soil the foundation may be optionally substituted by an anchoring system that is mechanically driven into the soil, the post being less than or greater than the useful height of the fence.

STEPPED SECTION

On the steps, install the longest post (normal length + step height) on the lower part of the fence and clamp the mesh to the upper and lower sections of the mesh. Install twice the number of brackets for the tension wires and struts on the post.

SLOPED SECTION

Wherever the fence changes direction, install an angle tension post or inside angle, as required, anchoring the struts so that they are aligned with the two directions of the mesh. On the angle post, the rack and the mesh are installed on the outside part of the fence. On the inside angle post, the rack and the mesh are installed on the inside part

SECTION WITH BARBED WIRE BAYONET

Optional installation of barbed wire for security fences.

Supplement with a slanted arm for installing the necessary brackets and staples for the barbed wire.

Additional single inclined extension bracket with barbed wire Additional double inclined extension bracket with barbed wire (only for Lux-80 tube)

Assembly manual

Anticorrosion coating

• All the materials of the Brico-Fax system are hot-dip galvanised and plastic-coated with the Rivisa Protecline anticorrosion coating system.

• Minimum thickness: 100 microns

• Option of applying the Rivisa Protecline Plus plastic coating, which prolongs the useful life of the materials by 30%

• Available in several colours from the Rivisa RAL chart. Colours:

1 Mark the line of the enclosure with the help of a rope. Lay the foundation posts, with the rack facing outwards, starting with the ends, the tension posts and finally the intermediate posts.

4 Tension the wires between each pair of tension posts, starting with the bottom row.

2 Spread the mesh on the outside of the ground.

5 Tension the cables between each pair of tensioning posts, starting with the bottom row.

3 Staple the mesh to the end post by inserting the ends of the pliers with a clamp into the holes of the zip and closing to tighten. Repeat the operation.

6 Stretch and tension the mesh by stapling it to the nearest tension post.

• Easy-to-handle versatile enclosure

• Long useful life

• Enclosure for large areas

Technical features

POSTS AND ACCESSORIES

• Lux 50 or Lux 80 type-post depending on heights, provided with longitudinal rack for fixing accessories and the necessary BRACKETS to bear the tension of meshes. Low-carbon sheet, in accordance with the EN-10142 standard. Pull strength of 300 to 500 N/mm 2

• Accessories coupled to the rack by anchoring screw.

• Polypropylene cap which is resistant to atmospheric agents.

• Galvanised, reinforced wire staple, anchored vertically to the rack to prevent it from slipping lengthways.

KNOTTED MESH

• A reliable, economical mesh for enclosing large spaces, made of rectangular knotted mesh, wire with triple-galvanised protection (240gr Zn/m2), upper and lower diameter of 2.40mm and the rest of the wire has a diameter of 1.90mm. Variable distances between the vertical wires (see table of characteristics).

Gates and bayonet extension

Swing and/or sliding gates can be inserted at any point in the enclosure. The Lux Electro-welded mesh fenced enclosure harmonises with the Light or Strong gate models

STRAIGHT SECTION

The end posts are installed at the beginning and the end of the fence, the mid posts every 6m and the tension posts every 56m of straight section. In hard or highly compacted soil the foundation may be optionally substituted by an anchoring system that is mechanically driven into the soil, the post being less than or greater than the useful height of the fence.

STEPPED SECTION

On the steps, install the longest post (normal length + step height) on the lower part of the fence and clamp the mesh to the upper and lower sections of the mesh. Install twice the number of brackets for the tension wires and struts on the post.

SLOPED SECTION

Wherever the fence changes level (i.e., where the slope gradient changes), install a straight tension post. The posts on the slanted sections of the fence must be vertically levelled, so that they are oblique to the direction of the tension wires (parallel to the ground) and to the mesh.

SECTION WITH EXTENSION ARM FOR BARBED WIRE

Optional installation of barbed wire for security fences.

Supplement with a slanted arm for installing the necessary brackets and staples for the barbed wire.

Additional single inclined extension bracket with barbed wire

Additional double inclined extension bracket with barbed wire (only for Lux-80

Assembly manual

Accessories

Anticorrosion coating

POLES AND ACCESSORIES

• All Lux Knotted Mesh Fence materials are hot-dip galvanised.

• Accessories: electrolytic galvanised

• Rectangular knotted mesh with galvanised triple protection wire 240grs Zn/m 2

1 Mark the line of the enclosure with the help of a rope. Lay the foundation posts, with the rack facing outwards, starting with the ends, the tension posts and finally the intermediate posts.

4 Join the rolls of netting required to complete the entire length using the ratchet tensioner.

2 Spread the mesh on the outside of the ground.

5 Stretch and tension the mesh by stapling it to the nearest tension post.

3 Staple the mesh to the end post by inserting the ends of the pliers with a clamp into the holes of the zip and closing to tighten. Repeat the operation

6 Staple the horizontal wire rows to the intermediate posts and the last vertical wire of the fabric to the tension posts.

Clôtures residenciales et industrielles Residential and industrial fences

OUTSTANDING

• Light and strong residential fencing

• Exceptional service life due to their anticorrosion coating

• Non-removable security screw system

• Easy installation

• Complete system

Application places

Side view

POST AND ACCESSORIES

• Lux 50-type post equipped with longitudinal rack for anchoring the accessories that will secure the panel (Fax bracket)

• Low-carbon sheet, in accordance with the EN-10346 standard. Pull strength of 300 to 400 N/mm2

• Posts equipped with polypropylene cap which will not degrade in harsh weather.

Detail of Lux 50 post

Profile weight: 1.50Kg/ml Galvanised sheet metal Z-275 I/V= 2.20cm 3

ELECTRO-WELDED MESH PANEL

• Electro-welded mesh with several folds, to improve its rigidity

• Mesh size: 100/55

• Wire diameter: 4mm

• Upper or lower defensive edge, depending on the direction of the panel.

Fax frame detail

POST/FRAME FASTENING SYSTEM

Metal Fax support

Attached to the rack by means of a nondetachable M.8x21mm Torx-05 type security screw fitted by means of a special key.

Anchoring system

FOUNDATION

On the ground or wall surfaces, the foundations of the posts can be made using concrete.

BASE PLATE

Optional installation of a base plate, for installing the post on a concrete wall. Dimension of a plate 120x120x8mm.

BASE PLATE IN L

Option of adding an L plate to fix the posts to a concrete wall. Plate dimensions: 120x120x8mm.

Section with extension (bayonet)

• Option of adding barbed wire to increase the security of the fence.

• Supplementary inclined arm to place the brackets and staples necessary for the installation of the barbed wire.

Bayonet system with barbed wire.

BAYONET

Double bayonet system with barbed wire. Only possible with LUX80 post

Anticorrosion coating

All the materials of system are hot dip galvanised and plastic coated with Rivisa ® Protecline anticorrosion coating system.

• Minimum thickness: 100 microns

• Option of applying the Rivisa ® Protecline Plus plastic coating, which prolongs the useful life of the materials

• Option of applying the Rivisa ® Protecline Plus triple plastic coating, which prolongs the useful life of the materials

• Available in several colours from the Rivisa RAL chart. Colours:

Assembly manual

1 Mark the line of the enclosure with a rope. Drill the holes for the post foundation.

5 Install the second post following the same steps.

2 Cement the first post and level it with a level.

6 Repeat as many times as necessary.

3 Install the front of the Fax bracket on the Lux post rack and place the panel in front of the bracket.

7 If anchoring with a base plate instead of a foundation, screw the base and insert the first post. Hang the panel and insert the next post.

4 Place the upper part of the bracket on the panel and screw it to the already installed front panel using the screw. Once tightened, finish off with the plug.

8 If necessary, cut the panel to obtain a more precise finish.

DOUBLE

BAYONET

OUTSTANDING

• Rigidity and quality of the materials

• Exceptional service life due to their anticorrosion coating

• Non-removable security screw system

• Easy installation

• Complete system

Application places

Technical features

POST AND ACCESSORIES

• Lux 50 or Lux 80-type post according to heights, provided with a longitudinal rack for anchoring the accessories that will secure the panel (FAX bracket)

• Low-carbon sheet, in accordance with the EN-10327 standard. Pull strength of 300 to 400 N/mm2

• Posts provided with polypropylene cap which will not degrade in harsh weather

Detail of Lux 50 post

Profile weight: 1.50Kg/ml

Galvanised sheet metal Z-275

I/V= 2.20cm3

ELECTRO-WELDED MESH PANEL

• Electro-welded panel with several folds to improve its rigidity

• Dimensions of the panel: 200/50

• Diameter of the wire: 5mm

• Upper or lower defensive edge, in accordance with the orientation of the panel

Side view

Detail of Lux 80 post

Profile weight: 3Kg/ml

Galvanised sheet metal Z-275

I/V= 7.76cm3

POST/FRAME FASTENING SYSTEM

Metal Fax support: Attached to the rack by means of a non-detachable M.8x21 Torx-05 type security screw fitted by means of a special key.

2m00* 2m00 2m40

*Panel Fax y Fax Medium

Anchoring system

FOUNDATION

The posts can be sealed with concrete in the walls or in the ground.

BASE PLATE

Optional installation of a base plate, for installing the post on a concrete wall. Dimension of a plate 120x120x8mm.

BASE PLATE IN L Option to add an L plate to fix the posts to a concrete wall. Dimensions of the plate: 120x120x8mm.

Section with extension (bayonet)

Fence with 45° inclined extension bracket. Posts with extension bracket and 0.60 m mesh frame fastened to the inclined section using supports; alternatively, several rows of barbed wire can be fastened to it.

Bayonet with barbed wire

Double bayonet with barbed wire (only 80 Lux tube)

Anticorrosion coating

Bayonet with 0m60 mesh frame

Assembly manual

All the materials of system are hot dip galvanised and plastic coated with Rivisa ® Protecline anticorrosion coating system.

• Minimum thickness: 100 microns

• Option of applying the Rivisa ® Protecline Plus plastic coating, which prolongs the useful life of the materials

• Option of applying the Rivisa ® Protecline Plus triple plastic coating, which prolongs the useful life of the materials

• Available in several colours from the Rivisa RAL chart. Colours:

1 Mark the line of the enclosure with a rope. Drill the holes for the post foundation.

5 Install the second post following the same steps.

2 Cement the first post and level it with a level.

6 Repeat as many times as necessary

3 Fit the front of the Fax bracket to the Lux rack and place the panel in front of the bracket.

7 If anchoring with a base plate instead of a foundation, screw the base and insert the first post. Hang the panel and insert the next post.

4 Place the upper part of the bracket on the panel and screw it to the already installed front panel with the screw. Once tightened, finish with the cap.

8 If necessary, cut the panel to obtain a more precise finish.

BAYONET

DOUBLE BAYONET

BAYONET WITH BARBED WIRE

OUTSTANDING

• Rigidity and quality of the materials

• Exceptional service life due to their anticorrosion coating

• Non-removable security screw system

• Easy installation

• Complete system

Application places

Technical features

POST AND ACCESSORIES

• Lux 50 or Lux 80-type post according to heights, provided with a longitudinal rack for anchoring the accessories that will secure the panel (FAX bracket)

• Low-carbon sheet, in accordance with the EN-10346 standard. Pull strength of 300 to 400 N/mm2

• Posts provided with polypropylene cap which will not degrade in harsh weather

ELECTRO-WELDED MESH PANEL

• Electro-welded panel

• Dimensions of the panel: 200/50

• Diameter of the wire: 8/6/8mm or 6/5/6mm

• Upper or lower defensive edge, in accordance with the orientation of the panel Profile weight: 1.50Kg/ml

1.2mm

3Kg/ml

Z-275

1.2mm

Side view

POST/FRAME FASTENING SYSTEM

Metal Fax support: Attached to the rack by means of a non-detachable M.8x21 Torx-05 type security screw fitted by means of a special key.

Anchoring system

FOUNDATION

On the ground or wall surfaces, the foundations of the posts can be made using concrete.

Optional installation of a base L-plate to fix the posts to a concrete wall. Dimensions: 120x120x8mm.

Section with extension (bayonet)

Anticorrosion coating

All the materials of system are hot dip galvanised and plastic coated with Rivisa ® Protecline anticorrosion coating system.

• Minimum thickness: 100 microns

• Option of applying the Rivisa ® Protecline Plus plastic coating, which prolongs the useful life of the materials

• Option of applying the Rivisa ® Protecline Plus triple plastic coating, which prolongs the useful life of the materials

• Available in several colours from the Rivisa RAL chart. Colours:

1 Mark the line of the enclosure with a rope. Drill the holes for the post foundation.

5 Install the second post following the same steps.

2 Cement the first post and level it with a level.

6 Repeat as many times as necessary

3 Install the front of the Fax holder on the Lux rack and place the panel in front of the holder.

7 If anchoring with a base plate instead of a foundation, screw the base and insert the first post. Hang the panel and insert the next post.

4 Place the upper part of the bracket on the panel and screw it to the already installed front panel with the screw. Once tightened, finish with the cap.

8 If necessary, cut the panel to obtain a more precise finish.

OUTSTANDING

• Industrial fence of exclusive design

• Rigidity and quality of the materials

• Exceptional service life due to their anticorrosion coating

• Non-removable security screw system

• Easy installation

• Complete system

Application places

MAXI FAX® SYSTEM

Technical features

POST AND ACCESSORIES

• Post type Lux-80 reinforced by 3mm/t.a. (W=12.11cm3) or Lux 80-1.5mm/t.a. (W=5.6cm3), according to heights, provided with a longitudinal rack for anchoring the accessories that will secure the panel (Fax bracket)

• Low-carbon sheet, in accordance with the EN-10346 standard. Pull strength of 300 to 400 N/mm2

• Posts provided with polypropylene cap which will not degrade in harsh weather

ELECTRO-WELDED MESH PANEL

• Electro-welded panel with several folds to improve its rigidity

• Dimensions of the panel: 44/55mm

• Diameter of the wire: 4mm (horizontal) and 5mm (vertical)

• Upper or lower defensive edge, in accordance with the orientation of the panel

Side view

POST/FRAME FASTENING SYSTEM

Fax metal bracket: Attached to the rack by means of a non-removable safety screw type Torx-05 of M.8x21 installed using a special wrench.

Anchoring system

FOUNDATION

On the ground or wall surfaces, the foundations of the posts can be made using concrete.

BASE PLATE

Optional installation of a base plate, for installing the post on a concrete wall. Dimension of a plate 120x120x8mm.

BASE PLATE IN L

On the ground or wall surfaces, the foundations of the posts can be made using concrete.

Section with extension (bayonet)

Fence with 45° inclined extension bracket. Posts with extension bracket and 0.60 m mesh frame fastened to the inclined section using supports; alternatively, several rows of barbed wire can be fastened to it.

Bayonet with barbed wire

Double bayonet with barbed wire (only 80 Lux tube)

Bayonet with 0 m6 mesh frame

Anticorrosion coating

All the materials of system are hot dip galvanised and plastic coated with Rivisa ® Protecline anticorrosion coating system.

• Minimum thickness: 100 microns

• Option of applying the Rivisa ® Protecline Plus plastic coating, which prolongs the useful life of the materials

• Option of applying the Rivisa ® Protecline Plus triple plastic coating, which prolongs the useful life of the materials

• Available in several colours from the Rivisa RAL chart. Colours:

Assembly manual

1 Mark the line of the enclosure with a rope. Drill the holes for the post foundation. 2m 53

5 Install the second post following the same steps.

2 Cement the first post and level it with a level.

6 Repeat as many times as necessary

3 Fit the front of the Fax bracket to the Lux rack and place the panel in front of the bracket.

7 If anchoring with a base plate instead of a foundation, screw the base and insert the first post. Hang the panel and insert the next post.

4 Place the upper part of the bracket on the panel and screw it to the already installed front panel with the screw. Once tightened, finish with the cap.

8 If necessary, cut the panel to obtain a more precise finish.

BAYONET

DOUBLE BAYONET

BAYONET

OUTSTANDING

• May be erected quickly without fastening fittings between post and frame

• Rigidity and quality of the materials

• Exceptional service life due to their anticorrosion coating

• Complete system

POST

• Ritmo-type post 1.2mm thick (I/V=5.46cm3). Profile specially shaped to help the installation of the panels. The panels are inserted directly into the notches that are specifically designed to support and adjust the fence

• Steel carbon plate according to the EN-10346 standard

• Minimum elastic resistance 250 N/mm2

• Minimum mechanical resistance 330 N/mm2

• Posts provided with polypropylene cap which will not degrade in harsh weather

PANEL

• Welded woven wire panels with multiple knots to increase rigidity

• Dimensions of the panels: 200/55

• Wire diameter: 5mm

• Defensive spike finishing on top or bottom following panel orientation

Side view

KEY

Locking part to secure the panels while the concrete hardens at the bottom of the posts; it is reusable and once the concrete has hardened, it must be removed.

y Ritmo Medium

Anchoring system

FOUNDATION

On the ground or wall surfaces, the foundations of the posts can be made using concrete. BASE PLATE IN L

CONCRETE BASE WALL

It is possible to include a concrete slab

between the line posts to act as a

No civil works are needed.

and

Section with extension (bayonet)

• Option of adding barbed wire to increase the security of the fence.

• Supplementary inclined arm to place the brackets and staples necessary for the installation of the barbed wire or 0m 60 frame.

Reversible bayonet system with barbed wire.

Double bayonet system with barbed wire.

Bayonet system with 0m60 frame.

Anticorrosion coating

All the materials of system are hot dip galvanised and plastic coated with Rivisa ® Protecline anticorrosion coating system.

• Minimum thickness: 100 microns

• Option of applying the Rivisa ® Protecline Plus plastic coating, which prolongs the useful life of the materials

• Option of applying the Rivisa ® Protecline Plus triple plastic coating, which prolongs the useful life of the materials

• Available in several colours from the Rivisa RAL chart. Colours:

Assembly manual

1 Mark the line of the enclosure with a rope. Drill the holes for the post foundation.

5 Install the second post following the same steps.

2 Cement the first post and level it with a level.

6 Repeat as many times as necessary.

3 Hook the first panel to the post.

7 If anchoring with a base plate instead of a foundation, screw the base and insert the first post. Hang the panel and insert the next post.

4 Place the upper part of the bracket on the panel and screw it to the already installed front panel with the screw. Once tightened, finish with the cap.

8 If necessary, cut the panel to obtain a more precise finish.

BAYONET

DOUBLE BAYONET

BAYONET

OUTSTANDING

• May be

• Rigidity and quality of the materials

• Exceptional service life due to their anticorrosion coating

• Complete system

Technical features

• Ritmo-type post 1.2mm thick (I/V=5.46cm 3). Profile specially shaped to help the installation of the panels. The panels are inserted directly into the notches that are specifically designed to support and adjust the fence.

• Steel carbon plate according to the EN-10327 standard.

• Minimum elastic resistance 250 N/mm2

• Minimum mechanical resistance 330 N/mm2

• Posts provided with polypropylene cap which will not degrade in harsh weather.

• Defensive spike finishing on top or bottom following panel orientation.

Detail of Ritmo post

5.66cm 3

• Welded woven wire panels with multiple knots to increase rigidity.

• Dimensions of the panels: 200/55mm.

• Wire diameter: 6/5/6mm.

panel

Side view

Locking part to secure the panels while the concrete hardens at the bottom of the posts; it is reusable and once the concrete has hardened, it must be removed.

Anchoring system

FOUNDATION

On the ground or wall surfaces, the foundations of the posts can be made using concrete.

BASE PLATE

Optional installation of a base plate, for installing the post on a concrete wall. Dimension of a plate 120x120x8mm.

Concrete base wall

It is possible to include

BASE PLATE L

Option to add an L-plate L-plate to fix the posts to a concrete wall. Plate dimensions: 120x120x8mm.

SIDE PLATE.

Option of installing Ritmo posts with a side plate.

Section with extension (bayonet)

• Option of adding barbed wire to increase the security of the fence.

• Supplementary inclined arm to place the brackets and staples necessary for the installation of the barbed wire or 0m 60 frame.

Reversible bayonet system with barbed wire.

Double bayonet system with barbed wire.

Bayonet system with 0m 60 frame.

Anticorrosion coating

All the materials of system are hot dip galvanised and plastic coated with Rivisa ® Protecline anticorrosion coating system.

• Minimum thickness: 100 microns

• Option of applying the Rivisa ® Protecline Plus plastic coating, which prolongs the useful life of the materials

• Option of applying the Rivisa ® Protecline Plus triple plastic coating, which prolongs the useful life of the materials

• Available in several colours from the Rivisa RAL chart. Colours:

Assembly manual

1 Mark the line of the enclosure with a rope. Drill the holes for the post foundation.

5 Install the second post following the same steps.

2 Cement the first post and level it with a level.

6 Repeat as many times as necessary

3 Hook the first panel to the post.

7 If anchoring with a base plate instead of a foundation, screw the base and insert the first post. Hang the panel and insert the next post.

4 Place the upper part of the bracket on the panel and screw it to the already installed front panel with the screw. Once tightened, finish with the cap.

8 If necessary, cut the panel to obtain a more precise finish.

BAYONET

DOUBLE BAYONET

BAYONET

OUTSTANDING

• Rapid assembly

• Inflexible, high-quality materials

• Clips with optional undetachable screws

• Exceptional service life thanks to anticorrosion coating

• Complete system

Technical features

POST

• Ritmo-type post Clip with a thickness of 1.2mm. Profile specially shaped to help the installation of the panels. The panels mate to the post using easily installed clip-type supports.

• Special pliers for installation of the clips

• Steel carbon plate according to the EN-10327 standard

• Tensile strength from 300 to 400 N/mm2

• Posts provided with polypropylene cap which will not degrade in harsh weather

PANEL

• Welded woven wire panels with multiple knots to increase rigidity

• Dimensions of the panels: 200/55

• Wire diameter: 5mm

• Defensive spike finishing on top or bottom following panel orientation

of Ritmo Clip frame

Side view

SUPPORT CLIP

Blockade clip without screw to secure the panels to the post.

Optional safety screw.

Anchoring system

FOUNDATION

On the ground or wall surfaces, the foundations of the posts can be made using concrete.

BASE PLATE

Optional installation of a base plate, for installing the post on a concrete wall. Dimension of a plate 120x120x8mm.

Concrete base wall

It is possible to include a concrete

500mm

and 40mm thick between the line posts to act as a wall. No civil works are needed.

BASE PLATE L Option to add an L-plate L-plate to fix the posts to a concrete wall. Plate dimensions: 120x120x8mm.

SIDE PLATE.

Option of installing Ritmo posts with a side plate.

Ritmo Clip pos Clip

Section with extension (bayonet)

• Option of adding barbed wire to increase the security of the fence.

• Supplementary inclined arm to place the brackets and staples necessary for the installation of the barbed wire or the 0m 60 frame.

Reversible bayonet system with barbed wire.

Double bayonet system with barbed wire.

Anticorrosion coating

Bayonet system with 0m 60 frame.

Assembly manual

All the materials of system are hot dip galvanised and plastic coated with Rivisa ® Protecline anticorrosion coating system.

• Minimum thickness: 100 microns

• Option of applying the Rivisa ® Protecline Plus plastic coating, which prolongs the useful life of the materials

• Option of applying the Rivisa ® Protecline Plus triple plastic coating, which prolongs the useful life of the materials

• Available in several colours from the Rivisa RAL chart. Colours:

1 Mark the line of the enclosure with a rope. Drill the holes for the post foundation.

5 Install the second post following the same steps.

2 Lay the first post on the foundation and plumb it with the help of a level.

6 Repeat the operation as many times as necessary.

3 Place the first panel on the post, in the position where it will be installed.

7 If base plate anchoring has been used instead of foundation anchoring, screw in the base and insert the first post. Hook in the panel and insert the next post.

4 Attach the clips to secure the panels to the post, using the clip mounting pliers.

8 If necessary, trim the panel for a more accurate finish.

BAYONET

DOUBLE BAYONET

BAYONET

OUTSTANDING

• May be erected quickly without fastening fittings between post and frame

• Rigidity and quality of the materials

• Exceptional service life due to their anticorrosion coating

• Complete system

POST

Ritmo-type post Clip with a thickness of 1.2mm. Profile specially shaped to help the installation of the panels. The panels mate to the post using easily installed clip-type supports.

• Special pliers for installation of the clips

• Steel carbon plate according to the EN-10327 standard

• Tensile strength from 300 to 400 N/mm2

• Posts provided with polypropylene cap which will not degrade in harsh weather PANEL

• Welded woven wire panels with multiple knots to increase rigidity

• Dimensions of the panels: 200x55mm.

• Wire diameter: 6/5/6mm o 8/6/8mm.

• Defensive spike finishing on top or bottom following panel orientation Detail

sheet Z-275 I/V= 5.54cm

Detail panel 8/6/8 Detail panel 6/5/6

Side view

• Screwless locking clip for securing panels to the post.

• Optional non-removable security screw.

• No civil works are needed. Profile weight: 2.70Kg/ml

Anchoring system

FOUNDATION

On the ground or wall surfaces, the foundations of the posts can be made using concrete.

BASE PLATE

Optional installation of a base plate, for installing the post on a concrete wal. Dimension of a plate 120x120x8mm.

Concrete base wall

• It is possible to include a concrete slab 500mm high and 40mm thick between the line posts to act as a wall.

BASE PLATE L

Option to add an L-plate L-plate to fix the posts to a concrete wall. Plate dimensions: 120x120x8mm.

SIDE PLATE.

Option of installing Ritmo posts with a side plate.

of Ritmo Clip post

Section with extension (bayonet)

• Option of adding barbed wire to increase the security of the fence.

• Supplementary inclined arm to place the brackets and staples necessary for the installation of the barbed wire or the 0m 60 frame.

Reversible bayonet system with barbed wire.

Double bayonet system with barbed wire.

Anticorrosion coating

Bayonet system with 0m60 frame.

Assembly manual

All the materials of system are hot dip galvanised and plastic coated with Rivisa ® Protecline anticorrosion coating system.

• Minimum thickness: 100 microns

• Option of applying the Rivisa ® Protecline Plus plastic coating, which prolongs the useful life of the materials

• Option of applying the Rivisa ® Protecline Plus triple plastic coating, which prolongs the useful life of the materials

• Available in several colours from the Rivisa RAL chart. Colours:

1 Mark the line of the enclosure with a rope. Drill the holes for the post foundation.

5 Install the second post following the same steps.

2 Cement the first post and

6 Repeat as many times as necessary

3 Hook the first panel to the post.

7 If anchoring with a base plate instead of a foundation, screw the base and insert the first post. Hang the panel and insert the next post.

4 Attach the clips to secure the panels to the post, using the clip mounting pliers.

8 If necessary, cut the panel to obtain a more precise finish.

BAYONET

DOUBLE BAYONET

BAYONET

OUTSTANDING

• Residential fence manufactured in metal sections of great rigidity and electro-welded mesh.

• Very strong circular section posts

• Rapid and simple erection

• Non-removable security screw system

• Unique and versatile post/frame fastening system

Application places

Assembly

• Non-removable safety bolt system that offers a perfect technical solution with a high level of aesthetics.

• The strap model alone can provide changes in direction at different angles, slopes and stepped sections without the need for welds.

Technical features Round post

POST AND ACCESORIES

• Ø60x2mm steel sheet posts, depending on height

• Polypropylene cap which will not degrade in harsh weather

PANEL

• Panel made of 40x40x1.5 horizontal sections and 30x30x1.5 vertical sections, with 300x55 electro-welded mesh, Vertical wire diameter 5mm and horizontal wire diameter 6mm

• Rapid assembly without welding

The connection between the post and the frame is made with 1.5mm-thick sheet metal clamps, which offer a robust but discreet appearance.

APPLICATION Ø60mm round posts

MATERIAL Metal clamps made of 1.5mmthick galvanised sheet metal.

FINISHING

The clamps are plasticised with Rivisa's Protecline coating system, in the same colour as the gate.

COMPOSITION Clamp + Bolts and screws

Anchoring systems

Option of installing the fence with a side plate.

A. Classic system panel

B. Wall plate

C. Anchor

Anticorrosion coating

A base plate can be used to install the posts on the concrete wall, or for fences less than 2m high. Dimensions of the plate: 120x120x8mm.

A. Classic system post

B. Base plate

C. Anchor

All the materials of system are hot dip galvanised and plastic coated with Rivisa ® Protecline anticorrosion coating system.

• Minimum thickness: 100 microns

• Option of applying the Rivisa ® Protecline Plus plastic coating, which prolongs the useful life of the materials

• Option of applying the Rivisa ® Protecline Plus triple plastic coating, which prolongs the useful life of the materials

• Available in several colours from the Rivisa RAL chart. Colours:

Assembly manual

Preparing the ground

Step 1

Mark the line of the enclosure with the help of a rope. Drill the holes for the foundation of the posts at the distance marked by the centre line.

Post and clamp assembly

Step 3

Mount the metal clamp on the post (4 pcs. per intermediate post and 2 pcs. per end post).

Step 2

Cement the first post and plumb it with the help of a level.

Step 4

Position the frame, making sure that it is securely fastened inside the clamps.

Frame and end section assembly

Step 5

Install the second post following the same steps, and repeat the operation as many times as necessary.

C= D-85

Step 6

* Install the wild card accessory on the frame and bolt the assembly to the post clamp.

Measure the wheelbase. Subtract 85mm from the resulting measurement and cut the frame to this measurement (C). BASE PLATE

OUTSTANDING

• Industrial fence manufactured with highly rigid metal sections

• Robust appearance of the fence

• Very strong circular section posts

• Rapid and simple erection

• Non-removable security screw system

• Unique and versatile post/frame fastening system

Application places

Assembly

Technical features

• Ø60x2mm or Ø60x3mm steel-plated posts, depending on height

PANEL

• Polypropylene cap which will not degrade in harsh weather.

Galvanised sheet Z-275

I/V= 7.29cm 3

Profile 3.56Kg/ml

Galvanised sheet Z-275

Thickness: 2mm I/V= 8.38cm 3

• Panel made of 40x40x1.5 horizontal sections and 35x35x1.5 vertical sections

• Rapid assembly without welding

Round post

The connection between the post and the frame is made with 1.5mm-thick sheet metal clamps, which offer a

appearance.

Install the attachment to make a special-width panel and bolt the assembly to the post attachment. ROUND

APPLICATION Ø60mm round posts

MATERIAL Metal clamps made of 1.5mmthick galvanised sheet metal.

FINISHING

The clamps are plasticised with Rivisa's Protecline coating system, in the same colour as the gate.

COMPOSITION Clamp + Bolts and screws

Square post

APPLICATION 60x60mm square posts

MATERIAL Sleeves manufactured in polypropylene FINISHING Polypropylene black colour

Anchoring systems

Post installation with concrete footings.

A. Calitax system post

B. Foundation

Option of installing the fence with a side plate.

A. Calitax system panel

B. Wall plate

C. Anchor

Anticorrosion coating

BASE PLATE

A base plate can be used to install the posts on the concrete wall, or for fences less than 2m00 high. Dimensions of the plate: 120x120x8mm.

A. Calitax system post

B. Base plate

C. Anchor

All the materials of system are hot dip galvanised and plastic coated with Rivisa ® Protecline anticorrosion coating system.

• Minimum thickness: 100 microns

• Option of applying the Rivisa ® Protecline Plus plastic coating, which prolongs the useful life of the materials

• Option of applying the Rivisa ® Protecline Plus triple plastic coating, which prolongs the useful life of the materials

• Available in several colours from the Rivisa RAL chart. Colours:

Assembly manual

Preparing the ground

Step 1

Mark the line of the enclosure with the help of a rope. Drill the holes for the foundation of the posts at the distance marked by the centre line.

Post and clamp assembly

Step 2

Cement the first post and plumb it with the help of a level.

Frame and end section assembly

Cement the next post and fit the panel into the clamps. Screw the 4 clamps to the frame.

Step 4

Position the frame, making sure that it is securely fastened inside the clamps.

Repeat the operation as many times as necessary. If base plate anchoring has been used instead of foundation anchoring, screw the base and insert the first post. Hook the panel and insert the next post.

OUTSTANDING

• Fence of a residential design

• Frames that allow a certain level of privacy

• Rapid and simple erection

• Non-removable security screw system

• Unique and versatile post/frame fastening system

Application places

Assembly

• The fastening between post and frame is made using metal straps manufactured from sheets 1.5 mm thick that give it a robust aesthetic and are discreet at the same time.

• Non-removable safety bolt system that offers a perfect technical solution with a high level of aesthetics.

• The strap model alone can provide changes in direction at different angles, slopes and stepped sections without the

for welds.

• On the stepped section and the sloping section, the longest post (normal length and step/drop) is placed on the lower part and fixed to the frames of both

and

Technical features

POST

• Ø60x2mm steel-plated posts, depending on height

• Polypropylene cap which will not degrade in harsh weather.

PANEL

• Panel made of 40x40x1.5 horizontal sections and 30x30x1.5 vertical sections, with plate perforated in squares of 30x30mm with a thickness of 1.5mm

• Rapid assembly without welding

Round post

The connection between the post and the frame is made with 1.5mm thick sheet metal clamps, which offer a robust but discreet appearance.

ROUND POST CONNECTION SYSTEM APPLICATION

APPLICATION Ø60mm round posts

Profile

I/V= 7.29cm 3 Profile 3.56Kg/ml

MATERIAL Metal clamps made of 1.5mm thick galvanized sheet metal.

FINISHING

Fence height

of welding a defensive profile on

The clamps are plasticized with Rivisa's Protecline coating system and in the same color as the gate.

COMPOSITION Clamp + Bolts and screws

Square post

Install the attachment to make a special-width panel and bolt the assembly to the post attachment. The connection between post and frame is made with high-strength plastic bushings.

APPLICATION 60x60mm square posts

MATERIAL Sleeves manufactured in polypropylene

FINISHING Polypropylene black colour COMPOSITION Bushing + M8 Screws + M8

Anchoring systems

Assembly manual

Preparing the ground

Step 1

Mark the line of the enclosure with the help of a rope. Drill the holes for the foundation of the posts at the distance marked by the centre line.

Post and clamp assembly

Step 3

Mount the metal clamp on the post (4 pcs. per intermediate post and 2 pcs. per end post).

Step 2

Cement the first post and plumb it with the help of a level.

Step 4

Position the frame, making sure that it is securely fastened inside the clamps.

C.

Anticorrosion coating

All the materials of ystem are hot dip galvanised and plastic coated with Rivisa ® Protecline anticorrosion coating system.

• Minimum thickness: 100 microns

• Option of applying the Rivisa ® Protecline Plus plastic coating, which prolongs the useful life of the materials

• Option of applying the Rivisa ® Protecline Plus triple plastic coating, which prolongs the useful life of the materials

• Available in several colours from the Rivisa RAL chart. Colours:

Frame and end section assembly

Step 5

Cement the next post and fit the panel into the clamps. Screw the 4 clamps to the frame.

Step 6

If base plate anchoring has been used instead of foundation anchoring, screw on the base and insert the first post. Hook the panel and insert the next post.

*Install the wildcard fitting on the frame and bolt the assembly to the post clamp.

OUTSTANDING

• Fence of a residential design

• Frames that allow a certain level of privacy

• Rapid and simple erection

• Non-removable security screw system

• Unique and versatile post/frame fastening system

Application places

•

Assembly

•

Technical features Round post

• Ø60x2mm or 60x60x2mm steel sheet posts.

• Polypropylene cap that will not be degraded by atmospheric agents.

PANEL

• Panel made of 40x40x1.5mm (horizontal) and 30x30x1.5mm (vertical) profiles, with 1.5mm thick die-cut sheet metal.

• Quick assembly without welding.

Profile weight: 2.86Kg/ml

Galvanised sheet Z-275

I/V= 5.11cm 3

Profile 3.56Kg/ml

Galvanised sheet Z-275

Thickness 2mm

I/V= 8.38cm 3

The connection between the post and the frame is made with 1.5 mm-thick sheet metal clamps, which offer a robust but discreet appearance.

ROUND POST CONNECTION SYSTEM APPLICATION

APPLICATION Ø60mm round posts

MATERIAL

FINISHING

Metal clamps made of 1.5mmthick galvanised sheet metal.

The clamps are plasticised with Rivisa's Protecline coating system, in the same colour as the gate.

COMPOSITION Clamp + Bolts and screws

Install the attachment to make a special-width panel and bolt the assembly to the post attachment.

The connection between post and frame is made with high-strength plastic bushings. SQUARE POST CONNECTION SYSTEM

APPLICATION 60x60mm square posts

MATERIAL Sleeves manufactured in polypropylene

FINISHING Polypropylene black colour

COMPOSITION Bushing + M8 Screws + M8 Nut

Anchoring systems

Assembly manual

Preparing the ground

Step 1

Mark the line of the enclosure with the help of a rope. Drill the holes for the foundation of the posts at the distance marked by the centre line.

Post and clamp assembly

Step 3 Mount the metal clamp on the post (4 pcs. per intermediate post and 2 pcs. per end post).

Anticorrosion coating

All the materials of the Brico-Fax system are hot dip galvanised and plastic coated with Rivisa ® Protecline anticorrosion coating system.

• Minimum thickness: 100 microns

• Option of applying the Rivisa ® Protecline Plus plastic coating, which prolongs the useful life of the materials

• Option of applying the Rivisa ® Protecline Plus triple plastic coating, which prolongs the useful life of the materials

• Available in several colours from the Rivisa RAL chart. Colours:

Step 2

Cement the first post and plumb it with the help of a level.

Step 4 Position the frame, making sure that it is securely fastened inside the clamps.

Frame and end section assembly

Step 5

Cement the next post and fit the panel into the clamps. Screw the 4 clamps to the frame.

Step 6

If base plate anchoring has been used instead of foundation anchoring, screw on the base and insert the first post.. Hook the panel and insert the next post. * Install the

on the

and bolt the assembly to the post clamp

OUTSTANDING

• Residential design fence

• Quick and simple assembly

• Easy to assemble, no need for a specialized installer

• Thanks to its assembly method, it takes up little space and facilitates transportation

Application places

Anchoring systems

• Steel sheet posts with 60x60x2mm profile for angle posts.

• Panel made using specially cold-formed profiles, which may or may not include spacers, depending on the design specifications. This construction ensures a sturdy structure that is adaptable to various needs and applications.

• Quick assembly without welding.

Accessories and post

Assembly

Anticorrosion coating

All

OUTSTANDING

• Fence has a restrained, elegant industrial design

• Fence has a robust and deterrent appearance

• Rapid and simple erection

• Non-removable security screw system

• Unique and versatile post/frame fastening system

Application places

Assembly

• The fastening between post and frame is made using metal straps manufactured from sheets

and

• Non-removable safety bolt system that offers a perfect technical solution with a high level of aesthetics.

• The strap model alone can provide changes in direction at different angles, slopes and stepped

for welds.

• On the stepped

and

without

Technical features

• 60x2mm or 60x3mm steel-plated posts, depending on height

• Polypropylene cap will not degrade in harsh weather

PANEL

• Panel made of 40x40x1.5mm horizontal sections and 25x25mm square-shaped bars, thickness 1.5mm (vertical)

• Rapid assembly without welding

Round post

The connection between the post and the frame is made with 1.5mm thick sheet metal clamps, which offer a robust but discreet appearance.

ROUND POST CONNECTION SYSTEM APPLICATION

APPLICATION Ø60mm round posts

I/V= 5.11cm

7.29cm

8.38cm

MATERIAL Metal clamps made of 1.5mm thick galvanized sheet metal.

FINISHING

The clamps are plasticized with Rivisa's Protecline coating system and in the same color as the gate.

COMPOSITION Clamp + Bolts and screws

Square post

APPLICATION 60x60mm square posts

MATERIAL Sleeves manufactured in polypropylene

FINISHING Polypropylene black colour

COMPOSITION Bushing + M8 Screws + M8 Nut

Anchoring systems

Assembly manual

Preparing the ground

Step 1

Mark the line of the enclosure with the help of a rope. Drill the holes for the foundation of the posts at the distance marked by the centre line.

Post and clamp assembly

Anticorrosion coating

All the materials of system are hot dip galvanised and plastic coated with Rivisa ® Protecline anticorrosion coating system.

• Minimum thickness: 100 microns

• Option of applying the Rivisa ® Protecline Plus plastic coating, which prolongs the useful life of the materials

• Option of applying the Rivisa ® Protecline Plus triple plastic coating, which prolongs the useful life of the materials

• Available in several colours from the Rivisa RAL chart. Colours:

Frame and end section assembly

Step 5

Cement the next post and fit the panel into the clamps. Screw the 4 clamps to the frame.

Step 2

Cement the first post and plumb it with the help of a level.

Repeat

OUTSTANDING

• Fence has a restrained, elegant industrial design

• Fence has a robust and deterrent appearance

• Rapid and simple erection

• Non-removable security screw system

• Unique and versatile post/frame fastening system

Application places

ULTRA® ROND SYSTEM

Assembly

•

• The strap model alone can provide changes in direction at different angles, slopes and stepped sections without the need for welds.

POSTS AND ACCESSORIES

• Steel sheet posts measuring Ø60x2mm, Ø60x3mm y 60x60x2mm according to the height

• Polypropylene cap resistant to atmospheric agents.

PANEL

• Frame made of 40x40x1.5mm profiles (horizontal) and round profile bars Ø25x1.5mm thick (vertical).

• Quick assembly without welding

ProfileØ60x2mm

Profile

I/V= 5.11cm 3

Profile Ø60x3mm

Profile weight: 4.22Kg/ml

Galvanised sheet Z-275

I/V= 7.29cm 3

Profile 3.56Kg/ml

Galvanised sheet Z-275

Thickness 2mm I/V= 8.38cm 3

Round post

The connection between the post and the frame is made with 1.5mm thick sheet metal clamps, which offer a robust but discreet appearance.

ROUND POST CONNECTION SYSTEM APPLICATION

APPLICATION Ø60mm round posts

MATERIAL Metal clamps made of 1.5mm thick galvanized sheet metal.

FINISHING

The clamps are plasticized with Rivisa's Protecline coating system and in the same color as the gate.

COMPOSITION Clamp + Bolts and screws

Square post

Finishes

Anchoring systems

B.

Anticorrosion coating

A.

B. Wall plate

C. Anchor

All the materials of system are hot dip galvanised and plastic coated with Rivisa ® Protecline anticorrosion coating system.

• Minimum thickness: 100 microns

• Option of applying the Rivisa ® Protecline Plus plastic coating, which prolongs the useful life of the materials

• Option of applying the Rivisa ® Protecline Plus triple plastic coating, which prolongs the useful life of the materials

• Available in several colours from the Rivisa RAL chart. Colours:

Assembly manual

Preparing the ground

Step 1

Mark the line of the enclosure with the help of a rope. Drill the holes for the foundation of the posts at the distance marked by the centre line.

Post and clamp assembly

Frame and end section assembly

Step 5

Cement the next post and fit the panel into the clamps. Screw the 4 clamps to the frame.

Step 2

Cement the first post and plumb it with the help of a level.

Step 6

Repeat the operation as many times as necessary. If base plate anchoring has been used instead of foundation anchoring, screw the base and insert the first post.

OUTSTANDING

• Design residential fence

• Frames that provide a certain level of privacy

• Quick and easy installation

• Indestructible security screw system

• Unique and versatile post/frame connection system

Application places

Assembly

POSTS AND ACCESSORIES

• Steel sheet posts measuring Ø60x2mm, Ø60x3mm y 60x60x2mm according to the height

• Polypropylene cap resistant to atmospheric agents.

Detail of round post

ProfileØ60x2mm

Profile weight: 2.86Kg/ml

Galvanised sheet Z-275

I/V= 5.11cm 3

Profile Ø60x3mm

Profile weight: 4.22Kg/ml

Galvanised sheet Z-275

I/V= 7.29cm 3

Detail of square post

Profile 3.56Kg/ml

Galvanised sheet Z-275

Thickness 2mm

I/V= 8.38cm 3

PANEL

• Frame made of 40x40x1.5mm profiles (horizontal) and round profile bars Ø25x1.5mm thick (vertical).

• Quick assembly without welding

NOTE: For sections with more than 10 frames, it is advisable to readjust the interaxes so as not to accumulate errors in the measurement.

Round post

The connection between the post and the frame is made with 1.5mm thick sheet metal clamps, which offer a robust but discreet appearance.

ROUND POST CONNECTION SYSTEM APPLICATION

APPLICATION Ø60mm round posts

MATERIAL Metal clamps made of 1.5mm thick galvanized sheet metal.

FINISHING

The clamps are plasticized with Rivisa's Protecline coating system and in the same color as the gate.

COMPOSITION Clamp + Bolts and screws

APPLICATION 60x60mm square posts

MATERIAL Sleeves manufactured in polypropylene

FINISHING Polypropylene black colour

COMPOSITION Bushing + M8 Screws + M8 Nut

Perforation

Anchoring systems

Assembly manual

Preparing the ground

Step 1

Mark the line of the enclosure with the help of a rope. Drill the holes for the foundation of the posts at the distance marked by the centre line.

Post and clamp assembly

Step 3

Mount the metal clamp on the post (4 pcs. per intermediate post and 2 pcs. per end post).

Anticorrosion coating

C. Anchor

All the materials of system are hot dip galvanised and plastic coated with Rivisa ® Protecline anticorrosion coating system.

• Minimum thickness: 100 microns

• Option of applying the Rivisa ® Protecline Plus plastic coating, which prolongs the useful life of the materials

• Option of applying the Rivisa ® Protecline Plus triple plastic coating, which prolongs the useful life of the materials

• Available in several colours from the Rivisa RAL chart. Colours:

Step 2

Cement the first post and plumb it with the help of a level.

Step 4

Position the frame, making sure that it is securely fastened inside the clamps

Montaje de bastidor y tramo final

Frame and end section assembly

Step 5

Cement the next post and fit the panel into the clamps. Screw the 4 clamps to the frame.

Step 6

Repeat the operation as many times as necessary. If base plate anchoring has been used instead of foundation anchoring, screw the base and insert the first post.

OUTSTANDING

• Industrial fence manufactured with highly rigid metal sections

• Robust appearance of the fence

• High-strength square cross-section post

• Rapid and simple erection

• Non-removable security screw system

• Unique and versatile post/frame fastening system

Application places

Assembly

Technical features Square post

The connection between the post and the frame is made with high-strength metal brackets.

POSTS AND ACCESSORIES

• Ø60x2mm steel-plated posts.

• Polypropylene cap will not degrade in harsh weather.

PANEL

• Panel made of 40x40x1.5 horizontal sections and vertical sections diameter 25x1.5 mm ep random implementation.

• Rapid assembly without welding.

Anchoring systems

Assembly manual

Preparing the ground

Post and clamp assembly

Anticorrosion coating

All the materials of system are hot dip galvanised and plastic coated with Rivisa ® Protecline anticorrosion coating system.

• Minimum thickness: 100 microns

• Option of applying the Rivisa ® Protecline Plus plastic coating, which prolongs the useful life of the materials

• Option of applying the Rivisa ® Protecline Plus triple plastic coating, which prolongs the useful life of the materials

• Available in several colours from the Rivisa RAL chart. Colours:

Frame and end section assembly

Foundation the next post and fit the panel into the brackets. Screw the 4 brackets to the frame. Step

Step

Repeat as many times as necessary.

Application places Assembly

OUTSTANDING

• The fence has an elegant and contemporary residential design

• System of round bars

• Non-aggressive fence, ideal for play areas

• Rapid and simple erection

• Non-removable security screw system

• Unique and versatile post/frame fastening system

POST

• 60x2mm or 60x3mm steel-plated posts, depending on height

• Polypropylene cap will not degrade in harsh weather

PANEL

• Panel made of 40x40x1.5mm horizontal sections, and Ø20mm

Round post

The connection between the post and the frame is made with 1.5mm thick sheet metal clamps, which offer a robust but discreet appearance.

ROUND POST CONNECTION SYSTEM APPLICATION

APPLICATION Ø60mm round posts

3

Profile Ø60x3mm

Profile weight: 4.22Kg/ml

Galvanised sheet metal Z-275

I/V= 7.29cm 3

Profile weight 3.56Kg/ml

Galvanised sheet metal Z-275

Thickness: 2mm I/V= 8.38cm 3

MATERIAL

FINISHING

Metal clamps made of 1.5mm thick galvanized sheet metal.

The clamps are plasticized with Rivisa's Protecline coating system and in the same color as the gate.

COMPOSITION Clamp + Bolts and screws

Square post

Fence height

APPLICATION Square post 60x60mm

MATERIAL Bushings made of polypropylene

FINISHING Black polypropylene COMPOSITION Cap + M8 Screws + M8 NUT

Anchoring systems

Assembly manual

Preparing the ground

Step 1

Mark the line of the enclosure with the help of a rope. Drill the holes for the foundation of the posts at the distance marked by the centre line.

Step 2

Lay the first post on the foundation and plumb it with the help of a level.

Anticorrosion coating

All the materials of system are hot dip galvanised and plastic coated with Rivisa ® Protecline anticorrosion coating system.

• Minimum thickness: 100 microns

• Option of applying the Rivisa ® Protecline Plus plastic coating, which prolongs the useful life of the materials

• Option of applying the Rivisa ® Protecline Plus triple plastic coating, which prolongs the useful life of the materials

• Available in several colours from the Rivisa RAL chart. Colours:

Preparing the ground

Step 3

Mount the metal clamp on the post (4 pcs. per intermediate post and 2 pcs. per end post).

Frame and end section assembly

Step 5

Put the next post in the foundation and fit the panel into the brackets. Screw the 4 brackets to the frame.

Step 4

Position the frame, ensuring that it is securely fastened inside the brackets.

Step 6

Repeat as many times as necessary.

If base plate anchoring has been used instead of foundation anchoring, screw on the base and insert the first post. Hook in the panel and insert the next post.

OUTSTANDING

• Industrial fence manufactured with highly rigid metal sections

• Robust appearance of the fence

• Very strong circular section posts

• Rapid and simple erection

• Non-removable security screw system

• Unique and versatile post/frame fastening system

Application places

Assembly

and frame are

• Ø60x2mm or Ø60x3mm steel-plated posts, depending on height

• Polypropylene cap which will not degrade in harsh weather Ø60x2mm or Ø60x3mm steel-plated posts, depending on height

• Polypropylene cap will not degrade in harsh weather

• Panel made of 40x40x1.5 horizontal sections and vertical sections diameter 25x1.5

Round post

The connection between the post and the frame is made with 1.5mm thick sheet metal clamps, which offer a robust but discreet appearance.

ROUND POST CONNECTION SYSTEM APPLICATION

APPLICATION Ø60mm round posts

MATERIAL

FINISHING

Metal clamps made of 1.5mm thick galvanized sheet metal.

The clamps are plasticized with Rivisa's Protecline coating system and in the same color as the gate.

COMPOSITION Clamp + Bolts and screws

Square post

1m00

Anchoring systems

Assembly manual

Preparing the ground

Step 1

Mark the line of the enclosure with the help of a rope. Drill the holes for the foundation of the posts at the distance marked by the centre line.

Step 2

Lay the first post on the foundation and plumb it with the help of a level.

Anticorrosion coating

All the materials of system are hot dip galvanised and plastic coated with Rivisa ® Protecline anticorrosion coating system.

• Minimum thickness: 100 microns

• Option of applying the Rivisa ® Protecline Plus plastic coating, which prolongs the useful life of the materials

• Option of applying the Rivisa ® Protecline Plus triple plastic coating, which prolongs the useful life of the materials

• Available in several colours from the Rivisa RAL chart. Colours:

Preparing the ground

Step 3

Mount the metal clamp on the post (4 pcs. per intermediate post and 2 pcs. per end post).

Frame and end section assembly

Step 5

Put the next post in the foundation and fit the panel into the brackets. Screw the 4 brackets to the frame.

Step 4

Position the frame, ensuring that it is securely fastened inside the brackets.

Step 6

Repeat as many times as necessary.

If base plate anchoring has been used instead of foundation anchoring, screw on the base and insert the first post. Hook in the panel and insert the next post.

OUTSTANDING

• Industrial fence manufactured with highly rigid metal profiles

• Robust appearance of the fence

• Circular section post with high resistance

• Quick and easy installation

• Indestructible security screw system

• Unique and versatile post/frame connection system

Application places

Assembly

POST

• Ø60x2mm or Ø60x3mm steel-plated posts, depending on height

• Polypropylene cap which will not degrade in harsh weather Ø60x2mm or Ø60x3mm steel-plated posts, depending on height

• Polypropylene cap will not degrade in harsh weather PANEL

• Panel made of 40x40x1.5 horizontal sections and vertical sections diameter 25x1.5 mm ep random implementation

• Rapid assembly without welding

Square post Technical features

Round post

The connection between the post and the frame is made with 1.5mm thick sheet metal clamps, which offer a robust but discreet appearance.

ROUND POST CONNECTION SYSTEM APPLICATION

APPLICATION Ø60mm round posts

MATERIAL Metal clamps made of 1.5mm thick galvanized sheet metal.

FINISHING

The clamps are plasticized with Rivisa's Protecline coating system and in the same color as the gate.

COMPOSITION Clamp + Bolts and screws

INTERMEDIATE POST

Anchoring systems

Option of installing the fence with a side plate.

A. Frame Tifon

B. Base plate

C. Anchor

Anticorrosion coating

A base plate can be used to install the posts on the concrete wall, or for fences less than 2m high.

A. Tifon fence post

B. Base plate

C. Anchor

All the materials of system are hot dip galvanised and plastic coated with Rivisa ® Protecline anticorrosion coating system.

• Minimum thickness: 100 microns

• Option of applying the Rivisa ® Protecline Plus plastic coating, which prolongs the useful life of the materials

• Option of applying the Rivisa ® Protecline Plus triple plastic coating, which prolongs the useful life of the materials

• Available in several colours from the Rivisa RAL chart. Colours:

Assembly manual

Preparing the ground

Step 1

Mark the line of the enclosure with the help of a rope.

Drill the holes for the foundation of the posts at the distance marked by the centre line.

Step 2

Lay the first post on the foundation and plumb it with the help of a level.

Preparing the ground

Step 3

Mount the metal clamp on the post (4 pcs. per intermediate post and 2 pcs. per end post).

Frame and end section assembly

Step 5

Put the next post in the foundation and fit the panel into the brackets.

Screw the 4 brackets to the frame.

Step 4

Position the frame, ensuring that it is securely fastened inside the brackets.

Step 6

Repeat as many times as necessary.

If base plate anchoring has been used instead of foundation anchoring, screw on the base and insert the first post. Hook in the panel and insert the next post.

Application places

• High security post and frame system

• High resistance security system

• Exceptional service life due to their anticorrosion coating

Application places

POSTS AND MESH

• Machining poles of 100x4 (W= 27.82 cm 3), with all the needed components to incorporate and tighten the Chain Link mail. The mechanical features of the tubes follow UNE-19-011-86 standards

• Crossbeams Ø100x4mm placed 3m above ground level and double crossbeam placed at 6m above ground level at the

poles

For those enclosures equipped with microphone

recommend installing the plastic coating

plastic coating)

*Available on certain enclosure

Anticorrosion coating

All the materials of the Defence Plus fence are hot-dip galvanised:

• Minimum thickness: 100 microns

• Colour:

Hot-dip galvanised

Assembly

Enclosure built with 100x4 diameter poles and chain link 50/16 mail. Intermediate poles are placed every 2m 50. Six lines of No.16 tightening wire should be also installed.

Assembling options

There are several ways of installing the enclosure, adding complementary elements that will increase the efficacy and protection of the system.

OPTION 1. ASSEMBLING CONCERTINA

Concertina is the perfect complement for security perimeter protection. It dissuades any trespassing attempt. Rivisa recommends using the Harpoon-type concertina, with a diameter of 600x50mm, finished in galvanised stainless steel. Different combinations are available.

CONCERTINA FEATURES

Reinforced stainless steel blades are a very aggressive product. The blades are designed in order to improve the anchoring effect in situations where a maximum security is needed.

ASSEMBLING CONCERTINA ON A CONCRETE WALL

A concrete wall may be added to the High Security System. A double concertina can be installed to increase the security.

OPTION 2: ANTI-CLIMB MESH

ANTI-CLIMB MESH

The anti-climb mesh is a perfect complement for this system. It prevents intruders from introducing their feet or fingers through the chain-link mesh. In penitentiaries, it is recommended to install an anti-climb mesh measuring 10x10x0.8mm. In correctional facilities, it is recommended to install an anti-climb mesh measuring 6x6x0.8mm.

OPTION 3: BARBED WIRE

Barbed wire is the perfect complement for medium and high security enclosures.It grants better security of the perimeter. 3 or 4 lines of barbed wire can be installed.

ANTI-CLIMB MESH

OUTSTANDING

• High security post and frame system

• Non-removable fence, highly resistant to vandalism

• Exceptional life

• Complete system

• Low maintenance cost

DEFENCE® PLUS

Assembly

POST AND ACCESSORIES DEFENCE PLUS PANEL

• Defence Plus posts have a square cross-section of 80x80x2mm, 100x100x2mm and 120x120x3mm (depending on height).

• The frames are installed using a connecting plate and nonremovable safety threaded rods, special brackets or nonremovable through threaded rods.

• The posts are made of galvanised sheet metal and plasticcoated with the Rivisa Protecline anti-corrosion coating system.

• The Defence Plus high security panels have the following features.

• Characteristics (see table below).

• They are manufactured with 4mm diameter steel wire and electro-welded joints with a rectangular grid of 12.7x76.2mm.

Application places

* Please contact us for more finishing options

BETWEEN AXLES: ON REQUEST

BAYONET EXTENSION WITH BARBED WIRE

A bayonet extension with 4 rows of barbed wire can be mounted on the upper part of the fence. The bayonet is manufactured with a 50 mm “T” profile, and has the necessary fittings to be able to fix the barbed wire.

Stiffening system

These systems keep the frame perfectly aligned with the perimeter, increasing the rigidity of the fence and preventing deformation of the mesh due to pressure or impact.

Option of making swing system and sliding system gates filled with high-security Defence Plus panels.

(A) ANGULAR

Angular profile stiffeners measuring 40x40x4mm Anchorages by means of non-detachable screws, metric M8x20mm

(B) FOLDS

The position and number of longitudinal folds will depend on the height of the fence.

Anticorrosion coating

All the materials of the Defence Plus system are hot-dip galvanised and plastic-coated with the Rivisa ® Protecline anticorrosion coating system.

• Minimum thickness: 100 microns

• Option of applying the Rivisa ® Protecline Plus plastic coating, which prolongs the useful life of the materials

• Option of applying the Rivisa ® Protecline Plus triple plastic coating, which prolongs the useful life of the materials

• Available in several colours from the Rivisa RAL chart. Colours:

OUTSTANDING

• High security post and frame system

• Non-removable fence, highly resistant to vandalism

• Exceptional life

• Complete system

• Low maintenance cost

Application places

Assembly

POSTS AND ACCESSORIES

• Defence Plus posts have a square base of 80x80x2mm, 100x100x2mm or 120x120x3mm (depending on the height)

• Mesh panels are installed using a securing panel and security screws

• The posts are manufactured with galvanised metal and laminated with the Rivisa Protecline anticorrosion covering

Assembly option

4m

5m 5m

6m see features

EXTENDER POST FOR CCTV SYSTEMS

The Defence Plus with Integrated Electronics fence posts can be extended for use with CCTV systems (cameras, domes, heat sensors, etc.)

Electro-welded Defence that allow

include hidden sensors.

Anticorrosion coating

1.Defence

All the materials of the Defence Plus system are hot-dip galvanised and plastic-coated with the Rivisa ® Protecline anticorrosion coating system.

• Minimum thickness: 100 microns

• Option of applying the Rivisa ® Protecline Plus plastic coating, which prolongs the useful life of the materials

• Option of applying the Rivisa ® Protecline Plus triple plastic coating, which prolongs the useful life of the materials

• Available in several colours from the Rivisa RAL chart. Colours:

OUTSTANDING

• Gates manufactured with metal sections and electro-welded mesh.

• Versatility for openings

• Perfect fitting of the gate leaves

• High quality materials and accessories

• Gates approved to the CE standard

Application places

LIGHT SWING GATE

Accessory column for residential areas Technical features

• Uprights and mesh: Leaf formed of metal profiles (see table) and electro-welded mesh measuring 200/50 Ø5mm

• Support columns with square profile (see table), with small flanges for optionally attaching struts, the end post of the fence or the grips for embedding in a wall as required

• Adjustable hinges allowing for a better fit of the gate

• Lock with box and plastic keyhole cover (see detail) and with the option of installing an automatic locking system

• Barbed wire (extension arm) accessory fastened to the leaf by means of non-removable screws

LOCK

Lock fitted with a non-degradable polypropylene casing and cover. Option of installing an electric lock.

METAL BOLT

Assembly consisting of a metal stop anchored to the floor and a latch mounted in the centre of the two leaves to prevent the door from being opened from the outside.

POLYAMIDE LOCK FOR WICKET DOOR

Polyamide lock for garden gates. Clamp fixing ensures quick and robust mounting on square or round posts.

HINGES

Adjustable hinges for perfect gate adjustment.

METAL STOP

Metal stop for swing gates with internal opening.

1m20

Anticorrosion coating

All the materials of system are hot dip galvanised and plastic coated with Rivisa ® Protecline anticorrosion coating system.

• Minimum thickness: 100 microns

• Option of applying the Rivisa ® Protecline Plus plastic coating, which prolongs the useful life of the materials

• Option of applying the Rivisa ® Protecline Plus triple plastic coating, which prolongs the useful life of the materials

• Available in several colours from the Rivisa RAL chart. Colours:

Markinge of swing doors

Rivisa® complies with the standard: EN-13241-1:2003 which defines the safety and performance requirements for swing doors when installed in areas accessible to people. Rivisa® standard doors successfully passed the “ TEST OF DECLARATION OF CONFORMITY ” to obtain the certificate.

OUTSTANDING

• • Gates manufactured from very rigid metal sections

• Robust gate appearance

• Versatile for openings

• Perfect adjustment of the gate leaves

• High quality materials and accessories

• Locking system with anti-levering feature

• Gates approved to the CE standard

Application places

MEDIUM SWING GATE

Assembly

Accessory column for residential areas Technical features

• Gate posts and leaf meshes made up of a rectangular profile framework and square profile bars (see table)

• Support columns with square profile (see table), with small flanges for optionally attaching struts, the end post of the fence or the grips for embedding in a wall as required

• Barbed wire (extension arm) accessory fastened to the leaf by means of non-removable screws

LOCK

Lock fitted with a non-degradable polypropylene casing and cover. Option of installing an electric lock.

POLYAMIDE LOCK FOR WICKET DOOR

Polyamide lock for garden gates. Clamp fixing ensures quick and robust mounting on square or round posts.

HINGES

Adjustable hinges for perfect gate adjustment.

METAL BOLT

Assembly consisting of a metal stop anchored to the floor and a latch mounted in the centre of the two leaves to prevent the door from being opened from the outside.

METAL STOP

Metal stop for swing gates with internal opening.

Anticorrosion coating

All the materials of system are hot dip galvanised and plastic coated with Rivisa ® Protecline anticorrosion coating system.

• Minimum thickness: 100 microns

• Option of applying the Rivisa ® Protecline Plus plastic coating, which prolongs the useful life of the materials

• Option of applying the Rivisa ® Protecline Plus triple plastic coating, which prolongs the useful life of the materials

• Available in several colours from the Rivisa RAL chart. Colours:

Markinge of swing doors

OUTSTANDING Assembly

• Gates manufactured from very rigid metal sections

• Robust gate appearance

• Versatile for openings

• Perfect adjustment of the gate leaves

• High quality materials and accessories

• Locking system with anti-levering feature

• Gates approved to the CE standard

Application places

STRONG SWING GATE

• Gate posts and leaf meshes made up of a rectangular profile framework and square profile bars (see table)

• Support columns with square profile (see table), with small flanges for optionally attaching struts, the end post of the fence or the grips for embedding in a wall as required

• Barbed wire (extension arm) accessory fastened to the leaf by means of non-removable screws

Accessory column for residential areas

180° HINGE WITH 4-DIMENSIONAL ADJUSTMENT

Hot-dip galvanised 180° hinge with 4-dimensional adjustment. Depth, height and distance between post and gate are adjustable after installation.

SECURITY LOCK

Stainless steel security lock for metal doors. The patented stainless steel anchoring system prevents the leaves from separating.

INDUSTRIAL LOCK

Industrial lock with aluminium housing and stainless steel mechanism.

METAL BOLT

Assembly consisting of a metal stop anchored to the floor and a latch mounted in the centre of the two leaves to prevent the door from being opened from the outside.

METAL STOP

Metal stop for swing gates with internal opening.

Anticorrosion coating

All the materials of system are hot dip galvanised and plastic coated with Rivisa ® Protecline anticorrosion coating system.

• Minimum thickness: 100 microns

• Option of applying the Rivisa ® Protecline Plus plastic coating, which prolongs the useful life of the materials

• Option of applying the Rivisa ® Protecline Plus triple plastic coating, which prolongs the useful life of the materials

• Available in several colours from the Rivisa RAL chart. Colours:

Markinge of swing doors

Rivisa® complies with the standard: EN-13241-1:2003 which defines the safety and performance requirements for swing doors when installed in areas accessible to people. Rivisa® standard doors successfully passed the “ TEST OF DECLARATION OF CONFORMITY ” to obtain the certificate.

OUTSTANDING Assembly

• Gates manufactured from very rigid metal sections

• Robust gate appearance

• Versatile for openings

• Perfect adjustment of the gate leaves

• High quality materials and accessories

• Locking system with anti-levering feature

• Gates approved to the CE standard

Application places

Technical features

• Sheets formed by a rectangular-profile frame and a die-cut sheet measuring 30x30mm square and 1.5mm thick (see table).

• Support columns of square profile (see table).

• Adjustable hinges.

• Lock provided with an aluminum casing with the option of integrating an electric lock closing system.

• Supplement (bayonet) for hawthorn coupled to the leaf uprights with non-removeable threaded rods

Accesory pillar for residential complex

RESIDENTIAL KIT

Complete installation kit for residential gates, with different combinations that allow aesthetic and functional needs to be met in residential areas. There are several combinations for the residential kit:

A. Sliding gate + pedestrian access gate with magnetic lock

B. Double leaf mechanised gate + pedestrian access gate with magnetic lock

Accessories standard swing gate

180° HINGE WITH 4-DIMENSIONAL ADJUSTMENT

Hot-dip galvanised 180° hinge with 4-dimensional adjustment. Depth, height and distance between post and gate are adjustable after installation.

SECURITY LOCK

Stainless steel security lock for metal doors. The patented stainless steel anchoring system prevents the leaves from separating.

INDUSTRIAL LOCK

Industrial lock with aluminium housing and stainless steel mechanism.

METAL BOLT

Assembly consisting of a metal stop anchored to the floor and a latch mounted in the centre of the two leaves to prevent the door from being opened from the outside.

METAL STOP

Metal stop for swing gates with internal opening.

Anticorrosion coating

All the materials of the system are hot-dip galvanised and plastic-coated with the Rivisa ® Protecline anticorrosion coating system.

• Minimum thickness: 100 microns

• Option of applying the Rivisa ® Protecline Plus plastic coating, which prolongs the useful life of the materials

• Option of applying the Rivisa ® Protecline Plus triple plastic coating, which prolongs the useful life of the materials

• Available in several colours from the Rivisa RAL chart. Colours:

Markinge of swing doors

Rivisa® complies with the standard: EN-13241-1:2003 which defines the safety and performance requirements for swing doors when installed in areas accessible to people. Rivisa® standard doors successfully passed the “ TEST OF DECLARATION OF CONFORMITY ” to obtain the certificate.

OUTSTANDING Assembly

• Gates manufactured of very rigid metal section

• Robust gate appearance

• Versatile for openings

• Perfect adjustment of the gate leaves

• High quality materials and accessories

• Locking system with anti-levering feature

• Gates approved to the CE standard

Application places

• The leaves consist of a rectangular profile frame and die-cut sheet metal in the style of the Nove Nat gate and WEIGH

• 1.5mm (see table).

• Square profile support columns (see table).

• Adjustable hinges.

• Lock provided with an aluminium housing with the option of integrating an electric lock locking system.

• Bayonet for thorn attached to the uprights of the leaf with nondetachable Threaded rods.

Accessory pillar for residential complex

RESIDENTIAL SET

Complete installation kit for residential gates, with different combinations that allow aesthetic and functional needs to be met in residential areas. There are several combinations for the residential kit: A. Sliding gate + pedestrian access gate with magnetic lock

Double leaf mechanised gate + pedestrian access gate with magnetic lock

Accessories standard swing gate

180° HINGE WITH 4-DIMENSIONAL ADJUSTMENT

Hot-dip galvanised 180° hinge with 4-dimensional adjustment. Depth, height and distance between post and gate are adjustable after installation. METAL BOLT

SECURITY LOCK

Stainless steel security lock for metal doors. The patented stainless steel anchoring system prevents the leaves from separating.

INDUSTRIAL LOCK

Industrial lock with aluminium housing and stainless steel mechanism.

Assembly consisting of a metal stop anchored to the floor and a latch mounted in the centre of the two leaves to prevent the door from being opened from the outside.

METAL STOP

Metal stop for swing gates with internal opening.

Anticorrosion coating

All the materials of the system are hot-dip galvanised and plastic-coated with the Rivisa ® Protecline anticorrosion coating system.

• Minimum thickness: 100 microns

• Option of applying the Rivisa ® Protecline Plus plastic coating, which prolongs the useful life of the materials

• Option of applying the Rivisa ® Protecline Plus triple plastic coating, which prolongs the useful life of the materials

• Available in several colours from the Rivisa RAL chart. Colours:

Markinge of swing doors

Rivisa® complies with the standard: EN-13241-1:2003 which defines the safety and performance requirements for swing doors when installed in areas accessible to people. Rivisa® standard doors successfully passed the “ TEST OF DECLARATION OF CONFORMITY ” to obtain the certificate.

OUTSTANDING Assembly

• Gates manufactured from very rigid metal sections

• Complete Ultra gate system

• Versatile for openings

• Perfect adjustment of the gate leaves

• High quality materials and accessories

• Locking system with anti-levering feature

• Gates approved to the CE standard

Application places

ULTRA® SWING GATES

• Leaves consisting of rectangular profile frame and 25x25mm bars.

• Square profile support columns (see table).

• Adjustable hinges that allow enhanced adjustment of the door.

• Lock provided with stainless steel box and stainless steel mouthpiece (see detail).

• Bayonet for thorns attached to the uprights of the leaf with Threaded rods that cannot be disassembled.

Accesory pillar for residential complex

RESIDENTIAL SET

Complete installation kit for residential gates, with different combinations that allow aesthetic and functional needs to be met in residential areas. There are several combinations for the residential kit:

A. Sliding gate + pedestrian access gate with magnetic lock B. Double leaf mechanised gate + pedestrian access gate with magnetic lock

Accessories standard swing gate

180° HINGE WITH 4-DIMENSIONAL ADJUSTMENT

Hot-dip galvanised 180° hinge with 4-dimensional adjustment. Depth, height and distance between post and gate are adjustable after installation.

SECURITY LOCK

Stainless steel security lock for metal doors.

The patented stainless steel anchoring system prevents the leaves from separating.

INDUSTRIAL LOCK

Industrial lock with aluminium housing and stainless steel mechanism.

METAL BOLT

Assembly consisting of a metal stop anchored to the floor and a latch mounted in the centre of the two leaves to prevent the door from being opened from the outside.

METAL STOP

Metal stop for swing gates with internal opening.

Anticorrosion coating

All the materials of the system are hot-dip galvanised and plastic-coated with the Rivisa ® Protecline anticorrosion coating system.

• Minimum thickness: 100 microns

• Option of applying the Rivisa ® Protecline Plus plastic coating, which prolongs the useful life of the materials

• Option of applying the Rivisa ® Protecline Plus triple plastic coating, which prolongs the useful life of the materials

• Available in several colours from the Rivisa RAL chart. Colours:

Markinge of swing doors

Rivisa® complies with the standard: EN-13241-1:2003 which defines the safety and performance requirements for swing doors when installed in areas accessible to people. Rivisa® standard doors successfully passed the “ TEST OF DECLARATION OF CONFORMITY ” to obtain the certificate.

OUTSTANDING Assembly

• Gates manufactured from very rigid metal sections

• Robust gate appearance

• Versatile for openings

• Perfect adjustment of the gate leaves

• High quality materials and accessories

• Locking system with anti-levering feature

• Gates approved to the CE standard

Application places

ULTRA® ROND SWING GATES

• Leaves consisting of rectangular profile frame and bars, Ø25mm.

• Square profile support columns (see table).

• Adjustable hinges that allow enhanced adjustment of the door.

• • Lock fitted with stainless steel box and stainless steel mouthpiece (see detail).

Accesory pillar for residential complex

RESIDENTIAL SET

Complete installation kit for residential gates, with different combinations that allow aesthetic and functional needs to be met in residential areas. There are several combinations for the residential kit:

A. Sliding gate + pedestrian access gate with magnetic lock B. Double leaf mechanised gate + pedestrian access gate with magnetic lock

Accessories standard swing gate

180° HINGE WITH 4-DIMENSIONAL ADJUSTMENT

Hot-dip galvanised 180° hinge with 4-dimensional adjustment. Depth, height and distance between post and gate are adjustable after installation.

SECURITY LOCK

Stainless steel security lock for metal doors. The patented stainless steel anchoring system prevents the leaves from separating.

INDUSTRIAL LOCK

Industrial lock with aluminium housing and stainless steel mechanism.

METAL BOLT

Assembly consisting of a metal stop anchored to the floor and a latch mounted in the centre of the two leaves to prevent the door from being opened from the outside.

METAL STOP

Metal stop for swing gates with internal opening.

Anticorrosion coating

All the materials of the system are hot-dip galvanised and plastic-coated with the Rivisa ® Protecline anticorrosion coating system.

• Minimum thickness: 100 microns

• Option of applying the Rivisa ® Protecline Plus plastic coating, which prolongs the useful life of the materials

• Option of applying the Rivisa ® Protecline Plus triple plastic coating, which prolongs the useful life of the materials

• Available in several colours from the Rivisa RAL chart. Colours:

Markinge of swing doors

Rivisa® complies with the standard: EN-13241-1:2003 which defines the safety and performance requirements for swing doors when installed in areas accessible to people. Rivisa® standard doors successfully passed the “ TEST OF DECLARATION OF CONFORMITY ” to obtain the certificate.

OUTSTANDING

• Gates manufactured with highly rigid metal profiles

• Complete Pantah gate and fence system

• Robust appearance of the gates

• Versatility in openings

• Perfect adjustment of the gate leaves

• High-quality materials and accessories

• Locking system with anti-leveraging feature

• Gates approved according to CE regulations

Application places

Assembly

• Leaves consisting of rectangular profile frame and bars, Ø25mm.

• Square profile support columns (see table).

• Adjustable hinges that allow enhanced adjustment of the door.

• • Lock fitted with stainless steel box and

mouthpiece (see detail).

Accesory pillar for residential complex

RESIDENTIAL SET

Complete installation kit for residential gates, with different combinations that allow aesthetic and functional needs to be met in residential areas. There are several combinations for the residential kit: A. Sliding gate + pedestrian access gate with magnetic lock B. Double leaf mechanised gate + pedestrian access gate with magnetic lock

Accessories standard swing gate

180° HINGE WITH 4-DIMENSIONAL ADJUSTMENT

Hot-dip galvanised 180° hinge with 4-dimensional adjustment. Depth, height and distance between post and gate are adjustable after installation.

SECURITY LOCK

Stainless steel security lock for metal doors. The patented stainless steel anchoring system prevents the leaves from separating.

INDUSTRIAL LOCK

Industrial lock with aluminium housing and stainless steel mechanism.

METAL BOLT

Assembly consisting of a metal stop anchored to the floor and a latch mounted in the centre of the two leaves to prevent the door from being opened from the outside.

METAL STOP

Metal stop for swing gates with internal opening.

Anticorrosion coating

All the materials of system are hot dip galvanised and plastic coated with Rivisa ® Protecline anticorrosion coating system.

• Minimum thickness: 100 microns

• Option of applying the Rivisa ® Protecline Plus plastic coating, which prolongs the useful life of the materials

• Option of applying the Rivisa ® Protecline Plus triple plastic coating, which prolongs the useful life of the materials

• Available in several colours from the Rivisa RAL chart. Colours:

Markinge of swing doors

Rivisa® complies with the standard: EN-13241-1:2003 which defines the safety and performance requirements for swing doors when installed in areas accessible to people. Rivisa® standard doors successfully passed the “ TEST OF DECLARATION OF CONFORMITY ” to obtain the certificate.

OUTSTANDING

• Gates manufactured from very rigid metal sections

• Complete Flater gate system

• Versatile for openings

• Perfect adjustment of the gate leaves

• High quality materials and accessories

• Locking system with anti-levering feature

• Gates approved to the CE standard

Application places

FLATER® SWING GATES

• Leaves consisting of rectangular profile frame and bars, 50X10mm.

• Square profile support columns (see table).

• Adjustable hinges that allow enhanced adjustment of the door.

• Lock provided with stainless steel box and stainless steel mouth-plug (see detail).

• Bayonet for thorn fitted to the uprights of the leaf with nondetachable threaded rods.

Accesory pillar for residential complex

RESIDENTIAL SET

Complete installation kit for residential gates, with different combinations that allow aesthetic and functional needs to be met in residential areas. There are several combinations for the residential kit: A. Sliding gate + pedestrian access gate with magnetic lock B. Double leaf mechanised gate + pedestrian access gate with magnetic lock

Accessories standard swing gate

180° HINGE WITH 4-DIMENSIONAL ADJUSTMENT

Hot-dip galvanised 180° hinge with 4-dimensional adjustment. Depth, height and distance between post and gate are adjustable after installation.

SECURITY LOCK

Stainless steel security lock for metal doors. The patented stainless steel anchoring system prevents the leaves from separating.

INDUSTRIAL LOCK

Industrial lock with aluminium housing and stainless steel mechanism.

METAL BOLT

Assembly consisting of a metal stop anchored to the floor and a latch mounted in the centre of the two leaves to prevent the door from being opened from the outside.

METAL STOP

Metal stop for swing gates with internal opening.

Anticorrosion coating

All the materials of the system are hot-dip galvanised and plastic-coated with the Rivisa ® Protecline anticorrosion coating system.

• Minimum thickness: 100 microns

• Option of applying the Rivisa ® Protecline Plus plastic coating, which prolongs the useful life of the materials

• Option of applying the Rivisa ® Protecline Plus triple plastic coating, which prolongs the useful life of the materials

• Available in several colours from the Rivisa RAL chart. Colours:

Markinge of swing doors

Rivisa® complies with the standard: EN-13241-1:2003 which defines the safety and performance requirements for swing doors when installed in areas accessible to people. Rivisa® standard doors successfully passed the “ TEST OF DECLARATION OF CONFORMITY ” to obtain the certificate.

OUTSTANDING Assembly

• Gates manufactured from very rigid metal sections

• Robust gate appearance

• Versatile for openings

• Perfect adjustment of the gate leaves

• High quality materials and accessories

• Locking system with anti-levering feature

• Gates approved to the CE standard

Application places

• Leaves consisting of rectangular profile frame and bars, Ø20mm.

• Square profile support columns (see table).

• Adjustable hinges that allow a greater adjustment of the door.

• Lock fitted with stainless steel box and stainless steel mouthpiece (see detail).

• Bayonet for thorn fitted to the leaf uprights with non-removable threaded rods.

Accesory pillar for residential complex

RESIDENTIAL SET

Complete installation kit for residential gates, with different combinations that allow aesthetic and functional needs to be met in residential areas. There are several combinations for the residential kit:

A. Sliding gate + pedestrian access gate with magnetic lock

B. Double leaf mechanised gate + pedestrian access gate with magnetic lock

Accessories standard swing gate

180° HINGE WITH 4-DIMENSIONAL ADJUSTMENT

Hot-dip galvanised 180° hinge with 4-dimensional adjustment. Depth, height and distance between post and gate are adjustable after installation.

SECURITY LOCK

Stainless steel security lock for metal doors.

The patented stainless steel anchoring system prevents the leaves from separating.

INDUSTRIAL LOCK

Industrial lock with aluminium housing and stainless steel mechanism.

METAL BOLT

Assembly consisting of a metal stop anchored to the floor and a latch mounted in the centre of the two leaves to prevent the door from being opened from the outside.

METAL STOP

Metal stop for swing gates with internal opening.

Anticorrosion coating

All the materials of the system are hot-dip galvanised and plastic-coated with the Rivisa ® Protecline anticorrosion coating system.

• Minimum thickness: 100 microns

• Option of applying the Rivisa ® Protecline Plus plastic coating, which prolongs the useful life of the materials

• Option of applying the Rivisa ® Protecline Plus triple plastic coating, which prolongs the useful life of the materials

• Available in several colours from the Rivisa RAL chart. Colours:

Markinge of swing doors

Rivisa® complies with the standard: EN-13241-1:2003 which defines the safety and performance requirements for swing doors when installed in areas accessible to people. Rivisa® standard doors successfully passed the “ TEST OF DECLARATION OF CONFORMITY ” to obtain the certificate.

OUTSTANDING

• Gates manufactured from very rigid metal sections

• Robust gate appearance

• Versatile for openings

• Perfect adjustment of the gate leaves

• High quality materials and accessories

• Locking system with anti-levering feature

• Gates approved to the CE standard

Application places

Assembly

• Leaves consisting of rectangular profile frame and bars, Ø25mm.

• Square profile support columns (see table).

• Adjustable hinges that allow enhanced adjustment of the door.

• Lock fitted with stainless steel box and stainless steel mouthpiece (see detail).

• Bayonet for thorns attached to the uprights of the leaf with non-detachable threaded rods.

Accesory pillar for residential complex

RESIDENTIAL SET

Complete installation kit for residential gates, with different combinations that allow aesthetic and functional needs to be met in residential areas. There are several combinations for the residential kit:

A. Sliding gate + pedestrian access gate with magnetic lock

B. Double leaf mechanised gate + pedestrian access gate with magnetic lock

Accessories standard swing gate

180° HINGE WITH 4-DIMENSIONAL ADJUSTMENT

Hot-dip galvanised 180° hinge with 4-dimensional adjustment. Depth, height and distance between post and gate are adjustable after installation.

SECURITY LOCK

Stainless steel security lock for metal doors.

The patented stainless steel anchoring system prevents the leaves from separating.

INDUSTRIAL LOCK

Industrial lock with aluminium housing and stainless steel mechanism.

METAL BOLT

Assembly consisting of a metal stop anchored to the floor and a latch mounted in the centre of the two leaves to prevent the door from being opened from the outside.

METAL STOP

Metal stop for swing gates with internal opening.

Anticorrosion coating

All the materials of the system are hot-dip galvanised and plastic-coated with the Rivisa ® Protecline anticorrosion coating system.

• Minimum thickness: 100 microns

• Option of applying the Rivisa ® Protecline Plus plastic coating, which prolongs the useful life of the materials

• Option of applying the Rivisa ® Protecline Plus triple plastic coating, which prolongs the useful life of the materials

• Available in several colours from the Rivisa RAL chart. Colours:

Markinge of swing doors

Rivisa® complies with the standard: EN-13241-1:2003 which defines the safety and performance requirements for swing doors when installed in areas accessible to people. Rivisa® standard doors successfully passed the “ TEST OF DECLARATION OF CONFORMITY ” to obtain the certificate.

OUTSTANDING

• Puertas fabricadas con perfilería metálica de gran rigidez

• Sistema completo de verja y puertas Tifón

• Aspecto robusto de las puertas

• Versatilidad de las aperturas

• Ajuste perfecto de las hojas

• Materiales y accesorios de gran calidad

• Sistema de cerradura con antiapalancamiento

• Puertas homologadas según la normativa CE

Application places

Assembly

Accessory column for residential areas Technical

• Leaves consisting of rectangular profile frame and bars, Ø25mm.

• Square profile support columns (see table).

• Adjustable hinges that allow enhanced adjustment of the door.

• Lock fitted with stainless steel box and stainless steel mouthpiece (see detail).

• Bayonet for thorns attached to the uprights of the leaf with non-detachable threaded rods.

RESIDENTIAL SET

Complete installation kit for residential gates, with different combinations that allow aesthetic and functional needs to be met in residential areas. There are several combinations for the residential kit: A. Sliding gate + pedestrian access gate with magnetic lock B. Double leaf mechanised gate + pedestrian access gate with magnetic

Accessories standard swing gate

180° HINGE WITH 4-DIMENSIONAL ADJUSTMENT

Hot-dip galvanised 180° hinge with 4-dimensional adjustment. Depth, height and distance between post and gate are adjustable after installation.

SECURITY LOCK

Stainless steel security lock for metal doors. The patented stainless steel anchoring system prevents the leaves from separating.

INDUSTRIAL LOCK

Industrial lock with aluminium housing and stainless steel mechanism.

METAL BOLT

Assembly consisting of a metal stop anchored to the floor and a latch mounted in the centre of the two leaves to prevent the door from being opened from the outside.

METAL STOP

Metal stop for swing gates with internal opening.

Anticorrosion coating

All the materials of system are hot dip galvanised and plastic coated with Rivisa ® Protecline anticorrosion coating system.

• Minimum thickness: 100 microns

• Option of applying the Rivisa ® Protecline Plus plastic coating, which prolongs the useful life of the materials

• Option of applying the Rivisa ® Protecline Plus triple plastic coating, which prolongs the useful life of the materials

• Available in several colours from the Rivisa RAL chart. Colours:

Markinge of swing doors

Rivisa® complies with the standard: EN-13241-1:2003 which defines the safety and performance requirements for swing doors when installed in areas accessible to people. Rivisa® standard doors successfully passed the “ TEST OF DECLARATION OF CONFORMITY ” to obtain the certificate.

ACCESSORIES

LOCKS AND LATCHES

1. 1. CYLINDER FOR TRIANGULAR KEY

European symmetrical stainless steel cylinder which allows the lock to be fitted with a triangular key.

The triangular key acts on the bolt and the deadbolt. This system is adaptable to all locks. Applications: car parks, access for firemen.

2. CYLINDER 60 mm

Symmetrical European cylinder with 3 keys: 60mm, opening or varied.

3. CYLINDER 42 mm

Symmetrical European cylinder with 3 keys: 42 mm, opening or varied.

4. CYLINDER KEY BLANK

Blank key that allows copies to be made.

For all cylinder sizes.

5. MECHANICAL CODE LOCK

Mechanical code lock with thermo-lacquered aluminium case and stainless steel mechanism. Without batteries or electricity, this system makes it possible to easily equip all doors with access control.

6. TYPE DENY LOCK

Surface mounted security lock, supplied without cylinder.

7. HANDLE SET

Variety of handles and half-handles, made of aluminium or plastic.

8. ANTI-PANIC BAR

Panic bar that facilitates the opening and free exit of a door with a simple push. The aluminium panic bar replaces the standard handle, operates the latch and can be quickly installed on new or old doors.

9. CHILD SAFETY LOCK

Features a polyamide casing and stainless steel mechanism; to operate the lock it is necessary to press the safety mechanism and turn in a double simultaneous action. Impossible to open for children under five years of age (complies with NFP 90-306).

10. TRIANGLE KEY

Compatible with lock equipped with 11mm or 14mm triangle key instead of handle.

11. DEFENSIVE PROFILE

Option to weld a defensive profile on the top of the leaves to increase safety.

12. PADLOCK HOLDER

ACCESSORIES DOOR CLOSERS

13. SAMSON HYDRAULIC DOOR CLOSER FOR LARGE DOORS

The Samson is a powerful and versatile hydraulic door closer.

14. RHINO HYDRAULIC LOCK

Rhino hydraulic lock for 180 º openings.

15. SPRING HINGE FOR GARDEN DOORS

For Light hinged and Medium hinged doors with a maximum door WEIGHT of 75 kg it is possible to install return hinges.

ACCESSORIES FOR COLUMNS

16. COLUMNS ON BASE PLATE

The dimension of the plates is determined by the size and model of the door.

17. COLUMNS ON OFFSET BASE PLATES

The plates can be offset from the column axis for a better fit of the door when installed between walls.

ELECTRICAL ACCESSORIES

Easy to install surface mount electric lock for swing doors.

19. ELECTROMAGNETIC SURFACE MAGNET WITH HANDLES FOR SWING DOORS

Innovative screw-on electromagnetic surface magnet for access control. Available in 2 versions.

The MAG3000 with a pull force of 300 kg and the MAG5000 with 500 kg.

20. HANDLELESS ELECTROMAGNETIC SURFACE MAGNET FOR SWING DOORS

Electromagnetic screw magnet without handles. Available in 2 versions.

The MAGMAG3000 with a 300 kg holding force and the MAGMAG5000 with a 500 kg holding force.

ACCESSORIES FOR THE MOTORISATION OF SWING GATES

A. HORIZONTAL PROFILE

Welding of an intermediate 60x6mm sheet metal cross member.

B. SUPPORTS

Welded supports for fixing the arm motorisation.

C. METAL STOP

Stop plate welded to the locking leave.

D. 90° ADJUSTABLE HINGE WITH BEARING

Hinge on stainless steel bearing for the upper or lower part of the door. Mounted on all automation projects.

Opening of hinged doors

Option of manufacturing doors with leaves of different sizes.

HINGED DOOR

18. ELECTRIC SURFACE MOUNT LOCK

21. STEP SLEEVE Stainless steel sheath to protect your electrical cables in an outdoor environment.

22. FLAT SHEET METAL PLINTH

23. UNEQUAL LEAVES

DOUBLE

SINGLE-LEAF DOOR

Sliding gates and cantilever sliding gate

OUTSTANDING

• Easy operation

• Complete system

• Exceptional service life due to their anticorrosion coating

• The sliding gates combine perfectly with all the fence models

• Gates approved to the CE standard

Application places

Technical features

• Leaves with built-in welded metal transoms (see table below). Wheels provided with ball bearings installed in the baseboard

• Rail to be embedded on the ground

• Gatestop post and guiding plate with adjustable Teflon rolls

• Gates can be assembled with bars, mail or metal sheet

• Lock ready plates are optional

• Mechanised gates are optional (see Access technical features sheet)

• Closure options:

• A. Metal lock

• B. Supports for padlock and handles

Technical features

* Gates between 8m and 14m supplied in 2 assembled leaves.

DOOR OPENING DIRECTION

Unless otherwise stated, Rivisa sliding doors are supplied with right-hand opening.

Markinge of swing doors

Rivisa® complies with the standard: EN-13241-1:2003 which defines the safety and performance requirements for swing doors when installed in areas accessible to people. Rivisa® standard doors successfully passed the “ TEST OF DECLARATION OF CONFORMITY ” to obtain the certificate.

Technical details

Optional motorisation with applications of industrial use and zones where control of entry points must be precise. The motorisation system consists of a motor and highresistance motive gears.

1. BRIDGE GUIDE

2. TOP Frontal and queued safety stop, with a rubber silent block

3. CLOSING COLUMN:

GUIDE

WHEELS

WHEELS

Models on request

CLASSIC

®

Leaf made of welded metal profiles (see table) and filled with Classic 40x40x1.5mm (horizontal), 30x30x1.5mm (vertical) and 300x55mm electro-welded mesh, with Ø5mm vertical wires and Ø6mm horizontal wires.

CALITAX®

Leaf made up of welded metal profiles (see table) and filled with Calitax fencing with 40x40x1.5mm (horizontal) and 35x35x1.5mm (vertical) profiles.

* Optional FINISHING: door filled with Defence-Plus mesh.

NOVÉ ®

Leaf formed by welded metal profiles (see table) and filled with 40x40x1.5mm (horizontal), 30x30x1.5mm (vertical) Nové grille and perforated sheet with 30x30mm squares and a thickness of 1.5mm.

*this door model can only be manufactured up to a maximum length of 8m.

NOVÉ ® NAT

Door leaf made of welded metal profiles (see table) and filled with 40x40x1.5mm (horizontal), 30x30x1.5mm (vertical) Nové grille and NAT perforated sheet 1.5mm thick.

*This door model can only be manufactured up to a maximum length of 8m.

ULTRA ®

Sheet formed by welded metal profiles (see table) and filled with Ultra grill made with 40x40x1.5mm (horizontal) and 30x30x1.5mm (vertical) profiles.

ULTRA ® ROND

Sheet formed by welded metal profiles (see table) and filled with Ultra Rond grill made with 40x40x1.5mm (horizontal) profiles and Ø25x1.5mm (vertical) profiles.

PANTAH®

Sheet formed by welded metal profiles (see table) with horizontal crossbar filler of 40x40x1.5mm and vertical bars of 20mm diameter and 1.5mm thickness with random distribution

FLATER ®

Sheet formed by welded metal profiles (see table) and filled with Flater grill made with 50x30x1.5mm (horizontal) profiles and 50x10x1.5mm (vertical) profiles

Models on request Models on request

DECOR

Sheet formed by welded metal profiles (see table) and filled with Decor grill made with 40x40x1.5mm (horizontal) profiles and Ø20x1.5mm (vertical) profiles

NATURE

Sheet formed by welded metal profiles (see table) and filled with Nature grill made with 40x40x1.5mm (horizontal) profiles and Ø25x1.5mm (vertical) profiles

TIFÓN

Door leaf formed by welded metal profiles (see table) with horizontal crossbar filler of 40x40x1.5mm and vertical bars of 25mm diameter and 1.5mm thickness with random distribution.

Accessories WIDTHRING SYSTEM

1. SLIDING DOOR LOCK

Industrial type lock for sliding doors with powder coated aluminium case and stainless steel mechanism.

2. MECHANICAL CODE LOCK FOR A SLIDING DOOR

Mechanical code lock for sliding doors with powder coated aluminium case and stainless steel mechanism.

3. CYLINDER WITH TRIANGLE FOR FIRE BRIGADE

European 30 x 30 mm stainless steel cylinder with triangle for a fire brigade lock. The triangle acts on the bolt and the deadbolt. This system is adaptable to all locks.

4. 60 MM CYLINDER

Symmetrical European cylinder with 3 keys: 60 mm.

5. BLANK CYLINDER KEY

Blank key that allows copies to be made. For all cylinder sizes.

6. WELDED ON DEFENSIVE PROFILE

Foundation: anchoring system with all fastening elements of the gate concreted.

base plate system: anchorage via double-founded base plates system.

Anticorrosion coating

All the materials of the system are hot-dip galvanised and plastic-coated with the Rivisa ® Protecline anticorrosion coating system.

• Minimum thickness: 100 microns

• Option of applying the Rivisa ® Protecline Plus plastic coating, which prolongs the useful life of the materials

• Option of applying the Rivisa ® Protecline Plus triple plastic coating, which prolongs the useful life of the materials

• Available in several colours from the Rivisa RAL chart. Colours:

* Nové and Nové Nat sliding doors cannot be plastic-coated in

1.

2. With double

3. Base plate: anchor system motherboards and anchors.

OUTSTANDING

• Opening and closing system without rail

• Ease of operation

• Complete system

• Lifetime anti-corrosion coating for superb

• Gates approved according to CE

Application places

CANTILEVER SLIDING GATE

Technical features

THE CANTILEVER GATE IS IDEAL FOR:

• Areas where a tall space is available for the opening of the gate (about 2 times the span of the gate).

• Areas where the ground that regulary covered with snow.

• Places where there is constant traffic of vehicles and heavy trucks, such as quarries, factories, warehouses, airports and military installations.

TECHNICAL DETAILS:

• Gates with a total access available from 5 to 9 metres for only one leaf.

• Lower beam with a profile of 120x120x4mm

• Frame with a profile of 100x50x2mm

• Interior filling of the leaf 35x35x1.5mm

The Cantilever Gates are made with the following elements:

1. LOWER GUIDE: guidance system for the cantilever carriages to ensure that the gate slides perfectly.

2. GUIDE CARRIAGE: 2 sets of cantilever rollers inserted in the lower profile.

4. BRIDGE GUIDE: nylon wheels fitted with high strength and base plate for a perfect foundation.

5. Leaf of cantilever type and variable measures, made with profiles of great inflexibility and oversized plinth.

Marking of swing doors

3. Optional electrical functioning for applications of industrial use and zones where a control of the accesses is needed. The electrical functioning system of the cantilever gates consists of highresistance motor reducing gears.

6. CLOSING COLUMN: Structure of double final column of closing and safety gate stopper.

Rivisa® complies with the standard: EN-13241-1:2003 which defines the safety and performance requirements for swing doors when installed in areas accessible to people. Rivisa® standard doors have successfully passed the " DECLARATION OF CONFORMITY TEST " to obtain the certificate.

Model

CALITAX

Calitax sliding gate filled with vertical profiles measuring 35x35x1.5mm, blending with all models of fences.

SLIDING GATE

GATE

Gate leaf:

• Made of rectangular profiles welded to a lower beam of great strength.

• In the case of manual opening, the gate lock is fitted.

• Safety gate stopper for an optimal closing of the gate.

Anticorrosion coating

Bridge guide and closing column:

• The bridge guide and closing column are installed with a base plate.

• The bridge guide and the closing column are provided with a nylon roller for perfect adjustment of the opening and closing movement.

All the materials of the system are hot-dip galvanised and plastic-coated with the Rivisa ® Protecline anticorrosion coating system.

• Minimum thickness: 100 microns

• Option of applying the Rivisa ® Protecline Plus plastic coating, which prolongs the useful life of the materials

• Option of applying the Rivisa ® Protecline Plus triple plastic coating, which prolongs the useful life of the materials

• Available in several colours from the Rivisa RAL chart. Colours:

Barriers and automatic features

AUTOMATIC FEATURES FOR SLIDING GATES

From residential sliding gates to large industrial gates, automation systems for sliding gates with Rivisa’s rack are designed to meet every need. Designed to operate in any atmospheric conditions, they are simple and quick to maintain.

OUTSTANDING

• Integrated system

• Quality of materials and accessories

• Operational reliability

• Access control

AUTOMATIC FEATURES FOR SWING GATES

For single or double-leaf gates for residential, communal and industrial use, our electromechanical or oleodynamic automation systems provide an appropriate solution to your requirements.

Application places

LEAVES UP TO 3m 50

AUTOMATICS BARRIERS

1. FLASH LAMP

2. control PANEL (incorporated inside the control box)

3. PLUGGED RECEIVER (incorporated inside the control box)

4. REDUCING MOTOR SLIDING GATE

5. “NO CONTACT“ LOCK AND KEY

6. PHOTOCELL

7. REMOTE CONTROL

REDUCING MOTOR TYPE 1

SLIDING GATE AUTOMATION 1-10m

• Drive unit for gates from 1m to 10m in length.

• Power: 350W Release hand with key.

• Leaf speed: 12 metres/min.

REDUCING MOTOR TYPE 2

SLIDING GATE AUTOMATION 11-15m

• Driving unit for gates from 11m to 15m length.

• Power: 450W Release hand with key.

• Leaf speed: 10 metres/min.

Automatic features for swing gates

1. FLASH LAMP

2. CONTROL PANEL (incorporated inside the control box)

3. PLUGGED RECEIVER (incorporated inside the control box)

4. ELECTRIC LOCK

5. AUTOMATIC FEATURE FOR SWING GATE

6. “NO CONTACT“ LOCK AND KEY

7. REMOTE CONTROL

• Electronic reducing single-phase motor 230V-50Hz

• Power: 250W

• Speed: 14 mm / second

AUTOMATIC FEATURE FOR SWING GATES

DRIVE UNIT FOR SWING GATES:

• 1-leaf gates from 1m to 2m 50

• 2-leaf gates from 2m to 5m

• 1-leaf gates from

• 2-leaf gates from 5m to 8m in length

AUTOMATIC BARRIERS

• 1. FLASH LAMP

• 2. CONTROL PANEL WITH ANTI-CRUSHING SYSTEM

• (incorporated inside of control panel)

• 3. PLUGGED RECEIVER (incorporated inside of control panel)

• 4. PARKING BARRIER

• 5. “NO CONTACT“ LOCK AND KEY

• 6. PHOTOCELL

• 7. 1 CHANNEL MUTANCODE REMOTE CONTROL

Accessories

ABOUT RIVISA’S MOTORS:

• Company with ISO9001:2008 Quality Management System Certificate

• Actions in compliance with guidelines: 2006/42/CE, 2006/95/CE, 2004/108/CE

• CE Declaration of Conformity supplied within the installation manual

• The reducing motor of the gate complies with the UNE EN 60335-2-103:2003 regulation

• Safety devices are included for protection against crushing, shear and dragging during the normal operation of the sliding motorised doors. There is also protection against crushing in the event of failure of the automatic features or electrical supply, providing “justification of design”, tested in line with UNE EN 12453, UNE EN 12445 and UNE EN 12978 as included in the aforementioned guidelines.

• Each gate will include remote control with a properly equipped manoeuvre control panel and feature an IP65 outdoor rating, allowing remote start-and-stop operation of each gate leaf independently. It is also possible to supply a set of limit switches that can announce the status (closing/opening) of every leaf associated with the sliding gates independently.

• The opening and closing manoeuvres will both be achievable (in the case of motorised gates) by means of two possible control methods:

1. Semi-automatic control: This is initiated when a person issues the command via a button. The gate will under no circumstances be able to close automatically.

2. Automatic control: The opening manoeuvre begins when a person issues the command via a button, and the closing manoeuvre begins automatically after a delay programmed

Mobile fences

OUTSTANDING

• Quality of the materials

• Durability of the different models

• Flexibility and efficiency in transport

• Reflective band for road signs

Application places

MOBILE FENCES

UNIVERSAL PORTABLE FENCE

•

•

•

QUATTRO TUBI PORTABLE FENCE

• 2m high and 3m 50 long, built with Ø0.2mm tubes to increase the toughness of the frame

• Assembling this fence is simple thanks to the mounting bracket attached to the fence

• Uses: The Quattro Tubi fence model is a very tough, long-lasting fence, perfect for use on big construction sites and other locations where toughness is essential

PORTABLE FENCES

PORTABLE FENCE

• Lightweight fence, 2m high and 3m 50 long, built with Ø3.4mm iron wire and 4 longitudinal bends to increase toughness and durability

• Assembling this fence is simple thanks to the mounting bracket attached to the fence

• Uses: this enclosure is highly recommended in areas where a light and manageable fence is required. It may have other urban and industrial applications, and can be used at fairs, conferences and sporting events

*

PEDESTRIAN FENCE

• Fence 1m00 high and 3m42 wide, made with Ø20mm horizontal tubes to improve the firmness and resistance of the frame.

• Assembly is simple thanks to the connecting hook between fences incorporated into the fence.

• Applications: This portable model has a wide variety of uses, such as marking the boundaries of construction zones, gardens, work areas and events, as well as managing crowds and ensuring safety in public spaces.

Accessories

PORTABLE FENCE DOOR

This is a portable door that can be set up anywhere in the fence, and therefore it’s as versatile as the fence itself. The door can be fixed to any frame of our fences through the standard hinges. Measures 1m by 3m 50.

* The actual height of the fence changes depending on the length of the posts of Ø40mm

SECURITY SUPPORT POST Security support post used to increase stability along with an adjustable clamp.

Ø

* The actual height of the fence changes depending on the length of the posts of Ø40mm

SECURITY BRACKET

The frames of the fences can be secured together with the security bracket and a security screw. A security support post is optional.

OUTSTANDING

• Multiple aplications

• Complete systems

Application place

SPORT SYSTEM

General guidelines

AVAILABLE HEIGHTS:

• 4m

• 5m

• 6m

• 7m

• 8m

• Option of investigating extreme-height closures

POSTS:

• Steel posts Lux 80-1.5 mm/t.a. (W: 5.602 cm3) or Lux 80-R 3 mm/t.a.R (W: 12.11 cm 3) installed individually or in the form of duplicates (see table) and provided with a lengthways rack for anchoring the staples and accessories

• Mechanical features of the plate based on Regulation UNE 36137

ACCESSORIES:

• Accessories fastened to the rack by means of a fixing screw

• Polypropylene cap will not degrade in harsh weather

• Reinforced galvanised wire clamp, fixed vertically to the rack

CLOSURE TYPES:

• EXTREME-HEIGHT CLOSURE WITH POLYAMIDE MESH: stuffed polyamide mesh closure, with highly durable reinforcements made with plaited thread

• EXTREME-HEIGHT CLOSURE WITH POLYAMIDE MESH AND SINGLE-TWIST ENCLOSURE: stuffed polyamide mesh closure, reinforced in the lower section with single-twist mesh.

• EXTREME-HEIGHT CLOSURE WITH POLYAMIDE MESH AND ELECTRO-WELDED MESH: stuffed polyamide mesh closure, reinforced in the lower section with Maxi-fax or Double Spin 8/6/88 mesh.

• RAILS: The railing can be used to separate the pitch area from the spectator area; it also provides an elegant and functional passage area with the addition of a revolving door.

• The main applications of this product are in football stadiums, athletic and horse-racing tracks, multi-sport areas, etc extreme-height closure with polyamide mesh

Extreme-height closure with polyamide mesh

POLYAMIDE MESH: Reinforced polyamide high-tenacity mesh, manufactured with twisted polyamide, and reinforced by perimeter lines. Available mesh measures: 25x25 (golf), 33x33 (tennis) and 100x100 (football). The diameter of the plaited thread is 3mm, the breaking load is 50Kg and the melting point is 250 º . Available colours: white or green.

Extreme-height closure with polyamide mesh and single-twist closure

• POLYAMIDE MESH: Reinforced polyamide high-tenacity mesh, manufactured with twisted polyamide, and reinforced by perimeter line. Available mesh lengths: 25x25 (golf), 33x33 (tennis) and 100x100 (football). The diameter of the plaited thread is 3mm, the breaking load is 50Kg and the melting point is 250 º. Available colours: white or green.

• SINGLE-TWIST MESH: rhomboid made with wire with a traction resistance of at least

end and the tension posts will have guy-ropes installed with wires and crossbars, in order to improve

the fence (see detail in diagram)

* One-post inserts for single-twist mesh between two posts for polyamide mesh ** in the

and tension

The mid posts are installed at every 3m interval for chain link fences, and every 6m for polyamide mesh, with tension posts every 60m for straight sections.

The option of reinforcing the bottom part of the enclosure by using chain-link fencing, the features of the posts and the chain-link tension mesh can be seen on the Lux specifications sheet.

CROSSBAR 40

Extreme-height closure with polyamide mesh and electro-welded mesh

* DETAIL OF REINFORCEMENTS

REINFORCEMENT WITH FAX DH RAILING REINFORCEMENT WITH MAXI-FAX RAILING

Stuffed polyamide mesh closure, reinforced in the lower section with electro-welded Fax DH-type mesh. Mesh dimensions: 200/50mm, wire diameter 8/6/8mm.

Stuffed polyamide mesh closure, reinforced in the lower section with electro-welded Maxi-Faxtype mesh. Mesh dimensions: 45/55mm, horizontal and vertical wire diameter 8/6/4mm.

* One-post inserts for single-twist mesh between two posts for polyamide mesh ** in the end and tension posts

Enclosure for tennis courts

TECHNICAL FEATURES

• Lux 80-1.5 t.a. type posts for angles and adjacents and 80-1.5mm/t.a. for all others for heights of 3m and above, made of hot galvanised steel on the inside and outside and fitted with a rack for fastening staples and accessories

• Corner reinforced by crossbars

• Chain link diamond shaped mesh made of 50 kg/m 2 strength mesh

The railing can be used to separate the pitch area from the spectator area; it also provides an elegant and functional passage area with the addition of a revolving door.

The main applications are football pitches, athletics tracks, horse riding tracks, multi-sports areas, etc.

Accessory

RAILING WITHOUT PADDING:

60mm diameter galvanised steel tube and aluminium fittings for on-site assembly without welding. The HEIGHT of the railing from the ground is 1m 10 (recessed into the ground by 40cm) and the distance between vertical uprights is 2m70.

RAILING WITH PADDING:

In the case of railings filled with a 6/5/6 double-thread panel, the HEIGHT of the railing from the ground is 1m 15 (recessed into the ground by 40cm) and the distance between vertical posts is 2m 61.

The Double Thread infill guardrail panels are fixed to the vertical posts with metal clamps.

Anticorrosion coating

All the materials of the Railing are hot-dip galvanised and plastic-coated with the Rivisa ® Protecline anticorrosion coating system.

• Minimum thickness: 100 microns

• Option of applying the Rivisa ® Protecline Plus plastic coating, which prolongs the useful life of the materials

• Option of applying the Rivisa ® Protecline Plus triple plastic coating, which prolongs the useful life of the materials

• Available in several colours from the Rivisa RAL chart. Colours:
