ASCE 7-10 Wind Provisions and Effects on Wood Design and Construction
By Philip Line, P.E. and William L. Coulbourne, P.E., M. ASCE
The major change for wind design in ASCE 7-10, Minimum Design Loads for Buildings and Other Structures, is often broadly described as the introduction of new wind speed maps (referred to as ultimate wind speed maps in the 2012 International Building Code (IBC)). Several coordinated changes include: • revised load factors for wind in allowable stress design (ASD), and load and resistance factor design (LRFD) load combinations; • removal of the Occupancy Factor for wind due to new wind speed maps that vary by Risk Category (analogous to Occupancy Category); • reinstating applicability of Exposure D in hurricane prone regions; • revised wind speed triggers for definition of hurricane prone region and wind-borne debris region; and, • revised pressure values for minimum design loads.
Comparison of Design Velocity Pressure
The net effect of changes to mapped wind speeds and wind load factors on the calculated design velocity pressure can be significant in some locations, as shown in Table 1. Locations outside of the hurricane prone region, excluding special wind regions, can be generally represented by a ratio of approximately 1.0, as shown for Dallas, TX. An expected outcome, due to the uniform hazard basis of the new maps, is Figure 1: Application of minimum wind loads. that design pressures for Exposure C locations in the hurricane prone low-rise buildings designed in accordance region (Boston, Virginia Beach, and Miami) with the envelop procedure for low-rise are smaller under ASCE 7-10. Assuming buildings. For comparison, the minimum Exposure D, which is applicable in hur- design pressure of 10 psf, applicable for ricane prone regions per ASCE 7-10, an both walls and roofs under ASCE 7-05, approximate 10 percent increase in design when factored for LRFD is equal to 16 psf pressure is observed for Boston, MA and an (i.e. 10 psf x 1.6 = 16 psf). approximate 16 percent decrease in design pressure is observed for Virginia Beach, VA. Wind Speed Triggers Minimum Design Wind Loads
Minimum wind load provisions of ASCE 7-10 for design of main wind force resisting systems (MWFRS), under the directional procedure and envelop procedure, have also been revised to specify a minimum 16 psf wall pressure and a minimum roof pressure of 8 psf projected onto a vertical plane (Figure 1). And, it is now less likely to be the controlling minimum design wind load, particularly for some building configurations in lower wind speed regions and for Changes to mapped wind speeds are also coordinated with revision of several windspeed “trigger” values, such as the definition of hurricane prone regions (Figure 2). The revised wind speed trigger in ASCE 7-10 for hurricane prone regions (i.e. 115 mph) represents an algebraic conversion of the wind speed trigger in ASCE 7-05. Revised wind speed triggers for wind-borne debris regions and glazed opening protection have also changed, and do not follow the same conversion and exclusive linkage to wind speed maps for Risk Category II.
Table 1: Comparison of design velocity pressures using ASCE 7-10 and ASCE 7-05 (33-foot mean roof height).
ASCE 7-10 ASCE 7-05 Ratio
[A] [B] [C] Design Exp C Exp D Design Exp C Risk Wind Speed Velocity Velocity Wind Speed Velocity Location Category (MPH) Pressure (psf) Pressure (psf) (MPH) Pressure (psf) [A]/[C] [B]/[C] Boston, MA II 128 35.7 42.1 105 38.4 0.93 1.10 Va Beach, VA II 122 32.4 38.2 114 45.2 0.72 0.84 Miami, FL II 170 62.9 74.2 146 74.2 0.85 1.00 Dallas, TX II 115 28.8 - 90 28.2 1.02 Boston, MA III, IV 140 42.6 50.3 105 44.1 0.97 1.14 Va Beach, VA III, IV 132 37.9 44.7 114 52.0 0.73 0.86 Miami, FL III, IV 181 71.3 84.1 146 85.3 0.84 0.99 Dallas, TX III, IV 120 31.3 - 90 32.4 0.97 -
Figure 2: Illustration of hurricane prone regions (FEMA P-804).
Coordination with Codes and Standards
IBC adopts ASCE 7-10 provisions for wind design by reference, and incorporates ASCE 7-10 wind speed maps. A conversion of mapped wind speed to an ASD basis (i.e. Vasd per 2012 IBC is calculated as Vasd = Vult x 0.61/2) is added to the IBC to coordinate with previously established IBC wind speed triggers. For wood construction, the conversion is necessary for use of tables covering attachment of wood structural panels for wind, wind applicability limit for conventional light-frame construction, and wind uplift connector requirements in Section 2308. Within the 2012 International Residential Code (IRC), new maps illustrate ASD-based wind speeds. The IRC format of the wind speed map eliminates the need for conversion of the mapped value as is done in the IBC; however, the contour lines do not directly align with those in ASCE 7-10 maps incorporated in the IBC. The 2012 Wood Frame Construction Manual (WFCM) for One- and Two-Family Dwellings includes ASCE 7-10 Risk Category II wind speed maps, tabulated requirements for wind speeds ranging from 110 mph to 195 mph for both Exposures B and C, and a conversion table to adjust tabular values for Exposure D. The removal of the occupancy factor adjustment to wind loads in ASCE 7-10 will generally limit ease of applicability of WFCM load tables to other occupancy categories. Prior WFCM load tables were based on occupancy Category II, and were easily adjusted by the occupancy factor.
Summary
Model building codes and standards that rely on the new wind design approach in ASCE 7-10 include the 2012 IRC, the 2012 IBC, and the 2012 WFCM. Each of these documents addresses implementation of ASCE 7-10 in a different manner. This will likely create confusion for the users of these documents, as they reconcile new wind speed basis of ASCE 7-10 maps and different formats of the maps appearing in the 2012 IRC and 2012 IBC. For wood construction in accordance with the WFCM, the Risk Category II wind speed map is incorporated into the standard directly as it appears in ASCE 7-10 and tabulated requirements will be associated with ASCE 7-10 mapped wind speeds.▪
Philip Line, P.E. is the Director, Structural Engineering, American Wood Council. He may be reached at pline@awc.org. William Coulbourne, P.E., M. ASCE is the Director, Wind and Flood Hazard Mitigation, Applied Technology Council. He may be reached at bcoulbourne@atcouncil.org.
This article is based on a more comprehensive paper outlining additional details on changes to wind load provisions in ASCE 7-10. The longer, more comprehensive version has been posted online at STRUCTURE’s website, www.STRUCTUREmag.org.
