Equipment Guide

ICE CUBER WITH BIN

Hoshizaki Model No. KM‐115BAJ Ice Maker With Bin, Cube‐Style, air‐cooled, self‐contained condenser, production capacity up to 116 lb/24 hours at 70°/50° (102 lb AHRI certified at 90°/70°), 53 lb built‐in ice storage capacity, crescent style cube, front opening bin, stainless steel exterior, 115v/60/1‐ph, 5.5

ICE CUBER

Hoshizaki Model No. KM‐520MAJ Ice Maker, Cube‐Style, 22”W, air‐cooled, self‐contained condenser, production capacity up to 556 lb/24 hours at 70°/50° (480 lb AHRI certified at 90°/70°), stainless steel finish, crescent cube style, R‐404A refrigerant, 115v/60/1‐ph, 10.6 amps, NSF, UL, ENERGY STAR®

REFRIGERATED MERCHANDISER

Imbera USA Model No. G319 (1010590) Refrigerated Merchandiser, one‐section, 17.03 cu. ft. capacity, (5) shelves, black painted steel exterior, white interior, (1) hinged glass door, LED interior lighting, electronic temperature controller & fan motor, bottom mounted self‐contained refrigeration, 1/4 HP, 115v/60/1‐ph, 5.2 amps, cULus, NSF, UL EPH Classified, ENERGY STAR®

FREEZER MERCHANDISER

PROKOLD Model No. DURF‐16 Single, glass door freezer, Left hinge swing, glass rear door for effortless loading and unloading; Double plane, curved, front glass which reduces heat transfer and promotes product conservation; Fully adjustable stainless steel shelves; Stainless steel floor; Temperature range 36F to 41F; Heavy duty 3” casters (included) for easy mobility and to facilitate cleaning; LED lighting for enhanced product display; Easy‐lift front covers for access to condensing unit and easy cleaning; Electronic temperature controller; Gravity controlled cooling system, 1/4 HP compressor; R134a refrigerant that reduces and optimizes energy consumption.

DIPPING CABINET

Elecstar Limited Model No. SD450S Chest dipping cabinet with sneeze guard, LED light on front inner edge, casters, water drip tray, 110v/60HZ, 1 yr parts/5 yr compressor. 4 tub holders & 4 can skirts for 8 tub facing 6 tub storage

PIZZA PREPARATION REFRIGERATOR

Asber Model No. APTP‐67 Pizza Prep Table, 67‐1/4” wide, (2) solid doors, (4) shelves on rail system, includes (9) standard full set of 1/6 size pans (4” deep), insulated lid, 19” removable/ reversible white poly cutting board, CFC polyurethane insulation, temperature from 33° to 38°, environmentally friendly R134A refrigerant, front breathing, self contained refrigeration, magnetic door gasket, stainless steel interior & exterior, galvanized back panel, 4” swivel casters (2 with brakes), 1/3 HP, cETLus, ETL‐Sanitation, Made in North America

REACH-IN REFRIGERATOR

Asber Model No. ARR‐23 Refrigerator, reach‐in, one‐section, 23 cu. ft., (1) solid door, digital controller, (3) adjustable epoxy coated shelves, incandescent interior lighting, CFC polyurethane insulation, temperature from 33° to 38°, environmentally friendly R134A refrigerant, bottom mounted compressor, self closing doors with 90° stay, magnetic door gasket, stainless steel floor, interior & exterior, galvanized back panel, 4” swivel casters (2 with brakes), 1/4 HP, cETLus, ETL‐Sanitation, Made in North America

REACH-IN FREEZER

Asber Model No. ARF‐23 Freezer, reach‐in, one‐section, 23 cu. ft., (1) solid door, digital controller, (3) adjustable epoxy coated shelves, incandescent interior lighting, CFC polyurethane insulation, maintain temperature at ‐10°, environmentally friendly R404A refrigerant, bottom mounted compressor, self closing doors with 90° stay, magnetic door gasket, stainless steel floor, interior & exterior, galvanized back panel, 4” swivel casters (2 with brakes), 3/4 HP, cETLus, ETL‐Sanitation, Made in North America

Asber Model No. AEF‐4050 S‐CAS Fryer, gas, floor model, 50 lb. capacity, (3) 35,000 BTU burners, millivolt controls, left hinged cabinet door, safety shut‐off, 1‐1/4” drain valve, pressure regulator, includes chrome mesh crumb screen & twin baskets, stainless steel fry pot, front, door & sides, casters, 105,000 BTU, cETLus, Made in North America (*Factory only item/Non‐stocking model)

CONVECTION OVEN, GAS

American Range Model No. MSD‐1‐GC Convection Oven, single‐deck, gas, standard depth, manual controls, temperature range 150° F ‐ 500° F, one hour timer, 2‐speed fan, (5) chrome racks with (12) rack positions per deck, porcelain liner, 50/50 solid doors, stainless steel front, sides, top and 28” legs, 22.0 kW, 75,000 BTU, cETLus, ETL‐Sanitation, Made in USA

RANGE, 36”, 6 OPEN BURNERS

American Range Model No. AR‐6 Heavy Duty Restaurant Range, gas, 36”, (6) 32,000 BTU open burners, 26‐1/2” standard oven, includes (1) rack, stainless steel front, sides & high shelf, 6” chrome plated legs, 67.0 kW, 227,000 BTU, ETLSanitation, NSF, Made in USA

GAS COUNTER TOP GRIDDLE

Asber Model No. AEMG‐24 H Griddle, natural gas, counter top, 24”W x 32‐1/4”D x 13”H, (2) 24,000 BTU burners, 3/4” thick polished steel griddle plate, manual controls, 4”D grease trough, 14 gauge stainless steel splash guard, pressure regulator, stainless steel front, sides & ledge, adjustable feet, 48,000 BTU, cETLus, (ships with LP conversion kit) Made in North America Veetsan Star Model No. 502350 (VDU30) Dishwasher, under counter, 30 racks/hour, hot water sanitizing with built‐in booster heater, 304 stainless steel frame, wash tank, booster tank & side panels, drain, detergent & rinse aid pumps, 208v/60/1 convertible to 3‐ph, 6.85 kW, 1 HP

PIZZA DOUGH SPINNER

Univex Model No. SPRIZZA40 Pizza Spinner, bench model, 15‐3/4” (40cm) ring with felt, adjustable pizza crust, automatic start/stop, cord and plug, 3/4 hp, .55 Kw, cETLus, ETL‐Sanitation

PLANETARY MIXER

Univex Model No. SRM60+PM Pizza Mixer, floor model, 60 quart capacity, #12 PTO Hub, 2 speed drive, includes removable 2 piece safety guard, stainless steel bowl, dough hook, power bowl lift, ingredient chute, and 15 minute timer, interlock switches, alloy gears, 3 hp, cETLus, NSF, Made in USA

Pizza Oven, Deck Style, Gas

American Range Model No. A600 Heavy Duty iron frame construction. All Stainless steel front & sides. • Counterweight door with concealed hinges. Heavy duty double bolted extruded aluminum door handle. Burner access panel provides easy access for initial ignition. 60” x 36” x 8.6” oven interior. • Aluminized steel oven and combustion chamber. Four Heavy duty cast iron burners, rated @ 25,000 BTU/ Ea. Removable fixed orifices on main and pilot burners. Main gas, thermostat & safety pilot valve fully within body in a covered yet ventilated and accessible panel. Air mixers with adjustable air shutters and locking STONEBAKE plus with Quick Heat Technology, with 1 ½” thick cooking
