motorised wheelchair “two-in-one system”
It is a ‘two-in-one system’, i.e. a motorised wheelchair that becomes a manual wheelchair if required by removing the motors. The motorised version has the same driving and safety performance as an electronic wheelchair. It is manoeuvred using a simple joystick.
By releasing the motorised body and reinserting the rear wheels, the wheelchair becomes manual again.
The motorised body also allows the batteries to be removed (thanks to a convenient lifting strap), thus reducing the weight of the individual components to be handled. In this way SMARTY can be loaded into the boot of the car or stored when not in use.
The electric version has great stability (due to its robust body, which stabilises the rear of the manual wheelchair), reliability, and motor power (useful for ascents and safe for descents - as it has an electromagnetic brake).
15 Km
autonomy
6 Km/h speed
8%
gra
die
nts
Equipped with 15 km of autonomy, it reaches a speed of 6 km/h and overcomes gradients of 8% even from a standing start. SMARTY is equipped with a system of lights and direction indicators for better outdoor use. It has a buzzer to signal its presence. Driving and these functions are controlled by a practical joystick (which can be positioned on the right or left).
The wheelchair is available in 4 seat widths: (40.5 - 43 - 45.5 and 48 cm) and two depths (40 and 45 cm) SMARTY is designed and manufactured in Italy.
TECHNICAL FEATURES DIMENSIONS Total width: smallest size 40.5 cm seat: 60.5 cm largest size 48 cm seat: 66 cm Total depth: smallest size 40.5 cm seat: 105 cm largest size 48 cm seat: 105 cm Weight: wheelchair: 13 kg body: 43 kg body without the two batteries: 25 kg total: 56 kg Batteries: 2 x 12V = 24 V; 24 AH, weight 9 kg each Motor power: 300 W Maximum load: 130 kg Maximum speed: 6 km/h
130 kg
maximum user weight
56 kg total weight
DESCRIPTION
ARTICLE CODE
Motorised wheelchair
SMARTY
motorised wheelchair “two-in-one system”
• How does the electromagnetic or parking brake work? From the direction of travel, releasing the joystick (with the joystick switched on) locks the wheelchair (both on a flat surface and on a slope).
FAQ
• Can I climb steps? Small steps proportionate to the size of the front wheel radius (approximately 4 cm). • How long does it take to recharge the batteries? Approximately 4 hours • What happens if I don’t use the wheelchair for too long? It is better to charge the batteries once a month or disconnect all connections. • How long do batteries last (life cycle)? Two years at full capacity then a normal decline follows. • How long is the warranty? The warranty is as required by law, 24 months. It is 6 months on the battery as it is a consumable item. ● Available as of 1 December 2022
