aquatix
by landscape structures
Make a lasting impression.
Kids and kids-at-heart transform into their most playful selves when encountering an Aquatix® splash pad or spray park. Our signature water play experiences are known for delivering the latest in thrills, spills and chills to people of all abilities and on splash pads of all sizes.
Whether they’re running through it, standing under it or jumping over it, kids enjoying innovative aqua play get more than a cool respite on a hot day. They come away with experiences that last a lifetime.
Now, more and more communities can enjoy the tactile joys of water play. The innovative technology that goes into our AquaSmart® Packages means they’re sized right for smaller pocket parks and compact areas. These self-contained packages are ready to install and operate with just a push of the button.
Discover how Aquatix water-based activities can help you make a lasting impression in your community. Choose from our wide range of exclusive color palettes or create your own. Then coordinate your splash pad with our SkyWays® Shade Products or a nearby playstructure from Landscape Structures® for a complete environment that elevates all types of play.
With nearly 40 years of experience, Aquatix is a forerunner in water feature and spray park design, fabrication and construction. But we pull out all the stops when it comes to developing novel aqua play designs that result in spontaneous yelps of delight, candid laughs and imaginative game play.
Hurley Park Splash Pad
Kiwanis International is a global organization of volunteers dedicated to changing the world one child and one community at a time. As a proud partner, Landscape Structures® helps Kiwanis International fulfill their mission by bringing splash play and playgrounds to communities across the globe.
Chisholm
Jumpstart Playground & Spray Pad at Glencairn Neighbourhood Recreation Centre
Regina, Saskatchewan, Canada
Canadian Tire Jumpstart Charities helps kids overcome financial and accessibility barriers to sport and recreation in an effort to provide inclusive play for kids of all abilities. Landscape Structures® is proud to be a partner of Jumpstart as they work towards creating a more inclusive Canada, where all kids can access sport and play.
Martin Luther King Junior Recreational Complex
AquaSmart® Packages are thrilling, self-contained splash pads that are sized right for smaller pocket parks, daycare facilities and compact urban areas. Add one adjacent to a playground or even alongside a larger splash pad for a low-volume option. Installing an AquaSmart Package is a perfect project for a community build. It’s not only easier but faster too.
Discover AquaSmart® Packages
These splash pad opportunities are powered by HydroLogix®. The proprietary technology behind HydroLogix is also what makes these innovative packages intriguingly affordable. HydroLogix eliminates the need for costly electrical installation and operates with just a push of the button. Now you can place one of these self-contained splash pads just about anywhere, especially when electrical service is prohibitive or unwanted. No power bills, no potential power failures. This low-flow, low-water option greatly reduces water consumption while still providing plenty of opportunities for splashtastic play. Because there’s no need for a mechanical room or large vault, you can devote all the available space to having fun.
Each AquaSmart Package has been thoughtfully designed, so you can simply choose your colors and let the fun begin. Additionally, each AquaSmart Package comes with the HydroLogix User Sign. Visitors will get easy-to-follow instructions for initiating water fun via the HydroLogix Activation Bollard.
Splash pads powered by HydroLogix put kids in control of the action. One push and the entire splash pad comes to life. When the water shuts off, kids turn it into part of the game as they race back to start the splashing all over again. More details on pages 144-145. To see our complete product offering, visit aquatix.playlsi.com. U.S. Patent number 11,027,208
Package A
Play is the name of the game in this design that features multiple ways to cool off while staying active.
Package consists of: 1 HydroLogix® System, Pre-engineered plumbing package, 1 RippleRun with Acrylic Medium Rung, 2 RocketStreams, 1 Tot WellSpring, 2 Arch Jets, 1 Curvy Jet Manifold, 2 Sea Crawlers
See project photos on page 29.
An oversized garden invites kids to splash their way through the colorful flora and fauna.
Package B
Package C
Pair imaginative hands-on water play activities with a range of splashy sprays to create fun for all ages.
See project photos on page 14.
Package D
Natural elements provide delightful water play and beauty to be enjoyed by all ages.
Package E
Water splashes and sprays from above and below for a thrilling water escapade.
of:
A subtle setting packs the fun with water spray action for water enthusiasts of all ages.
Crawlers,
Stream Jet Triangles
Package F
Package G
This sculptural design presents plenty of watery surprises as adventurers navigate their way through the cooling sprays.
Package consists of: 1 HydroLogix System, Pre-engineered
See project photos on page 32.
Package H
Kids can explore a geometric water maze that lets them decide how wet they want to get.
Package I
Make a splash with this package that delivers an abundance of water-filled excitement for everyone.
Art installation or splash pad? The choice is for passersby interested in cooling down with a fine mist.
Package J
Package K
Two HydroLogix® systems help double the fun for this inclusive splash pad design.
Package consists of: 2 HydroLogix Systems, Pre-engineered plumbing package, 1 CanopyBucket with Acrylic, 1 FloraSwirl, 1 Mini FlashFlood, 2 RocketStreams, 1 TotPack Bee, 1 TotPack Bunny, 1 WellSpring, 2 Funnel
1
The inclusion of two HydroLogix systems delivers big splashes from above and below to kids of all ages.
NEW Package L
Twists,
Mini Outward Spray Ring, 1 Mini Upward Spray Ring, 2 Rooster Sprays, 2 Stream Jets
Package L
Designing Aqua Play
Aquatix® continues to shape the future of aqua play, moving the experience well beyond a fun way to cool off. Kids are encouraged to play games, form friendships and experience water in a whole new way through the inclusive, sensory-rich nature of aqua play.
We fabricate with stainless steel, fiberglass, glass fiber reinforced concrete (GFRC) and plastic materials. Aquatix also designs and builds our own LED lighting effects. The result is beautifully designed structures that provide everyone with novel and engaging opportunities to interact with water at any time of the day.
Designing spray park zones doesn’t have to be confusing. We focus on the interactive, age-appropriate, inclusive and safe play value of water and structures for each age group.
AGE APPROPRIATE ZONES
GENTLE ACTIVITY ZONE INFANT/TODDLER
Learning to enjoy texture and water
Lower, delicate ground sprays
Lower structures with gentle water formations
Placement of features close to perimeter and dry zones ensure easy adult supervision and interaction
UNIVERSAL ZONE ALL AGES
Variety of structures for the whole family
Unique water formations pour, dump, spray, wiggle, launch and spin
Combines ground spray and structures for all ages
Centrally placed in splash pad and often a transition zone from Gentle activity to Dynamic
DYNAMIC ZONE 7+ YEARS
Continual excitement and interaction
High-volume, highly interactive spray features and Climb N Play structures
Combination of sprays and structures
Placement of features close to perimeter and dry zones ensure easy adult supervision and interaction
A.
B. StarDome Flow
SandDollar
C.
A. AquaBarrel Half
B. AquaRock Small
C. AquaRock Large
A. SeaPier
B. SeaPier with Pelican Flow
A. SeaTrunk
B. AquaLogs Flow
C. AquaFall
B.
A.
C.
Some products require longer lead times.
A. SeaCannon Flow rate
B. BeachedWreck Flow
C. SeaTreasure Flow rate
AquaHedra®
A. Nautilus1 Flow rate 10 GPM (37,85 LPM) PSI 4 Dimensions 6' 6" x 7'
B. Landing Pads Multiple sizes available.
B.
A.
Nautilus2
A. RocketShip
B. FlashFlood Flow
C. Mini FlashFlood
B.
A. B.
C.
A.
B. BucketTrio Flow
A.
A. Available without acrylic
B.
A.
B.
A. JetStream Flow rate
B. RocketStream Flow rate
Arrows show directions of movement.
A. WhirlPad B. WhirlPad Mushroom Flow rate
C. HydroSphere
SplashFlash
TopoFlow
PuzzlePath
AquaGather Station
• SplashFlash This inverted dome creates a pressurized flash-flood system. Whoosh!
• TopoFlow Kids use diverters to block and unblock channels, charting the topographic water flow.
• PuzzlePath Splash-pad-goers redirect the water to move it through a maze of their own making.
A. UniFlow
B. WaterWay
A.
WhirlFlex Single Ribs
Left and right tilt available.
Large
Medium
Small
A.
B. SplashArc
Available without acrylic
A.
A.
B.
with acrylic
Shown without acrylic
RippleRun Single Rungs
Shown
A. BloomBurst Set B. BloomBurst Rise Flow rate 10 GPM (37,85 LPM) PSI 8 Dimensions 10' 0" x 5' 3" (3,05 m x 1,61 m) Splash zone 15' 0" Dia. (4,57 m Dia.)
B.
A.
B. PalmSpring
A.
A.
B. DragonFlier
A. Available without acrylic
B.
B. Available without acrylic
A.
B. SprayVine
A. B.
A. SplashPack
B. SplashPack Whale
A. C.
A.
B.
C. SplashPack
A. SplashPack Swimming Hippo
B. SplashPack Bear
C. SplashPack Lion
C.
B.
HydraHub1
Flow rate 200 to 300 GPM (757,08 to 1135,62 LPM) Dimensions 19' 5" x 45' 9" x 59' 9" (5,92 m x 19,99 m x 18,26 m) Splash zone 72' 0" Dia. (21,94 m Dia.)
HydraHub2
Arrows show directions of movement.
B.
A. FloraSwirl
B. FloraSpout
B. A. Available without acrylic
A. Tot WellSpring
B. Acrylic Tot Shower Dome
A. TotPack Bee B. TotPack Bunny C. TotPack Dalmatian D. TotPack Ladybug E. TotPack Piglet F. TotPack Puppy G. TotPack Turtle
A.
B. Funnel Twist
D. Geyser
A. Water Jewel Flow rate 25 GPM (94,63 LPM) PSI
B. Junior Water Jewel Flow
A.
A.
A. Sea Crawler
B. Fan Spray
A. Crackle Corn
B. Ground Funnel
C. Triple Mist
A. B.
C.
A. Under Water Bubbler Flow rate 10 to 20 GPM (37,85 to 75,71 LPM) PSI 8 Dimensions Will vary with flow
Side Wall
B.
A. C.
A.
C. B.
Center Pillar Ring
B. Mini Upward Spray Ring Flow
Mini Outward Spray
(49,21
B. Arch Jet Manifold
A.
C.
B.
A. Curvy Jet Manifold
B. Stream Jet
C. Curvy Jewel Manifold
A.
C.
Cast
Stream Jet/Arch Jet Ultra Low Flow
Stream Jet/Arch Jet Low Flow
Stream Jet/Arch Jet High Flow
Aquatix® offers a variety of nozzles that can be interchanged within the same socket. Create fun effects with this industry-leading assortment of ground sprays.
See product details on pages 90-99
in the Concrete Socket
Triple Arch Jet
Winter Cap
Triple Arch Jet
Stream Jet
Arch Jet
Bubbler Ground Funnel Rooster Tail
Crown Jet
Junior Water Jewel
Sea Crawler
Funnel Twist Mini Pillar
Triple Mist
Lights. Water. Action.
LED Jumping Jets are mesmerizing interactive fountains featuring dancing water formations and LED light shows that thrill, drawing crowds and providing endless entertainment value.
Numerous water and nozzle effects can be combined with LED lights to showcase endless possibilities. Water movements can dance across a spectrum of colors, ranging from singular color effects to multi-colored shows that magically shift from hue to hue, creating unexpected moments that bring about plenty of oohs and ahhs.
Work with Aquatix® to design programmed displays sure to engage onlookers and inspire awe. Displays automatically shift from day to night for ease of use.
The opportunities are endless with LED Jumping Jets. Embellish your splash pad with nighttime light and entertainment. Or pair an LED light show with nonsequencing water effects. We can help you find a solution that’s fun to watch and explore while accommodating your budget and footprint.
Connect with our professional designers to begin creating your unique interactive fountain today.
Discover more than meets the eye. With LED Jumping Jets, water is a splash for all of your senses! We specialize in creating beautifully patterned light and water displays that are as mesmerizing as they are playful. LED Jumping Jets turn any space into an invitation for all.
LED Jumping Jets displays are designed to look and function beautifully for years to come. We use stainless steel construction for durability, coupled with energy-efficient, waterproof and safe LED lighting. Choose from 13 nozzle options to create different display effects. An inline solenoid valve allows for the creation of unique water displays and playful patterns.
Create the fun. Change the patterns, timing and light display with a user-friendly DMX control panel. Choose the system that suits your needs, from preset water sequencing with white lights to a fully programmable DMX colorful light and water display.
Features include:
• Easy front panel access
• NEMA 4 water-tight enclosure
• UL-listed
• Intuitive menu-driven splash pad touch pad (SPTP)
• Convenient adjustability
Sequencing not available for all nozzles.
See Ground Spray section for product details on pages 90-99.
Arch Jet, Bubbler, Crown Jet, Funnel Twist, Ground Funnel, Junior Water Jewel, Mini Pillar, Rooster Spray, Sea Crawler, Stream Jet, Triple Arch Jet, Triple Mist Nozzle.
Whether incorporated into a larger splash pad area or used as a standalone display in a small area, LED Jumping Jets offer beauty and interactive fun that everyone will love. We are dedicated to elevating your space with water that dances, jumps and pops in vivid LED color.
Accessories
Get creative with our assortment of splash pad accessories. From vibrant lighting and custom signage to stylish shade solutions and site furnishings, we offer everything you need to design your perfect splash environment.
Illuminate Your Splash Pad With Accent Lights
Accent Lights from Aquatix® can be installed under or around splash pad products to illuminate the area. With Accent Lights, splash pads can stay open later, offering a safe and well-lit environment for families and friends to enjoy. This affordable accessory enhances the visual appeal of your splash pad, without breaking the budget.
See pages 18-19 for project photos.
A. Water Bucket Brigade Flow rate 40 to 80 GPM (151,42 to 302,83 LPM) PSI 6 Dimensions 14' 0" x 8' 0" (4,27 m x 2,44 m) Splash zone 30' 0" Dia. (9,14 m Dia.)
B. Water Bucket Flow rate 10 to 20 GPM (37,85 to 75,71 LPM) PSI 6 Dimensions 13' 0" x 4' 0" (3,96 m x 1,22 m) Splash zone 10' 0" x 15' 0" (3,05 m x 4,57 m)
C. Water Bucket Cluster Flow rate 45 to 60 GPM (170,34 to 227,12 LPM) PSI 6 Dimensions 14' 0" x 8' 0" (4,27 m x 2,44 m) Splash zone 25' 0" Dia. (7,62 m Dia.)
A.
B.
C.
A. Shower Water Dome Flow rate 10 to 25 GPM (37,85 to 94,63 LPM) PSI 10 Dimensions 9' 6" x 5' 6" (2,92 m x 1,71 m) Splash zone 15' 0" Dia. (6,09 m Dia.)
B. Mini Water Dome Flow rate 150 to 300 GPM (567,80 to 1135,60 LPM) PSI 4 Dimensions 9' 6" x 5' 6" (2,93 m x 1,71 m) Splash zone 20' 0" Dia. (6,10 m Dia.)
C. Water Dome Flow rate 200 to 400 GPM (757,08 to 1514,16 LPM) PSI 4 Dimensions 9' 6" x 7' 0" (2,93 m x 2,13 m) Splash zone 25' 0" Dia. (7,62 m Dia.)
A.
B.
C.
Water Cup Flow rate 200 to 400 GPM (757,08 to 1514,16 LPM) PSI 5 Dimensions 10' 6" x 7' 0" (3,23 m x 2,13 m) Splash zone 25' 0" Dia. (7,62 m Dia.)
Water Bars Flow rate 25 to 220 GPM (94,36 to 832,79 LPM) PSI 5 Dimensions 9' 0" x 5' 6" (2,74 m x 1,70 m) Splash zone 15' 0" x 10' 0" (4,57 m x 3,05 m)
A.
B.
A.
B.
A. Water Spout Flow rate 5 to 20 GPM (18,92 to 75,71 LPM) PSI 6 Dimensions 9' 0" x 0' 6" (2,74 m x 0,15 m) Splash zone 8' 0" x 10' 0" (2,44 m x 3,05 m)
B. Pipe Water Bar Flow rate 25 to 220 GPM (94,63 to 832,79 LPM) PSI 5 Dimensions 9' 0" x 6' 0" (2,74 m x 1,83 m) Splash zone 15' 0" x 10' 0" (4,57 m x 3,05 m)
C. Water Arch Bar Flow rate 25 to 220 GPM (94,63 to 832,79 LPM) PSI 5 Dimensions 4' 0" x 6' 0" (1,22 m x 1,83 m) Splash zone 10' 0" x 10' 0" (3,05 m x 3,05 m)
D. Water Post Flow rate 10 to 60 GPM (37,85 to 227,12 LPM) PSI 4 Dimensions 4' 0" x 0' 6" (1,22 m x 0,15 m) Splash zone 10' 0" Dia. (3,05 m Dia.)
A.
D.
Water Shower Flow rate 5 to 20 GPM (18,92 to 75,71 LPM) PSI 6 Dimensions 9' 0" x 0' 6" (2,74 m x 0,15 m) Splash zone 15' 0" Dia. (4,57 m Dia.)
Water Tent Flow rate 15 to 30 GPM (56,78 to 113,56 LPM) PSI 4 Dimensions 4' 0" x 0' 6" (1,22 m x 0,15 m) Splash zone 10' 0" Dia. (3,05 m Dia.)
Water Fire Nozzle Flow rate 10 to 15 GPM (37,85 to 56,78 LPM) PSI 10 Dimensions 3' 0" x 0' 6" (0,91 m x 0,15 m) Splash zone 15' 0" Radius (4,57 m Radius)
Arrows show directions of movement.
C.
B.
A.
B.
C.
Water Globe Flow rate 15 GPM (56,78 LPM) PSI 2 Dimensions 2' 6" Dia. (0,79 m Dia.) Splash zone 6' 0" Dia. (0,79 m Dia.)
(18,93
A.
B.
C.
D.
C.
A. Multi-Play Canopy
Flow rate 200 to 600 GPM (757,08 to 2271,25 LPM) Dimensions 17' 0" x 14' 0" x 15' 0" (5,18 m x 4,27 m x 4,57 m) Splash zone 25' 0" x 25' 0" (7,62 m x 7,62 m)
B. Multi-Play III: Water Bars
Flow rate 50 to 350 GPM (189,27 to 1324,89 LPM) Dimensions 14' 0" x 5' 1" x 11' 1" (4,27 m x 1,55 m x 3,38 m) Splash zone 30' 0" x 15' 0" (9,14 m x 4,57 m)
C. Multi-Play Tubular
Flow rate 200 to 600 GPM (757,08 to 2271,25 LPM) Dimensions 14' 0" x 5' 0" x 26' 0" (4,27 m x 1,52 m x 7,92 m) Splash zone 40' 0" x 15' 0" (12,19 m x 4,57 m)
All dimensions are height x width x length. All Multi-Play data is approximate and subject to change.
C.
A.
Flow rate 150 to 600 GPM (567,81 to 2271,24 LPM) Dimensions 14' 0" x 12' 0" x 15' 5" (4,27 m x 3,66 m x 4,72 m) Splash zone 30' 0" x 25' 0" (9,14 m x 7,62 m)
Flow rate 400 to 800 GPM (1514,16 to 3028,33 LPM) Dimensions 17' 5" x 20' 6" x 35' 0" (5,33 m x 6,78 m x 10,66 m) Splash zone 30' 0" x 45' 0" (9,14 m x 13,71 m)
Flow rate 150 to 600 GPM (567,81 to 2271,24 LPM) Dimensions 17' 0" x 12' 0" x 15' 5" (5,18 m x 3,66 m x 4,72 m) Splash zone 30' 0" x 25' 0" (9,14 m x 7,62 m)
A. Junior Climb N Slide
B. Multi-Level Climb N Slide
C. Junior Canopy Climb N Slide
A. Tot Arch Bar Flow rate 10 GPM (37,85 LPM) PSI 3 Dimensions 2' 6" x 0' 3" x 3' 9" (0,79 m x 0,07 m x 1,19 m) Splash zone 6' 0" x 6' 0" (1,83 m x 1,83 m)
B. Tot Rotating Water Ball Flow rate 5 GPM (18,93 LPM) PSI 5 Dimensions 2' 1" x 1' 0" (0,64 m x 0,30 m) Splash zone 10' 0" Dia. (3,05 m Dia.)
Tot Arch Flow rate 10 GPM (37,85 LPM) PSI 3 Dimensions 2' 8" x 5' 0" (0,18 m x 1,52 m) Splash zone 6' 0" x 6' 0" (1,83 m x 1,83 m)
show directions of movement.
C.
A. Arrows
B.
C.
Tot Ground Spray Covers A. Shapes
Numbers
Colors D. Designs
B.
C.
D.
Boulder NEW LOOK Flow rate 5 to 10 GPM (18,93 to 37,85 LPM) PSI 3 Dimensions 2' 9" x 2' 1" (0,88 m x 0,64 m) Splash zone 10' 0" Dia. (3,05 m Dia.)
NEW LOOK Flow rate 5 to 10 GPM (18,93 to 37,85 LPM) PSI 4 Dimensions 6' 6" x 1' 8" (1,98 m x 0,55 m) Splash zone 10' 0" Dia. (3,05 m Dia.)
NEW LOOK Flow rate 15 to 30 GPM (56,78 to 113,56 LPM) PSI 5 Dimensions 6' 6" x 5' 4" x 5' 4" (1,98 m x 1,64 m x 1,64 m) Splash zone 20' 0" Dia. (6,09 m Dia.)
A. Stone
B. Stone Pillar
C. Stone Cluster
A.
B.
C.
Banana Bucket Tree Flow rate 45 to 60 GPM (170,34 to 227,12 LPM) PSI 6 Dimensions 14' 6" x 8' 0" (4,27 m x 2,44 m) Splash zone 25' 0" Dia. (7,62 m Dia.)
Tree
Flow rate 5 to 20 GPM (18,93 to 75,71 LPM) PSI 6 Dimensions 10' 0" x 6' 5" (3,05 m x 1,98 m) Splash zone 15' 0" Dia. (4,57 m Dia.)
Flow rate 15 to 70 GPM (56,78 to 264,98 LPM) PSI 7 Dimensions 15' 0" x 6' 6" (4,57 m x 2,01 m) Splash zone 20' 0" Dia. (6,09 m Dia.)
II Flow rate 15 to 30 GPM (56,78 to 113,56 LPM) PSI 7 Dimensions 14' 1" x 10' 1" (4,29 m x 3,08 m) Splash zone 25' 0" x 25' 0" (7,62 m x 7,62 m)
A.
B. Pine
Shower
C. Tall Pine Bucket Shower
D. Creativi-Trees
A.
Palm Flow rate 10 GPM (37,85 LPM) PSI 15 Dimensions 9' 6" x 5' 5" (2,93 m x 1,67 m) Splash zone 15' 0" Dia. (4,57 m Dia.)
A. Misting
B. Reeds Flow rate
GPM
PSI
C. Cat Tail Spray Flow rate 5 to 10 GPM (18,93 to 37,85 LPM) PSI 5 Dimensions 10'
A. B. C.
Water Fire Hydrant Flow rate 15 to 20 GPM (56,78 to 75,71 LPM) PSI 3 Dimensions 2' 6" x 1' 0" (0,79 m x 0,30 m) Splash zone 10' 0" Dia. (3,05 m Dia.)
Silo Shower Flow rate 10 to 15 GPM (37,85 to 56,78 LPM) PSI 10 Dimensions 9' 7" x 4' 9" (2,95 m x 1,50 m) Splash zone 14' 0" Dia. (4,27 m Dia.)
Water Tower Flow rate 25 to 50 GPM (94,63 to 189,27 LPM) PSI 7 Dimensions 16' 6" x 7' 7" x 4' 4" (5,06 m x 2,35 m x 1,34 m) Splash zone 25' 0" Dia. (7,62 m Dia.)
Water Wind Mill Flow rate 15 to 25 GPM (56,78 to 94,63 LPM) PSI 7 Dimensions 14' 0" x 5' 11" (4,27 m x 1,56 m) Splash zone 15' 0" x 12' 0" (4,57 m x 3,66 m)
A.
B.
C.
D.
m x 2,13 m)
200 to 400 GPM (757,08 to 1,514 LPM) PSI 4 Dimensions 9' 6" x 7' 0" (2,93 m x 2,13 m)
5 to 10 GPM (18,93 to 37,85 LPM) PSI 3 Dimensions 4' 0" x 2' 0" (1,22 m x 0,61 m)
zone 25' 0" Dia. (7,62 m Dia.)
zone 8' 0" Dia. (2,44 m Dia.)
A. Turtle Dome Flow rate 200 to 400 GPM (757,08 to 1,514 LPM) PSI 4 Dimensions 9' 6" x 7' 0" (2,93
Splash zone 25' 0" Dia. (7,62 m Dia.)
B. Mushroom Dome Flow rate
Splash
C. Tot Mushroom Dome Flow rate
Splash
A.
B. C.
Water Dragon Flow rate 5 to 10 GPM (18,93 to 37,85 LPM) PSI 6 Dimensions 11' 0" x 0' 6" (3,35 m x 0,15 m) Splash zone 10' 0" x 0' 8" (3,05 m x 2,44 m)
Timmy the Tiger Flow rate 5 GPM (18,93 LPM) PSI 4 Dimensions 3' 0" x 0' 12" (0,91 m x 0,30 m) Splash zone 15' 0" Radius (4,57 m Radius)
Bobby the Bear Flow rate 5 GPM (18,93 LPM) PSI 4 Dimensions 3' 0" x 0' 12" (0,91 m x 0,30 m) Splash zone 15' 0" Radius (4,57 m Radius)
Snake Water Noodle Flow rate 5 to 10 GPM (18,93 to 37,85 LPM) PSI 5 Dimensions 10' 0" x 0' 2" (3,05 m x 0,06 m) Splash zone 10' 0" Dia. (3,05 m Dia.)
A.
B.
C.
D.
A.
B.
C.
D.
Aim N Spray Sports Balls Flow rate 5 GPM (18,93 LPM) PSI 4 Dimensions 3' 0" x 0' 12" (0,91 m x 0,30 m) Splash zone 15' 0" Radius (4,57 m Radius)
Sport Globe Flow rate 15 GPM (56,78 LPM) PSI 4 Dimensions 2' 6" Dia. (0,79 m Dia.) Splash zone 10' 0" Dia. (3,05 m Dia.)
Sport Water Shower Flow rate 5 to 20 GPM (18,93 to 75,71 LPM) PSI 6 Dimensions 9' 0" x 0' 12" (2,74 m x 0,30 m) Splash zone 15' 0" Dia. (4,57 m Dia.)
Bat & Ball Shower Flow rate 6 GPM (22,71 LPM) PSI 7 Dimensions 10' 0" x 1' 7" (3,05 m x 0,52 m) Splash zone 15' 0" Dia. (4,57 m Dia.)
A.
B.
C.
D.
A. Sport Shower Dome Flow rate 5 to 20 GPM (18,93 to 75,71 LPM) PSI 5 Dimensions 9' 6" x 5' 6" (2,92 m x 2,13 m) Splash zone 15' 0" Dia. (4,57 m Dia.)
B. Sport Rotating Water Ball Flow rate 15 GPM (56,78 LPM) PSI 5 Dimensions 9' 0" x 1' 7" (2,74 m x 0,52 m) Splash zone 20' 0" Dia. (6,10 m Dia.)
C. Spraying Sport Sphere Flow rate 10 to 15 GPM (37,85 to 56,78 LPM) PSI 3 Dimensions 1' 0" x 2' 0 (0,30 m x 0,61 m) Splash zone 8' 0" Dia. (2,44 m Dia.)
D. Spraying Sport Football Flow rate 6 GPM (22,71 LPM) PSI 3 Dimensions 0' 10" x 1' 6" x 2' 6" (0,25 m x 0,49 m x 0,79 m) Splash zone 10' 0" x 10' 0" (3,05 m x 3,05 m)
E. Spraying Puck Flow rate 7 GPM (26,49 LPM) PSI 5 Dimensions 0' 9" x 2' 4" (0,27 m x 0,73 m) Splash zone 8' 0" Dia. (2,44 m Dia.)
Pirate Flow rate 5 GPM (18,93 LPM) PSI 4 Dimensions 3' 0" x 0' 12" (0,91 m x 0,30 m) Splash zone 15' 0" Radius (4,57 m Radius)
Flow rate 5 GPM (18,93 LPM) PSI 4 Dimensions 3' 0" x 0' 12" (0,91 m x 0,30 m) Splash zone 15' 0" Radius (4,57 m Radius)
rate 5 GPM (18,93 LPM) PSI 4 Dimensions 3' 8" x 1' 8" (1,16 m x 0,55 m) Splash zone 15' 0" Radius (4,57 m
20 to 40 GPM (75,71 to 151,42 LPM) PSI 15 Dimensions 11' 0" x 8' 8" (3,35 m x 2,64 m) Splash zone 15' 0" x 12' 0" (4,57 m x 3,66 m)
A. Aim N Spray
B. Aim N Spray Bobber
C. Water Cannon Flow
Radius)
D. Mini Mast Flow rate
A.
B.
C.
D.
Slide Flow rate 5 to 10 GPM (18,93 to 37,85 LPM) PSI 1 Dimensions 6' 0" x 8' 0" (1,83 m x 2,44 m) Splash zone 16' 0" x 7' 0" (4,88 m x 2,13 m)
Flow rate 5 to 10 GPM (18,93 to 37,85 LPM) PSI 1 Dimensions 4' 2" x 11' 6" (1,28 m x 3,53 m) Splash zone 19' 0" x 9' 0" (5,79 m x 2,74 m)
Slide Flow rate 5 to 10 GPM (18,93 to 37,85 LPM) PSI 1 Dimensions 4' 4" x 10' 0" (1,32 m x 3,05 m) Splash zone 19' 0" x 7' 0" (5,79 m x 2,13 m)
A. 3D Duck
B. 3D Turtle Slide
C. 3D Rock
A. B.
C.
Custom Themes
Deliver a taste of Americana to your community with a patriotic-themed spray play environment. Or imagine creating a nature-inspired splash pad with friendly bears or embracing local folklore by making Sasquatch the star attraction! With Aquatix®, every splash becomes an imaginative adventure. Share your vision with us, and we’ll bring it to life with a custom theme that sets your splash pad apart and transforms aqua play into an unforgettable experience.
Mechanical Systems
Our mechanical systems are available in multiple formats—Recirculation Systems, Recirculation System Powered by MecH2O™, Conventional Domestic System and Domestic System Powered by HydroLogix® . We can help you choose the right option to match your project requirements and budget.
RECIRCULATION SYSTEM
Use a recirculation system to create a safe and fun splash pad without water consumption limits. Our industry-leading water quality treatment systems save millions of gallons of water annually, are easy to operate, and meet or exceed local health department regulations. Using our skid-mounted system, you can provide your own mechanical room or we can offer prefabricated enclosures for you.
Electrical/control wiring
Fresh water supply
Feature water system
Waste lines
Collection drain-line
1. Activation bollard
Touch-post activator
2. Ground spray
Flush spray feature with nozzle effects
3. Collector box
Dual port main drain collects splash pad water to return to tank
4. Drain-to-waste valve box
Solenoid valve diverts rainwater to waste
5. Drain-line to waste
Carries wastewater to sanitary or storm system
6. Aqua playstructures
Above-grade spray feature with various water activities
7. Underground water reservoir tank
Pre-fabricated and pre-plumbed with water level control, inlet loop, floating skimmer and submersible pump-out system
8. Lockable man-way with ladder access Easy access for servicing water reservoir tank
9. Distribution manifold Pre-plumbed and pre-fabricated with winterization blow-out port
10. Manual valves
Manually control each spray feature’s height and distance
11. Feature-pump skid Pre-fabricated and pre-plumbed with leveling legs
12. Filtration skid and automated chemical controller Prefabricated and pre-plumbed
13. Sand or cartridge filter Available with sand media or cartridges
14. System control panel
UL-listed controls for total system and feature operation, including hours of operation, duration, events sequencing and on/off controls
15. Main power supply
Typically 230 V, 1 phase 60 HZ and 112/120 V, 1 phase 60 HZ
16. Chemical treatment
Liquid chlorine and pH-adjustment reservoir and pump
17. Water-fill supply
Municipal water supply with pressure regulator (20 to 30 psi) and back-flow preventer (typically 1")
Optional equipment: UV treatment, Above-ground enclosure, Debris Chamber
Environmentally Friendly
A. Activation bollard
Low-voltage sensor located within the bollard cap activates water flow when cap is pressed. Turn on/ off entire splash pad features or designated zoned areas.
Also available flush-mount step activator.
B. Control panels
Control simple on/ off aqua play activities or add Programmable Logic Controller (PLC) to create splash pad zoning or sequenced activities, or LED light shows.
C. Water distribution manifold
Pre-plumbed water delivery system transfers water from feature pumpingsystem to aqua play features. Manual control valves regulate water flow to each water element. Upgrade with electric valves or solenoid valves for creating aqua play zones or when sequencing aqua play activities.
D. Filtration system
30-minute (minimum) flow turnover rate. Preplumbed with allschedule 80 PVC pipe and fittings, pre-wired and mounted on a powder coated steel skid with adjustable leveling legs. Main motor control panel can be mounted to filtration skid.
E. Chemical treatment
To consist of an automated chemical controller, liquid chlorine and acid tanks with metering pumps.
F. Water reservoir tank
Pre-cast concrete tank (5,000 psi meets ASTM C-913 and C-1227) with lockable access hatch, service ladder and required plumbing connection. Tank is sized to meet project requirements.
G. Ultra-violet disinfection
Secondary sanitization for recirculation system. UV system can be installed in filtration or feature pumping-system.
H. Above-ground enclosure
Safe, lockable enclosure that is directly mounted to a concrete support pad next to water play area.
A.
B.
C.
D.
G.
E.
F.
H.
MecH2O™ SYSTEM
Discover unparalleled simplicity and reliability with the patent pending MecH2O (pronounced mec-two-oh) water recirculation system. Engineered to redefine the standards of splash pad installation and maintenance, this innovative solution offers unmatched ease of use, ensuring lasting peace of mind. The pioneering technology of MecH2O includes a fully pre-fabricated mechanical system, mounted on top of a pre-fabricated concrete water tank all within a compact footprint.
See pages 34-35 for an installed project.
Electrical/control wiring
Fresh water supply
Feature water system
Waste lines
Collection drain-line
1. Activation bollard
Touch-post activator
2. Ground spray
Flush spray feature with nozzle effects
3. Collector box
Dual port main drain collects splash pad water to return to tank
Above grade spray feature with various water activities
7. MecH2O System
Underground Water Reservoir Tank To be pre–fabricated and pre–plumbed with water level control, inlet loop, floating skimmer and submersible pump-out system
Lockable Man-way with Ladder Access
Easy access for servicing water reservoir tank
Distribution Manifold Pre–plumbed, pre–fabricated with winterization blow–out port
Manual Valves Manually control each spray feature’s spray height and distance
Feature Pump To consist of a self priming feature pump with integral hair and link strainer
Filtration Pump Available with sand media or cartridges
System Control Panel
UL-listed controls for total system and feature operation, including hours of operation, duration, events sequencing and on/off controls
Main Power Supply
Typically 230 V 1PH /100A
Chemical Treatment
Automatic chemical controller with liquid chlorine and pH-adjustment reservoir and pump
Water Fill Supply Municipal water supply with pressure regulator (20 to 30 psi) and back–flow preventer (typically 1”)
Sanitary Waste Connection
Municipal sanitary waste line with required air gap
4. Drain-to-waste valve box
Solenoid valve diverts rainwater to waste 5. Drain-line to waste
Carries wastewater to sanitary or storm system 6. Aqua playstructures
Water Fill Supply
Sanitary Drain
A. Activation bollard
Low-voltage sensor located within the bollard cap activates water flow when cap is pressed. Turn on/off entire splash pad features or designated zoned areas. Also available flush-mount step activator.
B. Underground water reservoir tank To be pre–fabricated and pre–plumbed with water level control, inlet loop, floating skimmer and submersible pump-out system. Lockable man-way with ladder access that provides easy access for maintenance of water reservoir tank.
C. Pre-fabricated mechanical system MecH2O includes a fully pre-fabricated mechanical system, mounted on top of a pre-fabricated concrete water tank all within an 8' 6" x 20' footprint. Because MecH2O is prefabricated by Aquatix® and goes through rigorous testing prior to shipping, we can ensure that quality and functionality standards are optimal.
D. System control panel
UL-listed control panel for total system controls and feature operation controls including operational hours, duration of time, sequencing of events and on/off controls.
E. Maintenance and safety components
Enclosure is outfitted with ventilation system, eye wash station, interior lighting, electrical outlets, switches and hose bibbs. Overhead I-beam and trolley, compliant to OSHA Confined Space tie-off requirements, assists with movement of heavy materials within enclosure.
A.
B.
C.
E.
D.
Eye wash station
Overhead I-beam Winterization hub
CONVENTIONAL DOMESTIC SINGLE-PASS SYSTEM
Design a cost-effective splash pad when water consumption is unregulated using a domestic single-pass system. Ideal for limited use and/or minimum water consumption, you can also reclaim water by routing to a retention pond and reuse for irrigation. Choose from above-ground enclosures or below-grade vaults.
Electrical/control wiring
Fresh water supply
Feature water system
Waste lines
1. Activation bollard
Touch-post activator
2. Ground spray
Flush spray feature with nozzle effects
3. Drain-to-waste box
Carries splash pad water to wastewater
4. Aqua playstructures
Above-grade spray feature with various water activities
5. Drain-line to waste Carries wastewater to sanitary or storm system or retention pond
6. Distribution manifold Pre-plumbed and pre-fabricated with winterization blow-out port
7 Solenoid valves
Optional on each feature for sequencing of events
8. Manual valves
Manually control each spray feature’s height and distance
9. Main solenoid valve On/off control for splash pad main water supply
10. System control panel UL-listed controls for total system and feature operation, including hours of operation, duration, events sequencing and on/off controls
11. Main power supply Typically 120 V, Single Phase, 60 Hz power feed
12. Main water supply Municipal water supply with pressure regulator (20 to 30 psi) and back-flow preventer
Optional equipment:
Above- or below-grade equipment enclosures and water re-purpose reservoir
A. Activation bollard
Low-voltage sensor located within the bollard cap activates water flow when cap is pressed. Turn on/ off entire splash pad features or designated zoned areas. Also available flush-mount step activator.
B. Control panels
Control simple on/off aqua play activities or add Programmable Logic Controller (PLC) to create splash pad zoning or sequenced activities.
C. Water distribution manifold
Pre-plumbed water delivery system transfers water from main water supply to aqua play features. Manual control valves regulate water flow to each water element. Upgrade with solenoid valves for creating aqua play zones or when sequencing aqua play activities.
D. City water system equipment vault
Safe, lockable fiberglass enclosure is pre-fabricated with all mechanical components for easy installation and service.
E. Equipment enclosure
Safe, lockable enclosure is mounted directly to a concrete support pad next to aqua play area.
F. Drain-to-waste outlet
Directs water from the sloped splash pad to sanitary, storm or retention pond. Drain contains removable strainer basket.
A.
B.
C.
DOMESTIC SYSTEM POWERED BY HYDROLOGIX®
The patented HydroLogix® system is a non-electrical water delivery system you can use to power many of your favorite splash pad designs. This entire system is fabricated from durable stainless steel materials that are vandal and corrosion resistant. Ideal water pressure is 30 to 40 psi which will deliver 60 gallons per minute to aqua playstructures and ground sprays.
Get creative with your design and use two HydroLogix systems side by side!
See pages 20-21 for an installed project.
See our AquaSmart® Packages, powered by the HydroLogix system, which includes our pre-engineered plumbing system, on pages 38-51.
Fresh water supply Feature water system Waste lines
1. Activation bollard Touch-post activator 2. Ground spray
Flush spray feature with nozzle effects 3. HydroLogix hub Provides drainage for splash pad and distribution manifold with manual valves for supply lines
Aqua playstructures
Above-grade spray feature with various water activities
Drain-line to waste Carries 4" wastewater to sanitary or storm system
Main water supply Municipal 2" water supply with pressure regulator (30 to 40 psi) and back-flow preventer
On/Off timer
Battery operated 2" solenoid valve with programmable time clock to set hours of operation. Can be located above ground at backflow preventer or below ground in irrigation valve box.
A. Activation bollard
Push button activates water flow when button is pressed. Turns on entire splash pad.
B. Drain-to-waste outlet
Directs water from the sloped splash pad to storm sewer or retention pond or tank.
C. Water distribution manifold Manual control valves regulate water flow to each water element.
D. Installation example AquaSmart Package with pre-engineered plumbing system.
A.
B.
C.
D.
You can count on the experienced Aquatix® design and engineering professionals to help you meet your project requirements—from initial creative concepts to complete engineered drawings, including insightful opportunities for inclusive play.
If you would like to learn firsthand about best practices in Inclusive Spray Park Design, sign up for one of our IACET, LACES or AIA accredited continuing education programs at aquatix.playlsi.com.
A. CONCEPT AND BUDGET ANALYSIS
We can help you evaluate value, costs and available funding. Our cost estimate package includes 3D rendered concepts, age-appropriate products, mechanical systems and pricing.
B. SCHEMATIC 2D DRAWINGS
Schematic 2D drawings and specifications provide fundamental concepts for design/build projects, allowing owners to gather installation budgets with the use of Aquatix products.
C. CONSTRUCTION DOCUMENT
After the concept and budget are approved, you’ll need technical drawings for permits, bids and construction. Our construction document package includes complete written specifications, splash pad construction details, mechanical and electrical system design, and all product and material installation detailing. Professional engineering stamp is provided as required
A.
B.
C.
The team at Aquatix has helped communities across the world design and construct interactive aqua play environments. In addition to our global network of aqua play experts to guide you from concepting through completion, our experienced field supervisors can assist you with pre-construction consultation, technical support, maintenance and start-up, and training. Even more, we provide an installer endorsement program to assist your installer in becoming a proficient and reliable partner in splash pad installation. Please email us at aquatixsupport@playsi.com to learn more.
Choose from a variety of brilliant color options for each individual part of an Aquatix® structure to create your own bright and colorful aqua play environment.
PAINT COLOR OPTIONS
Our multi-step polyurethane finishing system is specifically designed to help prevent wear and fading caused by chemically treated water and UV rays. Aquatix can provide complimentary touch-up paint to be used onsite for continued perfection.
PALETTES—PAINT AND ACRYLIC MATERIALS
CUSTOM PAINTING
Custom color matching is available. Establish a unique color scheme or reinforce a unified look with other Aquatix equipment and surrounding site amenities.
Palette 6
Palette 7
Palette 8
Palette 9
Tangerine Orange Cranberry Red Maroon
SOLID PANEL COLOR OPTIONS
At .50", our versatile, environmentally stabilized solid panels are made with high-impact-resistant polymer.
TWO-TONE PANEL COLOR OPTIONS
Two-tone panels offer contrasting colors and are ideal for engraving. At .50" and .75", our versatile, environmentally stabilized solid panels are made with high-impact-resistant polymer.
ACRYLIC PANEL COLOR OPTIONS
High-quality, lightweight, chemicalresistant acrylic panels have excellent outdoor stability. Ideally suited for a wide range of applications: panel attachments, theming, flowers, wings and much more.
Red
Blue Yellow Orange Green
You have our word
More than just a contract, our warranty is our personal commitment that you’ll be satisfied with your purchase now and well into the future. As an employee-owned company, we take great pride in the quality of everything we make. And we’re so confident that you’ll be delighted with your purchase that we back our products with the most comprehensive long-term warranties in the industry. It’s just one more way that we show how much we care about our customers and communities.
• 25-Year Limited Warranty All stainless steel and fiberglass structures against defects in workmanship and materials.
• 5-Year Limited Warranty All brass and stainless steel components, including spray nozzles, spray caps and spray heads. Landing pad material against defects in workmanship and materials. Glass Fiber Reinforced Concrete (GFRC) structures or GFRC exterior defects—exclusion includes scale buildup, efflorescence, hairline cracks (defined by anything wider than a nickel in width) and spalling, flaking or wear and tear to paint coat due to traffic locations.
• 3-Year Limited Warranty All belting material
• 2-Year Limited Warranty All moving parts, finishes, hardware, polyurethane collars, acrylic and plastic panel attachments. HydroLogix® System components against defects in workmanship and materials. Does not cover any clouding of paint/clear coat due to improper chemicals, pool additives or pool cleaning products. High pressure power washing is NOT recommended on GFRC components.
• 1-Year Limited Warranty All mechanical system components against defects in workmanship and materials. Landing pad installation. All LED/Jumping Jet Can internal components and Accent Lights. All MecH2O™ recirculation system components and enclosure plus standard component warranty applies.
The environment near a saltwater coast can be extremely corrosive. Some corrosion and/or deterioration is considered “normal wear” in this environment. Product installed within 500 yards (457 meters) of a saltwater shoreline will only be covered for half the period of the standard product warranty, up to a maximum of five years, for defects caused by corrosion. Products installed in direct contact with saltwater or that are subjected to salt spray are not covered by the standard warranty for any defects caused by corrosion.
For our full warranty, contact your local Aquatix® consultant.
The contracts to assist you
Aquatix is proud to have been awarded several national purchasing contracts. These contracts are nationally available, competitively bid, government-to-government procurement services. Through these contracts, Aquatix offers the best pricing on all of our quality products while satisfying your bid law requirements.
by landscape structures
1101 McKinley Parkway Delano, MN 55328-8605
888.438.6574
763.972.5200
aquatix.playlsi.com
With nearly 40 years of experience, Aquatix® is a leader in water feature and spray park design, fabrication and construction. With pioneering integrated mechanical systems, the company provides a sustainable solution that empowers hours of innovative activity without water consumption limits. Aquatix applies Landscape Structures’ groundbreaking design to the creation of imaginative new water experiences.
