Doweling Jig

903-706

SELF-CENTERING DOWEL JIGS

• Anodized aluminum bodies with hardened steel guides.903-706 and 940-344 have 1/4", 5/16", 3/8", 7/16", and 1/2" permanent holes. • 903-713 has two tapped holes for supplied bushings to let you drill 3 sizes of holes on 3/4" centers in one setting (1/4", 5/16", 3/8") plus 7/16" and 1/2" permanent holes. • 940-344 handles materials from 3/8" to 6" thick. • Extra wide viewing hole and distinctive marks make it easy to line up for perfect results. • Use a spacer block on one side to drill holes offset from center if needed. • 903-706 and 903-713 accept up to 2-5/16" wide stock. • USA.

Self-centering dowel jig 6" self-centering dowel jig Self-center dowel jig w/bushings 3 pack 1/4" replacement bushings 3 pack 5/16" replacement bushings 3 pack 3/8" replacement bushings

$68.99 $87.99 $79.99 $12.89 $12.89 $12.89

SELF-CENTERING DOWL-IT® JIGS

Quick and accurate.Handle stock up to 2" thick.Hardened steel guides for 1/4", 5/16", 3/8", 7/16" and 1/2" drills. Improved Dowl-it®has 7/16", 1/2" 120-001 single guide holes and 2 threaded insert guild holes 1-1/4? on center with 2/ea 1/4?, 5/16" & 3/8? bushings.Drill two holes with 1 setting and get consistent spacing between holes.Extra 1/4", 2000-N and 5/16", 2000-P bushing sleeves available.USA.

120-001 120-002

Dowl-it® Improved Dowl-it®

Edge-to-edge doweling

Miter-joint doweling

HARDENED STEEL DRILL BUSHINGS IN ELEVEN SIZES

ADD DURABILITY AND PRECISION TO SHOP-BUILT JIGS

Make your own custom drilling fixtures using these durable, hardened steel drill bushings:Hardened to RC 50. Special knurled surface lets them hold in wood fixtures.Install with a soft mallet.Chamfered edges protect drill bits. USA.

ID x OD x Length.

1/8" x 3/8" x 1/2" 821-869 3/16" x 3/8" x 1/2"

821-876

1/4" x 1/2" x 1/2" 821-883 5/16" x 1/2" x 1/2"

Each 10+ 50+ $6.19 $5.49 $5.19 $6.89 $6.19 $5.79 $7.99 $7.09 $6.89 $7.99 $7.39 $7.09

821-890

3/8" x 3/4" x 5/8" 821-897 7/16" x 3/4" x 5/8"

$7.99 $7.29 $7.09 $7.99 $7.29 $6.99

821-904

1/2" x 3/4" x 5/8" $14.99 $13.59 $13.09 5mm x 3/8" x 1/2" 7mm x 1/2" x 1/2" 8mm x 1/2" x 1/2"

$6.99 $6.29 $5.99 $6.99 $6.29 $5.99 $9.99 $8.89 $8.49

821-925

9mm x 3/4" x 5/8"

$9.99 $8.89 $8.49 Edge-to-side doweling

MULTI-USE DOWELING JIG

Easy to assemble and use, the Multi-Use Doweling Jig Kit will help you accurately drill edge-to-edge and edge-to-side holes plus - best of all - miter joint dowel holes: Durable metal body and frame.Two each of 1/4", 3/8", 6mm, 8mm and 10mm hardened steel bushings.Removable center plate allows jig to be used as a vise.Comes with "E" clamp, assembly hardware and instructions.Approx.21/8"H x 5-3/8"W x 7"L (closed);weighs 2.7 lbs.Available 'B' block has a pair each of 5/16", 7/16", and 1/2" guide holes.Imported.

126-143 Multi-dowel jig

$64.19

DOWEL CENTERS

Functional dowel center are nickel plated steel with sharp points for precise dowel hole center marking in hard or soft wood: • Available as sets of 10 of each size or a combined set of 40.

Imported.

116-251 Ten 1/4" dowel centers 116-244 Ten 5/16" dowel centers 116-236 Ten 3/8" dowel centers 116-228 Ten 1/2" dowel centers 116-269 All 40 centers

$5.19 $6.19 $7.69 $8.29 $22.99

WOODTEK® DRILL BIT EXTENDER QUICKLY ADDS 3-3/4" TO YOUR 3/8" SHANK DRILL BIT

Your 3/8" dia.shank drill bit fastens into bit extender using four hex screws (included).Just tighten the bit extender shank into your 3/8" or larger drill chuck and begin drilling.All steel - 5" O.A.L.with 5/8" outside diameter.Imported.

DOWELING JIG FOR PERFECT EDGE-TO-EDGE JOINING

Features precision machined, die-cast aluminum construction (no plastic); black oxide steel shafts. Includes one each 1/4", 5/16", 3/8" and 1/2" hardened steel, self-locking drill guide bushings. Extra bushings available for purchase so you can work even faster. Instructions included.

100-131 Double edge to edge dowel jig

Pkg. of 3 Extra Bushings

100-099 1/4" bushings 100-107 5/16" bushings 100-123 1/2" bushings 100-115 3/8" bushings

$32.99 $7.29 $6.59 $6.59 $7.29

MILESCRAFT® CABINETMATE™ SHELF-PIN HOLE JIG

The CabinetMate™Shelf-Pin Hole Jig allows accurate drilling of eleven holes, evenly spaced at 32mm apart, in just one setting plus it can be used on cabinet sides before assembly, already assembled cabinets and face-frame or frameless cabinets. The two index pins allow you to step-down the jig so you can drill longer runs of shelf-pin holes. A stand-out feature of the CabinetMate™is that it also allows you to mark the locations for euro-style hinges. Includes a 1/4" self-centering, spring-loaded, HSS, bradpoint drill bit that enables the holes you drill to self-center with the main body cabinet holes. The bit is pre-set to bore a crisp hole with consistent depth for perfect fitting shelf pins. The CabinetMate™has a rigid main body and comes with a built in closed storage compartment for your bit and two indexing pins. If you are looking for a very affordable, high quality and extremely versatile cabinet jig, the MilesCraft® CabinetMate™is the only one you will need to look at. Can be used with optional 5mm Self Centering Shelf Pin Bit 168-656. Imported. 168-647 MilesCraft ™CabinetMate™1316 Shelf Pin Hole Jig, 1/4" $25.99

INEXPENSIVE, YET HIGHLY ACCURATE SHELF PIN DRILL JIG

Short of buying costly line boring equipment, our shelf pin drill jig is one of the easiest to use and most cost effective ways to bore shelf pin holes based on the European 32mm standard. Our jig allows for a 37mm or 64mm set back. Simply place the detachable aluminum stop on the desired side for frame or frameless applications. If a series of holes longer than the length of the template are to be drilled, insert a shelf pin through the indexing hole in the template and into one of the previously shelf pin holes to step-down the jig and maintain perfect hole spacing. Use our Snappy™5mm self-centering bit (part # 897-303) for 5mm holes or our Snappy™1/4" self-centering bit (part # 897-310) for 1/4" holes (self-centering bits not included with jig).

PRECISION JIG HELPS DRILL ACCURATE SHELF HOLES

This is a real value that does the job accurately and quickly. Simply draw lines across your board where you want the holes (I’d suggest an inch apart). Then clamp the jig onto your shelf with its built-in “quick clamp.” Set two bushing carriers over the lines at the proper inset from the edge, add your bushings and drill. Repeat for the remaining shelf lines. Your shelves will seat solidly and level every time. For shelves up to 25" wide. Chrome plated steel rod, aluminum rod with inch and metric scales, four steel bushing carriers with brass knurled lock-in knobs and 20 hardened steel drill bushings (4 each: 1/4", 5/16", 3/8", 7/16", 1/2"). 126-300 Shelf-drilling jig $85.59

QUICKLY AND ACCURATELY DRILL KNOB OR PULL HOLES USING THIS JIG AND YOUR HAND DRILL

Lightweight but durable, this Self Centering Drill Jig will allow you to consistently and accurately position holes for knobs or pulls in virtually all cabinet applications. Horizontal rail end stops allow use on doors, drawers or off-center installations - highly visible markings permit at-a-glance setting and eliminate measuring. A thumbwheel adjusts the center to center distance of two hardened drill bushings from 3", 3-1/2", 4", 4-1/2", 76mm, 89mm, 96mm or 112mm handles - a third bushing remains centered for drilling single knob holes. Bushings accept 3/16" dia. bits. Jig will self center on 3" x 7-1/4" up to 24-1/2" x 39-1/4" panels - vertical offset is adjustable from 1-1/2" to 12" from the edge. Ingenious rack and pinion system is set into the aluminum rails for smoother operation. Injection molded body is impervious to glue, water and most chemicals, CNC machined aluminum rails are strong and rigid and polymer flip stops are non-marring. Weighs 5 lbs. USA.

892-834 Drill jig

$199.99

PRECISE CABINET DOOR HANDLE ALIGNMENT AND INSTALLATION TIME AFTER TIME

ONE TIME SET-UP ALLOWS INSTALLATION IN MINUTES

For professional or home use, the EZ Jig EZ-1000 Cabinet Door Handle Locator & Drill Guide is a one person tool that doesn't require marking, squaring, aligning or checking. Adjusts horizontally as well as vertically. Reversible, so it can be used on left and right as well as upper and lower cabinet doors. Versatile enough to drill holes for 3", 3-1/2" or 4" c/c handles. Features steel drill guides and a high impact composite body. 10"H x 5"W x 2"D, 1-1/8 lbs. Complete instructions included. Optional Metric Insert is for 96mm and 128mm cabinet door and drawer handle installation. One year manufacturer's warranty. USA.

LESS VIBRATION, LOWER RUNNING NOISE AND FASTER CUTTING SPEED

The NEW FEIN Oscillating Multi-Tools feature the patented QuickIN, tool-free blade mechanism in conjunction with the Starlock blade mount allows for extremely quick blade change. The decoupling of the housing from motor reduces vibration-making operation smoother and more comfortable. The metal drive head provides high load capacity with maximum service life. All gearbox parts are metal. The Tacho Generator has high quality electronics for constant speed even under load and infinitely variable electronic speed control. Starlock (SL) mounts are backward compatible with FEIN, Bosch OIS oscillating tools and fit most other major brands. Starlock PLUS (SLP) mounts can only be used with FEIN-Plus or FEIN-Max tools. FEIN Starlock Max tools can only use Starlock Max accessories. Made in Germany.

171-722 72295362090 FMT250QSL Multitalent Start Q $153.99 171-725 72295264090 FMM350QSL Multimaster Start Q $199.99 171-728 72295267090 FMM350QSL Multimaster Q-Start $255.99 171-731 72295261090 FMM350QSL Multimaster Top $352.99

171-722 171-725

• 171-722 – MultiTalent Start Q: Includes Model FMT250QSL MultiTool, Nylon storage bag, #129 abrasive backing pad, #152 E-Cut SLP 1-3/4" Universal

Bimetal blade, 3 each 80#, 120#, 180# abrasives. Germany. • 171-725 – MultiMaster Start Q: Includes Model FMM350QSL MultiTool, Nylon storage bag, #129 abrasive backing pad, #152 E-Cut SLP 1-3/4" Universal

Bimetal blade, 3 each 80#, 120#, 180# abrasives. Germany. • 171-728 – MultiMaster Q-Start: Includes Model FMM350QSL MultiTool, Plastic storage case, #129 abrasive backing pad, 3 each 60#, 80#, 120#, 180# abrasives, #152 E-Cut SLP 1-3/4" Universal Bimetal blade, #234 Long Rigid Scraper SLP, #161 2-9/16" E-Cut Bimetal Blade SLP, #106 3-3/8" Segmented HSS Saw Blade

SL. Germany. • 171-731 – MultiMaster Top: Includes Model FMM350QSL MultiTool, Plastic storage case, #129 abrasive traingle backing pad, #195 4-1/2" round abrasive backing pad, #137 abrasive triangle perforated backing pad, 2 pack each K60,

K80, K120 abrasives, 3 pack each standard triangle H&L abrasives 60#, 80#, 120#, 180#, 3 pack pack each perforated H&L abrasives 60#, 80#, 120#, 180#, #234 Long Rigid Scraper SLP, $160 E-cut blade SL, #169 TC Saw Blade SLP, #062 Segmented HSS Saw Blade, #161 E-Cut Bimetal blade SLP, #152 E-Cut

Bimetal blade, #012 Triangle Carbide Rasp, #137 Dust extraction pipe, #136 Dust

Extraction hood, #106 Felt Ring. Germany.

171-728 171-731

FEIN OSCILLATING MUTLITOOL BLADES - FITS FEIN, BOSCH AND MOST OTHER MAJOR BRANDS OF MULTI-TOOLS

Starlock (SL) mounts are backward compatible with FEIN, Bosch OIS oscillating tools and fit most other major brands including AEG, Bosch, Craftsman, Einhell, Hitachi, Makita, Metabo, Milwaukee, Porter-Cable, Rigid, Rockwell, Ryobi, Skil, Worx. List is not comprehensive and mounts may vary within a brand. Please check your owner's manual for compatibility. Starlock PLUS (SLP) mounts can only be used with FEIN-Plus or FEIN-Max tools. FEIN Starlock Max tools can only use Starlock Max accessories.

001

175 002

176 165

196 226

129 234

136 097

159 174 106

195 160

161 205 208 152 157 187 191 188 193

Qty.

171-590 #001 Carbide Rasp Triangular Shape Oscillating Blade SL Mount 1 $22.99 171-593 #002 Carbide Rasp Finger Shape Oscillating Blade SLP Mount 1 $24.79 171-596 #165 Flexible Scaper Blade SL Mount 1 $26.79 171-599 #226 Short Rigid Scaper Blade SL Mount 1 $16.49 171-602 #234 Long Rigid Scaper Blade SLP Mount 1 $19.79 171-605 #097 3-3/8" Solid Round Hss Saw Blade SL Mount 1 $28.89 171-608 #097 3-3/8" Solid Round Hss Saw Blade SL Mount 2 Pck 2 $52.59 171-611 #097 3-3/8" Solid Round Hss Saw Blade SL Mount 5 Pck 5 $118.59 171-614 #174 3-3/8" Solid Round Bimetal Hss Saw Blade SL Mnt 1 $40.19 171-617 #174 3-3/8" Solid Round Bimetal Hss Saw Blade SL 5 Pck 5 $185.59 171-620 #106 3-3/8" Segmented Hss Saw Blade SL Mount 1 $18.79 171-623 #106 3-3/8" Segmented Hss Saw Blade SL Mount 2 Pck 2 $35.49 171-626 #106 3-3/8" Segmented Hss Saw Blade SL Mount 5 Pck 5 $83.49 171-629 #175 4" Hss Bimetal Round Saw Blade SLP Mount 1 $70.19 171-632 #175 4" Hss Bimetal Round Saw Blade SLP Mount 5 Pck 5 $315.49 171-635 #176 4" Hss Bimetal Round Saw Blade W/Guard SLP Mount 1 $75.29 171-638 #196 4" Hss Bimetal Segmented Saw Blade SLP Mount 1 $70.19 171-641 #196 4" Hss Bimetal Segmented Saw Blade SLP Mount 5 Pck 5 $315.49 171-644 #129 Standard Triangular H&L Backing Pad SL Mount 2 $16.49 171-647 #136 Standard Triangular H&L Backing Pad W/Holes SL Mount 2 $24.79 171-650 #159 Finger Shaped H&L Backing Pad SL Mount 2 $25.29 171-653 #195 4-1/2" Round H&L Backing Pad SLP Mount W/6 Discs 1 $13.39

Qty.

171-656 #160 1-3/8" E-Cut Bimetal Long-Life Saw Blade SL Mount 1 $21.69 171-659 #160 1-3/8" E-Cut Bimetal Long-Life Saw Blade SL Mount 3 $51.59 171-662 #160 1-3/8" E-Cut Bimetal Long-Life Saw Blade SL Mount 10 $154.89 171-665 #161 2-9/16" E-Cut Bimetal Long-Life Saw Blade SLP Mount 1 $24.99 171-668 #161 2-9/16" E-Cut Bimetal Long-Life Saw Blade SLP Mount 3 $61.29 171-671 #161 2-9/16" E-Cut Bimetal Long-Life Saw Blade SLP Mount 10 $157.79 171-674 #205 1-3/8" E-Cut Japanese Bimetal Saw Blade SL Mount 1 $14.49 171-677 #205 1-3/8" E-Cut Japanese Bimetal Saw Blade SL Mount 3 $39.19 171-680 #205 1-3/8" E-Cut Japanese Bimetal Saw Blade SL Mount 10 $116.49 171-683 #208 2-9/16" E-Cut Japanese Bimetal Saw Blade SLP Mount 1 $15.69 171-686 #208 2-9/16" E-Cut Japanese Bimetal Saw Blade SLP Mount 3 $42.29 171-689 #208 2-9/16" E-Cut Japanese Bimetal Saw Blade SLP Mount 10 $129.39 171-692 #152 1-3/4" E-Cut Universal Bimetal Straight Blade SL Mount 1 $16.49 171-695 #152 1-3/4" E-Cut Universal Bimetal Straight Blade SLP Mount 3 $37.59 171-698 #152 1-3/4" E-Cut Universal Bimetal Straight Blade SLP Mount 10 $96.89 171-701 #157 1-3/16" E-Cut Universal Bimetal Straight Blade SL Mount 1 $9.39 171-704 #157 1-3/16" E-Cut Universal Bimetal Straight Blade SL Mount 3 $27.19 171-707 #157 1-3/16" E-Cut Universal Bimetal Straight Blade SL Mount 10 $77.39 171-710 #187 3-9/16" Carbide Segmented Saw Blade SLP Mount 1 $58.79 171-713 #191 1-3/8" Carbide E-Cut Straight Saw Blade SLP Mount 1 $41.29 171-716 #188 3-9/16" Diamond Segemented Saw Blade SLP Mount 1 $117.59 171-719 #193 1-3/8" Diamond E-Cut Straight Saw Blade SLP Mount 1 $108.29
