Selected Works of Qiuying Lu

QIU

YING LU PO RTFOLIO SELECT ED WORKS 2018-2022

01 02

PRODUCTION& LIVING INTO THE FLOW

03 04 05 FLOW

PARALLEL CONNECTION PROFESSIONAL WORK OTHER WORK

PRODUCTION & LIVING

Academic Project, Individual Work Apartment Design

Instructor: Zhiqiang Xu

Location: Guangzhou, China Spring 2018

In China, the contradiction between village and city is becoming more and more acute in the rapid urbanization.In Chisha Village of guangzhou, due to its proximity to the garment market, a large number of clothing workshops have appeared, and the production activities and daily living are completed in the same space, leaving them no room for entertainment. At the same time, the cheap rent makes it impossible for them to rent a better apartment.

2004 2022

The self-built Apartments in Chisha had become packed since the continuous increasing of housing demand from workers.

SITE

01

FAMILY WORKSHOP

THE CONTRADICTION BETWEEN PRODUCTION AND LIVING

The common plan of self-built houses is sitting room +1~2 rooms + kitchen and toilet, which dfoes not leave a space for production activity. If the residential unit is used as a production workshopvv, then the production of furniture will occupy most of the space, and there will be no space to put living objects (sofa, TV, etc.) and no entertainment activities.

STRATEGY

08:00 07:00 12:00 14:00 16:00 18:00 20:00 22:00 00:00 02:00 04:00 06:00 Living Room Bedroom Sleep Work Work Work Work Sleep Sleep Nap Lunch Dinner Kitchen Bathroom

STRUCTURE SYSTEM

Concrete and wood are respectively used to form Spaces for production and living.

2. Production Space 3. Living Space ( Wood Structure) 1. Concrete Shear Wall

N 0 5 10

1. Working Area 2. Living Room 3. Kitchen 4. Toilet 5. Bedroom 6. Balcony

Stair Transport Well Working Area Living Area 1 2 2 4 4 2 2 1 1 1 5 5 7 6 6 6 6

7. Transport Well

TRANSPORTATION SYSTEM

Through the small hoist and stairwell, workers can easily lift the goods downstairs.

Carrige

The ground floor provides public space for the villagers to stop and talk. Large pieces of glass and height allow maximum daylight to be obtained so that limited distance between buildings wouldn't make the interior dark.

INTO THE FLOW

UCLA Student Center

Advanced Topic Studio, Fall 2021

Acedemic project, Individual Work

Instructor: Neil Daneri

In this project, I aim to improve the flow and continuity of the space and create a stronger connection with the surrounding site. While people on the street and in the landscape tend to be in constant motion, those in the building generally maintain a relatively stable condition. To enhance the fluidity of the space, I will explore design solutions that facilitate movement and provide seamless transitions between different areas. By establishing a stronger connection with the site, the building will feel more integrated into its surroundings and offer a more cohesive experience for its occupants.

Stable Clear

Function Function

Fluid Ambiguous

Circulation Circulation

02

The ramp and roof system create a complex visual connection and wander exerience because of the stack of the volumes. People can not only walk on the ground but also go across the roof and enjoy a higher view of the school.

The interior space aims to create a soft and ambiguous atmosphere. The streamline stairs and walls blur the edge of the space, drive people come in and explore the building smoothly.

1. Lobby 2. Multi-purpose Hall 3. Program offices 4. Director’s Office 5. Efficiency Kitchen 6. Mechanical 7. Chair Storage 8. Equipment Storage 9. Public toilets 10. Library 11. Accessible Roof

MULTI-PURPOSE HALL

The white color and soft lightning blur the edge of the space, indicate a flowing wandering experience.

PARALLEL HOUSING

Housing Design

Advanced Topic Studio, Fall 2020

Individual Project

Instructor: Garrett Ricciardi

Housing in Los Angeles is very atomic. The sharp boundaries between private properties and the public make the street have no where to stop, creating a fragmented, discontinuous walking experience. To make a better community, parrellel walls were adopted to create a continuous and walkable apartment visually and physically. The shear walls were aligned in 45 degrees so that more corners beside roads could appear for people to stop and talk.

03

FORM RESEARCH

25’ 25’ 25’ 25’ 20’ 20’ 20’ 20’

Normal housing: enter the unit directly from the corridor 1.Split 2.Dislocation 3. 45° triangular lightwell

1. Walkway 2. Bridge on the wall 3. Public plaza 4. Entrance

PROFESSIONAL WORK

Besides the academic projects, I also got full exercise in my previous work and internship. With various projects in different scale, functions and clients, I have better knowledge of architectural design and construction.

04

Shenzhen Qianhai

05 06 07

Commercial Complex INTO THE FLOW PARALLEL CONNECTION PROFESSIONAL WORK

1. 概念设计方案

SHENZHEN QIANHAI COMMERCIAL COMPLEX

Professional Work Location：Shenzhen Qianhai

Role: Concept design, Facade Design, 3D Modeling, Line Drawing

This is a competition project for a mixed-use development that aims to connect a plot of land that is divided by a highway, and create a sustainable public space for a crowded urban area with a lack of public spaces. To achieve this, the project features a three-dimensional corridor that extends through the development, integrating the architecture with the surrounding urban context. The corridor serves as a continuous public space, connecting different parts of the development and offering a dynamic and engaging environment for both commercial and residential uses.

概念设计方案

概念方案生成与分析

本设计建筑形体推导严格遵循建筑空间及功能组织逻辑，充分挖掘建筑形体对于场地环境、公共空间营造的回应，避免刻意夸大自身奇异表情。

一、基本体量测算依据设计招标任务书及《关于完善人才住房制度的若干措施》深发2016【13】号文中对于人才公寓建设的相关规定，对于建筑的基本体量测算显示，两栋1200㎡的150m超高层塔楼可满足人才住房供应量的需求。

二、板塔结合的高区布局为了充分利用场地周边丰富的景观资源以及居住塔楼各个方向的可视界面，避免楼间对视，本设计将西侧方塔置于场地南端，西侧塔楼以板楼形式退至北端，使主塔楼层实现完美避让。同时，板点结合的规划组合，也对场地东南向公共景观带形成环抱式半围了公共绿轴在场地内的空间延展性。

三、多孔性的低区围合在板点结合的高区规划组合下，本设计在场地的东南侧增设了一组具有多孔渗透性的低区围合。这一低区建筑体量的设计，不仅体现了对于城市公共空间方向上，近人步行尺度的空间感受的高度关注，也为城市公共空间向场地内部的渗透增添了不同氛围的差异化层次，使得居住内庭既对城市开放，又独具有别于公共绿地开阔感的静谧。

四、户型差异、形体穿插和空中花园结合居住产品不同面积段所产生的不同进深需求，以及不同户型的面宽差异在立面表情上所具有的的不同特色，本设计对两栋超高层塔楼的形体进行了对应性的组织，形成不同肌理的体量在三维空间上的穿插和咬合。而形体错位所带来的的空中露台，进一步强调了公共空间在垂直方向的延伸，形成不同高度上的交流和对话。

五、连续的立体公共环廊基于体块穿插所形成的的空中公共平台，本设计结合社区商业和服务功能、在居住体量内部嵌入一条立体的空中环路，使公共交流的发生得以连续。环路内的架空庭院，同时反哺于区域微气候，并提升居住单元的舒适

1. 概念设计方案

1.3. 概念方案生成与分析

标准化居住产品设计特色分析

设计目标：

吸引具有境外文化背景的中高端人才，在全租赁性质的政策性住房中，满足更丰富的人

性化需求

设计策略：

该项目建筑六种户型，结合高度模数化与预制化理念，以服务带-生活带景观带的布局呈现，打造既国际化，又不失地域居住舒适性的特色产品。

1、除35㎡studio户型外，全系列产品考虑儿童房乃至双子女家庭的配置需求，为中长期周转人才提供成家立业的空间基础。

2、最大化利用场地周边景观资源，以连续广阔的超长景观阳台，打造绿色自然的多样生活场景。

3、全系列均配备连续、可供灵活拓展的主厅空间。为私人聚会，居家办公、乃至亲密会客提供无限的可能性。

65㎡标准

实际数量3675452283624121212 要求占比≥30%≤45%≤19≤3%≤2%≤1%100% 实际占比30%45%19%3%2%1%100%

项目概况

项目名称：前海乐居桂湾人才住房项目用地单位：深圳市前海人才乐居有限公司

主要技术经济指标

建设用地面积（㎡） 8306.04总建筑面积（㎡）计容积率建筑面积（㎡）100707容积率/规定容积率地上规定建筑面积（㎡）95907不计容积率建筑面积（㎡）36126 地上核减建筑面积（㎡）0

地下规定建筑面积（㎡）33636 地上核增建筑面积（㎡）4800地下核增建筑面积（㎡）2490

建筑基底面积（㎡） 3521建筑覆盖率绿地面积/折算绿地面积（㎡）5040/548绿化覆盖率最高高度（m） 148.5最大层数（地上/地下）44/3 停车位（地上/地下） 0/558自行车停车位数（地上/地下）22/500

1.4. 概念方案技术图纸与说明

宗地号：T201-0109 用地位置：前海合作区四开发单元05街坊01 、02地块户型种类

F户型

要求数量≥360≤540≤228≤36≤24≤12≥1200

04

35㎡标准 A户型

B户型 80㎡标准 C户型 100㎡标准 D户型 120㎡标准 E户型 150㎡标准

总量

项目名称：前海乐居桂湾人才住房项目用地单位：深圳市前海人才乐居有限公司用地位置：前海合作区四开发单元05街坊01

总建筑面积（㎡）计容积率建筑面积（㎡）计规定容积率建筑面积（㎡）公寓面积（㎡）89922089922 95907商业面积（㎡）598505985 地上核增建筑面积（㎡）消防避难空间（㎡） 4800架空绿化休闲（㎡）不计容积率建筑面积（㎡）地下规定建筑面积（㎡）地下商业（㎡）

地上核增建筑面积（㎡）4800地下核增建筑面积（㎡）2490 42% 67% 148.5最大层数（地上/地下）44/3 0/558自行车停车位数（地上/地下）22/500

地下车库（㎡）设备用房（㎡）地下核增建筑面积（㎡） 2490 136833 3967 建筑面积（㎡） 23709 城市公共通道（㎡）2490 890 建筑面积分配建筑功能 3910 5960 100707 36126 33636 8306.04总建筑面积（㎡） 136833 计容积率建筑面积（㎡）100707容积率/规定容积率 12.12/11.56 地上规定建筑面积（㎡）95907不计容积率建筑面积（㎡）36126 地下规定建筑面积（㎡）33636

规定核减合计

NANJING AGING COMMUNITY

Professional Work Location：Nanjing, China

Role: Residential Design, Facade Design, 3D Modeling, Line Drawing

This is a renovation project for Shenzhen Airport and its surrounding buildings. My involvement in the project includes the facade renovation of the airport cargo building and the conceptual and structural design of three pedestrian bridges.

铝合金渐变百叶 Aluminium alloy shutter 50mm铝方通 Aluminum Tube 钢龙骨 Steel keel 货站大楼立面改造 RENOVATION OF AIRPORT CARGO ELEVATION STEP1：结构模型示意 STEP2：结构设计荷载恒载（自重+0.2KN/m2建筑面板）屋顶活荷载0.5KN/m2 风荷载（风压0.75,B类风敏感1.1倍） STEP3：应力比校核主桥整体构件应力比最大0.68<1 满足设计需要恒载（KN/m）活载(KN/m）左风(KN/m） STEP4：位移校核竖向1.0D+1.0RL：10mm/1700mm=1/170<1/125，满足恒加活(mm)

05

BEIJING AGING COMMUNITY

Professional Work Location：Nanjing, China

Role: Residential Design, Facade Design, 3D Modeling, Line Drawing

Located in Beijing's residential area, this senior living project is designed to provide comprehensive care and support for elderly residents. The project includes a variety of elderlyfriendly housing options, such as accessible apartments and assisted living facilities. Additionally, there are medical facilities on-site to provide convenient healthcare services for residents. The project also features various public amenities, including community lounges, gardens, and walkways, that are designed to foster social interaction and promote wellbeing.

06

NANJING AGING COMMUNITY

Professional Work Location：Nanjing, China

Role: Residential Design, Facade Design, 3D Modeling, Line Drawing

In this project, I aim to improve the flow and continuity of the space and create a stronger connection with the surrounding site. While people on the street and in the landscape tend to be in constant motion, those in the building generally maintain a relatively stable condition. To enhance the fluidity of the space, I will explore design solutions that facilitate movement and provide seamless transitions between different areas. By establishing a stronger connection with the site, the building will feel more integrated into its surroundings and offer a more cohesive experience for its occupants.
